Defining and structuring software problems through Problem Frames

1
Defining and structuringsoftware
problemsthrough Problem Frames

• Charles Wallace Xinli Wang Virginia Bluth
• Michigan Technological University
• wallace_at_mtu.edu

2
Software problems(Jackson, 1995)
Problem context interaction between software
machine and its environment Requirements
stated purely in terms of environmental
phenomena Specification restricted to
machine-environment phenomena
phenomena that affect machine state
machine phenomena
specification phenomena
environmental phenomena
phenomena visible outside machine (requirement
phenomena)
3
Locating and bounding the problem(Jackson, 1995,
2000)

• Problem stated in terms of concrete, observable
  phenomena
• avoids overgeneralization of context
• (getting away from the realities of the
  customers world)
• Problem stated in terms of machine-environment
  interaction
• avoids overgeneralization of requirements
• (getting away from the realities of the
  customers problem)

4
What are phenomena?

• events indivisible, instantaneous occurrences
• arrival of elevator car at a floor
• elevator user pressing floor button
• states entity properties, or relations between
  entities
• not instantaneous have some duration
• elevator door status closed, closing, open,
  opening
• floor at which elevator car is currently parked
• weight of car contents

5
What is the machine?

• The software product under development
• (which possibly interacts with other software
  machines)
• Be careful about what you mean by machine
• e.g. In workpieces problems (e.g. word processor,
  spreadsheet), the workpieces are documents,
  residing in computer memory
• still, best to think of them as outside the
  machine

6
Example Elevator controller problem
environmental phenomena outside machine domain

• physical position of elevator car
• current speed and direction of cable
• illumination of floor buttons on panel

machine phenomena invisible to environment

• updating car_direction variable
• decrementing time_to_door_close counter
• adding floor request to pending_requests

shared phenomena

• open the door command (from controller)
• door is blocked signal (to controller)

7
Problem structuring(Jackson, 1995, 2000)
Attack the complexity of a software problem by
creating a set of projections of the
problem Projections (subproblems) may overlap
(i.e. share phenomena) Each projection belongs
to a well-known class of similar problems a
problem frame Strong similarities to notion of
design patterns As we deal with instances of
each problem frame, we learn heuristics (rules of
thumb) for documenting and learning about such
problems
8
Problem frame document

• components single context diagram
• multiple problem diagrams
• diagram elements
• domains (nodes)
• requirements (nodes)
• interfaces (shared phenomena) (edges)
• requirement references (edges)

9
Domains

• represent sets of individuals
• (distinguishable things of interest in problem)
• domain may possess certain attributes
• may be related to other domains via shared
  phenomena
• Machine domain exactly one per problem frame
• no attributes except those shared with
  environment
• Realized (designed) domain
• software developers may help in its design
• typically, electronic representations of data

10
Connection domain

• exists purely as intermediary between multiple
  domains
• e.g. communication channel
• can always be ignored...
• pro higher abstraction level con abstraction
  may leak
• reasons to include connection domain
• communication failure
• communication delay
• connection domain referred to in requirements
• conversion of phenomena via connection domain

11
Shared phenomenon (Interface)
e.g. admission machine detects coin inserted by
customer
(domain)
(interface)
(domain)

• Note the abstraction here
• mechanism for accepting and detecting coin
  ignored
• OK if coin detection is a given
• not OK if we're designing the coin detector

admission machine
customer
insert coin
12
Beyond binary interfaces
e.g. supermarket purchase
customer
clerk
purchase
product
13
Note this can be broken into multiple binary
interfaces... with a lowering of abstraction level
pay
customer
clerk
take
give
product
Now, we have to stipulate that give precedes
take if pay fails, then take shall also
fail,
14
Requirement

• Form If (antecedent), then (consequent)
• Antecedent and consequent refer to shared
  phenomena
• References in the antecedent descriptive
  (indicative) mood
• References in the consequent prescriptive
  (optative) mood
• No indicative or optative references to machine
  domain
• requirements don't refer to machine
• Antecedent may be empty, but consequent must not

