Overview

• Introduction to perception
• Collision detection
• Broad phase
• Narrow phase
• Point mesh relationship

3
Perception is important

• Helps create the illusion of intelligence
• E.g.
• You approach a bot silently, from the rear but it
  immediately turns around and frags you with a
  chain gun
• You run and hide. It is impossible for an enemy
  to know where you are, but it nevertheless
  proceeds directly to your location
• You notice a guard in a guard tower. It sweeps
  the ground with a search light. You follow a path
  that avoids the search light, but the guard still
  sees you

4
Perception

• We have 5 senses
• Sound
• Touch
• Sight
• Smell
• Taste
• Games currently model only 3 senses
• Touch
• Sound
• Sight

5
Perception

• Game bots do not really perceive!
• Instead use simplified models
• Distance
• Intersections of points, planes, spheres, rays
• States
• Character modelling
• Sound effects
• To give the illusion of perception

6
Touch

• Detecting when two 3D objects collide
• Examples
• The player collides with the walls
• The player walks up a stairs
• A projectile hits a game entity
• A projectile hits a wall
• The player collides with a game entity
• The player goes somewhere they are not supposed to

7
Difficulties with Collision Detection

• If we have n objects
• Object 1 may collide with n-1 other objects
• It cant collide with itself
• Object 2 may collide with n-2 other objects
• We have already checked 1 and 2 collision
• Thats equivalent to
• (n-1) (n-2) (n-3) ... 1
• Or
• n!
• In other words, lots.

8
Difficulties with Collision Detection

• True collision detection is calculating the
  intersection between arbitrarily complex polygons
• Polygons deform when the collisions occur
• A collision can cause a force in the objects that
  collide

9
Difficulties with Collision Detection

• A Mesh may contain thousands of triangles

10
Collision detection problems
11
Collision detection problems
12
In practice then

• Broad phase collision detection (AKA Macro
  collision detection
• Narrow phase collision detection (AKA Micro
  collision detection)

13
Collision detection algorithms

• Broad Phase
• Point and bounding box
• Point and bounding sphere
• Bounding box bounding box
• Bounding sphere bounding sphere
• Box sphere
• Ray sphere
• Ray bounding box
• Narrow phase
• Point and plane
• Ray and plane
• Plane and plane

14
Bounding box and sphere

• We can use bounding boxes and spheres to
  determine which meshes to check for collisions
  (Broad phase)
• At some point we need to compare each triangle of
  each mesh whose bounding box/sphere collides to
  check for a true collision (Narrow Phase)
• We might also need to know where the collision
  occurred

15
Broad Phase Collision Detection

• Bounding boxes
• if (A._upperBound.x lt B._lowerBound.x)
• return false
• if (A._lowerBound.y gt B._upperBound.y)
• return false
• if (A._lowerBound.x gt B._upperBound.x)
• return false
• if (A._upperBound.y lt B._upperBound.x)
• return false
• return true

16
Bounding boxes

• Are usually axis aligned (edges aligned with the
  X, Y and Z axis)
• We have to transform the ray/point into the boxs
  local space to do the check if they are not

17
Bounding Spheres

• It is very easy to detect if bounding spheres
  overlap, for instance,
• Object A has centre at ax,ay,az and radius ar
• Object B has centre at bx,by,bz and radius br
• Then the bounding spheres intersect if
• sqrt((ax-bx)2(ay-by)2(az-bz)2) lt arbr
• OR
• (ax-bx)2(ay-by)2(az-bz)2 lt (arbr)2
• The distance from one centre point to the next
  centre point lt the sum of the two radii

18
Bounding spheres

• You can check if a point is inside a sphere
• If (distance from point to centre) lt radius then
  the point is inside thesphere

19
Bounding volumes for meshes

• D3DXComputeBoundingBox
• D3DXComputeBoundingSphere
• Do these return coordinates in local space or
  world space?

20
Geometry refresher

• Point
• x, y, zD3DXVECTOR3/ D3DXVECTOR2
• 2D Line
• Start, end points
• Slope and intercept (y mx c)
• Ray
• pos and look
• Ray (_pos, _look)
• p(t) p0 t(u)
• 0 p0 t(u) p(t)
• Plane
• A vector N (The normal) and a point P (on the
  plane)
• Ax By Cz D
• The vector A, B, C is the plane Normal
• D is the shortest signed distance from the origin
  to the plane

21
Planes

• Can be described using a point on the plane and a
  normal vector, a vector perpendicular to the
  plane

22
Equation of a plane

• Remember
• Cos(PI / 2) 0, so
• If A and B are perpendicular vectorsA.B 0
• The equation of a plane is given by
• n.(p p0) 0

23
Equation of a plane

• n.(p-p0) Can be written as
• n.p n.p0 (Distributive)
• We can therefore write the equation asn.p d
  0Where d -n.p0
• d is also shortest signed distance from the
  origin to the plane
• When storing a plane, we can get away with
  storing n and d (A 4D vector)

24
Planes in DirectX

• We can use the classD3DXPLANE to represent a
  plane D3DXPLANE plane D3DXPLANE(float a,
  float b, float c, float d)Where a, b, c are
  the x, y, z of the normal d is the constant d

