Data Warehousing

1
Data Warehousing

• and
• OLAP

2
Motivation

• Aims of information technology
• To help workers in their everyday business
  activity and improve their productivity
  clerical data processing tasks
• To help knowledge workers (executives, managers,
  analysts) make faster and better decisions
  decision support systems
• Two types of applications
• Operational applications
• Analytical applications

3
Motivation

• On the other hand
• In most organizations, data about specific parts
  of business is there - lots and lots of data,
  somewhere, in some form.
• Data is available but not information -- and not
  the right information at the right time.
• Data warehouse is to
• bring together information from multiple sources
  as to provide a consistent database source for
  decision support queries.
• off-load decision support applications from the
  on-line transaction system.

4
Warehousing

• Growing industry 8 billion in 1998
• Range from desktop to huge warehouses
• Walmart 900-CPU, 2,700 disks, 23TB
• Teradata system
• Lots of new terms
• ROLAP, MOLAP, HOLAP
• rollup. drill-down, slice dice

5
The Architecture of Data
Whats has been learned from data
Logical model
summaries by who, what, when, where,...
physical layout of data
who, what, when, where,
6
Decision Support and OLAP

• DSS Information technology to help knowledge
  workers (executives, managers, analysts) make
  faster and better decisions
• what were the sales volumes by region and by
  product category in the last year?
• how did the share price of computer manufacturers
  correlate with quarterly profits over the past 10
  years?
• will a 10 discount increase sales volume
  sufficiently?
• OLAP is an element of decision support system
• Data mining is a powerful, high-performance data
  analysis tool for decision support.

7
Data Processing Models

• There are two basic data processing models
• OLTP the main aim of OLTP is reliable and
  efficient processing of a large number of
  transactions and ensuring data consistency.
• OLAP the main aim of OLAP is efficient
  multidimensional processing of large data
  volumes.

8
Traditional OLTP

• Traditionally, DBMS have been used for on-line
  transaction processing (OLTP)
• order entry pull up order xx-yy-zz and update
  status field
• banking transfer 100 from account X to account
  Y
• clerical data processing tasks
• detailed up-to-date data
• structured, repetitive tasks
• short transactions are the unit of work
• read and/or update a few records
• isolation, recovery, and integrity are critical

9
OLTP vs. OLAP

• OLTP On Line Transaction Processing
• Describes processing at operational sites
• OLAP On Line Analytical Processing
• Describes processing at warehouse

10
OLTP vs. OLAP

• OLTP OLAP
• users Clerk, IT professional Knowledge
  worker
• function day to day operations decision
  support
• DB design application-oriented subject-oriented

• data current, up-to-date historical,
  summarized
• detailed, flat relational
  multidimensional
• isolated integrated, consolidated
• usage repetitive ad-hoc
• access read/write, lots of scans
• index/hash on prim. key
• unit of work short, simple transaction complex
  query
• records accessed tens millions
• users thousands hundreds
• DB size 100MB-GB 100GB-TB
• metric transaction throughput query throughput,
  response

11
What is a Data Warehouse

• A data warehouse is a subject-oriented,
  integrated, time-variant, and nonvolatile
  collection of data in support of managements
  decision-making process. --- W. H. Inmon
• Collection of data that is used primarily in
  organizational decision making
• A decision support database that is maintained
  separately from the organizations operational
  database

12
Data Warehouse - Subject Oriented

• Subject oriented oriented to the major subject
  areas of the corporation that have been defined
  in the data model.
• E.g. for an insurance company customer, product,
  transaction or activity, policy, claim, account,
  and etc.
• Operational DB and applications may be organized
  differently
• E.g. based on type of insurance's auto, life,
  medical, fire, ...

13
Data Warehouse Integrated

• There is no consistency in encoding, naming
  conventions, , among different data sources
• Heterogeneous data sources
• When data is moved to the warehouse, it is
  converted.

14
Data Warehouse - Non-Volatile

• Operational data is regularly accessed and
  manipulated a record at a time, and update is
  done to data in the operational environment.
• Warehouse Data is loaded and accessed. Update of
  data does not occur in the data warehouse
  environment.

