The 511 keV Annihilation Emission From The Galactic Center

1
The 511 keV Annihilation Emission From The
Galactic Center

• Department of Physics
• National Tsing Hua University
• G.T. Chen
• 2007/1/2

2
References

• K.S. Cheng et al. 2006 ApJ
• Annihilation emission form the galactic black
  hole
• W. Wang et al. 2006 AA
• Could electron-positron annihilation lines in
  the galactic center result from pulsar winds ?
• W. Wang 2005 astro-ph/0510461
• Millisecond pulsar population in the galactic
  center and high energy contributions
• N. Guessoum et al. 2005 AA
• The live and deaths of positrons in the
  interstellar medium
• Jean et al. 2006 AA
• Spectral analysis of the galactic ee-
  annihilation emission
• Knodlseder et al. 2006 AA
• The all-sky distribution of 511 keV
  electron-positron annihilation emission

3
Outline

• Introduction
• Models (I) (II)
• Discussion and Future Work

4
Introduction

• Radiation of e-e- annihilation from the galactic
  center was first reported in 1972
• Recently, we have the observation data by SPI of
  the INTEGRAL

5
Introduction

• The bulge emission is spherically symmetric and
  is centered on the galactic center with an
  extension of 50-80 (FWHM)
• Total flux

6
Introduction

• Line width

(Churazov et al. 2005 MNRAS)
(Jean et al. 2006 AA)

• Positronium fraction

(Jean et al. 2006 AA)

• production positron rate

(J. Knodlseder et al. 2005 AA)
7
Introduction
Weidenspointner et al. 2006 AA
8
Introduction
Jean et al. 2006 AA
9
Introduction

• Problems
• The production of positrons
• The galactic map of the annihilation line
• The propagation/evolution of the positrons
  between their production sites and annihilation
  places

10
Introduction

• Positrons can be produced by
• ß decay
• Pion decay
• Pair production (e- e- ) through photon-photon
  interactions
• Pair production by the interaction of an e- with
  a strong magnetic field

11
Introduction

• Positronium (PS)
• It is the bound state of e and e-

Para-PS state
Ortho-PS state
12
Introduction

• In order to determine the overall spectrum of the
  line produced by galactic positrons, we must
  consider the model of ISM ? distributions,
  temperatures and ionization of the gases and
  dusts.
• Taking all the physical information (processes,
  cross sections, line widths, gas distributions,
  etc.) into account , we can reproduce the
  observational data

13
Introduction

• The ISMs in the galactic center
• Cold neutral component (n10 cm-3, T80K)
• Warm neutral component (n0.3 cm-3, T8000K)
• Warm ionized component (n0.17 cm-3, T8000K)
• Hot component (n310-3 cm-3, T4.5105K)

14
Models (I) (II)
15
Models

• Star accretion by central supermassive black hole
  (Model I)
• (K.S. Cheng et al. 2006 ApJ )
• Millisecond pulsars in the galactic bulge region
  (Model II)
• (W. Wang et al. 2006 AA)

16
Model (I)

• The assumptions in this model
• The rate of production of positrons
• If positrons are produced via p-p collisions, the
  total energy of protons must not exceed
• The spatial distribution of positrons should
  extend over a region with angular radius 50-80
  around GC when they cool down to thermal energies


17
Model (I)

• The capture of stars by Galactic black hole
  provides relativistic protons
• Collisions of these protons with surrounding gas
  result in relativistic positrons with energy Egt30
  MeV

18
Model (I)
Electron/Positron Production Spectrum
electrons
positrons
K.S. Cheng et al. 2006
19
Model (I)

• Consider the interactions of positrons and gases
  ---ionization loss synchrotron inverse Compton
  loss bremsstrahlung loss , we can describe the
  evolution of the positrons spectrum from
  relativistic to thermal energies

20
Model (I)
ne1 cm-3 T2.5 eV
K.S. Cheng et al. 2006
21
Model (I)

• Later Coulomb collision continue to form the
  equilibrium distribution and accumulate positrons
  in the thermal energy range, then these thermal
  positrons decrease because of annihilation

22
Model (I)
Guessoum et al. 2005 AA
23
Model (I)

• In this case, they assume the annihilation
  spectrum is caused by in-flight annihilation with
  e- and charge exchange with H

24
Model (I)
ne1 cm-3 T2.5 eV
K.S. Cheng et al. 2006
25
Model (I)
ne310-3 cm-3 T100 eV
K.S. Cheng et al. 2006
26
Model (II)

• There possibly exists a population of millisecond
  pulsars (MSPs) in the Galactic center region.
• MSPs could emit GeV gamma-rays through
  synchrotron-curvature radiation as predicted by
  outer gap models
• MSP winds provide good candidates for the e- e-
  sources in the Galactic center

27
Model (II)

• They consider the e- e- pair production occurs
  in the pulsar outer-magnetosphere region
• MSP winds are positron sources which result from
  pair cascade near neutron star surface
• MSPs are active near Hubble time, so they are
  continuous positron injecting sources

28
Model (II)

• Typical parameters
• How many MSPs in this region ?

P3 ms B3108 G ? Injection rate
29
Discussion Future Work

• Study much details in the model(I)
• Apply some tools learning from model(I) to MSPs
  model

30
gtgtThank Youltlt
31
Guessoum et al. 2005 AA
32
Guessoum et al. 2005 AA
33
Guessoum et al. 2005 AA
34
(No Transcript)
35
(No Transcript)
36
(No Transcript)
37
Guessoum et al. 2005 AA
38
Annihilation rel. electrons
Ionization loss of positrons
Ionization loss of electrons
Syn.Inverse Compton rel. electrons
K.S. Cheng et al. 2006
39
Energy threshold of reactions induced by positrons
Guessoum et al. 2005 AA
40
Guessoum et al. 2005 AA
