Chapter 4 INHERITANCE

1
Chapter 4 INHERITANCE
2
4.1 INTRODUCTION

• Suppose that a class Student has already been
  designed and implemented and that a new
  application needs a class GradStudent. Since a
  GradStudent is a Student, rather than build the
  class GradStudent from scrath, we can add to the
  class Student whatever data and methods it needs
  to become a GradStudent.

3
4.1 INTRODUCTION(Cont.)

• The resulting class GradStudent is said to be
  inherited from the class Student.
• The new class GradStudent is called a derived
  class or a subclass of Student.
• The orginal class Student is called the base
  class or superclass of GradStudent.

4
4.1 INTRODUCTION(Cont.)

• The derived class GradStudent inherits all of the
  data and methods from the existing class
  Student(except for constructors, the destructor,
  and an overload of the assignment operator).
• A derived class thus has all of the data and
  method (with the exceptions noted) of its base
  class, in addition to added data and methods.

5
FIGURE 4.1.1

• Class GradStudent is derived from class Student.

6
4.1 INTRODUCTION(Cont.)

• Inheritance promotes code reuse because the code
  in the base class is inherited by the subclass
  and thus need not be rewitten.
• If the code were rewritten, bugs might
  inadvertently be introduced.
• Inheritance also provides a mechanism to express
  the natural relationships among the components of
  a program.

7
4.1 INTRODUCTION(Cont.)

• Inheritance is required for polymorphism in which
  the particular method to invoke depends on the
  class to which the object belongs, but the class
  to which the object belongs is not known until
  the program is executing.(examined in CH5)
• Besides the is a relationship present in
  inheritance (e.g., a GradStudent is a Student),
  we can think of a derived class as a specialized
  version of the base class.

8
FIGURE 4.1.2

• Class CPen is derived from class Pen.

9
4.1 INTRODUCTION(Cont.)

• A derived class can itself serve as a base class
  for another class.
• Notice that as we move down the hierarchy, each
  class is a specialized version of its base class.

Direct base class for Car Indirect base class for
Coupe Direct derived class from Vehicle Direct
base class for Coupe Direct derived calss from
Car Indirect derived class from Vehicle
10
4.1 INTRODUCTION(Cont.)

• C also supports multiple inheritance, in which
  a derived class can have multiple base classes.
  (also be discussed in 4.7)
• Class directly support the creation of abstract
  data types. Inheritance extends that support by
  promoting the derivation of new abstract data
  types from already existing ones.
• Object-oriented languages thus provide
  programmers with the tools for programming with
  abstract data types.

11
4.2 BASIC CONCEPTS AND SYNTAX

• To derive class DC from class BC, we write
• //BC is the base class DC is the derived class
• class DC public BC
• //
• Except for public BC the preceding
  declaration looks like an ordinary class
  declaration.

12
4.2 BASIC CONCEPTS AND SYNTAX(Cont.)

• The C Postscript section at the end of this
  chapter discusses the other types of inheritance,
  in which the keyword public is omitted or
  replaced by either private or protected.
• // BC is the base class DC is the derived class
• Class DC BC // Caution default
  inheritance is private
• //
• If public is omitted the inheritance defaults to
  private.

13
4.2 BASIC CONCEPTS AND SYNTAX(Cont.)

• Example 4.2.1
• class Pen
• public
• enum ink Off, On
• void set_status ink
• void set_location( int, int )
• Private
• int x
• int y
• ink status

p.set_status( PenOn ) p.set_status( PenOff
) p.set_location( x, y )
14
4.2 BASIC CONCEPTS AND SYNTAX(Cont.)

• Suppose that our hardware is upgraded so that we
  have a colored pen. Rather than declare a brand
  new class to describe the colored pen, we can
  derive a colored pen class from the pen class
• class Cpen public Pen
• public
• void set_color( int )
• private
• int color

15
FIGURE 4.2.1

• Pen CPen

X Y Status Set_status Set_location
X Y Status Set_status Set_location Color Set_color
From Pen
Base class
Derived class
16
4.2 BASIC CONCEPTS AND SYNTAX(Cont.)

• private Members in Inheritance
• Each private member in a base class is visible
  only in the base class.
• A private member of a base class is inherited by
  the derived class, but it is not visible in the
  derived class.
• Although a private member of a base class cannot
  be directly accessed in a derived class, it might
  be indirectly accessed through a derived method.