15
Requirement example
If the customer inserts a coin, the gate shall
become unlocked.
insert (event)
lock, unlock (events)
admission machine
customer
gate
insert (event)
lock-status (state)
admission criteria
(Note arrow for optative reference)
This requirement refers to the (unshared) lock
status of gate, rather than the (shared)
machine-gate events lock and unlock
16
Patient monitoring dosage problemAdapted from
(Jackson, 2000)
A patient monitoring program is required for the
ICU in a hospital. Each patient is monitored by
an analog device which measures factors such as
pulse, temperature, and blood pressure. The
program reads these factors on a periodic basis
(specified for each patient) and stores them in a
database. For each patient, safe ranges for
each factor are also specified by medical staff.
If a factor falls outside a patient's safe range,
or if an analog device fails, the nurses station
is notified.
17
Patient monitoring dosage problem (Continued)
A patient may be connected to an intravenous
pump that supplies medication. There are three
ways in which medication may be administered via
the pump. First, medical staff may stipulate
that a patient is to receive regular periodic
dosages through the pump. Second, staff
may request a single dosage to be applied
immediately. Finally, if authorized earlier by
medical staff, a patient may request an immediate
dosage by pressing a button on the pump. In all
cases, the total daily dosage must not exceed the
limit entered earlier by medical staff. If a
pump fails, the nurses station is notified.
18
Domains
monitoring program (machine) patients analog
devices medical staff nurses' station intravenous
pump
19
Factors (vital signs) make them domains?
pulse, temperature, etc. not really concrete
things probably best to treat them as patient
attributes
20
Periods, ranges dosages (PRD) make them
domains?
con they're data structures, internal to
solution pro any sensible solution will have
such data structures awkward to talk about
problem without reference to these terms
21
Since the pump and the analog devices both
connect patients to the machine, should they be
merged into a single domain?
The pump and the analog devices have little
state information or shared phenomena in
common best to treat them as separate domains
22
How about removing medical staff and PRD?
OK only if each patient gets the same
(unchanging) treatment (unrealistic)
23
How about hiding medical staff behind nurses
station?
If so, then nurses station becomes connection
domain, channeling staff input to machine
24
How about removing medical staff and keeping PRD?
periods ranges domain allows for different
patient treatments but treatments cannot
change (unrealistic)
25
How about removing patients?

• No way --- vital component of problem,
• even though theres no direct link to machine
• What can we learn from patients? Some examples
• range of expected vital sign values ?
• range of expected analog device readings
• frequency of patient movement in/out of the ICU
  ?
• frequency of additions/deletions to PRD
  database
• patients need for pain medication ?
• usability issues surrounding dosage requests

26
Factors database designed domain?
if no ? database is an off the shelf
component, not our right/responsibility to
design it
if yes ? is it to be accessed by others?
if yes ? we need to add others as a domain if
no ? database is internal to solution does it
really belong in requirements?
27
Patient monitoring dosage problemContext
diagram
periods, ranges dosages (designed)
factors database
nurses' station
a periods, ranges, dosages b factor
report c alert d pump control / request
dose e patient readings f enter
period/range/dose g dose button / administer
dose h vital signs
b
a
c
monitor machine
d
IV pump
f
e
g
medical staff
ICU patients
analog devices
h
28
Problem frames

• Simple, generic archetypal subproblems
• Information display problem
• Required behavior problem
• Commanded behavior problem
• Workpieces problem
• Transformation problem

29
Information display problem frame(Jackson, 2000)
real world (RW)
a
a
information system (IS)
report-world
b
display (D)
c
a WorldState (RW) b Reports (IS) c
DisplayState (D)
When world state is so-and-so... machine detects
state info and sends report... causing
appropriate change in display state.
30
Device failure alertInformation display problem
If an analog device or pump fails, the nurses'
station shall be notified. (This is really two
information display problems in one Analog
device failure and pump failure) Real world
Analog devices, IV pump Information requester
Nurses station
31
Patient alertInformation display problem
If a patient's vital signs are outside safe
ranges, the nurses' station shall be
notified. Real world ICU patients Information
requester Nurses station Connection domain
Analog devices Periods, Ranges Dosages
database must be consulted
32
Information display

• When world state is so-and-so
• real world may be static or dynamic
• if world is static and small, problem is trivial
• if world is dynamic, how frequently does machine
  sample world?
• e.g. Device and patient alert problems
• both involve dynamic real-world phenomena
• Device alert sampling frequency fixed
• Patient alert sampling frequency determined by
  medical staff
• Device alert sampling must be frequent enough
• not to hide patient alerts

33
Information display

• machine detects state info...
• often, there is a machine-real world connection
  domain
• real world interpreted by sensor or data-entry
  person

real world (RW)
a SensorData (S) b WorldData (RW)
b
sensor (S)
a
information system (IS)
Usual concerns apply with regard to connection
domains failure, translation, ...
34
Information display

• Device alert problem
• What is the failure model of the devices?
• Does device signal its impending failure?
  (unlikely)
• Fail-stop device simply stops sending data
• In this case, we may sense failure via device
  heartbeat
• Byzantine failed device continues to send
  (bogus) data
• This complicates failure detection

35
Information display

• Machine must model the real world
• e.g. patient modeled as a triple (temp, blood
  pressure, pulse rate)
• each factor is an electronic approximation of the
  real vital signs
• gap between model and real world how accurate
  must model be?
• What is the frequency of model state checking?
• What is the granularity of data?