15
Data Warehouse - Time Variance

• The time horizon for the data warehouse is
  significantly longer than that of operational
  systems.
• Operational database current value data.
• Data warehouse data nothing more than a
  sophisticated series of snapshots, taken of at
  some moment in time.
• The key structure of operational data may or may
  not contain some element of time. The key
  structure of the data warehouse always contains
  some element of time.

16
Why Separate Data Warehouse?

• Performance
• special data organization, access methods, and
  implementation methods are needed to support
  multidimensional views and operations typical of
  OLAP
• Complex OLAP queries would degrade performance
  for operational transactions
• Concurrency control and recovery modes of OLTP
  are not compatible with OLAP analysis

17
Why Separate Data Warehouse?

• Function
• missing data Decision support requires
  historical data which operational DBs do not
  typically maintain
• data consolidation DS requires consolidation
  (aggregation, summarization) of data from
  heterogeneous sources operational DBs, external
  sources
• data quality different sources typically use
  inconsistent data representations, codes and
  formats which have to be reconciled.

18
Advantages of Warehousing

• High query performance
• Queries not visible outside warehouse
• Local processing at sources unaffected
• Can operate when sources unavailable
• Can query data not stored in a DBMS
• Extra information at warehouse
• Modify, summarize (store aggregates)
• Add historical information

19
Advantages of Mediator Systems

• No need to copy data
• less storage
• no need to purchase data
• More up-to-date data
• Query needs can be unknown
• Only query interface needed at sources
• May be less draining on sources

20
Operational databases
The Architecture of Data Warehousing
External data sources
Extract Transform Load Refresh
Metadata repository
Data Warehouse
Data marts
Serves
OLAP server
Data mining
Reports
OLAP
21
Data Sources

• Data sources are often the operational systems,
  providing the lowest level of data.
• Data sources are designed for operational use,
  not for decision support, and the data reflect
  this fact.
• Multiple data sources are often from different
  systems, run on a wide range of hardware and much
  of the software is built in-house or highly
  customized.
• Multiple data sources introduce a large number of
  issues -- semantic conflicts.

22
Creating and Maintaining a Warehouse

• Data warehouse needs several tools that automate
  or support tasks such as
• Data extraction from different external data
  sources, operational databases, files of standard
  applications (e.g. Excel, COBOL applications),
  and other documents (Word, WWW).
• Data cleaning (finding and resolving
  inconsistency in the source data)
• Integration and transformation of data (between
  different data formats, languages, etc.)

23
Creating and Maintaining a Warehouse

• Data loading (loading the data into the data
  warehouse)
• Data replication (replicating source database
  into the data warehouse)
• Data refreshment
• Data archiving
• Checking for data quality
• Analyzing metadata

24
Physical Structure of Data Warehouse

• There are three basic architectures for
  constructing a data warehouse
• Centralized
• Distributed
• Federated
• Tiered
• The data warehouse is distributed for load
  balancing, scalability and higher availability

25
Physical Structure of Data Warehouse
Client
Client
Client
Central Data Warehouse
Source
Source
Centralized architecture
26
Physical Structure of Data Warehouse
End Users
Marketing Financial Distribution
Local Data Marts
Logical Data Warehouse
Source
Source
Federated architecture
27
Physical Structure of Data Warehouse
Workstations (higly summarized data)
Local Data Marts
Physical Data Warehouse
Tiered architecture
Source
Source
28
Physical Structure of Data Warehouse

• Federated architecture
• The logical data warehouse is only virtual
• Tiered architecture
• The central data warehouse is physical
• There exist local data marts on different triers
  which store copies or summarization of the
  previous trier.

29
Conceptual Modeling ofData Warehouses

• Three basic conceptual schemas
• Star schema
• Snowflake schema
• Fact constellations

30
Star schema

• Star schema A single object (fact table) in the
  middle connected to a number of dimension tables

31
Star schema
32
Star schema
33
Terms

• Basic notion a measure (e.g. sales, qty, etc)
• Given a collection of numeric measures
• Each measure depends on a set of dimensions (e.g.
  sales volume as a function of product, time, and
  location)

34
Terms

• Relation, which relates the dimensions to the
  measure of interest, is called the fact table
  (e.g. sale)
• Information about dimensions can be represented
  as a collection of relations called the
  dimension tables (product, customer, store)
• Each dimension can have a set of associated
  attributes

