Audio Databases

1
Audio Databases
2
Metadata

• Using metadata to represent audio content is done
  in a very similar way as we did for video.
• The metadata used to represent audio content may
  be viewed as a set of objects spread out cover a
  time line.
• We may index the metadata associated with audio
  in exactly the same way as we indexed video, and
  the same query-processing techniques may be used
  over again.

3
Example

• The following figure shows the line segments
  associated with part of an opera.
• Activity1 may be Act 1 of the opera, activity2
  may be Act 1, Scene 1, and so on.

4
Example (conti.)

• Each activity may have an associated set of
  fields.
• Singers It may be a set valued field containing
  records having a Role, SingerType and SingerName.
  If the triple (Lohengrin, Tenor, Rene Kollo)
  appears in the segment 50, 100), Rene Kollo, a
  tenor, is singing the role of Lohengrin during
  the time segment 50, 100) of the opera.
• Score It may be a field of type music_doc which
  points to a relevant part of the music score
  associated with the time segment 50, 100).
• Transcript It may be a field of type document
  that points to the relevant part of the libretto
  during the time segment 50, 100).

5
Signal-Based Audio Content

• In some applications, creation of metadata is
  somewhat complex, speaker unknown or content
  unclear.
• Audio data is considered as a signal, ?(x), over
  time x.
• Different features of the signal ? are extracted,
  indexed and stored for efficient retrieval.
• Metadata may still be used to complement the
  signal data.

6
Sample Audio Signals
7
Signal

• Period of vibration, T time taken for a
  particle in the wave to return to its starting
  position, ex. from point A to point B.
• Frequency of vibration, f number of vibrations
  per second. f 1/T.
• Velocity, v the speed of the crests and troughs
  move to the right. v w/T w ? f, where w
  denotes the wavelength of the wave.
• Amplitude, a the maximum intensity of the
  signal associated with the wave.

8
Indexing by Segmentation

• Split up the audio signal into relatively
  homogeneous windows. This may be done in one of
  two ways
• Application developer can specify, a priori, a
  window size w (in sec. or min.), and assume that
  the waves properties within that window are
  obtained by averaging.
• Use a homogeneity predicate as in the case of
  images, except that this homogeneity predicate
  applies to the one-dimensional case..

9
Windowing Using audio signal

• The following figure shows a nonhomogeneous audio
  signal. After split into five windows, each
  window is homogeneous in the sense that it has a
  constant amplitude, wavelength, and wave velocity.

10
Indexing Using Feature Extraction

• After segmentation, the audio signal may be
  viewed as a sequence of n windows, w1, , wn.
• For each window, we extract some features
  associated with the audio signal.
• If k features are extracted, then an audio signal
  may be considered to be a sequence of n points in
  a k-dimensional space.

11
Example Features

• Intensity(I) the power of the signal generated
  by the wave (in Watts per square meters).
• Where ? is the density of the material through
  which the sound is being propagated.
• Loudness(L)
• Where L0 denotes the loudness with the lowest
  frequency (about 15Hz) that a human ear can
  detect.

12
Content Index

• In general, to index the content of an audio
  signal, we proceed with the following two step
• Find a set w1, , wn of window segments.
• For each window wi, store a vector consisting of
  K acoustical attributes.
• An audio database may be viewed as a set of
  (K3)-tuples consisting of the audio source
  (audio file), the window (within that audio
  file), the duration of the window, and the K
  feature values associated with that window.
• A k-d tree can be used to index audio data.

13
Content-based Retrieval for Music Databases
14
Introduction

• The management of large collections of music data
  in a multimedia database has received much
  attention in the past few years.
• For music content-based retrieval, we can extract
  the features, such as melodies, rhythms and
  chords, from the music data and develop indices
  that will help to retrieve the relevant music
  data quickly.

15
Music Feature string
Ex sol-do-re-mi-mi-mi-mi-re-mi-do-do Melody
feature stringeabccccbaa Rhythm
string1-1-1-2-2-1-1-1-1-2-2 Music feature
stinge1a1b1c2c2c1c1b1a2a2
A sample of You Are My Sunshine
16
Features of Music Data

• Coding scheme a music object ? a sequence of
  music segments
• music segment (segment type, segment duration,
  segment pitch)
• four segment types (type A), (type B),
  (type C), and (type D)

17
Features of Music Data

• For example,

the sequence of music segments (B,3,-3)
(A,1,1) (D,3,-3) (B,1,-2) (C,1,2) (C,1,2)
(C,1,1)
18
music segment (type, duration, pitch)
19
Music Data Retrieval System Architecture
20
Indexing

• String Indexing for music data
• Suffix tree
• Numeric Indexing for music data
• R-tree

21
Suffix tree

• A suffix tree is an index structure that has been
  proposed to locate strings that are exactly
  matched to a target string.
• No two edges out of a node can have edge-labels
  beginning with the same character.
• For any leaf i, the concatenation of the
  edge-labels on the path from the root to leaf i
  exactly spells out the suffix of string that
  starts at position i.

