INDE 599 Lecture

1
INDE 599 - Lecture 8

• Jeffrey J. Berkley, PhD
• Office 209 Sieg Hall
• Office Hours 330-420PM Tuesday Thursday
• e-mail jberkley_at_u.washington.edu

2
Last Time

• What OpenGL is
• Initializing an OpenGL window.
• Drawing points, lines and polygons.
• Color
• Display Lists

3
Adding the Graphics Window

• Under the project menu, choose Add To Project and
  the Components and Controls.
• Choose DialogGLDlg.ogx and press OK.
• You should now see that a dialog called
  IDD_DIALOGGL_DIALOG has been added to your
  project.
• You should also see a class called CDialogGLDlg.

4
Using the Graphics Window as a Modeless Dialog

• Add include "OpenGLExampleView.h (or whatever
  your view file is named) to the DialogGLDlg.cpp
  file.
• Add include DialogGLDlg.h to your view.cpp
  file.
• Add a pointer to this new class in the view.h
  file as a public attribute (add CDialogGLDlg
  m_pOpenGLDlg) and forward declare CDialogGLDlg.
• In the view.cpp constructor, initialize the
  CDialogGLDlg class with the line m_pOpenGLDlgnew
  CDialogGLDlg(this)

5
Using the Graphics Window as a Modeless Dialog

• In the view.cpp destructor, delete the
  CDialogGLDlg class with the line delete
  m_pOpenGLDlg
• Create a button or menu item to activate the
  window and map a function to it.
• In that function add the code
• if(m_pOpenGLDlg-GetSafeHwnd()0)
• m_pOpenGLDlg-Create()
• else m_pOpenGLDlg-DestroyWindow()

6
Lighting Properties

• Set your lighting properties with commands such
  as these
• float fAmbientLight 0.7f, 0.7f, 0.7f,
  1.0f
• float fDiffuseLight 0.8f, 0.8f, 0.8f,
  1.0f
• float fSpecularLight 1.0f, 1.0f, 1.0f,
  1.0f
• glLightfv( GL_LIGHT0, GL_AMBIENT,
  fAmbientLight)
• glLightfv( GL_LIGHT0, GL_DIFFUSE,
  fDiffuseLight)
• glLightfv( GL_LIGHT0, GL_SPECULAR,
  fSpecularLight)

7
Material Properties for Lighting

• While not essential, you can also vary material
  properties for each object by declaring different
  properties in the code before rendering each
  object
• float fAmbientMat 0.7f, 0.7f, 0.7f,
  1.0f
• float fDiffuseMat 0.8f, 0.8f, 0.8f,
  1.0f
• float fSpecularMat 1.0f, 1.0f, 1.0f,
  1.0f
• glMaterialfv(GL_FRONT, GL_AMBIENT, fAmbientMat)
• glMaterialfv(GL_FRONT, GL_DIFFUSE, fDiffuseMat)
• glMaterialfv(GL_FRONT, GL_SPECULAR,
  fSpecularMat)

8
Setting the Position of Your Light

• The position can be set with code like the
  following
• float fPosition1.0,1.0,0.0,0.0
• glLightfv(GL_LIGHT0, GL_POSITION, fPosition)

9
Activate Your Light

• Now a few commands to enable the light
• glLightModelf(GL_LIGHT_MODEL_TWO_SIDE, 1.0)
• glPolygonMode(GL_FRONT_AND_BACK,GL_FILL)
• glEnable(GL_LIGHT0)
• glEnable(GL_LIGHTING)
• Dont forget to set the normal when rendering
  each of your polygons!

10
Texture Maps

• Texture maps allow you to add pictures to your
  polygons. This can be MUCH more efficient than
  trying to define individual pixels on a polygon.
• The hardest part of adding a texture map is
  loading it, so Ill give you code for this.

