XML Web Services: Toxics Release Inventory

1
XML Web ServicesToxics Release Inventory

• Brand Niemann
• XML Web Services Evangelist
• Data Standards Branch
• January 12, 2002

Disclaimer Any reference to or depiction of the
commercial product of any vendor is for
illustrative purposes only and does not
constitute an endorsement by EPA or the trainer.
2
Overview

• 1. Background
• 2. National Database to FileMaker XML
• 3. Web Pages and PDF to XML Documents
• 4. Data Tables to XML Data Islands
• 5. Some Future Steps
• 6. Questions and Answers

3
1. Background

• The Toxics Release Inventory (TRI), published by
  the U.S. EPA, is a valuable source of information
  regarding toxic chemicals that are being used,
  manufactured, treated, transported, or released
  into the environment.
• Two statutes, Section 313 of the Emergency
  Planning and Community Right-To-Know Act (EPCRA)
  and section 6607 of the Pollution Prevention Act
  (PPA), mandate that a publicly accessible toxic
  chemical database be developed and maintained by
  US EPA. This database, known as the Toxics
  Release Inventory (TRI), contains information
  concerning waste management activities and the
  release of toxic chemicals by facilities that
  manufacture, process, or otherwise use said
  materials. Using this information, citizens,
  businesses, and governments can work together to
  protect the quality of their land, air and water.

4
2. National Database to FileMaker XML

• 2.1 FileMaker 5.5
• http//www.filemaker.com
• 2.2 Steps
• Download National.exe (16.7 MB) and extract.
• http//epa.gov/tri/tri99/data/
• Import each of 4 files into FileMaker 5.5 (164
  MB).
• Make the 4 files sharable on the Web.
• Use the FileMaker URL syntax for XML output.
• 2.3 Interface Customization Possibilities.
• http//www.filemaker.com/products/fmu_home.html

5
2.1 FileMaker 5.5

• Subsidiary of Apple Computer with powerful
  desktop desktop database functionality that
  supports multiple platforms including the Web.
• The workgroup database of choice with
  organizations more than 65 of the 1.2 million
  units shipped in 2000-2001 were volume license
  sales - second to Microsoft Access.
• Third party developer resources
• Macromedia Dreamweaver
• Adobe GoLive
• Allaire ColdFusion

6
2.1 FileMaker 5.5 Database-to-XML
7
2.2 1999 Toxics Release Inventory (TRI) Data Files

• File Type 1 Facility, Chemical, Releases and
  Other Waste Management Summary Information. This
  file contains facility information (Part I on
  Form R and Form A) as well as most chemical
  information (Part II on Form R and Form A). Data
  elements are reported individually. The
  information is also disaggregated based on Waste
  Management code (i.e., "M" code), and aggregated
  up to On-site Releases, Off-site Releases, Other
  On-site Waste Management, and Transfers Off-site
  for Further Waste Management categories. (84,079
  records)
• File Type 2 Detailed Waste Management and Source
  Reduction Activities. This files contains
  facility information (Part I on Form R and Form
  A) as well as the detailed information regarding
  source reduction and recycling activities (Part
  II, Section 8 on Form R) and on-site waste
  treatment methods (Part II, Section 7 on Form R).
  (84,079 records)
• File Type 3A Details of Transfers Off-site. This
  file contains facility information (Part I on
  Form R and Form A) as well as details of
  individual transfers off-site (Part II, Section
  6.2 on Form R). (100,033 records)
• File Type 3B Details of Transfers to Publicly
  Owned Treatment Works (POTW). This file contains
  facility information (Part I on Form R and Form
  A) as well as a list of POTWs (Part II, Section
  6.1.B on Form R). (84,079 records)

8
2.2 TRI National File Type 1 in FileMaker 5.5
9
2.2 TRI National File Type 1 in Web Browser
10
2.2 TRI National File Type 1 in Web Browser
11
2.2 TRI National File Type 1 in IE 6 (XML)
12
2.3 Interface Customization Possibilities

• Change default.htm to own.
• Use own stylesheet (XSL). Need Developer version.
• Use HTML and Java to build Web application or
  portal.
• Local Emergency Planning Committee database
• http//www.epa.gov/ceppo/lepclist.htm
• List of Lists database
• http//130.11.53.73/lol/
• Population Estimation from Year 2000 Census
  Blocks
• http//198.246.85.108591/population

13
3. PDF and Web Pages to XML Documents

• 3.1 Content Re-design and Re-publishing.
• 3.2 Repurposing PDF to Excel.
• 3.3 Repurposing PDF to XML.
• 3.4 Repurposing PDF to Folio Views.
• 3.5 NextPage Folio Views, LivePublish, and NXT 3.
• 3.6 Comments.