17
Example 4.2.2

• class Point
• public
• void set_x( int x1 ) x x1
• void set_y( int y1 ) y y1
• int get_x() const return x
• int get_y() const return y
• private
• int x
• int y

class Intense_point public Point public
void set_intensity( int i ) intensity I
int get_intensity() const return intensity
private int intensity
18
Example 4.2.2 (Cont.)
19
4.2 BASIC CONCEPTS AND SYNTAX(Cont.)

• Adjusting Access
• The access status of an inherited member can be
  changed with a using declaration.
• See example 4.2.3

20
EXAMPLE 4.2.3

• class BC // base class
• public
• void set_x( float a ) x a
• private
• float x
• class DC public BC // derived class
• public
• void set_y( float ) y b
• private
• flaot y
• using BCset_x

int main() DC d d.set_y( 4.31 ) //OK
d.set_x( -8.03 ) // ERROR //
set_x is private in DC
21
4.2 BASIC CONCEPTS AND SYNTAX(Cont.)

• Name Hiding
• If a derived class adds a data member with the
  same name as a data member in the base class ,
  the local data member hides the inherited data
  member.
• Similarly, if a derived class adds a method with
  the same name in the base class, the added method
  hides the base classs method.

22
EXAMPLE 4.2.4

• class BC // base class
• public
• void h( float ) // BCh
• class DC public BC // derived class
• public
• void h( char ) // DANGER hides
  BCh
• int main()
• DC d1
• d1.h( Boffo! ) //DCh, not BCh
• d1.h( 707.7 ) // ERROR DCh
  hides BCh
• d1.BCh( 707.7 ) //OK invokes BCh
• //

23
4.2 BASIC CONCEPTS AND SYNTAX(Cont.)

• Indirect Inheritance
• Data members and methods may traverse several
  inheritance links as they are included from a
  base to a derived class.
• Inheritance thus may be either direct (to a
  derived class from a direct base class) or
  indirect (to a derived class from an indirect
  base class).

24
EXAMPLE 4.2.5

• // direct base class for Cat,
• //indirect base class for HouseCat
• class Animal
• public
• string species
• float lifeExpectancy
• bool warmBlooded_P
• // direct derived class from Animal
• // direct base class for HouseCat
• class Cat public Animal
• public
• string range 100
• float favoritePrey 100 100

// indirect derived class from Animal // direct
derived class from Cat class HouseCat public
Cat public string toys 1000
string catPsychiatrist string catDentist
string catDoctor string apparentOwner
25
4.3 SAMPLE APPLICATION TRACKING FILMS

• Problem
• Sample Output
• Solution
• C Implementation
• Discussion
• Program Development

26
4.4 protected MEMBERS

• Becides private and public members, C provides
  protected members.
• In the absence of inheritance, a protected member
  is just like a private member it is visible only
  within the class.
• In public inheritance, a protected member differs
  from a private member in that a protected member
  in the base class is protected in the derived
  class.
• Thus when a derived class inherits a protected
  member from a base class, that protected member
  is visible in the derived class.

27
EXAMPLE 4.4.1

• class BC
• public
• void set_x( int a ) x a
• protected
• int get_x() const return x
• private
• int x
• class DC public BC
• public
• void add2() int c get_x() set_x( c2
  )

28
EXAMPLE 4.4.1(Cont.)

• int main()
• DC d
• d.set_x( 3 ) //OK set_x is public in DC
• // ERROR get_x is protected in DC
• cout ltlt d.get_x() ltlt \n
• d.x 77 // ERROR x is private in BC
• d.add2() // OK add2 is public in DC

class DC public BC // // ERROR x
is accessible only within BC void add3() x
3 //
29
4.4 protected MEMBERS(Cont.)

• A derived class may access protected members that
  it inherits from a base class.
• In other words , these protected members are
  visible in the derived class.
• Yet a derived class may not access protected
  members of a base class object, that is , an
  object that belongs to the base class but not to
  the derived class.

30
EXAMPLE 4.4.2

• Class BC
• protected
• int get_w() const
• //
• Class DC public BC
• public
• // get_w belongs to DC because it is
  inherited from BC
• void get_val() const return get_w()
• // ERROR b.get_w not visible in DC
  since b.get_w is a
• //member of BC , not DC
• void base_w( const BC b ) const coutltlt
  b.get_w() ltlt\n

31
4.4 protected MEMBERS(Cont.)