35
Example of Star Schema
36
Dimension Hierarchies

• For each dimension, the set of associated
  attributes can be structured as a hierarchy

sType
store
city
region
customer
city
state
country
37
Dimension Hierarchies
38
Snowflake Schema

• Snowflake schema A refinement of star schema
  where the dimensional hierarchy is represented
  explicitly by normalizing the dimension tables

39
Example of Snowflake Schema
Month
Year
Month Year
Date
Year
Date Month
Measurements
40
Fact constellations

• Fact constellations Multiple fact tables share
  dimension tables

41
Database design methodology for data warehouses
(1)

• Nine-step methodology proposed by Kimball

42
Database design methodology for data warehouses
(2)

• There are manny approaches that offer alternative
  routes to the creation of a data warehouse
• Typical approach decompose the design of the
  data warehouse into manageable parts data
  marts, At a later stage, the integration of the
  smaller data marts leads to the creation of the
  enterprise-wide data warehouse.
• The methodology specifies the steps required for
  the design of a data mart, however, the
  methodology also ties together separate data
  marts so that over time they merge together into
  a coherent overall data warehouse.

43
Step 1 Choosing the process

• The process (function) refers to the subject
  matter of a particular data marts. The first data
  mart to be built should be the one that is most
  likely to be delivered on time, within budget,
  and to answer the most commercially important
  business questions.
• The best choice for the first data mart tends to
  be the one that is related to sales

44
Step 2 Choosing the grain

• Choosing the grain means deciding exactly what a
  fact table record represents. For example, the
  entity Sales may represent the facts about each
  property sale. Therefore, the grain of the
  Property_Sales fact table is individual
  property sale.
• Only when the grain for the fact table is chosen
  we can identify the dimensions of the fact table.
• The grain decision for the fact table also
  determines the grain of each of the dimension
  tables. For example, if the grain for the
  Property_Sales is an individual property sale,
  then the grain of the Client dimension is the
  detail of the client who bought a particular
  property.

45
Step 3 Identifying and conforming the dimensions

• Dimensions set the context for formulating
  queries about the facts in the fact table.
• We identify dimensions in sufficient detail to
  describee things such as clients and properties
  at the correct grain.
• If any dimension occurs in two data marts, they
  must be exactly the same dimension, or or one
  must be a subset of the other (this is the only
  way that two DM share one or more dimensions in
  teh same application).
• When a dimension is used in more than one DM, the
  dimension is referred to as being conformed.

46
Step 4 Choosing the facts

• The grain of the fact table determines which
  facts can be used in the data mart all facts
  must be expressed at the level implied by the
  grain.
• In other words, if the grain of the fact table is
  an individual property sale, then all the
  numerical facts must refer to this particular
  sale (the facts should be numeric and additive).

47
Step 5 Storing pre-calculations in the fact table

• Once the facts have been selected each should be
  re-examined to determine whether there are
  opportunities to use pre-calculations.
• Common example a profit or loss statement
• These types of facts are useful since they are
  additive quantities, from which we can derive
  valuable information.
• This is particularly true for a value that is
  fundamental to an enterprise, or if there is any
  chance of a user calculating the value
  incorrectly.

48
Step 6 Rounding out the dimension tables

• In this step we return to the dimension tables
  and add as many text descriptions to the
  dimensions as possible.
• The text descriptions should be as intuitive and
  understandable to the users as possible

49
Step 7 Choosing the duration of the data
warehouse

• The duration measures how far back in time the
  fact table goes.
• For some companies (e.g. insurance companies)
  there may be a legal requirement to retain data
  extending back five or more years.
• Very large fact tables raise at least two very
  significant data warehouse design issues
• The older data, the more likely there will be
  problems in reading and interpreting the old
  files
• It is mandatory that the old versions of the
  important dimensions be used, not the most
  current versions (we will discuss this issue
  later on)

50
Step 8 Tracking slowly changing dimensions

• The changing dimension problem means that the
  proper description of the old client and the old
  branch must be used with the old data warehouse
  schema
• Usually, the data warehouse must assign a
  generalized key to these important dimensions in
  order to distinguish multiple snapshots of
  clients and branches over a period of time
• There are different types of changes in
  dimensions
• A dimension attribute is overwritten
• A dimension attribute caauses a new dimension
  record to be created
• etc.

