OSG AuthZ components

1
OSG AuthZ components

• Dane Skow
• Gabriele Carcassi

2
Full privilege scenario

voms-proxy-init
Submission site
User
VOs
Execution site
site GUMSServer
Gatekeeper
PRIMA
grid3-usertxt
gums-host
ü centralized mapping ü account pool ü/û dynamic
mappings (broken by accounting) ü role/group
based mappings
3
Compatibility scenario

grid-proxy-init
Submission site
User
VOs
Execution site
gums-host
site GUMSServer
Gatekeeper
both maps
grid-mapfile
gums-host
grid3-usertxt
gums-host
gums-host
ü centralized mapping ü account pool û dynamic
mappings û role/group based mappings
4
Ye olde Grid3 setup

grid-proxy-init
Submission site
User
Execution site
edg-mkgridmap
Gatekeeper
grid-mapfile
VOs
grid3-usertxt
û centralized mapping û account pool û dynamic
mappings û role/group based mappings
5
PRIMA module

• Its a C library that implement the gatekeeper
  callout
• Gets the credentials
• Validates certificate and attributes
• Formats a SAML message and sends it to GUMS
• Parses the response
• Returns the uid to the gatekeeper
• Distributed as part of VDT

6
Details

• PRIMA sends only the first VOMS FQAN, not the
  whole list encoded in the certificate. GUMS makes
  decisions only on one FQAN.

7
Attribute verification

• PRIMA can verify the VOMS attributes, but
  typically we do not do that
• In OSG we lack a mechanism to easily distribute
  the certificates of the VO servers
• GUMS verifies the presence in the VO
• periodically downloads the full list of users
  from the VO server (has to do that for maps
  generation)
• prevents forging a fake VO
• foresee to disable in case attribute verification
  is done at the gatekeeper end, and no maps are
  needed
• Should attribute verification be delegated to the
  server?

8
PRIMA Complaints

• Mainly about the log
• Not clear error information (the actual GUMS
  errors are not passed through the protocol)
• Lacks a one liner entry with all information when
  successful (there is one, but, for example, lacks
  the FQAN)

9
What is GUMS?

• GUMS purpose is to manage the mapping between
  Grid Credentials to Site credentials
• Centralized one GUMS per site, one configuration
  file for all gatekeepers/services
• PDP enforcement is done at the
  gatekeeper/service (through grid-mapfiles or
  callouts)
• Customizable designed to be integrated with
  other site systems with little effort

10
Centralized management

• Designed by and for a site with a number of
  heterogeneous gatekeepers
• For example, BNL GUMS has more than 10
  gatekeepers (4 from STAR, 1 PHENIX, 6 ATLAS)
  other ATLAS services (dCache, DIAL, )
• Some of these are OSG, some are test machines,
  some needs special test maps,
• One place of configuration allows control and
  consistency
• (For a small site, with one gatekeeper and 20
  nodes, that is fine with a single account per VO,
  we currently recommend mapfiles and
  edg-mkgridmap.)

11
GUMS overview
Tomcat server
SAML obligations over SOAP/HTTPS
Glite trustmanager
PRIMA
GUMS DB
Business logic
Persistence (hibernate,ldap)
AuthZWS
Cmd line
AdminWS (Axis)
SOAP/HTTPS
Web UI (JSP)
Webbrowser
HTTPS
WS Web Service UI User Interface
filesystem
XML configuration
12
GUMS Policy example

className'gov.bnl.gums.hibernate.HIbernatePersist
anceFactory' /
name'usatlasPool' className'gov.bnl.gums.LDAPGroup'
server'grid-vo.nikhef.nl' query'ouusatlas,oatl
as,dceu-datagrid,dcorg
persistanceFactory'mysql' name'usatlas' /

untMapper' persistanceFactory'mysql'
name'bnlMapping' / className'gov.bnl.gums.AccountPoolMapper'
persistanceFactory'mysql' name'bnlPool' /
countMapper' groupName'usatlas1' /

className'gov.bnl.gums.VOMSGroup'
url'https//vo.racf.bnl.gov8443/edg-voms-admin/s
tar/services/VOMSAdmin
persistanceFactory'mysql' name'star'
sslCertfile'/etc/grid-security/hostcert.pem'
sslKey'/etc/grid-security/hostkey.pem'/
className'gov.bnl.gums.ManualAccountMapper'
persistanceFactory'mysql' name'bnlMapping' /
ccountMapper' jndiNisUrl'nis//nis2.somewhere.com
/rhic.bnl.gov' /

s.CertificateHostGroup" cn'star.somewhere.gov'
groups'star' / className"gov.bnl.gums.CertificateHostGroup"
cn'gums.somewhere.gov' groups'star,phenix,usatla
sPool' /
13
GUMS Authorization

• GUMS admin can perform any operation through web
  service and web ui door
• Host can only perform read operations (map
  generation and mapping requests) for itself
• Configuration can be changed through filesystem
  only (automatically reloaded when changed)

14
GUMS performance

• BNL production server gives 30 req/sec
• Not that good
• Is not the bottleneck right now, as the
  production gatekeeper can only give 5 req/sec
• Performance test show that
• Overall delay (client-server-client) is 220ms
• The GUMS logic is responsible for up to 20ms
• The rest is plain AXIS SOAP SSL
• Its not glite trustmanagers fault either

15
GUMS performance

• JClarens group confirmed this while comparing
  SOAP with XML-RPC
• XML-RPC without SSL 373 req/sec with SSL 274
• SOAP without SSL 218 req/sec with SSL 23
• 10 times slower!
• Is it SOAP? Is it Axis implementation?
• At least, GUMS can run on a cluster
• All state resides in the database, transactions
  are used, no session transfer needed, no cluster
  cache needed
• Almost all the configuration file is on
  filesystem, an needs to be updated on all
  machines (at the same time)

16
GUMS Complaints

• The configuration file is difficult
• It usually takes people a few tries
• We should simplify it
• We should probably have ways to share parts of
  it (contact a location to get standard OSG groups
  definitions?)

17
Storage AuthZ (not in prod)
Execution site
Gatekeeper GRAMgridFTP
site GUMSServer
PRIMA
SAML obligations over SOAP/HTTPS
SRM/dCache
StorageAuthorizationService
gPLAZMA
Adds AuthZ params that are dCache specific. XACML
policy.
18
Storage AuthZ

• gPlazma is dCache authorization infrastructure,
  which can be set to contact the Storage
  Authorization Service
• Distributed as part of dCache, Beta quality
• The Storage AuthZ Service speaks the same SAML
  GUMS does, and is configured with a XACML policy
• Contact GUMS to retrieve the mapping
• Adds other AuthZ parameters (i.e. gid, user home
  path, )
• Prototype level

19
Other issues maps

• GUMS is able to generate grid-mapfiles and also
  an inverse accounting map used by OSG accounting
• Want to move away from them creating a map means
  exploring all the policy, which breaks dynamic
  account mapping (i.e. for a pool, we have to
  assigns accounts to everybody)
• Assumption we believe that inverse maps (uid-
  DN) are not needed
• For example, in accounting what you really need
  is a history of what uid was assigned to what DN.
  That changes with time. Its better handled by
  looking at log files.

20
Conclusions

• GUMS and PRIMA are deployed in production on a
  number of OSG sites
• Privilege project depends on the following
  formats
• VOMS Proxy format (PRIMA)
• AuthZ request SAML obligations (everything)
