Java Memory Management

1
Java Memory Management

• Charles-François THUEUX
• Sitraka Inc.
• cft_at_sitraka.com

2
Overview

• Review of Javas Memory Model
• Loitering Objects
• Effective Memory Management
• Design
• Implementation
• Documentation
• Conclusion and Further Reading

3
Memory Safety in Java

• A key aspect in the design of...
• the Java Language
• no pointer arithmetic
• the Java Virtual Machine (JVM)
• bytecode instruction set
• runtime checks (array bounds, ref casts)
• garbage collection

4
Memory Safety in Java

• Eliminated many memory-related problems
• Buffer overruns
• De-referencing stale pointers
• Memory leaks
• However Java programs can exhibit the macro-level
  symptoms of traditional memory leaks
• Process size seemingly grows without bounds

5
Javas Memory Model

• The intent of Garbage Collection is to remove
  objects that are no longer needed
• Undecidable in general
• Java uses an approximation
• remove objects that are no longer reachable
• The reachability test starts at the Heaps root
  set

6
The Root Set

• Set of foundational object references
• static reference fields within class definitions
• local reference variables within the method
  frames of each Java thread stack
• The contents of the Root Set change dynamically
  as your program runs
• As threads enter and exit methods, local
  reference variables enter and leave the Root Set

7
The Dynamic Root Set - 1
Consider a single thread of execution...

• 1 public
• 2 class MyApp
• 3
• 4 private static MyApp myApp null
• 5
• 6 public static
• 7 void
• 8 main( String args )
• 9
• 10 myApp new MyApp( )
• 11 myApp.method1( )
• 12 myApp.method2( )
• 13

Root Set MyApp myApp String args
8
The Dynamic Root Set - 2

• 14 private void
• 15 method1( )
• 16
• 17 BigObject bigObj new BigObject( )
• 18 ...
• 19
• 20
• 21 private void
• 22 method2( )
• 23
• 24 BiggerObject biggerObj new BiggerObject(
  )
• 25 ...
• 26
• 27

Root Set MyApp myApp String
args BigObject bigObj
9
The Dynamic Root Set - 3

• 1 public
• 2 class MyApp
• 3
• 4 private static MyApp myApp null
• 5
• 6 public static
• 7 void
• 8 main( String args )
• 9
• 10 myApp new MyApp( )
• 11 myApp.method1( )
• 12 myApp.method2( )
• 13

Root Set MyApp myApp String args
10
The Dynamic Root Set - 4

• 14 private void
• 15 method1( )
• 16
• 17 BigObject bigObj new BigObject( )
• 18 ...
• 19
• 20
• 21 private void
• 22 method2( )
• 23
• 24 BiggerObject biggerObj new BiggerObject(
  )
• 25 ...
• 26
• 27

Root Set MyApp myApp String
args BiggerObject biggerObj
11
The Dynamic Root Set - 5

• 1 public
• 2 class MyApp
• 3
• 4 private static MyApp myApp null
• 5
• 6 public static
• 7 void
• 8 main( String args )
• 9
• 10 myApp new MyApp( )
• 11 myApp.method1( )
• 12 myApp.method2( )
• 13

Root Set MyApp myApp
12
Reachable Objects

• Elements within the Root Set refer to objects
  within the JVMs Heap
• Reference variables within those objects refer to
  further objects within the Heap

Root Set
Object
Reference
13
Object States

• Define three progressive object states
• Allocated
• Exists within the JVMs heap
• Reachable
• A path exists (directly or indirectly) from a
  member of the root set, through a sequence of
  references, to that object.
• Live
• From the intent of the applications design, the
  program will use the object (meaning at least one
  of its fields will be accessed and/or one of its
  methods will be invoked) along some future path
  of execution.

14
The JVM Heap
allocated
reachable
live
15
C/C vs. Java

• Memory leak in C/C
• Object was allocated, but its not reachable
• malloc()/new, but forgot to free()/delete before
  destroying the memory pointer
• Memory leak in Java
• The object is reachable, but its not live
• a reference was set, but it hasnt been
  eliminated
• Object is reachable to the GC, but the source
  code to fix the leak may not be available to you

16
Memory Leaks in Java

• Impact is often more severe than C/C
• Rarely a single object, but a whole sub-graph
• A single lingering reference can have massive
  memory impact (and a significant performance
  impact)

Unintentional reference
17
Loitering Objects

• The term Memory Leak has too much historical
  baggage from C/C
• and it doesnt accurately describe the
  formulation of the problem as it pertains to Java
• A new term Loitering Object
• An object that remains within the Heap past its
  useful life

18
Reference Management

• The key to effective memory management in Java is
  effective reference management
• What undermines effective reference management ?
• Awareness of the issue
• Bad habits from C/C development
• Class Libraries and Application Frameworks
• Ill-defined reference management policies
• Encapsulate flawed reference assignments

19
Reference Management

• As a Java programmer, how can I effectively
  manage references within my software, and promote
  better reference management ?
• 1. Design
• 2. Implementation
• 3. Documentation

20
1. Design for Ref. Mgmt.