51
Step 9 Deciding the query priorities and the
query modes

• In this step we consider physical design issues.
• The presence of pre-stored summaries and
  aggregates
• Indices
• Materialized views
• Security issue
• Backup issue
• Archive issue

52
Database design methodology for data warehouses -
summary

• At the end of this methodology, we have a design
  for a data mart that supports the requirements of
  a particular bussiness process and allows the
  easy integration with other related data martsto
  ultimately form the enterprise-wide data
  warehouse.
• A dimensional model, which contains more than one
  fact table sharing one or more conformed
  dimension tables, is referred to as a fact
  constellation.

53
Multidimensional Data Model

• Sales of products may be represented in one
  dimension (as a fact relation) or
• in two dimensions, e.g. clients and products
• Multidimensional Data Model

54
Multidimensional Data Model
Two-dimensional cube
Fact relation
55
Multidimensional Data Model
Fact relation
3-dimensional cube
56
Multidimensional Data Model and Aggregates

• Add up amounts for day 1
• In SQL SELECT sum(Amt) FROM SALE WHERE
  Date 1

result
81
57
Multidimensional Data Model and Aggregates

• Add up amounts by day
• In SQL SELECT Date, sum(Amt)
• FROM SALE GROUP BY Date

result
58
Multidimensional Data Model and Aggregates

• Add up amounts by client, product
• In SQL SELECT client, product, sum(amt)
  FROM SALE
• GROUP BY client, product

59
Multidimensional Data Model and Aggregates
60
Multidimensional Data Model and Aggregates

• In multidimensional data model together with
  measure values usually we store summarizing
  information (aggregates)

61
Aggregates

• Operators sum, count, max, min, median,
  ave
• Having clause
• Using dimension hierarchy
• average by region (within store)
• maximum by month (within date)

62
Cube Aggregation
Example computing sums
day 2
. . .
day 1
129
63
Cube Operators
day 2
. . .
sale(c1,,)
day 1
129
sale(c2,p2,)
sale(,,)
64
Cube

day 2
sale(,p2,)
day 1
65
Aggregation Using Hierarchies
customer
region
country
(customer c1 in Region A customers c2, c3 in
Region B)
66
Aggregation Using Hierarchies
client
city
10
3
21
c1
New Orleans
12
9
c2
5
region
11
7
7
c3
Date of sale
12
11
15
Poznan
c4
CD
video
Camera
aggregation with respect to city
67
A Sample Data Cube
Date
1Q
2Q
3Q
4Q
camera
C o u n t r y
Product
video
USA
CD
Canada
Mexico
68
Exercise (1)

• Suppose the AAA Automobile Co. builds a data
  warehouse to analyze sales of its cars.
• The measure - price of a car
• We would like to answer the following typical
  queries
• find total sales by day, week, month and year
• find total sales by week, month, ... for each
  dealer
• find total sales by week, month, ... for each car
  model
• find total sales by month for all dealers in a
  given city, region and state.

69
Exercise (2)

• Dimensions
• time (day, week, month, quarter, year)
• dealer (name, city, state, region, phone)
• cars (serialno, model, color, category , )
• Design the conceptual data warehouse schema

70
OLAP Servers

• Relational OLAP (ROLAP)
• Extended relational DBMS that maps operations on
  multidimensional data to standard relations
  operations
• Store all information, including fact tables, as
  relations
• Multidimensional OLAP (MOLAP)
• Special purpose server that directly implements
  multidimensional data and operations
• store multidimensional datasets as arrays

71
OLAP Servers

• Hybrid OLAP (HOLAP)
• Give users/system administrators freedom to
  select different partitions.