• A private member is inherited but not visible in
  derived class.
• Except for a friend function(see Section 6.4),
  only method of a class can access a private
  member of that class.
• A protected member is inherited and visible in a
  derived class. Thus a protected member can be
  visible throughout the class hierarchy.
• Except for a friend function, only methods within
  the class hierarchy can access a protected
  member.
• By making a member of a class public, we make the
  member visible wherever the class is visible.

32
EXAMPLE 4.4.3
BC
Public Protected private
Init_x Get_x x

• class BC
• public
• void init_x() x 0
• protected
• int get_x() const return x
• private
• int x
• class DC
• public
• void g() init_x() coutltlt get_x() ltlt
  \n

DC
Public Protected Public Private to B
Init_x Get_x G
x
33
4.4 protected MEMBERS(Cont.)

• In general, protected data should be avoided.
• Data that might be protected can usually be made
  private and made accessible by protected
  accessors.
• More complex data members are sometimes better
  declared protected instead of supplying
  complicated accessors.
• Using private data members promotes data hiding.
• A class with private data members and protected
  accessors can be completely reimplemented without
  disturbing the interface.

34
EXAMPLE 4.4.4

• Class BC
• //
• protected
• int y
• Can be better

Class BC // protected int
get_y() const return y void set_y( int
a ) y a private int y
35
4.5 CONSTRUCTORS AND DESTRUCTORS UNDER INHERITANCE

• Constructors Under Inheritance
• An object in a derived class inherits
  characteristics from the base class but also has
  characteristics that are specific to the derived
  class.

36
4.5 CONSTRUCTORS AND DESTRUCTORS UNDER INHERITANCE

• A base class constructor ( if any ) is invoked
  when a derived class object is created.
• The base class constructor handles initialization
  and other matters for the from the base class
  part of the object.
• If the derived class has a constructor of its own
  , this constructor can handle the added by
  derived class part of the object.

37
EXAMPLE 4.5.1

• class BC // base class
• public
• BC() x y -1 // base constructor
• protected
• int get_x() const return x
• int get_y() const return y
• private
• int x
• int y
• class DC public BC //derived class
• public
• void write() const cout ltlt get_x()
  get_y() ltlt \n

Int main() //d1.BC() invoked DC
d1 //1 written to standard output
d1.write() //
38
4.5 CONSTRUCTORS AND DESTRUCTORS UNDER INHERITANCE

• Base class constructors are often sufficient for
  the derived class.
• Sometimes, however, it makes sense for derived
  class to have its own constructors.
• A constructor specific to a derived class may
  invoke a base class constructor, if one exits.

39
EXAMPLE 4.5.2

• class Animal
• public
• Animal() species Animal
• Animal( const char s ) species s
• private
• string species
• class Primate public Animal
• public
• Primate() Animal( Primate )
• Primate( int n ) Animal( Primate )
  heart_cham n
• private
• int heart_cham
• private

40
EXAMPLE 4.5.2(Cont.)

• Animal slug //
  Animal()
• Animal tweety( canary ) // Animal(
  const char )
• Primate godzilla //
  Primate()
• Primate human( 4 ) //
  Primate( int )
• The two Primate constructors invoke a base class
• Animal constructor in their initialization
  section
• Primate() Animal( Primate )
• Primate( int n ) Animal( Primate )
• heart_cham n

41
4.5 CONSTRUCTORS AND DESTRUCTORS UNDER INHERITANCE

• In a deep inheritance hierarchy, creation of an
  object belonging to a derived class may have a
  domino effect with respect to constructor
  invocation.

42
EXAMPLE 4.5.3
class Human public Primate public
Human() Primate() Human( int c )
Primate( c )

• Class Animal
• public
• Animal() species Animal
• Animal( const char s ) species s
• private
• string species
• Class Primate public Animal
• public
• Primate() Animal( Primate )
• Primate( int n ) Animal( Primate )
• heart_cham n
• private
• int heart_cham

Human jill() // Human() Human fred( 4 )
// Human( int )
43
FIGURE 4.5.3

• Animal Animal ( ) body executes first
• Primate Primate ( ) body executes second
• Human Human ( ) body executes third

44
4.5 CONSTRUCTORS AND DESTRUCTORS UNDER INHERITANCE

• Derived Class Constructor Rules
• If a base class has constructors but no default
  constructor, then a derived class constructor
  must explicitly invoke some base class
  constructor.
• See Example 4.5.4

45
EXAMPLE 4.5.4
46
4.5 CONSTRUCTORS AND DESTRUCTORS UNDER INHERITANCE

• Suppose that a base class has a default
  constructor and that a derived class has
  constructors, none of which explicitly invoke any
  base class constructor.
• In this case, the base class default constructor
  is invoked automatically whenever a derived class
  object is created.