14
3.1 Content Re-design and Re-publishing

• Background
• backgrd_factors.pdf
• Database
• National.exe
• Press
• 40 pdf files at http//epa.gov/tri/tri99/press/pre
  ss.htm
• Tri99press.xsl (34 tables)
• Previous
• Tri97.nfo and tri97.xls
• Questions and Answers
• Qa.pdf (file error)
• Report
• 1999pdr.pdf, completereport.pdf,
  sfs_introduction.pdf (Tri99.xsl - 23 tables).

15
3.1 Content Re-design and Re-publishing
16
3.2 Repurposing PDF to Excel

• See Adobe Acrobat Help pages 103-109 82-84
• See next two slides for background.
• Do Edit, Preferences, Text/Formatted Text
  Preferences, Default Selection Type Table, Okay.
• Select Table/Formatted Text Select Tool and draw
  a box around the table to be converted.
• Do Edit, Copy (or CtrlC)
• In a blank Excel worksheet do Edit, Paste
  (Ctrl-V)
• Results tri99.xls and tri99press.xls.

17
Acobat 5.0 Repurposing and Extracting

• Acrobat 5.0 gives you powerful commands for
  repurposing or extracting text and graphics in
  PDF files.You can use the Save As command to save
  all text in a PDF file in Rich Text Format (RTF)
  for import into your favorite authoring
  application. If your PDF files use tagged Adobe
  PDF, you can extract the text without losing the
  formatting. For example, you can save pages of
  tables from a PDF file for import into an
  application such as Adobe FrameMaker or Microsoft
  Word and the table formatting will be preserved.
  Both PDFMaker and Acrobat Web Capture create
  tagged Adobe PDF automatically. (See About the
  different types of Adobe PDF documents on next
  slide) You can also use the Save As command to
  save each page in a PDF file to an image format.
  You can use the Export command to export all
  images in a PDF file each image is saved in a
  separate file. In addition, Acrobat provides
  several toolsthe text select tool, the column
  select tool, the table/formatted text select
  tool, and the graphics select toolfor copying
  and pasting small amounts of text and graphics
  from a PDF file to your clipboard.You can also
  paste text from a PDF document into a comment or
  bookmark name. While in a PDF document, you
  select the text or graphic and copy it onto the
  clipboard. Once the text or graphic is on the
  clipboard, you can launch the other application
  and paste the text or graphic into a file.

18
About the different types of Adobe PDF documents

• There are three types of Adobe PDF documents
  unstructured, structured, and tagged. These
  document types differ in what they contain and
  how their contents can be repurposed. In general,
  the more structural information the Adobe PDF
  document contains, the more options you have for
  repurposing its contents.
• 1. Unstructured Adobe PDF You can save
  unstructured Adobe PDF files to other formats
  such as RTF with good results. An unstructured
  Adobe PDF file saved to RTF recognizes
  paragraphs, but not basic text formatting, lists,
  or tables.You cant reflow unstructured Adobe PDF
  files into different-sized devices, such as eBook
  reading devices. Unstructured Adobe PDF files
  arent reliably accessible using a screen reader
  for Windows.
• 2. Structured Adobe PDF You can save structured
  Adobe PDF files to other formats such as RTF with
  results that are better than unstructured Adobe
  PDF files but not as good as tagged Adobe PDF
  files. Structured Adobe PDF files saved to RTF
  recognize paragraphs and basic text formatting,
  but not lists or tables.You cant reflow
  structured Adobe PDF files into different-sized
  devices. Structured Adobe PDF files can be
  accessed using a screen reader for Windows, but
  without the reliability of tagged Adobe PDF
  files.
• 3. Tagged Adobe PDF You can save tagged Adobe
  PDF files to other formats such as RTF with the
  best results, including the recognition of
  paragraphs, basic text formatting, lists, and
  tables.You can reflow tagged Adobe PDF files so
  that theyre readable in different-sized
  devices.Tagged Adobe PDF files have been
  optimized for accessibility, so they can be
  accessed reliably using a screen reader for
  Windows.