22
Exababc ababc,babc,abc,bc,c
?
?
?
23
ExDo Re Do Re Mi ?ababc
24
Numeric Mapping

• Numeric Mapping Function
• v(m)the integer value of segment of m adjacent
  notes
• m adjacent notes from melody feature string
• P(xi)the integer value of each note
• 1 ? i ? m

25
Numeric Mapping (Con.)

• For example A music feature string denoted by
  bcdbc , n10, m4

26
Example

• two tigers (S1 Do Re Mi Do Do Re Mi Do)

The integer value of music of two tigers.
27
Numeric Indexing Structure (R-Tree)
Non-leaf Node
Leaf Node
Link List
28
Pitch Change

• abca?bcdb-1,1,-2
• m adjacent notes from melody feature string
• Adj the maximum value of distance of two
  pitches
• D the total number of distances of pitches

29
Example abcaabcaSuppose m10, Adj9, D19
30
Numeric Index
31
Searching in Numeric Index

• Exact Matching
• For example Music query segment is ccdbb
• ccdbb?ccdb
• ?cdbb

1322
1132
32
Non-leaf Node
Leaf Node
Link List

• s2,s3? s2,s3? s2,s3
• position_s2 ? 2,3),position_s3 ? 1,4) ?s2.

33
Approximate Searching
We can examine the difference between the
transformed value of the query string and
existing data.

• n the number of pitches
• m adjacent notes from melody feature string
• h the distance of two pitches

34
Example
Ex b b c d a b c d 1 1 2 3
0 1 2 3 3 2 1 1 3
2 1 0
Approximate matching conditions for m4, n10,h1
35
Multi-Feature indexing

• Combine Suffix tree
• Independent Suffix tree
• Twin Suffix tree
• Grid-Twin Suffix tree
• Numeric Index
• Hybrid Multi-feature Index

36
Combine Suffix Tree

• The feature strings are directly used to
  construct the index in the index structure
  Combined Suffix Tree.

Exa1a2b1?12,7 121?12,7,1,6
37
Independent Suffix Tree

• The Independent Suffix Trees separates the
  feature strings into a melody and a rhythm string
  and stores them in two independent suffix trees.

(Melodyababc)
(Rhythm12122)
constructed from a1b2a1b2c2
38
Twin Suffix Tree

• Twin Suffix Tree is constructed by adding
  additional information to the Independent Tree.
• This index structure consists of a melody and a
  rhythm suffix tree with links pointing.

39
Twin Suffix Tree

• The Twin Suffix Tree constructed from
  a1b2a2b1a2b2c2

40
Grid-Twin Suffix Tree

• Use a hash function to map each suffix of the
  feature string into a specific bucket of a 2D
  grid.
• The hash function uses the first n symbols of the
  suffix to map it into a specific bucket.

41
Grid-Twin Suffix Tree
a1b2a2c1a3
42
Condensed Grid-Twin Suffix Tree
43
Condensed Grid-Twin Suffix Tree

• abaca
• caaca

44
Multi-Feature Numeric Indexing for Music Data
45
Multi-Feature Numeric Indexing for Music Data
46
Multi-Feature Numeric Indexing for Music Data
rhythm
chord
500
melody
500
47
Hybrid Multi-Feature Index

• Using a multi-feature tree structure instead of
  grid structure in GTST.

48
Suffix Trees with Bit Arrays

• Instead of the links between corresponding
  feature nodes in Twin Suffix Tree, the bit arrays
  are created to indicate the relationships between
  suffix trees.

49
Feature Extraction of Music Data

• We can find some sequence of notes appeared more
  than one time in a music object, which are called
  the repeating patterns.
• A lot of researches in musicology and music
  psychology consent that the repeating pattern is
  one of general features in music structure
  modeling.

50
Repeating Patterns of Music Data

• Repeating patterns In string S, there is a
  sub-string appearing more than once and its
  length being equal to or greater than 2 .
• Non-trivial repeating patterns The frequency of
  the repeating pattern X appearing in the string S
  is more than it is appearing in any other
  repeating patterns.
• Fault tolerant non-trivial repeating patterns It
  allows the sequences with partial different notes
  being as in the same non-trivial repeating
  pattern.

