SPRINT PCS

1
SPRINT PCS

• E911 PHASE II

2
SPRINT PCS E9-1-1 Phase II

• Handset-Based Location Technology
• Assisted GPS Handsets
• Two handset models with Assisted GPS chips (GPS
  AFLT) were available October 1, 2001
• Currently, all new handsets contain AGPS chips
• Additional Network Equipment Required
• Mobile Positioning Center required to process
  location measurements and pass to PSAP ALI
• Positioning Determining Equipment needed to take
  location measurements from handsets network

3
SPRINT PCS E9-1-1 Phase II

• PSAP/LEC Requirements - Phase II
• Sprint PCS supports NCAS Wireline Compatibility
  Mode
• 10 digit ESRK sent to PSAP
• Callback latitude/longitude comes with ALI
  bid
• LEC or PSAP ALI database must support pull
  interface (E2 or Enhanced PAM)
• Re-bid capability for location updates during
  course of call (both CPE ALI)
• PSAP CPE to display latitude longitude
• recommend also display uncertainty factor

4
Sprint PCS Network
Intrado
P DE
Sprint PCS IP Network
National ALI Database
LM
W911
CRDB
Frame Relay/ IP
MPC Platform
Sprint PCS SS7 Network
PSAP ALI
MSC
Dial
PSTN
911
PSAP
5
Sprint PCSs Location Technology Solution
Intersystem Messaging
P DE
LM
W911

ESPOSREQ
Location Cache
6. Wireless Network
GPOSREQ
esposreq
MPC
Precision Location Obtained
ORREQ
WLI
gposreq
CRDB
WLI
orreq
6
LM
3-12 Satellites
24 Satellites
GPOSREQ
gposreq
PDE
Determines pseudo-ranges of 3-12 Satellites
DataBurst
DataBurst
Internal Calculations
Serving MSC
Reference GPS (WARN)
SMDPP
IP
smdpp
IP