19
3.2 Repurposing PDF to Excel
20
3.2 Repurposing PDF to Excel
21
3.3 Repurposing PDF to XML

• Adobe PDF Document as HTML
• http//access.adobe.com/simple_form.html
• Save As XML Plug-In for Windows (B2)
• http//www.adobe.com/support/downloads/detail.jsp?
  hexID89a2
• Install and do Help and About Adobe Acrobat
  Plugins and select SaveasXML.
• Do File, Save as, XML-1.00 without styling
  (.xml) or XHTML-1.00 with CSS-1.00 (.htm).
  (Note Must be a tagged Acrobat PDF.)
• See SaveAsXML Developer Information for Creating
  and Modifying Mapping Tables (DeveloperInfo.pdf).

22
3.3 Repurposing PDF to XML
23
3.3 Repurposing PDF to XML
24
3.3 Repurposing PDF to XML
25
3.3 Repurposing PDF to XML
26
3.4 Repurposing PDF to Folio Views

• Imports major word processing and Web formats.
• Use Adobe Acrobat 5.0.5.
• Not the free Acrobat Reader.
• Do File, Open as Adobe PDF, then File, Save as,
  RTF.
• Use Folio View 4.2
• Do File, New and give it a name, Open or File,
  Import, select RTF, Open.
• Also do File, Import URL for Web formats.
• Apply structure, links, formatting, etc. using
  the GUI.

27
3.4 Repurposing PDF to Folio Views
28
3.4 Repurposing PDF to Folio Views
29
3.5 NextPage Folio Views, LivePublish, and NXT 3

• NextPage http//www.nextpage.com
• Folio Views SGML-like markup (pre-XML) in a
  GUI.
• CD-ROM distribution.
• Web Server (Markup-to-HTML on the fly).
• LivePublish Basic XML support (uses DTD and see
  next slide).
• Site Administrator.
• Personal Edition (Desktop and CD-ROM).
• Web Server (Markup-to-HTML on the fly).
• NXT 3 Advanced support for XML (LivePublish
  plus XSL, SOAP, etc. see later slide).
• Content Network Manager.
• Content Network Server.

30
3.5 NextPage LivePublish

• Uses of XML (see separate handout)
• Serve up native XML.
• Convert XML to HTML using a CSS or XSL at run
  time using the Display Filter API.
• Convert XML to HTML at build time.
• Uses an XML-based file to define site look and
  feel.
• The build Makefiles are XML files that define the
  structure and contents of the information
  collections.
• XML-based legacy conversion tools simplify the
  conversion of existing content into HTML.
• Indexsheets (XIL) define and control the indexing
  of content like stylesheets (XSL) define and
  control the formatting (see separate handout).

31
3.5 NextPage Folio Views
32
3.5 NextPage LivePublish Site Administrator
33
3.5 NextPage LivePublish Personal Edition
34
3.5 NextPage LivePublish Personal Edition
35
3.5 NextPage LivePublish Web Server
36
3.5 NextPage NXT 3 Content Network

• NextPage Web Services White Paper
• NXT 3 has been delivering XML Web Services since
  July 2000 based on an early SOAP recommendations
  before SOAP became a standard.
• NextPage is developing full support for SOAP,
  WSDL, and UDDI standards and conforming Web
  service frameworks such as .Net and Sun One
  (Java).
• Basic XML Web services provides low-level
  communication and NXT 3 provides high-level data
  coordination when intelligent evaluation of
  distributed content and collaborative
  capabilities in the context of business processes
  is needed (just released Matrix).

37
3.5 NextPage NXT 3 Content Network Manager
38
3.5 NextPage NXT 3 Content Network Web Server
39
3.6 Comments

• Previous work
• 1995 Folio Views Infobase and Excel files.
• TRI 1997 CD-ROM Users Guide Infobase.
• Could add Year 2000 easily to Year 1999.
• Organized files by folders for indexing with the
  NXT 3 File Service (recall section 3.1 screen
  capture and see next slide).
• Can/should create tagged PDF files when you use
  Acrobat PDFMaker 5.0 to create PDF files from
  within Microsoft Office 2000 applications.

40
3.6 Discussion
41
4. Excel Data Tables to XML Data Islands

• 4.1 Excel-to-XML and XML-to-Excel Round-tripping.
• 4.2 XML Spy 4.2.
• 4.3 Application of XML Step by Step, Second
  Edition, Data Binding.
• 4.4 Comments.

42
4.1 Excel-to-HTML(XML) andHTML(XML)-to-Excel
Round-tripping

• In Excel do File, Save as Web Page, select
  Republish Sheet, Publish, Open in Browser,
  Publish.
• In IE 5 or 6 do View Source and explore the
  XML-like markup.
• In Excel do File, Open, Files of type Web pages.