36
Information display
requirement If P(rw), then display
P(rw). solution create model m If Q(m(rw)),
then display P(rw). Do we really need to
require that Q(m(rw)) ? P(rw) ? A weaker
condition may be sufficient e.g. Q(m(rw)) ?
P(rw) P(rw) ? Q(m(rw)) (no false
positives) (no false negatives) In
device/patient alert problems, false negatives
unacceptable False positives may be
tolerated risks of wasting medical staff time,
annoying patients
37
Information display

• machine sends report, causing appropriate
  change in display state.
• e.g. Device/patient alert problems
• need to know precisely which device has failed
• also need to know which patient is connected to
  the device
• how are patients identified?
• Display design important nonfunctional
  (usability) issues
• e.g. Alert problems clarity of presentation is
  essential

38
Variant Commanded display
real world (RW)
a
a
information system (IS)
report-world
display (D)
c
d
b
c
enquiry operator (EO)
a WorldState (RW) b Queries (EO) c Reports
(IS) d DisplayState (D)
When world state is so-and-so... machine detects
state info... if operator then makes a query...
machine sends a report... causing appropriate
change in display state.
39
Information display issues(summary)
world state entities, attributes to be
displayed causal relations between real-world
entities (laws of nature) static/dynamic
world, rate of sampling detection connection
domain? Delays, distortions? model level of
accuracy frequency of model updates, data
granularity false positives/negatives
acceptable? query (commanded display
only) language of legal queries syntax (form),
semantics (meaning) report what information is
needed display layout, presentation of
information
40
Required behavior problem frame
behavior rules
a
b
controller machine (CM)
controlled domain (CD)
a Commands (CM), DomainState (CD) b DomainState
(CD)
Machine issues commands... (possibly after
considering current domain state
information)... that keep domain in an acceptable
state.
41
Regular dosageRequired behavior problem
If regular dosage is prescribed for a
patient, the given dose will be applied regularly
at the given interval, unless the total daily
dosage exceeds the limit. Controlled domain IV
Pump Periods, Ranges Dosages must be
consulted for dosage amount, interval
42
Required behavior

• Information display problem could be seen as
  required behavior,
• with the display being the controlled domain,
  but
• in information display problems, controlling
  the display is
• typically not difficult
• the real difficulty is in capturing the real
  world accurately.

43
Required behavior
Machine issues commands What are the commands
at the machines disposal? e.g. for Regular
Dosage problem, say the commands are pump on,
pump off This implies that dosages will be
determined by precise timing on the part of the
machine Note the distinction between the
commands (at the CM-CD interface) and the domain
state (mentioned in the requirement) The
requirement does not mention anything about
machine commands
44
Required behavior

• possibly after considering current domain
  state information...
• How much feedback is needed from controlled
  domain?
• If effects of commands are totally predictable,
• and only our machine affects domain, then machine
  needs no state info
• Otherwise, need to know
• range of variation of commands effects
• how to detect failed commands
• how to undo/redo failed commands
• effects that other domains may have on the
  controlled domain

45
Required behavior

• that keep domain in an acceptable state.
• What are the direct effects of the machine
  commands on the
• controlled domain? What are the indirect
  effects?
• e.g. Can we assume that keeping pump on for x
  seconds
• results in some amount f(x) of medication being
  administered?
• Controlled domain may include uncontrollable
  states
• (e.g. mobile unit that goes out of communication
  range)
• Can controller take domain to a state thats no
  longer controllable?
• If so, need to disable certain sequences of
  commands

46
Required behavior issues(summary)
machine commands format, effects on controlled
domain range of variation of commands
effects detectability, undoability, redoability
of failed commands effects on the controlled
domain from outside the controller domain
state what feedback is needed? what is
controllable state space? effects of machine
commands on doman direct, indirect (via laws
of nature)
47
Commanded behavior problem frame
operator (O)
a
a
controller machine (CM)
behavior rules
b
controlled domain (CD)
c
a OperatorCommands (O) b MachineCommands
(CM) c DomainState (CD)
Operator issues commands... machine rejects
non-sensible ones... machine ignores commands
unviable in current domain state... for sensible,
viable commands, machine responds with its
own commands that keep the domain in an
acceptable state.
48
Patient-administered dosageCommanded behavior
problem
If authorized earlier by medical staff, patients
may request immediate dosages. Operator ICU
Patients Controlled domain IV Pump Periods,
Ranges Dosages database must be consulted
49
Staff-administered dosageCommanded behavior
problem
Staff may request a single dosage to be
applied to a patient immediately. Operator
Medical staff Controlled domain IV
pump Periods, Ranges Dosages database must be
consulted
50
Commanded behavior
Operator issues commands... Operator commands
and machine commands may be quite different e.g.
single command from patient/staff translated
into a pump on/ pump off sequence, with an
appropriate time interval in between Design of
operator commands is important e.g.
staff-administered dosage specify dosage
level? need to balance flexibility/expressivity
vs. ease/speed of use Note patient-administered
dosage requests come via the pump design of the
patient command interface is out of our hands
51
Commanded behavior