47
EXAMPLE 4.5.5
48
EXAMPLE 4.5.5(Cont.)

• If DC has constructors but BC has no
  constructors, then the appropriate DC constructor
  executes automatically whenever a DC object is
  created.
• If DC has no constructors but BC has
  constructors, then BC must have a default
  constructor so that BCs default constructor can
  execute automatically whenever a DC object is
  created.
• If DC has constructors and BC ahs a default
  constructor, then BCs default constructor
  executes automatically whenever a DC object is
  created unless the appropriate DC constructor
  explicitly invokes, in its initialization
  section,som other BC constructor.
• If DC and BC have constructors but BC has no
  default constructor, then each DC constructor
  must explicitly invoke, in its initialization
  section, a BC constructor, which then executes
  when a DC object is created.

49
4.5 CONSTRUCTORS AND DESTRUCTORS UNDER INHERITANCE

• It makes sense that the creation of a derived
  class object should cause some base class
  constructor, if any , to execute.
• A derived class constructor may depend upon
  actions from a base class constructor.
• A derived class object is a specialization of a
  base class object, which means that the body of a
  base class constructor, if the class has
  constructors, should execute first when a
  derived class object is created. The body of a
  more specialized constructor, which is the local
  derived class constructor, then can handle any
  special details.

50
EXAMPLE 4.5.6
51
4.5 CONSTRUCTORS AND DESTRUCTORS UNDER INHERITANCE

• Destructors Under Inheritance
• Constructor bodies in an inheritance hierarchy
  execute in a
• Base class to derived class
• order. Destructor bodies in an inheritance
  hierarchy execute in a
• Derived class to base class
• order. So the destructor bodies execute in the
  reverse order of the constructor bodies.

52
EXAMPLE 4.5.7
53
4.5 CONSTRUCTORS AND DESTRUCTORS UNDER INHERITANCE

• A destructor often frees storage allocated by a
  constructor.
• By firing in the reverse order of constructors,
  destructors ensure that the most recently
  allocated storage is the first storage to be
  freed.
• Unlike constructors, a destructor never explicity
  invokes another destructor. Since each class has
  at most one destructor, it is unambiguous which
  destructor, if any , should execute.

54
EXAMPLE 4.5.8
55
4.6 SAMPLE APPLICATIONA SEQUENCE HIERARCHY

• Problem
• Sample Output
• Solution
• C Implementation
• Discussion
• Program Development

56
4.7 MULTIPLE INHERITANCE

• In single inheritance, a derived class has a
  single base class. In multiple inheritance, a
  derived class has multiple base classes.
• In technical jargon, a hierarchy with only single
  inheritance is a tree, whereas a hierarchy with
  multiple inheritance is a graph.

BC
Single inheritance
DC
BC1
BC2
Multiple inheritance
DC
57
4.7 MULTIPLE INHERITANCE(Cont.)

• In a single inheritance hierarchy, a derived
  class typically represents a specialization of
  its base class.
• Because classes are user-defined data types in
  C, such a derived class is a specialization or
  refinement of the more general data type that its
  base class represents.
• In a multiple inheritance hierarchy, a derived
  class typically represents a combination of its
  base class.

58
EXAMPLE 4.7.1
59
EXAMPLE 4.7.2
60
4.7 MULTIPLE INHERITANCE(Cont.)

• Inheritance and Access
• The rules of inheritance and access do not change
  from a single to a multiple inheritance
  hierarchy. A derived class inherits data members
  from all its base classes.
• Multiple inheritance increases opportunities for
  name conflicts. The conflict can occur between
  the derived class and one of the base classes or
  between the base classes themselves. It is up to
  the programmer to resolve the conflict.

61
EXAMPLE 4.7.3
62
4.7 MULTIPLE INHERITANCE(Cont.)

• Virtual Base Classes
• Multiple inheritance hierarchies can be complex,
  which may lead to the situation in which a
  derived class inherit multiple times from the
  same indirect base class.

63
EXAMPLE 4.7.4
BC
DC1
DC2
z
64
(No Transcript)
