Digital Rights Management and Trusted Computing

1
Digital Rights Management and Trusted Computing

• Kari Kostiainen
• T-110.7200 Special Course in Operating System
  Security
• April 13th 2007

2
First paper Enabling fair use with trusted
computing(unpublished draft)
3
Motivation

• Good DRM system should enable various use cases
• Listening a song three times before purchase
• Renting a movie so that it can be watched only
  once
• Moving a purchased song from one device to
  another
• Enforcing this kind of stateful licenses is
  difficult in open platforms
• Reverting the system to a previous state is easy
  ? the movie can be watched again
• Existing solutions are not satisfactory
• Obfuscation and rootkits
• Online solutions
• Dongles and smardcards
• This paper presents an architecture that enables
  enforcement of stateful licenses on open
  platforms using trusted computing

4
Security objectives

• License integrity and enforcement
• All parties must enforce licenses and
  unauthorized alteration must be infeasible
• Freshness
• Replay-attacks must be infeasible
• License availability
• Usage without online connectivity must be
  possible
• Privacy
• The system should preserve users privacy

5
System model

• Strong isolation between compartments
• Trusted channels bound to configurations of
  compartments
• In principle all compartments could be located on
  different machines

6
Implementation

• Hardware layer normal PC hardware with TPM
• Virtualization layer based on L4-family
  microkernels (Xen could be used as well)
• Trusted software layer based on PERSEUS security
  architecture
• Application layer legacy operating system
  (para-virtualized Linux) and security critical
  applications

7
System startup

• Normal TPM-based boot sequence
• BIOS measures master boot record (MBR) before
  giving control to it
• MBR measures kernel before giving control to it
• and so on
• Uses modified GRUB boot loader
• The Compartment Manager (CM) measures other
  compartments, legacy operating systems and
  applications before executing them

8
Establishing trusted channels
TPM creates PKBIND and SKBIND
Verify signature using AIK
RC compares to known comp_confLC and TCB_conf
TPM creates certBIND using AIK
RC creates a secret key sk
TM verifies that comp_confLC is same
TPM verifies that TCB_conf is same
9
Secure storage overview

• Storage Manager maintains metadata index that
  logs usage of securely stored items
• To maintain freshness the index also manages a
  software counter that is incremented
  synchronously with TPM 1.2 monotonic hardware
  counter
• ? Provides protection against attacks that try
  to revert into previous state

10
Using secure storage
Sealed against TCB configuration
Same TCB configuration
TPM counter check missing?
11
Second paperEnabling advanced mobile DRM
scenarios N. Asokan and Jan-Erik Ekberg
12
Example use case

• Timo has purchased a song using his mobile device
• Anna would like to listen the song as well
• Timo transfers the song to Annas device for
  limited free listening
• If Anna wants to continue listening she must
  commit to purchasing the song for herself
• Constant online connectivity should not be needed
• How to implement a system like this that provides
  flexible and fair use of purchased content
  without allowing unauthorized use?

13
Conceptual architecture

• DRM device is a tamper-resistant module
• Protocol engine contains the actual DRM
  enforcement logic
• Different payment methods can be plugged into
  this architecture

14
Types of rights and transfers

• Each piece of content has two types of rights
• Usage rights that govern local use
• Transfer rights that specify how new rights can
  be created for different devices
• Different kind of transfers are possible
• Give once the right is transferred the original
  device cannot use the content anymore
• Copy a new right is created for the new device

15
Vouchers determine rights

• Each piece of content is encrypted with a content
  key
• Rights for a piece are embodied in a voucher that
  contains
• Description of content
• Description of rights
• Content key encrypted using public key of target
  device
• Sequence number for freshness
• MAC for integrity
• When rights are transferred the sending device
  creates a new voucher for the target device
• Sending device must check that target device is
  compliant

16
Metering and reporting new rights

• Creation of new rights must be metered and
  reported
• Otherwise, unauthorized copying could take place
• New created right can be either sender-reported
  or receiver-reported
• Preview vouchers are special case of
  receiver-reported voucher
• Unreported voucher is marked as report-pending
• When a proof of reporting is inserted into
  device, the report-pending voucher is converted
  into an unconstrained one
• If the number of report-pending vouchers exceeds
  a certain limit, the device could be disabled in
  some fashion

17
Lifecycle of vouchers
18
Rights transfer protocol
19
Requirements from platform

• The user cannot make modifications in the OS
  kernel
• OS processes cannot access each others memory
  areas
• Small tamper-resistant secure storage for kernel
  which can be used to bootstrap larger secure
  storage
• Process claiming to be DRM engine must be
  authenticated
• Integrity checks could be used

20
Implementation
21
Own thoughts about these paper and DRM in general
22
Own thoughts

• The DRM system should be flexible, so that users
  can consume legally purchased content on all of
  their devices
• This means that all devices should be compliant ?
  all devices should have TPM or something similar
• Will device manufacturers put TPM to 20 MP3
  player?
• I dont think so
• Thus, these schemes do not seem promising for
  music
• If TPMs get very popular in PCs use cases like
  enforcement of software license or video rental
  might work
• But even then it would be difficult to get all
  audio and video device drivers accepted

23
Thank you!