11
Texture Maps
tx1, ty1

• In a nut shell, you pull apiece out of a picture
  andpaste it to a polygon.
• Here is some example code
• glEnable( GL_TEXTURE_2D )
• glColor3f(1.0,1.0,1.0)
• glBegin(GL_TRIANGLES)
• glNormal3f(nx1,ny1,nz1)
• glTexCoord2f(tx1,ty1)
• glVertex3f(x1,y1,z1)
• glNormal3f(nx2,ny2,nz2)
• glTexCoord2f(tx2,ty2)
• glVertex3f(x2,y2,z2)
• glNormal3f(nx3,ny3,nz3)
• glTexCoord2f(tx3,ty3)
• glVertex3f(x3,y3,z3)
• glEnd()

tx2, ty2
tx3, ty3
12
The Long Way of Using Textures

• 1) Turn on texture mapping by saying
  glEnable(GL_TEXTURE_2D) This is usually done in
  the beginning of the program. BUT, you will want
  to turn it back off before you draw primatives
  using color instead. So, say glDisable(GL_TEXTURE
  _2D) - Then draw your colored shapes, then turn
  it back on by saying glEnable(GL_TEXTURE_2D)
• 2) Load a texture. Once you have the data of the
  texture you loaded, you need to register it with
  OpenGL. Ill give you code for this, but in case
  you really want to know.the first step to do
  this is
• glGenTextures(1, textureArraytextureID) This
  generates a unique texture reference to the
  desired index of our texture array. We then pass
  this data into glBindTexture() to set the current
  texture being mapped.
• glBindTexture(GL_TEXTURE_2D, textureArraytexture
  ID) We NEED to call glBindTexture() after we
  generate the texture using glGenTextures,
  otherwise it won't be assigned the data from the
  next function, gluBuild2DMipmaps()

13
The Long Way of Adding Textures

• gluBuild2DMipmaps(GL_TEXTURE_2D, 3,
  pBitmap-sizeX, pBitmap-sizeY, GL_RGB,
  GL_UNSIGNED_BYTE, pBitmap-data) What is a mip
  map you ask? Mip maps are a bunch of different
  scaled sizes of the texture. The reason for this
  is because it makes the texture look nicer if we
  are farther away or up close to the texture. It
  picks the best size depending on the distance we
  are from it. It is a good idea to make textures
  that are a power of 2, like 2, 4, 8, 16, 32, 64,
  128, 256, etc... This makes it so it can get a
  smoother representation when it scales, otherwise
  it could look worse when scaled. After we build
  the mip maps, we then need to set the type of
  filter we want to use.
• glTexParameteri(GL_TEXTURE_2D,GL_TEXTURE_MIN_FILT
  ER,GL_LINEAR)

14
The Long Way of Adding Textures

• glTexParameteri(GL_TEXTURE_2D,GL_TEXTURE_MAG_FILT
  ER,GL_LINEAR) If we use GL_LINEAR it will look
  smoother, but takes a little speed hit. If we use
  GL_NEAREST it will be a bit faster, but will look
  pixelated and blotchy. The MIN filter is used
  whenever the pixel being textured maps to an area
  greater than one texture element. The MAX filter
  is used when the pixel being textured maps to an
  area less than or equal to one texture element
• 3) After we load the texture, we just need to
  call glBindTexture() to set that as the current
  texture being mapped. Not necessary if you are
  only loading one texture map.

15
The Long Way of Adding Textures

• 4) Next, we need to give each vertex a texture
  coordinate, also called (U, V) coordinates. We do
  that by calling glTexCoord2f(U, V) This assigns
  a part of the bitmap to the next vertice passed
  in. It's like putting a sticker on paper, you
  just match the correct corner with the correct
  paper corner. You have to be carefull when you do
  this or else the image will be flipped or upside
  down. It depends on the direction of your camera
  though. The order is VERY important.
• 5) Lastly, you need to delete the textures after
  you are finished. You do this by calling
  glDeleteTextures(1, textureArraytextureIndex)

16
Animation

• A RenderScene() function can be inserted in
  Windows OnPaint() function. OnPaint() is called
  whenever the window is moved or resized. You can
  insert this by mapping to the message WM_PAINT
  using the ClassWizard.
• You might want the window to update when events
  happen that change the view (i.e. moving the
  mouse might rotate your view). Dont call
  OnPaint() yourself. Call InvalidateRect(NULL,FALS
  E)

17
Animation

• Using the RenderScene() scene function you
  create, you would do the following
• Clear the buffers with glClear(GL_COLOR_BUFFER_BIT
  GL_DEPTH_BUFFER_BIT)
• Load the identity matrix into the buffer with
  glLoadIdentity()to put your viewpoint at the
  origin.
• Translate your viewpoint away from the origin.
• Translate, rotate and scale your scene.

18
Next Time

• Matrix Transformation
• Splines, Curves, Patches
