PROJECT REPORT FUEL INJECTION SYSTEM OF DIESEL ENGINES

1
PROJECT REPORTFUEL INJECTION SYSTEMOF DIESEL
ENGINES

• PROJECT GUIDE
• Mrs. PRATIBHA KUMARI
• PRESENTED BY
• Mohd.Shoeb
• Anupam Munjal
• Radhika Yadav

2
AIM

• To prepare a working model of
• FUEL INJECTION SYSTEM
• OF DIESEL ENGINE

3
NEED AND SCOPE

• To provide a working model of
• FUEL INJECTION SYSTEM FOR DIESEL ENGINE
• for the automobile lab of mechanical engineering
  department,KIET.
• This model will help the students to gain a
  practical knowledge about actual working process
  of a fuel injection system in diesel engine.

4
INTRODUCTION

• THE INJECTION SYSTEM IN DIESEL
• ENGINES CAN BE OF TWO TYPES
• 1. AIR INJECTION.
• 2. AIRLESS INJECTION.
• IN AIR INJECTION SYSTEM THE DIESEL IS
  INJECTED ALONG WITH THE COMPRESSED AIR WHEREAS
  IN
• AIRLESS INJECTION SYSTEM ONLY
• THE LIQUID DIESEL IS INJECTED INTO
• THE CYLINDER.

5
MAIN COMPONENTS

• THE MAIN COMPONENTS USED IN THE
• MODEL ARE
• FUEL TANK
• FEED VALVE
• PLUNGER TYPE PUMP
• PRESSURE GUAGE
• FUEL INJECTOR
• NOZZLE

6
BLOCK DIAGRAM

•


PRESSURE GUAGE
FUEL TANK
FEED VALVE
NOZZLE
FUEL PUMP
FUEL SPRAY INTO CYLINDER
PLUNGER TYPE
7
FUEL TANK

• Filling
• Storage of fuel
• Gauging
• Venting
• Feed of engine

8
FUEL TANK CAPACITY
9
FUEL INJECTION PUMP

• A FUEL INJECTION PUMP IS USED TO
• TO SUPPLY PRECISELY METERED QUANTITY OF DIESEL
  UNDER HIGH
• PRESSURE TO THE INJECTORS AT WELL TIMED
  INSTANTS.

10
(No Transcript)
11
(No Transcript)
12
TYPES OF FUEL INJECTION PUMPS

• 1.VARIABLE SPILL AND VARIABLE STOKE TYPES
• 2.SINGLE CYLINDER(PLUNGER) AND
• MULTI CYLINDER(PLUNGER) TYPES
• 3.JERK PUMP TYPE AND DISTRIBUTOR
• TYPE
• 4.CAM OPERATED IN LINE PLUNGER TYPE AND ROTARY
  DISTRIBUTOR TYPE

13
FUEL INJECTION PUMP
14
FUEL INJECTION PUMP(MULTI CYLINDER)(courtesy of
www.alibaba.com)
15
FUEL INJECTOR

• A FUEL INJECTOR IS USED TO INJECT THE
  FUEL IN THE CYLINDER IN ATOMISED FORM AND
  IN PROPER QUANTITY. FUEL INJECTORS ARE
  AVAILABLE IN SEVERAL DESIGNS.MAIN COMPONENTS OF
  FUEL INJECTORS ARE NOZZLE
• VALVE
• BODY
• SPRING
• The nozzle is its main part which is
  attached to the nozzle holder. Entry of fuel in
  the injector is from the fuel injection pump.

16
(No Transcript)
17
FUEL INJECTION LOCATION
18
FIRING FUEL INJECTOR
19
SOME FUEL INJECTORS
20
MATERIALS

• Fuel tank is made of cast iron and alloy steel
• Fuel tank is made of plastics or zinc nickel
  plated steel
• Main body of fuel injector is made of cast iron
  and plunger is made of zirconia

21
(No Transcript)
22
INJECTION NOZZLES

• The nozzle is the main part of injector which
  is attached to the nozzle holder. There are two
  types of nozzle
• 1. Closed
• 2. Open
• The distinction being according to whether the
  injection pressure is controlled by a spring
  loaded needle valve or whether valve is dispensed
  with. Open nozzles are not much used these days.

23
TYPES OF NOZZLE

• The closed type injection nozzles may be
  classified into following types
• Hole type single hole type and multiple hole
  type
• Pintle type
• Pintaux type
• Long stem type
• Delayed action type
• Throttle type

24
INJECTION NOZZLES
25
VCO FUEL INJECTION NOZZLE
26
DHANYAWAAD