72
OLAP Queries

• Roll up summarize data along a dimension
  hierarchy
• if we are given total sales volume per city we
  can aggregate on the Location to obtain sales per
  states

73
OLAP Queries
client
city
10
3
21
c1
New Orleans
12
9
c2
5
region
11
7
7
c3
Date of sale
12
11
15
Poznan
c4
CD
video
Camera
roll up
74
OLAP Queries

• Roll down, drill down go from higher level
  summary to lower level summary or detailed data
• For a particular product category, find the
  detailed sales data for each salesperson by date
• Given total sales by state, we can ask for sales
  per city, or just sales by city for a selected
  state

75
OLAP Queries
day 2
day 1
129
76
OLAP Queries

• Slice and dice select and project
• Sales of video in USA over the last 6 months
• Slicing and dicing reduce the number of
  dimensions
• Pivot reorient cube
• The result of pivoting is called a
  cross-tabulation
• If we pivot the Sales cube on the Client and
  Product dimensions, we obtain a table for each
  client for each product value

77
OLAP Queries

• Pivoting can be combined with aggregation

78
OLAP Queries

• Ranking selection of first n elements (e.g.
  select 5 best purchased products in July)
• Others stored procedures, selection, etc.
• Time functions
• e.g., time average

79
Implementing a Warehouse
80
Implementing a Warehouse

• Designing and rolling out a data warehouse is a
  complex process, consisting of the following
  activities
• Define the architecture, do capacity palnning,
  and select the storage servers, database and OLAP
  servers (ROLAP vs MOLAP), and tools,
• Integrate the servers, storage, and client tools,
• Design the warehouse schema and views,

81
Implementing a Warehouse

• Define the physical warehouse organization, data
  placement, partitioning, and access method,
• Connect the sources using gateways, ODBC drivers,
  or other wrappers,
• Design and implement scripts for data extraction,
  cleaning, transformation, load, and refresh,

82
Implementing a Warehouse

• Populate the repository with the schema and view
  definitions, scripts, and other metadata,
• Design and implement end-user applications,
• Roll out the warehouse and applications.

83
Implementing a Warehouse

• Monitoring Sending data from sources
• Integrating Loading, cleansing,...
• Processing Query processing, indexing, ...
• Managing Metadata, Design, ...

84
Monitoring

• Data Extraction
• Data extraction from external sources is usually
  implemented via gateways and standard interfaces
  (such as Information Builders EDA/SQL, ODBC,
  JDBC, Oracle Open Connect, Sybase Enterprise
  Connect, Informix Enterprise Gateway, etc.)

85
Monitoring Techniques

• Detect changes to an information source that are
  of interest to the warehouse
• define triggers in a full-functionality DBMS
• examine the updates in the log file
• write programs for legacy systems
• polling (queries to source)
• screen scraping
• Propagate the change in a generic form to the
  integrator

86
Integration

• Integrator
• Receive changes from the monitors
• make the data conform to the conceptual schema
  used by the warehouse
• Integrate the changes into the warehouse
• merge the data with existing data already present
• resolve possible update anomalies
• Data Cleaning
• Data Loading

87
Data Cleaning

• Data cleaning is important to warehouse there
  is high probability of errors and anomalies in
  the data
• inconsistent field lengths, inconsistent
  descriptions, inconsistent value assignments,
  missing entries and violation of integrity
  constraints.
• optional fields in data entry are significant
  sources of inconsistent data.

88
Data Cleaning Techniques

• Data migration allows simple data transformation
  rules to be specified, e.g. replace the string
  gender by sex (Warehouse Manager from Prism is
  an example of this tool)
• Data scrubbing uses domain-specific knowledge to
  scrub data (e.g. postal addresses) (Integrity and
  Trillum fall in this category)
• Data auditing discovers rules and relationships
  by scanning data (detect outliers). Such tools
  may be considered as variants of data mining tools

89
Data Loading

• After extracting, cleaning and transforming, data
  must be loaded into the warehouse.
• Loading the warehouse includes some other
  processing tasks checking integrity constraints,
  sorting, summarizing, etc.
• Typically, batch load utilities are used for
  loading. A load utility must allow the
  administrator to monitor status, to cancel,
  suspend, and resume a load, and to restart after
  failure with no loss of data integrity

90
Data Loading Issues

• The load utilities for data warehouses have to
  deal with very large data volumes
• Sequential loads can take a very long time.
• Full load can be treated as a single long batch
  transaction that builds up a new database. Using
  checkpoints ensures that if a failure occurs
  during the load, the process can restart from the
  last checkpoint

91
Data Refresh

• Refreshing a warehouse means propagating updates
  on source data to the data stored in the
  warehouse
• when to refresh
• periodically (daily or weekly)
• immediately (defered refresh and immediate
  refresh)
• determined by usage, types of data source, etc.

