Garbage collection for data structure organisation

1
Garbage collection for data structure organisation

• by George Kurian

2
The basics

• Garbage Collector
• Responsible for managing memory in Java (and
  other languages).
• Its run to free memory.
• Traverses the objects in the heap determining if
  they are live or not.
• Tracing from the roots.
• Method stack.
• Global variables
• Others
• Once every linked object is scanned and marked,
  we know everything else is garbage.
• Live objects and dead objects
• Live objects are those currently still in use by
  the running program.
• References contained somewhere.
• Dead objects have no references to them such
  objects can be garbage collected and their space
  recovered.

Live objects
External References
Dead objects
3
The problem

• Complex data structures
• Highly connected internally.
• Object references not always a good indication of
  the necessity of an object.
• Object might be garbage but is still referenced
  internally.
• Garbage Collection only understands Object
  references.
• No concept of the internals of the data
  structure.
• Not possible for data structure to correctly
  identify needed objects without knowledge of
  every object that uses it.
• Garbage Collector has this knowledge.
• Due to us continually maintaining unused objects
  we create a memory leak.

4
The target problem

• Persistent Data Structures
• Persistent Array
• Stores multiple versions of the same data.
• Might have versions that no one uses.
• The items are garbage but we cannot safely remove
  them easily.
• Union Find
• Provides the simplest case for reasoning about
  the solution.

5
The solution must be..

• Transparent
• The complexity of addressing the cleanup should
  not be exposed to the user or the programmer of
  the data structure (or at least be minimised).
• Efficient
• We should not impose undue cost on the usual
  functioning of the GC. The advantages must be
  worth having.
• Minimal Change
• There should be the least change possible made to
  the garbage collector.
• Ensures better portability and generalisability.
• Safe
• We should not affect the semantics of existing
  objects.

6
Failed solutions

• The various approaches affected the balances.
• Branch adjusted list
• Data structure intensive solution.
• Relies on run time reorganisation.
• Uses standard GC to clean up objects.
• Fat Nodes and Finalizers
• Uses already available GC features.
• Data structure representation vastly different
  from usual.
• Table of weak references
• Support from GC and Data Structure
• Mutator time entry addition, collection time
  entry verification.
• Data Structure controls cleanup.

7
Failed solutions (2)

• Fat Nodes and Finalizers
• No significant change to garbage collector
  required.
• - Exceedingly bulky data structure, even for
  simple purposes.
• - Low user transparency, must always deal with
  tokens.

• Branch adjusted list
• No change to the garbage collector required.
• Access of elements has the shortest possible
  path to the parent.
• - High penalty on addition and removal of data.
• - Low sharing Greater number of objects.
• - Low programmer transparency, has to deal with
  how exactly to translate structure.

0

T
R
S
a
d
n
1
S
b
T
R
S
8
The basics (2)

• Generational Copying Collector
• Heap divided into different regions.
• Maintains different generations of objects.
• Mature, Nursery.
• Collection is done on separate regions.
• Newly created objects die first.
• Nursery collection is always done
• Mature collection done when we need additional
  space.
• Conservative, assumes mature objects are always
  live.
• Copies live objects from one half to the other.
• Minimises the time taken in doing a GC .
• We dont check if every object in the heap is
  live every time.
• Write barrier.
• Objects in nursery that have a reference from
  Mature always need to be preserved.
• Remset
• Offers a way of storing Object References during
  the GC.

9
Generational Copying Collector
Allocation into nursery

• Normal GC

Nursery
Mature1
Mature0
Live objects copied into mature
Nursery
Mature1
Mature0
Dead objects left behind
10
Generational Copying Collector
Mature object
Allocation into nursery

• Full GC

Nursery
Mature1
Mature0
Live objects copied into new mature
Nursery
Mature1
Mature0
Dead objects left behind
Once GC is finished the space is available to be
allocated in again.
11
JikesRVM

• Provides a framework for implementing GC
  algorithms in Java.
• Extended current implementation of GenCopy to add
  complex data structure handling.

12
Solution components

• Data structure
• Identify needed elements within the structure.
• Reorganise the data structure as not to point to
  unneeded objects.
• Garbage Collector
• Inform the GC about which objects we need
  information about.
• The data structure objects.
• GC tells us which of these are live and calls
  appropriate methods on them.
• We need information about the fringes of the data
  structure.
• Clears up unneeded items.
• Items left behind after reorganisation as well as
  other dead objects.

