High Concentration and High Temperature Aerosol
Sampling

• NATE TOPHAM
• AEROSOL MECHANICS

2
Topics to be Discussed

• Sources
• Formation Mechanisms
• Challenges with Sampling
• Sampling Methods
• Summary

Anthropogenic aerosol formation
http//stopsmokingwithbanjojones.blogspot.com/2007
/01/shocking-disregard-for-law.html
3
High Concentration/Temperature Aerosols

• Some are desirable
• Carbon black, pigments, ceramic powders
• Some are undesirable
• MSW Incinerators, welding, automobile engines,
  aircraft engines, hazardous waste incinerators

http//www.twi.co.uk/content/c1478.html
http//sites.google.com/site/leedsfoe/Home/no-to-i
ncineration
4
High Concentration Aerosol Generation

• Characteristics of aerosols are dependent on
  industry in which theyre produced
• Beneficial Aerosols
• Monodisperse distribution is often desired
• Process parameters must be modified to achieve
  desired size size distribution
• Sampling analysis required for quality control
  measures
• Harmful Aerosols
• Desired size range is based on control technology
  used
• Combustion aerosols are often very difficult to
  collect due to their size

5
Characteristics of High Temperature Aerosols

• What mechanisms discussed in this class are
  evident in these images?

Welding Agglomerate Particle
Welding Primary Particle
6
Issues with Sampling

• Potential interference with sampling devices
• Coagulation
• Decrease in number concentration
• Increase in particle size
• Condensation
• Increase in mass concentration
• Increase in particle size
• Big problem with organic aerosols
• Thermophoresis
• Loss of particles in sampling system
• Results from high temperature aerosols gas
  passing through cool sampling system

7
Thermophoresis
is very large when the gas flow containing the
aerosols is from a combustion source and a cold
probe is inserted

• How will thermophoresis impact data on aerosols
  from a combustion source?
• Particle number concentration will be lower than
  actual value
• Particle number concentration could be higher
  than the actual value
• How?
• Impact on regulatory control
• PM concentration might seem lower than actual
  value, violator could get away with excessive
  emission

8
Sampling Issues (continued)

• Potential interference with sampling devices
• Overloading
• Damage to filters or instrumentation from high
  temperature
• Time dependent changes in aerosols
• Temperature changes yield changes in aerosol
  properties and distribution

9
Sampling Methods

• Sampling techniques vary based on analytical
  techinques
• Destructive vs. non-destructive analytical
  techniques
• Destructive Inductively-coupled Plasma
• If the aerosols are deformed or agglomerate
  during sampling, its OK!
• We digest aerosols for this technique, theyre
  destroyed in the end anyway
• Non-destructive Transmission Electron
  Microscopy
• If the aerosols are deformed/destroyed, the TEM
  images will not represent the true aerosol
  properties

10

• Different filters have different operable
  temperature ranges
• Some filters would actually melt when attempting
  to sample high temperature aerosols

Chow, J. Air Waste Manage. Assoc. 45 320-382.
1995
11
Sampling Methods

• Dilution
• Goal Quench all changes in aerosol
  characteristics as quickly as possible
• Primary
• Addresses a number of challenges this type of
  sampling presents
• Overloading
• Reduces number concentration to operable range
  for analytical instruments
• Coagulation
• Reduces collisions
• Thermophoresis
• Aerosols and gas are cooled, lowering the
  temperature difference between aerosols and
  surfaces of sampling equipment

12
Sampling Methods

• Dilution
• Secondary
• Lowers number concentration to a level that is
  within operable range for instrumentation
• Optional, process is similar to that of primary
  dilution
• Long mixing times are desirable to ensure
  homogeneity of sample

http//www.dekati.com/cms/dekati_diluter/accessori
es
13
In-Situ Sampling Methods

• EPA Methods
• Method 5
• External filtration
• Widely used for stationary sources, such as
  utility plants, incinerators, other stacks
• Sampling probe is placed directly in gas flow
  carrying aerosols
• Method 17
• In-stack filtration
• Allows isokinetic sampling, however, it is more
  difficult in high temperature flows

http//www.cleanair.com/Equipment/Express/catm5tr.
htm
14
EPA Method 5
Example sampling train from gas-fired boiler
http//www.epa.gov/ttn/emc/ftir/reports/r04.html
15
High Temperature Impactor