51
Example

• Consider the melody string C-D-E-F-C-D-E-C-D-E-F
  , this melody string has ten repeating patterns

non-trivial freq(C-D-E-F) freq(D-E-F)
freq(E-F) freq(F) 2 freq(C-D-E)
freq(C-D) freq(D-E) freq(C) freq(D)
freq(E) 3. gtonly C-D-E-F and C-D-E
are non-trivial.
52
Music Feature Extractions

• Correlative Matrix
• FastPET
• RP-Tree
• 2RC
• Similar Non-trivial Repeating Pattern
• Fault Tolerance Non-trivial Repeating Patterns

53
CORRELATIVE MATRIX
CScandidate set gt CS(pattern,rep_count,sub_coun
t)
There are four cases to set CS 1.Ti,j1 and
T(i1),(j1) 0 T1,4 1 and T2,50 ---gt
insert CS("C",1,0) 2.Ti,j1 and T(i1),(j1) ?
0 T1,5 1 and T2,6?0 ---gt modify to
CS("C",2,1) 3.Ti,jgt1 and T(i1),(j1) ? 0
T2,6 2 and T3,7?0 --gt insert CS("CA",1,1),("A",1
,1) 4.Ti,jgt1 and T(i1),(j1) 0 T4,8 4
and T5,90 ---gt insert CS("CAAC",1,0),("AAC"
,1,1),("AC",1,1) change ("C",6,1) into
("C",7,2)
The correlative matrix of the string
SCAACCAACDCBC"
54
CORRELATIVE MATRIX (cont.)
There are two more tasks we have to do 1.If a
repeating pattern is a substring of another
repeating pattern, and their repeating are the
same, it will be removed from the candidate set
CS. EX("CA",1,1),("CAA",1,1),("AA",1,1),("
AAC",1,1) and ("AC",1,1) are be moved
since they are all the substring of
the repeating pattern
("CAAC",1,0) 2.We should calculate the real
repeating frequency for every repeating pattern
found. EX "C"
f
55
RP-TREE
The RP-tree for the music feature string
SABCDEFGHABCDEFGHIJABC
56
RP-TREE (cont.)
57
FastPET Fast Pattern Extracting Technique
58
FastPET (cont.)
1 2 3 4 5 6
7 8 9 10 11 12
13 14
abc
P8 3,P11 3 PatternSet abc,3
59
FastPET (cont.)
1 2 3 4 5
6 7 8 9 10
11 12 13 14
P8 3,P11 3, 4 PatternSet
abc,3,abcd, 2
60
FastPET (cont.)
i
Non-trivial RP for abcdbcdabcabcd
P5 3, P8 3,P9 2, P11 3,
4,P12 3 PatternSet bc, 4,
abc,3, bcd, 3, abcd, 2
61
2RC (Two-Row Comparsion)

• 2RC can provide memory saving, O(n).
• Example Sabcdbcdabcabcd

i1
1 2 3 4 5 6
7 8 9 10 11 12
13 14
Row A
62
2RC (cont.)
1 2 3 4 5 6
7 8 9 10 11 12
13 14
i2
Row A
Row B
63
2RC (cont.)
i3
1 2 3 4 5 6
7 8 9 10 11 12
13 14
Row A
Row B
64
2RC (cont.)
i4
1 2 3 4 5 6
7 8 9 10 11 12
13 14
Row A
Row B
PatternSetabc,3
65
True suffix tree approach for non-trivial
repeating pattern discovering (TRP)

• Step 1. constructing suffix tree by adding a stop
  symbol into the tail of string S.
• Step 2. finding out repeating patterns.
• Step 3. pattern sweeping.

66
Example 1 - Step 1 of TRP

• True suffix tree of Sabcdbcdabcabcd.

3
67
Example 1 - Step 2 of TRP

• All repeating patterns of music object S
  abcdbcdabcabcd.

68
Example 1 - Step 3 of TRP

• Pattern sweeping for music object S
  abcdbcdabcabcd.

Non-trivial repeating patterns
69
Example 2 - TRP

• Pattern sweeping for repeating patterns of S
  aaaaaaaaaa.

Non-trivial repeating pattern
70
Fault Tolerant Non-trivial Repeating Pattern
Discovering

• Step 1. Constructing Suffix Tree
• Step 2. Creating Repeating Pattern Table
• Step 3. Greedy Concatenating Repeating Patterns
• Step 4. Exacting Fault Tolerant Non-trivial
  Repeating Patterns

71
Step 2 of FTRP

• Creating Repeating Pattern Table

72
Step 3 of FTRP

• Greedy Concatenating Repeating Patterns

bc?dae
fault 1
fault 0
RP
RP
RP
RP
73
Step 4 of FTRP

• Exacting Fault Tolerant Non-trivial Repeating
  Patterns

bc and dae are all in bc?dae
74
Performance Study

• The Effect on Repeating Pattern Found

75

• Hit Ratio Improvement