25
Construction

• You can construct a planeD3DXPLANE
  D3DXPlaneFromPointNormal( D3DXPLANE pOut, CONST
  D3DXVECTOR3 pPoint, CONST D3DXVECTOR3 pNormal
  )
• D3DXPlaneFromPoints( plane, planeVertices0,
  planeVertices1, planeVertices2)

26
Useful things to do with planes

• If p is a pointIf n.p d 0, the point is on
  the planeIf n.p d gt 0, the point is in front
  of the planeIf n.p d lt 0, the point is behind
  the plane
• Use D3DXPlaneDotCoord(D3DXPLANE plane,
  D3DXVECTOR3 v)
• To do the above calculation

27
In DalekWorld

• Everything extends Entity
• Entity collidesWith(D3DXVECTOR3 point)
• Supports 3 types
• inner_box (World)
• outer_box (Walls)
• sphere (for Meshes)

28
Inner box

• // Check if we colide with the roof or ceiling
• if ((point-gty lt _lowerBound.y) (point-gty gt
  _upperBound.y))
• return this
• // Check and see if we collide with the outer
  walls
• if ((point-gtx gt (_lowerBound.x))
• (point-gtx lt (_upperBound.x))
• (point-gtz gt (_lowerBound.z))
• (point-gtz lt (_upperBound.z)))
• return NULL
• else
• return this
• break

29
Outer box

• if ((point-gtx gt _lowerBound.x)
• (point-gtx lt _upperBound.x)
• (point-gtz gt _lowerBound.z)
• (point-gtz lt _upperBound.z)
• (point-gty gt _lowerBound.y)
• (point-gty lt _upperBound.y))
• return this
• else
• return NULL

30
Sphere

• float distance D3DXVec3Length((point -
  _centrePoint))
• return (distance lt _radius) ? this NULL

31
World
32

• retVal EntitycollidesWith(point)
• if (retVal ! NULL)
• return retVal
• // Now see if we collide with the inner walls
• for(int i 0 i lt _walls.size() i )
• retVal _wallsi-gtcollidesWith(point)
• if (retVal ! NULL)
• return retVal
• // Now see if we colide with any daleks
• for(int i 0 i lt _daleks.size() i )

33
In Code

• void Entitywalk(float units)
• D3DXVECTOR3 newPos
• D3DXVECTOR3 testPos
• newPos _pos D3DXVECTOR3(_look.x, 0.0f,
  _look.z) units
• testPos newPos _look _margin
• Entity boundableEntity _world-gtcollidesWith(
  testPos)
• if ((!_isGhost) (boundableEntity NULL)
  (boundableEntity this))
• _moved true
• _pos newPos

34

• void Entitystrafe(float units)
• D3DXVECTOR3 newPos, testPos
• newPos _pos D3DXVECTOR3(_right.x, 0.0f,
  _right.z) units
• testPos newPos _look 2
• Entity boundableEntity _world-gtcollidesWith(
  testPos)
• if ( (!_isGhost) (boundableEntity NULL)
  (boundableEntity this))
• _moved true
• _pos newPos

35
So far only broad phase

• But what about rocks etc in the world
• That have boundaries that are not axis aligned
• We need to combine broad phase with narrow phase
  for movement
• First do a broad phase collision detection check
  (bounding sphere/box)
• Then do a narrow phase check

36
(No Transcript)
37
Point Mesh Collision algorithm

• First check to see if the point is inside the
  entities bounding sphere
• If it is,
• Translate the point by the inverse of the mesh
  world transform, to bring the point into the mesh
  local space
• Get the number of planes from the Mesh
• Get the index buffer from the Mesh
• Get the Vertex buffer from the mesh
• For each plane
• Retrieve 3 indices from the index buffer
• Retrieve the three vertices corresponding to the
  indices
• Make a plane out of the three vertices
• Calculate n.p d (call it x)
• if ( x gt 0)
• The point is outside one of the planes, so return
  false
• Return true

38

• int numPlanes _mesh-gtGetNumFaces()
• int bytesPerVertex _mesh-gtGetNumBytesPerVertex(
  )
• int numIndices numPlanes 3
• WORD indexBuffer NULL
• char vertexBuffer
• if (_mesh-gtLockIndexBuffer(D3DLOCK_DISCARD,(LPVOI
  D ) indexBuffer) D3D_OK)
• _mesh-gtLockVertexBuffer(D3DLOCK_DISCARD,(LPVOID
  ) vertexBuffer)
• for (int i 0 i lt (numIndices - 3) i 3)
• memcpy( planeVertices0, vertexBuffer
  (indexBufferi bytesPerVertex),
  sizeof(D3DXVECTOR3))
• memcpy( planeVertices1, vertexBuffer
  (indexBufferi 1 bytesPerVertex),
  sizeof(D3DXVECTOR3))
• memcpy( planeVertices2, vertexBuffer
  (indexBufferi 2 bytesPerVertex),
  sizeof(D3DXVECTOR3))
• printPlane(planeVertices)
• // Now make a plane out of the 3 vertices
• D3DXPLANE plane
• D3DXPlaneFromPoints( plane,
  planeVertices0, planeVertices1,
  planeVertices2)

39
Caveat!!

• The above algorithm only works for convex meshes