13
Features of the Data Structure

• Interface for cleanup
• Specifies the actions the data structure must do
  with the information provided by the garbage
  collector.
• Cleanup treats every object independently of data
  structure.
• No way to determine which object belongs to which
  structure.
• Can generalise cleanup for anything that
  implements the interface.
• Reference count field
• Exists per item of the data structure.
• Maintains a count of how many versions require
  that specific object.
• Three stage cleanup
• Stage 1
• Needed nodes identified by looking if the index
  has been previously seen in the version or not.
• As we traverse the data structure, increment the
  count of every needed object.
• Stage 2
• Traverse the data structure again but if there
  are objects that are not marked as needed we
  change the parent of that object to the parent of
  the unneeded object and continue.
• Stage 3
• Reset the counts on the objects in the data
  structure to prepare it for the next time GC is
  run.

14
Identifying Special objects

• Allocating special objects
• Requires identification of object.
• Check every object
• Implements an interface.
• Very expensive.
• Advice file
• Specifies where the object is created in the
  program.
• Value passed along with allocation is used to
  allocate into special space.
• Annotations?
• Can be picked up by the runtime to handle the
  object in a special way.

15
Garbage Collector

• Modified the number of spaces.
• Added a special space to hold our data structure
  objects.
• Allows us to identify our special objects from
  every other object.
• Can call appropriate methods on special objects
  to clean the structure.
• Can find out if an object is a special object
  based on its physical location.
• Makes checking easier during tracing.
• Modified the allocator
• Allocates the objects into the special space.
• Reads the allocation details before we run the
  program.
• Modified the Trace
• We dont carry out a standard trace over our
  special objects without processing first.
• Two Stages
• Tracing continues as normal across the heap.
• If we are referring to a special object, we copy
  the object into the new half.
• Further tracing is not done, instead we hold it
  in our own remset for processing later.
• After tracing is over
• Process the remset, reshuffling the links between
  the objects
• Restore objects back to standard trace and finish
  the trace
• Modified the collection time

16
Union Find example

• Given we have interconnected nodes in our special
  space.
• We want to reroot the externally referenced
  nodes.
• During the trace we store away these external
  referenced objects into our own remset.
• Once the trace is finished we look through the
  remset, casting them to the interface type.
• We call the reroot methods on the nodes.
• We restore the nodes that we kept into the main
  tracing remset and we complete tracing over them.
• In the persistent data structure we removed
  unneeded versions.

17
Garbage Collector internals

• Space layout

Special0
Mature1
Mature0
Special1
Nursery
Special Space
Externally referenced
18
Constant problems

• Allocation during Garbage Collection.
• Space might not be available during the GC.
• Might trample on pre existing data.
• Compromises some transparency of data structures.
• Have to add fields to the objects themselves to
  help us.
• Trivial cost, we make the data structure pay for
  carrying out cleanup.
• Loading of unknown methods during GC causes
  allocation.
• Problem faced and not ideally resolved.
• Methods for cleanup must be preloaded.

19
Resolution

• We do a normal trace over all the objects in the
  special space.
• At the very end once we are clear of the Garbage
  Collector we process the remset.
• Avoids allocation problems as the allocator is
  pointing to the right space to allocate into.
• Differed garbage collection of data structure
  till the next GC.
• But normal garbage will still be collected.

20
Optimisations

• Optimisations to the data structure like minimal
  connectivity can be done during Garbage
  Collection.
• Additional cost in terms of algorithmic
  complexity and time we spend in a GC.
• Improves overall access times to elements in the
  data structure.
• The costs have to be weighed, not always possible
  on data structures
• It was possible in our list based structure.

21
Optimisation example

• Nodes not garbage, but connectivity could be
  improved.

From
To
ROOT
ROOT
1
1
1
2
1
2
3
3
Versions
Versions
22
Conclusions

• Complexity distributed over GC and data
  structure.
• Good transparency.
• The user has to know very little about how the
  garbage collector will collect the structure.
  Just needs to implement simple methods.
• Object comparison
• Rest are inherited
• Good efficiency.
• Initial results show time taken on standard GC is
  shorter.
• Results still underway.
• Reasonable changes.
• Implementation extends the use of existing models
  already in use.
• Keeps the implementation simple.

23
Generalisations

• Works for a specific case.
• Should work for any case that needs to identify
  external references.
• Requires assistance from both Garbage Collector
  and Data Structure.
• Cheapest way of cleaning up the data structure.
• Data structure abstract class deals list based
  structures only at present.
• To Do
• Cycles.
• Simpler way of allocating objects
• Annotations
• Other data structures that arent list based.
• Loading of the interface methods before usage.
• Requires change to the Class Loader

24
The End.

• Questions?
