CSE 160 Lecture 2

1
CSE 160 Lecture 2
2
Todays Topics

• Flynns Taxonomy
• Bit-Serial, Vector, Pipelined Processors
• Interconnection Networks
• Topologies
• Routing
• Embedding
• Network Bisection

3
Taxonomy

• Flynn (1966) Classified machines by data and
  control streams

4
SIMD

• SIMD
• All processors execute the same program in
  lockstep
• Data that each processor sees is different
• Single control processor
• Individual processors can be turned on/off at
  each cycle
• Illiac IV, CM-2, MasPar are some examples
• Silicon Graphics Reality Graphics engine

5
MIMD

• All processors execute their own set of
  instructions
• Processors operate on separate datastreams
• No centralized clock implied
• SP-2, T3E, Clusters, Crays, etc.

6
SPMD/MPMD

• Single/Multiple Program Multiple Data
• SPMD processors run the same program but
  processors are necessarily run in lock step.
• Very popular and scalable programming style
• MPMD is similar except that different processors
  run different programs
• PVM distribution has some simple examples

7
Processor Types

• Four types
• Bit serial
• Vector
• Cache-based, pipelined
• Custom (eg. Tera MTA or KSR-1)

8
Bit Serial

• Only seen in SIMD machines like CM-2 or MasPar
• Each clock cycle, one bit of the data is
  loaded/written
• Simplifies memory system and memory trace count
• Popular for very dense (64K) processor arrays

9
Cache-based, Pipelined

• Garden Variety Microprocessor
• Sparc, Intel x86, MC68xxx, MIPs,
• Register-based ALUs and FPUs
• Registers are of scalar type
• Pipelined execution to improve performance of
  individual chips
• Splits up components of basic operation like
  addition into stages
• The more stages, the faster the speedup, but more
  problems with branching and data/control hazards
• Per-processor caches make it challenging to build
  SMPs (coherency issues)
• Now dominates the high-end market

10
Vector Processors

• Very specialized (eg. ) machines
• Registers are true vectors with power of 2
  lengths
• Designed to efficiently perform matrix-style
  operations
• Ax b ( b(I) ? A(I,J)x(J))
• Vector registers v1, v2, v3
• V1 A(I,), V2 b()
• MULV V3(I), V1, V2
• Chaining to efficiently handle larger vectors
  than size of vector registers
• Cray, Hitachi, SGI (now Cray SV-1) are examples

11
Some Custom Processors

• Denelcor HEP/Tera MTA
• Multiple register sets
• Stack Pointer, Instruction Pointer, Frame
  Pointer, etc.
• Facilitates hardware threads
• Switch each clock cycle to different register set
• Why? Stalls to memory subsystem in one thread can
  be hidden by concurrency
• KSR-1
• Cache-only memory processor
• Basically 2 generations behind standard micros

12
Going Parallel

• Late 70s, even vector monsters started to to
  go parallel
• For //-processing to work, individual processors
  must synchronize
• SIMD Synchronize every clock cycle
• MIMD Explicit sychronization
• Message passing
• Semaphores, monitors, fetch-and-increment
• Focus on interconnection networks for rest of
  lecture

13
Characterizing Networks

• Bandwidth
• Device/switch latency
• Switching types
• Circuit switched (eg. Telephone)
• Packet switched (eg. Internet)
• Store and forward
• Virtual Cut Through
• Wormhole routed
• Topology
• Number of connections
• Diameter (how many hops through switches)

14
Latency

• Latency is the amount of time taken for a command
  to start before any effect is seen
• Push on gas pedal before car goes forward
• Time you enter a line, before cashier starts on
  your job
• First bit leaves computer A, first bit arrives at
  computer B
• OR
• (Message latency) First bit leaves computer A,
  last bit arrives at computer B
• Startup latency is the amount of time to send a
  zero length message

15
Bandwidth

• Bits/second that can travel through a connection
• A really simple model for calculating the time to
  send a message of N bytes
• Time latency N/bandwidth
• Bisection is the minimum number of wires that
  must be cut to divide a network of machines into
  two equal halves.
• Bisection bandwidth is the total bandwidth
  through the bisection

16
Interconnection Topologies

• Completely connected
• Every node has a direct wire connection to every
  other node
• (N x (N-1))/2 Wires, Clearly impractical

17
Line/Ring
2
1
3
4
5
6
7

• Simple interconnection
• First topology where routing is an issue
• Needed when no direct connection exists between
  nodes
• Want go to node 4 from node 2 have to pass
  through node 3
• What happens if 2 want to communicate with 3 at
  the same time 1 want to communicate with 4?
• What is the bisection of a line/ring
• If the links are of bandwidth B, what is the
  bisection bandwidth
• What is the aggregate bandwidth of the network?