92
Data Refresh

• how to refresh
• data shipping
• transaction shipping
• Most commercial DBMS provide replication servers
  that support incremental techniques for
  propagating updates from a primary database to
  one or more replicas. Such replication servers
  can be used to incrementally refresh a warehouse
  when sources change

93
Data Shipping

• data shipping (e.g. Oracle Replication Server),
  a table in the warehouse is treated as a remote
  snapshot of a table in the source database.
  After_row trigger is used to update snapshot log
  table and propagate the updated data to the
  warehouse

94
Transaction Shipping

• transaction shipping (e.g. Sybase Replication
  Server, Microsoft SQL Server), the regular
  transaction log is used. The transaction log is
  checked to detect updates on replicated tables,
  and those log records are transferred to a
  replication server, which packages up the
  corresponding transactions to update the replicas

95
Derived Data

• Derived Warehouse Data
• indexes
• aggregates
• materialized views
• When to update derived data?
• The most difficult problem is how to refresh the
  derived data? The problem of constructing
  algorithms incrementally updating derived data
  has been the subject of much research!

96
Materialized Views

• Define new warehouse relations using SQL
  expressions

join of sale and product
97
Processing

• Index Structures
• What to Materialize?
• Algorithms

98
Index Structures

• Indexing principle
• mapping key values to records for associative
  direct access
• Most popular indexing techniques in relational
  database B-trees
• For multi-dimensional data, a large number of
  indexing techniques have been developed R-trees

99
Index Structures

• Index structures applied in warehouses
• inverted lists
• bit map indexes
• join indexes
• text indexes

100
Inverted Lists
. . .
data records
inverted lists
age index
101
Inverted Lists

• Query
• Get people with age 20 and name fred
• List for age 20 r4, r18, r34, r35
• List for name fred r18, r52
• Answer is intersection r18

102
Bitmap Indexes

• Bitmap index An indexing technique that has
  attracted attention in multi-dimensional database
  implementation
• table

103
Bitmap Indexes

• The index consists of bitmaps
• Index on City

bitmaps
104
Bitmap Indexes

• Index on Car

bitmaps
105
Bitmap Indexes

• Index on a particular column
• Index consists of a number of bit vectors -
  bitmaps
• Each value in the indexed column has a bit vector
  (bitmaps)
• The length of the bit vector is the number of
  records in the base table
• The i-th bit is set if the i-th row of the base
  table has the value for the indexed column

106
Bitmap Index
. . .
age index
data records
bit maps
107
Using Bitmap indexes

• Query
• Get people with age 20 and name fred
• List for age 20 1101100000
• List for name fred 0100000001
• Answer is intersection 010000000000
• Good if domain cardinality small
• Bit vectors can be compressed

108
Using Bitmap indexes

• They allow the use of efficient bit operations to
  answer some queries
• how many customers from Detroit have car Ford
• perform a bit-wise AND of two bitmaps answer
  c1
• how many customers have a car Honda
• count 1s in the bitmap - answer - 2
• Compression - bit vectors are usually sparse for
  large databases the need for decompression

109
Bitmap Index Summary

• With efficient hardware support for bitmap
  operations (AND, OR, XOR, NOT), bitmap index
  offers better access methods for certain queries
• e.g., selection on two attributes
• Some commercial products have implemented bitmap
  index
• Works poorly for high cardinality domains since
  the number of bitmaps increases
• Difficult to maintain - need reorganization when
  relation sizes change (new bitmaps)

110
Join

• Combine SALE, PRODUCT relations
• In SQL SELECT FROM SALE, PRODUCT

111
Join Indexes
join index
112
Join Indexes

• Traditional indexes map the value to a list of
  record ids. Join indexes map the tuples in the
  join result of two relations to the source
  tables.
• In data warehouse cases, join indexes relate the
  values of the dimensions of a star schema to rows
  in the fact table.
• For a warehouse with a Sales fact table and
  dimension city, a join index on city maintains
  for each distinct city a list of RIDs of the
  tuples recording the sales in the city
• Join indexes can span multiple dimensions

113
What to Materialize?

• Store in warehouse results useful for common
  queries
• Example

total sale
day 2
. . .
day 1
129
materialize
114
Cube Operation

• SELECT date, product, customer, SUM (amount)
• FROM SALES
• CUBE BY date, product, customer
• Need compute the following Group-Bys
• (date, product, customer),
• (date,product),(date, customer), (product,
  customer),
• (date), (product), (customer)

115
Cuboid Lattice

• Data cube can be viewed as a lattice of cuboids
• The bottom-most cuboid is the base cube.
• The top most cuboid contains only one cell.