• Isokinetic Sampling
• Some use ceramic fibers as substrate
• Some use virtual impactors
• Difficult to employ multistage impactors because
  secondary flow must be closely controlled in each
  stage

http//www.photometer.com/en/abc/show.html?qIsoki
netic20sample
16
Optical Methods

• Elastic Light Scattering
• Scattering/Extinction
• Mean particle size, number concentration for
  absorbing aerosols
• No size limitation
• Angular Dissymetry
• Mean size, number concentration, spread in
  distribution
• Polarization Ratio
• Measurable particle size greater than 0.1?
• Good for non-absorbing aerosols with known
  refractive index
• Non-Elastic Light Scattering
• Dynamic Light Scattering (Photon Correlation
  Spectroscopy)
• Diffusion Coefficient
• Requires system temperature to compute particle
  size, no size limitation, refractive index not
  needed

From Aerosol Measurement-Principles, Techniques,
and Applications 2nd Edition. (2001).
17
Challenges in Sampling

• Different sampling probes can yield different
  aerosol size distributions
• Thermophoresis is an important factor in final
  measured distribution due to thermophoresis at
  probe inlet
• Jiménez, Santiago Ballester, Javier (2005). A
  Comparative Study of Different Methods for the
  Sampling of High Temperature Combustion Aerosols.
  Aerosol Science and Technology, 39 (9), 811-821.

18
Reactions Between Vapor and Particles

• Vapor phase species can impact aerosol
  characteristics
• Laser-Induced Fluorescence
• In-Situ measurement technique that measures
  gaseous species that are precursors for gas to
  particle conversion
• In some systems, reaction between aerosols and
  particles is desired
• Owens, T.M. and Biswas, P. (1996). Vapor phase
  sorbent precursors for toxic metal emissions
  control from combustors. Ind. Eng. Chem. Res.,
  35. 792-798.
• Lee, M.H., Cho, K., Shah, A.P. and Biswas, P.
  (2005). Nanostructured sorbents for capture of
  cadmium species in combustion environments.
  Environ. Sci. Technol., 39. 8481-8489.
• Biswas, P. and Zachariah, M.R. (1997). In situ
  immobilization of lead species in combustion
  environments by injection of gas phase silica
  sorbent precursors. Environ. Sci. Technol.,
  31(9). 2455-2463.
• Liu, Z.S., Wey, M.Y. and Lin, C.L. (2001). The
  capture of heavy metals from incineration using a
  spray dryer integrated with a fabric filter using
  various additives. J. Air Waste Manage. Assoc.,
  51. 983-991.
• Whats the take-home message from these research
  studies?
• Reactions between aerosols and vapor phase
  chemicals are important, and can be controlled to
  achieve desirable physical and chemical traits
  in aerosols

19
Combustion Aerosols
Transmission electron microscopy image of
combustion aerosols

• Electron Microscopy
• X-Ray Diffraction
• Raman Spectroscopy
• Ex-Situ
• Chemical analysis of particles
• Mössbauer Spectroscopy
• Measures resonant absorption in a solid as a
  result of resonant emission from another solid

From Aerosol Measurement-Principles, Techniques,
and Applications 2nd Edition. (2001).
20
Summary

• High concentration high temperature aerosols
  come from a variety of sources
• Many mechanisms influence their formation
• These mechanisms present challenges for accurate
  sampling and analysis
• Many in-situ and ex-situ sampling techniques
  exist
• Combustion aerosols present unique sampling
  challenges