• machine rejects non-sensible commands...
• sensible commands have some reasonable meaning
  given the
• context of previous commands
• non-sensible commands may be disabled
• (e.g. grey out currently non-sensible menu
  items)
• e.g. Staff dosage request for a patient is not
  sensible without
• an earlier establishment of a daily dosage limit

52
Commanded behavior
machine ignores commands unviable in current
domain state... viable commands have some
reasonable meaning given the current state of
the controlled domain disabling unviable
commands more difficult requires sampling of
controlled domain e.g. Patient dosage requests
are always sensible, but not viable if
self-dosage not authorized, or dose would put
the daily dosage over the limit
53
Commanded behavior issues(summary)
Issues of required behavior, plus operator
commands syntax, mapping to machine
commands sensibility conditions on
commands viability conditions of CD for commands
54
Workpieces problem frame(Jackson, 2000)
user (U)
a
a
editor tool (ET)
edit workpieces
b
c
workpieces (WP)
a UserCommands (U) b WorkpieceOperations
(ET) c WorkpieceState (WP)
55
Period, Range Dosage data entryWorkpieces
problem
Sampling periods, safe ranges, and dosages for
each patient shall be entered by medical
staff. User Medical staff Workpieces Periods,
Ranges Dosages
56
Workpieces

• Similar to Commanded behavior frame ---
• but controlled domain here is totally
  computer-internal
• Workpieces intangible software objects (e.g.
  documents, files)
• usually easier to control than domains outside
  the computer
• very often a designed domain our
  right/responsibility to co-design it
• Challenges in workpieces problems
• identifying syntactically correct, sensible user
  commands
• viability conditions
• mapping between user and machine commands

57
Workpieces issues(summary)
Issues of commanded behavior, but the following
have less (or no) importance range of variation
of machine command effects issues regarding
failed commands controllable state space
58
Transformation problem frame(Jackson, 2000)
source (S)
a
c
mapping
transformer machine (TM)
b
d
destination (D)
a InputStream (S) b OutputStream (TM) c
InputData (S) d OutputData(D)
From a collection of input data, Source produces
input stream... Machine responds by producing an
output stream, creating output data at
destination that respects the input-output
mapping.
59
Patient factor storageTransformation problem
Patients' vital signs shall be stored in a
database. Source Analog devices Destination
Factors database Note Though it deals with
electronic records, this is not a workpieces
problem, since there is no autonomous user
performing arbitrary operations. Its a simple
translation from one electronic format to another.
60
Transformation
Source produces input stream... Machine responds
by producing an output stream input rate is
it truly streaming? Regular or
intermittent? output rate Is there an upper
limit? Can input rate ever exceed maximum output
rate? If so, can input data be dropped? If not,
what is the max expected amount of buffering
needed?
61
Transformation
creating output data at destination that
respects the input-output mapping. Range of
possible input data values Range of possible
output data values Mapping one-to-one,
one-to-many, many-to-one? e.g. Does factors
database store summary reports (many-to-one), or
does it store each individual reading
(one-to-one)?
62
Transformation issues(summary)
Input/output streams Input/output
rates Buffering vs. dropping Input/output data
ranges Mapping input data to output
data one-to-one, many-to-one, one-to-many
63
References

• M.A. Jackson. Software Requirements and
  Specifications. Addison Wesley, 1995.
• M.A. Jackson. Problem Frames. Addison Wesley,
  2000.
• B.L. Kovitz. Practical Software Requirements.
  Manning, 1999.

64
Patient Monitoring Dosage Links

• Patient monitoring products
• http//www.medical.philips.com/main/products/patie
  nt_monitoring/
• http//www.datascope.com/pm/patientmonitoring.html

• Medication delivery products
• http//www.baxter.com/products/medication_manageme
  nt/infusion_pumps/large_volume_infusion_pumps/inde
  x.html
• A first-person account of patient-controlled pain
  medication (very interesting)
• http//www.asktog.com/columns/030ThePump.html