116
Cuboid Lattice
129
all
city
product
date
city, product
city, date
product, date
use greedy algorithm to decide what to materialize
city, product, date
117
Efficient Data Cube Computation

• Materialization of data cube
• Materialize every (cuboid), none, or some.
• Algorithms for selection of which cuboids to
  materialize
• size, sharing, and access frequency
• Type/frequency of queries
• Query response time
• Storage cost
• Update cost

118
Dimension Hierarchies

• Client hierarchy

region
state
city
119
Dimension Hierarchies Computation
all
product
city
date
product, date
city, product
city, date
state
city, product, date
state, date
state, product
state, product, date
roll-up along client hierarchy
120
Cube Computation - Array Based Algorithm

• An MOLAP approach
• the base cuboid is stored as multidimensional
  array.
• read in a number of cells to compute partial
  cuboids

121
Cube computations
B
A
C
ALL
ABCABACBC ABC
122
View and Materialized Views

• View
• derived relation defined in terms of base
  (stored) relations
• Materialized views
• a view can be materialized by storing the tuples
  of the view in the database
• index structures can be built on the materialized
  view

123
View and Materialized Views

• Maintenance is an issue for materialized views
• recomputation
• incremental updating

124
Maintenance of materialized views

• Deficit departments
• To find all deficit departments
• group by deptid
• join (deptid)
• select all dept.names with budget lt sum(salary)

125
Maintenance of materialized views

• select DeptId, sum(salary) Real_Budget
• from Employee
• group by DeptId Temp (relation)
• select Name
• from Dept, Temp
• where Dept.DeptIdTemp.DeptId
• and Budget lt Real_Budget

126
Maintenance of materialized views

• assume the following update
• update Employee
• set salarysalary1000
• where LnameJabbar
• recompute the whole view?
• use intermediate materialized results (Temp), and
  update the view incrementally?

127
Managing
128
Metadata Repository

• Administrative metadata
• source database and their contents
• gateway descriptions
• warehouse schema, view and derived data
  definitions
• dimensions and hierarchies
• pre-defined queries and reports
• data mart locations and contents

129
Metadata Repository

• Administrative metadata
• data partitions
• data extraction, cleansing, transformation rules,
  defaults
• data refresh and purge rules
• user profiles, user groups
• security user authorization, access control

130
Metadata Repository

• Business
• business terms definition
• data ownership, charging
• Operational
• data layout
• data currency (e.g., active, archived, purged)
• use statistics, error reports, audit trails

131
Design

• What data is needed?
• Where does it come from?
• How to clean data?
• How to represent in warehouse (schema)?
• What to summarize?
• What to materialize?
• What to index?

132
Summary

• Data warehouse is not a software product or
  application - it is an important information
  processing system architecture for decision
  making!
• Data warehouse combines a number of products,
  each has operational uses besides data warehouse

133
Summary

• OLAP provides powerful and fast tools for
  reporting on data
• ROLAP vs. MOLAP
• Issues associated with data warehouses
• new techniques multidimensional database, data
  cube computation, query optimization, indexing,
• data warehousing and application design vendors
  and application developers.

134
Current State of Industry

• Extraction and integration done off-line
• Usually in large, time-consuming, batches
• Everything copied at warehouse
• Not selective about what is stored
• Query benefit vs storage update cost
• Query optimization aimed at OLTP
• High throughput instead of fast response
• Process whole query before displaying anything

135
Research

• Incremental Maintenance
• Data Consistency
• Data Expiration
• Recovery
• Data Quality
• Dynamic Data Warehouses (how to maintain data
  warehouse over changing external data sources?)

136
Research

• Rapid Monitor Construction
• Materialization Index Selection
• Data Fusion
• Integration of Text Relational Data
  Semistructured Data ..
• Data Mining