43
4.2 Data Tables to XML Data Islands

• XML Spy 4.2 (see Tutorial)
• Copying XML data to and from third party
  products
• XML Spy allows you to easily copy data to and
  from third party products. The copied data can be
  used within XML Spy as well as third-party
  products, enabling you to transfer XML data to
  spreadsheet-like applications (e.g. Microsoft
  Excel).
• The " Copy as Structured Text" command copies
  elements to the clipboard as they appear on
  screen. This command is useful for copying
  table-like data from the Enhanced Grid View as
  well as the integrated Database/Table View.
• The copied data can be used within XML Spy as
  well as third-party products, enabling you to
  transfer XML data to spreadsheet-like
  applications (e.g. Microsoft Excel).

44
4.3 Application of XML Step by Step, Second
Edition, Data Binding

• Re-format Excel worksheet with appropriate field
  names (Upper Camel Case). (See next slide)
• Import to FileMaker 5.5 using field names.
• Query FileMaker on the Web for XML output
• http//localhost/FMPro?dbtri99table1.fp5format
  dso_xmlfindall
• Add the XML output as a data island in the HTML
  file and display in IE5-6.
• See tri1999table1.xml and tri1999table1.htm

45
4.3 Application of XML Step by Step, Second
Edition, Data Binding
46
4.3 Application of XML Step by Step, Second
Edition, Data Binding
47
4.3 Application of XML Step by Step, Second
Edition, Data Binding

• Nevada
• 1
• 1529022
• 1868475
• 136431
• 2797
• 1.1647E09
• 1.1682E09
• 212998
• 1.1684E09
• ..

48
4.3 Application of XML Step by Step, Second
Edition, Data Binding
49
5. Some Future Steps

• 5.1 Microsoft Excel 2002 lets you open or save
  workbooks in XML format.
• 5.2 Access 2002 allows you to create a database
  table by importing an XML document or to export a
  database table or other object to an XML
  document.

50
5.1 Microsoft Excel 2002

• Source Chapter 15. Publishing Information on the
  Web, Step by Step Microsoft Excel 2002
• Previous Excel 2000 workbooks and worksheets
  could be saved as Web files and queries could
  bring Web data into workbooks.
• Excel 2002 extends those capabilities by
  providing live-links from Excel to Web files and
  by providing import and export of XML and Smart
  Tags (e.g. have Excel look for known stock
  symbols and connect to a Web site that has
  information related to that symbol).

51
5.1 Microsoft Excel 2002

• Working with Structured Data
• XML can identify rows and cells within the
  spreadsheet and allow spreadsheet data to move
  freely to other applications.
• Do File, Save As, Save as type, select XML
  Spreadsheet (.xml), and click Save. Click Yes
  when the message box appears.
• Open the XML file in Spy to examine its structure
  and content (PivotXML.xml).
• Open the XML file in Excel 2002 to see it
  re-display.

52
5.1 Microsoft Excel 2002
53
5.2 Access 2002

• Source Chapter 3. Getting Information Into and
  Out of a Database, Step by Step Microsoft Access
  2002
• Best practices
• Link to other databases rather than import so can
  view and edit in both systems.
• Share databases by exporting to XML (universal
  format).
• http//office.microsoft.com/assistance/2002/articl
  es/acExOfScenariosUsingXML.aspx
• Import
• Open Access 2002 database.
• File, Get External Data, Import, Files of type,
  XML Documents, Import both XML and XSD, select
  file to be imported, Import, Import XML, Options,
  Structure and Data, Okay.
• Open and view database tables to confirm data was
  imported.

54
5.2 Access 2002

• Exporting to other applications
• Works for Table, Query, Form, and Report.
• Open Access 2002 database and select a table.
• File, Export, select XML Documents, Save as type,
  Export, Export XML, select both Data (XML) and
  Schema (XSD) of the data, Okay.
• See screen captures on next pages.
• See Advanced, Schema tab and select appropriate
  option.
• Look at XML and XSD files (see examples below) in
  XML Spy 4.2
• Orders.xml, Order Details.xml, and Order
  Details.xsd.

55
5.2 Access 2002
56
5.2 Access 2002
57
5.2 Access 2002
58
6. Questions and Answers

• Brand Niemann. Ph.D.
• USEPA Headquarters, EPA West, Room 6143D
• Office of Environmental Information, MC 2822T
• 1200 Pennsylvania Avenue, NW, Washington, DC
  20460
• 202-566-1657
• niemann.brand_at_epa.gov
• EPA http//161.80.70.167
• Outside EPA http//130.11.44.140