18
Mesh/Torus

• Generalization of line/ring to multiple
  dimensions
• More routes between nodes
• What is the bisection of this network?

2
1
3
4
5
6
7
2
1
3
4
5
6
7
2
1
3
4
5
6
7
19
Hop Count

• Networks are measured by diameter
• This is the minimum number of hops that message
  must traverse for the two nodes that furthest
  apart
• Line Diameter N-1
• 2D (NxM) Mesh Diameter NM-2

20
Tree-based Networks

• Nodes organized in a tree fashion (important for
  some global algorithms)

Diameter of this network? Bisection, Bisection
Bandwidth?
21
Hypercubes
1D
2D
4D
3D
22
Hypercubes 2

• Dimension N Hypercube is constructed by
  connecting the corners of two N-1 hypercubes
• Relatively low wire count to build large networks
• Multiple routes from any destination to any node.
• Exercise to the reader, what is the dimenision of
  a K-dimensional Hypercube

23
Labeling/Routing in a Hypercube

• Nodes a labeled in Gray Code
• Connected neighbors have their binary node number
  representation differ by one bit.
• 3D cube

000
001
101
100
010
011
110
111
24
The e-cube routing algorithm

• Source address S S0 S1 S2 Sn
• Destination address D D0 D1 D2 Dn
• Let R R0 R1 R2 Rn S ? R
• Number of one bits in R indicate distance between
  S and D
• Starting at S, go to neighbor where first Rj 1
  (if Sj 0 then goto neighbor where Sj1)
• Continue routing from this intermediate node
  where the next Rk (k gt j) is one, goto that
  neighbor.

25
E-cube routing example

• 8 Dimensional Hypercube (256 Nodes)
• S 134 0x86 10000110
• D 215 0xD7 11010111
• S ? D 0x51 01010001
• Distance 3
• S ? 11000110 (198)
• 11010110 (214)
• 11010111 (215)

26
Embedding

• A network is embeddable if nodes and links can be
  mapped to a target network
• A mesh is embeddable in a hypercube
• There is mapping of hypercube nodes and networks
  to a mesh
• The dilation of an embedding is how many links
  are needed in the embedding network to represent
  the embedded network
• Perfect embeddings have dilation 1
• Embedding a tree into a mesh has a dilation of 2
  (See example in book)

27
Modern Parallel Machines are Packet Switched

• Break message into smaller blocks and send these
  pieces through the network
• Network intermediate points (routers) can be
  store-and-forward or virtual cut through
• Store and forward requires buffering at each
  switch if an incoming packet has packets ahead of
  it on an outgoing port (congestion)
• Virtual cut-through eliminates the always
  buffering for store and forward by cutting
  through the switch when the output port is free

28
Wormhole Routing

• Wormhole routing is a variation of virtual cut
  through
• Small headers (flow control digits Flits) pass
  through the network.
• When a flit is allowed to cut through a switch,
  the original sender is guaranteed a clear path
  through that switch.
• A tail flit closes the connection
• Wormhole was defined by Seitz and is used in
  Myrinet, a very popular cluster interconnect.

29
Latency of Circuit Switched and Virtual Cut
Through

• Circuit Switch Latency
• (Lc/B) l (L/B)
• Lc length of control packet
• B bandwidth
• l number of links
• L Length of Packet
• Virtual Cut-through latency
• (Lh/B) l (L/B)
• Lh length of header packet

30
Store-Forward and Wormhole routing Latency

• Wormhole Routing Latency
• (Lf/B) l (L/B)
• Lf Length of flit
• Store-Forward Latency
• (L/B) l
• Store and forward latency can be much worse for
  many hops.
• Virtual Cut Through, Wormhole, and Circuit Switch
  reach (L/B) as message length increases

31
Deadlock/Livelock

• Livelock/Deadlock is a potential problem in any
  network design.
• Livelock occurs in adaptive routing algorithms
  when a packet never finds destination
• Deadlock occurs when packets cannot be forwarded
  because waiting for other packets to move out of
  the way. Blocking packet is waiting for blocked
  packet to move

32
Next Time

• All about clusters
• Introduction to PVM (and MPI)
