Carbohydrates as Energy Sources

1
Carbohydrates as Energy Sources
2
Key Pathways in Carbohydrate Utilization

• Insulin-stimulated uptake
• Low circulating concentrations of insulin GLUT4
  is sequestered within cytosolic vesicles in
  myocytes and adipocytes
• Accumulation of glucose in blood triggers insulin
  release from pancreatic ß-cells
  Insulin-receptor signaling induces the
  redistribution of GLUT4 from intracellular
  storage sites to the plasma membrane once
  incorporated into the cell membrane, GLUT4
  facilitates the passive diffusion of circulating
  glucose down its concentration gradient

3
Glucose uptake in adipocytes
Ntambi 2000

• Insulin binds to the alpha subunit of the insulin
  receptor and activates the autophosphorylation
  (Tyr-P) of the adjacent beta subunit (a tyrosine
  kinase)
• An activated insulin receptor stimulates DNA and
  protein synthesis, and the translocation of GLUT4
  from the Golgi apparatus to the plasma membrane
• GLUT4 translocation facilitates cellular glucose
  uptake

4

• Once inside cells, glucose is rapidly
  phosphorylated by hexokinase to form
  Glucose-6-Phosphate (G6P)
• It is this form of glucose that serves as the
  initial substrate for glycolysis
• G6P cannot diffuse back out of cells
• Thus G6P serves to maintain the concentration
  gradient for glucose to passively enter cells.

5
Converting Sugars to an Energy Currency

• Key concepts
• Glycolysis
• TCA cycle
• Electron transport chain
• Oxidative phosphorylation

ATP
Sugar
6
Glycolysis

• G6P is trapped in cell cytosol
• Glycolysis occurs in cytosol

7

• ATP is consumed at RXN
• 1 and 3
• 6C molecule split into two
• 3C molecules
• 3C molecule drives
• production of NADH
• and ATP
• No net ATP until PEP is
• converted to pyruvate
• Under aerobic conditions,
• NADH will be further
• utilized in mitochondria to
• power the electron trans-
• port chain (generate ATP)

8
Glycolysis Summary

• C6H12O6 2 NAD 2 ADP 2 P -----gt 2 pyruvic
  acid, CH3(CO)COOH 2 ATP 2 NADH 2 H

Steps 1 and 3 - 2ATP Steps 6 and 9 4
ATP Net "visible" ATP produced 2
9
With insufficient oxygen, or in cells lacking
mitochondria (RBC), pyruvate will be reduced at
the expense of NADH, to lactate by lactate
dehydrogenase.
10
TCA (Citric Acid) Cycle

• Now, we are shifting from the cytosol, to the
  mitochondria
• Using C-containing molecules that originated with
  dietary carbohydrate and metabolized to
  tri-carboxylic acids , we are generating ATP and
  reducing power that will flow into the electron
  transport chain
• anything containing C and H that can be reduced
  to CO2 and H2O contains energy..oxygen serves
  as the terminal e- acceptor in the electron
  transport chain

11
(No Transcript)
12
(No Transcript)
13
TCA Cycle Key Features

• The citric acid cycle begins with Acetyl-CoA
  (ACoA) transferring its two-carbon acetyl group
  to the four-carbon acceptor compound
  (oxaloacetate) to form a six-carbon compound
  (citrate)
• The citrate then goes through a series of
  chemical transformations, losing first one, then
  a second carboxyl group as CO2. The carbons lost
  as CO2 originate from what was oxaloacetate, not
  directly from acetyl-CoA. The carbons donated by
  acetyl-CoA become part of the oxaloacetate carbon
  backbone after the first turn of the citric acid
  cycle. Loss of the ACoA-donated carbons as CO2
  requires several turns of the citric acid cycle.
  However, because of the role of the citric acid
  cycle in anabolism, they may not be lost since
  many TCA cycle intermediates are also used as
  precursors for the biosynthesis of other
  molecules.
• Most of the energy made available by the
  oxidative steps of the cycle is transferred as
  energy-rich electrons to NAD, forming NADH. For
  each acetyl group that enters the citric acid
  cycle, three molecules of NADH are produced