• For each Use Case within your application,
  explicitly characterize
• a. The lifecycle of each object
• b. The inter-relationships between various
  objects

21
Lifecycle Relationships

• Object B adopts As lifecycle and has no control
  over it

A
B
22
1a. Object Lifecycles

• For each object within the Use Case you are
  implementing, you need to explicitly define
• its point of creation
• the duration of its usefulness
• the point at which it should be eliminated from
  the runtime environment

23
1a. Object Lifecycles

• In Java, creating an object within the runtime
  environment is an explicit act, while its
  elimination is an implicit one
• Defining - within your design - the point when
  your object should be eliminated will help you
  validate the correctness of your Java
  implementation

24
1b. Inter-Object Relationships

• Objects establish relationships as they
  collaborate to accomplish their goals
• Examples
• Composition (a has-a relationship)
• Association (a uses-a relationship)
• Relationship lifecycles

25
1b. Inter-Object Relationships

• Think Symmetry
• If you define a method that establishes a
  relationship, ensure you define a method that
  revokes it.
• The Observer Pattern
• subject.addObserver( Observer )
• subject.removeObserver( Observer )

26
2. Implementation

• Loitering objects often arise from simple coding
  oversights or omissions
• forgot to null-ify a variable
• didnt remove an object from a list
• Use a Heap Analysis Tool to validate that your
  implementation adheres to your design

27
Reference Variable Scope

• Three forms of reference variables
• Class-based
• Reference variables within a class definition
  that have a static attribute associated with them
• Object-based
• Non static reference variables within a class
  definition
• Method-based
• Reference variables defined within the scope of a
  method

28
Reference Variable Scope

• Dont be concerned about assignments to
  method-based reference variables within methods
  of short execution time
• Be attentive of assignments to class-based and
  object-based reference variables, and
  method-based reference variables within methods
  of long execution times

29
Lingerer

• Reference used transiently by long-term object
• Reference always reset on next use
• e.g. associations with menu items
• e.g. global action or service

30
Lingerer Example

• Print action as singleton
• class Printer
• has data member Printable target
• calls target.doPrint()
• target inside printer not set to null on
  completion
• target is a lingering reference
• target cannot be GCed until next print

31
Lingerer Strategies

• Dont use a set of fields to maintain state
• enclose in object
• easier to maintain
• one reference to clean up
• Draw state diagram
• quiescent state no outgoing references
• Early exit methods or multi-stage process
• setup process cleanup

32
3. Documentation

• For methods that establish a relationship to
  another object, identify (in your javadoc
  description) the symmetric method that revokes
  the relationship

void addObserver( Observer ) Adds the Observer
argument to the subject's internal set of
observers. To remove the observer from this
internal set, invoke the removeObserver( Observer
) method.
33
Dealing with Flaws of Others

• After determining you have a loitering object,
  your investigation reveals that the object
  holding the reference to your loiterer is one
  which you do not have the source code to.
• How do you handle this ?

34
Using Their Code Properly ?

• Are you using their framework properly ?
• Understand their notion of object life cycles
• Think symmetry (again)
• An add() operation implies a remove()
• A register() implies an unregister()
• Does the symmetric operation (to the one that
  established the reference) remove it ?

35
Notify the Author

• Youve established that they are erroneously
  holding an object reference
• Create a simple test case
• Make it easy for the vendor to clearly identify
  the issue.
• Ask for
• Work arounds (if possible)
• Resolution to the fundamental problem

36
Eliminate Subgraph Elements

• If you can not fix the root cause, free up as
  much of the loitering subgraph as you can.

Unintentional reference
Unintentional reference
37
Conclusion

• The key to effective memory management in Java is
  effective reference management
• Incorporate reference management in your design
• Validate your Java implementation
• Document your reference management policies so
  others will know what to do

38
Further Reading

• Loitering Objects and Java Framework Design by
  Leonard Slipp, JavaReport, Volume 6, Number 1
  (January 2001)
• http//www.javareport.com/html/from_pages/article.
  asp?id249mon1yr2001
• How Do You Plug Java Memory Leaks ? by Ethan
  Henry and Ed Lycklama, Dr. Dobbs Journal, Java
  QA Column,Volume 25, Number 2 (February 2000)
• www.ddj.com/articles/2000/0002/0002l/0002l.htm
• Memory Leaks in Java Programs by Joel Nylund,
  JavaReport, Volume 4, Number 11 (November 1999).
• www.javareport.com/archive/9911/html/from_pages/ft
  p_feature.shtml