14
Key Features, TCA Cycle

• Electrons are also transferred to the electron
  acceptor Q, forming QH2.
• At the end of each cycle, the four-carbon
  oxaloacetate has been regenerated, and the cycle
  continues
• Mitochondria in animals including humans possess
  two succinyl-CoA synthetases, one that produces
  GTP from GDP, and another that produces ATP from
  ADP
• Products of the first turn of the cycle are one
  GTP (or ATP), three NADH, one QH2, two CO2
• Because two ACoA molecules are produced from each
  glucose molecule, two cycles are required per
  glucose molecule. Therefore, at the end of both
  cycles, the products are two GTP (or ATP), six
  NADH, two QH2, and four CO2

15
The Respiratory Chain

• We have generated reducing power per turn
• (1) FADH2
• (3) NADH
• (1) QH2
• But the energy currency we are after is ATP
• The respiratory (e-) transport chain allows us to
  finish extracting energy from what was our
  dietary carbs by oxidation of the reducing power,
  coupled to phosphorylation of ADP
• Oxidative Phosphorylation

ATP
16
What are the e- transporters?
17
ATP Yield

• Oxidation of NADH to NAD pumps 3 protons which
  charges the electrochemical gradient with enough
  potential to generate 3 ATP
• Oxidation of FADH2 to FAD pumps 2 protons which
  charges the electrochemical gradient with enough
  potential to generate 2 ATP.

18
Respiratory Chain

• Protons are translocated across the membrane,
  from the matrix to the intermembrane space
• Electrons are transported along the membrane,
  through a series of protein carriers
• Oxygen is the terminal electron acceptor,
  combining with e- and H ions to produce water
• As NADH and FADH2deliver more H and electrons
  into the ETC, the proton gradient increases, with
  H building up outside the inner mitochondrial
  membrane, and OH- inside the membrane
• It is the energy derived from this proton
  (electrochemical) gradient that is used to drive
  phosphorylation of ADP (synthesis of ATP)

19
NADH and FADH2 carry protons (H) and e- to the
electron transport chain located in the membrane.
The energy from the transfer of electrons along
the chain transports protons across the membrane
and creates an electrochemical gradient. As the
accumulating protons follow the electrochemical
gradient back across the membrane through an ATP
synthase complex, the energy of the gradient is
transferred by the ATP synthase system from the
gradient to ADP in the synthesis of ATP. At the
end of the electron transport chain, two protons,
two electrons, and half of an oxygen molecule
combine to form water. Since oxygen is the final
electron acceptor, the process is called aerobic
respiration.
20
From Cell Nutrition, 3rd ed.
21
Excess Energy from carbohydrates can be stored as
fat

• De novo lipogenesis
• Acetyl CoA is the key

22
Lipogenesis Key Points

• Occurs in the cytosol
• Catalyzed by acetyl CoA carboxylase
• Requires biotin for carboxylation rxn
• Product is malonyl CoA

This is the rate limiting step.
Full activation requires excess energy as is
reflected in (1) adequate cellular ATP and low
AMP, (2) an accumulation of citrate in the TCA
cycle that ultimately exits the mitochondria via
an elaborate shuttle to return to the cytosol
23
Lipogenesis Key Points

• Sequential additions of 2C units (acetyl CoA)
  results in the formation of palmitate (C160)
• Catalyzed by Fatty Acid Synthase
• An enzyme complex with 7 catalytic activities

24
Lipogenesis Key Points

• Palmitate is esterified on a glycerol backbone to
  form triacyl glycerol

25
Lipogenesis Key Points

• Avians and humans Liver (hepatocyte) is primary
  site of de novo lipogenesis
• Pig about 100 in the adipocyte itself
• Beef adipocyte
• Rodents adipocyte and hepatocyte, about 5050
• Dog/Cat Mixed, but probably favors hepatocyte
