Private Water Supplies

1
Private Water Supplies

• everything is voluntary!

2
Sanitary well cap
Good casing
Sloping Ground
Soil
Grout seal
Bedrock
Water Table
Groundwater aquifer
3
(No Transcript)
4
Protect the Wellhead Area!
X
5
Some Problems Occur Naturally
Iron
Hydrogen Sulfide
Hardness
Manganese
Corrosive
6
We Cause Many Problems
7
How do I know what to test my water for?

• Symptoms tastes, odors, stains
• Local land use and activities
• Local water testing results

8
Symptoms

• White residue, dull laundry - hardness
• Reddish stains, metallic taste iron
• Black stains, metallic taste - manganese
• Rotten egg odor - hydrogen sulfide gas
• Blue stains, metallic taste - corrosive water

9
Be Aware of Local Activities
10
(No Transcript)
11
How close must activities beto my well to cause
a problem?
12
Coliform Bacteria

• A large group of common surface bacteria
• Indicate the potential for harmful bacteria
• Possible sources
• Surface water
• Animal waste
• Septic system
• Occur frequently especially in springs and
  shallow wells

13
The Most Common Problems
of water supplies with problem
14
Common Aesthetic Problems
of water supplies with problem
15
Water Testing

• Routine tests give you protection
• Use certified labs!
• Annual bacteria test
• Every 3 years pH, TDS, local pollutant

16
Interpreting a Water Test

• Compare your result with the Drinking Water
  Standard which gives the acceptable level
• Primary Standard (MCL)
• health risk
• Secondary Standard (RMCL)
• taste, stain, odor

17
(No Transcript)
18
Drought Stages

• Drought Watch
• 5 voluntary water use reduction
• Drought Warning
• 10-15 voluntary water use reduction
• Drought Emergency
• Mandatory water restrictions
• Ban on non-essential water use
• These DO apply to private wells springs

19
How is the Drought Stage Determined?

• Precipitation
• Stream flow
• Groundwater levels
• Palmer Drought Index
• Reservoir storage

20
Historical Droughts in Pennsylvania
Palmer Drought Index
21
Drought Outlook

• Short-term relief likely
• Ground water and surface water drought will
  continue
• 12 to 20 inches of precipitation needed over next
  three months

22
Natural Groundwater Fluctuations
Ground Surface
Deeper Underground
23
No pumping static water level
Submersible pump
24
Normal drawdown
25
Sporadic Water Loss
26
Permanent Water Loss
27
More and More Users!
1 million wells and counting
Wells drilled 1966-1994
28
Pennsylvania Water Law

• You do NOT own the water under your property
• You are entitled to reasonable use
• Little protection of existing sources
• Permitting of large users in Delaware and
  Susquehanna Basins
• Several pending bills on water use

29
Preventing a Dry Well

• Obtain your well log
• Your well driller
• Bureau of Topographic and Geologic Survey
• 717-702-2074
• Identify alternate sources
• Always conserve water!
• Talk to neighbors, local well drillers
• Monitor your water supply if possible
• Monitor nearby wells on the web

30
http//wwwpah2o.er.usgs.gov/
observed
average
record low
31
If You Lose Your Water . . .

• Water may return in time
• Emergency water conservation
• Reduce peak demands
• Have well driller determine the cause
• Faulty or worn-out pump
• Electrical problem
• Low water level
• Lower the pump in the existing well
• Deepen existing well
• Drill new well
• Beware of unlicensed drillers

32
Always Conserve Water!
33
Achieving Water Conservation

• Change in water use habits
• Install water saving devices

34
Water UseStudy of Eight Families in Central PA

• Average use
• 100 to 322 gallons per day
• Peak use
• 240 to 880 gallons per day

35
Consumptive Water Use
Septic System
Non-Consumptive Water Use
36
Average Water Use
Gallons per person per day
Toilet Shower Clothes Outside
Other Bath Washer
37
Toilet Water Use
38
Clothes Washer

• Standard
• 40 to 55 gallons per load
• Front-loading
• 22 to 33 gallons per load

39
Showers

• Standard
• 4 to 6 gallons per minute
• Low flow
• 2 gallons per minute

40
Faucets

• Standard
• 4 to 6 gallons per minute
• Flow control aerators
• Kitchen 1.5 gallons per minute
• Bathroom 0.5 gallons per minute

41
Effect of Water Conservation
Total savings 32
42
Water Harvesting
43
(No Transcript)
44
Types of Water Treatment

• Point of entry
• Point of use

45
Examples of Point of Entry

• Water softener
• Ultraviolet light (disinfection)
• Carbon filter (volatiles)

46
Examples of Point of Use

• Reverse osmosis
• Distiller
• Carbon filter
• faucet or counter-top

47
Water Treatment

• Disinfection
• Ion exchange
• Oxidation-reduction
• Filtration

48
Disinfection
49
continuous chlorination
50
Ultraviolet Light Sterilizer
U-V Tube
51
Ion Exchange
52
Water Softening

• cation exchange process
• remove calcium, magnesium
• add sodium (potassium)
• will remove some iron

53
Schematic of Softener
Water Softener
54
Oxidation
55
Iron Removal
56
Iron Treatment Options
57
Carbon Filtration
58
Filter Maintenance

• replace GAC every 6 mos.
• dispose of properly

59
(No Transcript)
60
Solving Water Problems

• new source
• pollution control
• maintenance inspection
• treatment

61
Before You Buy Treatment Equipment

• have your water tested by a certified lab
• dont rely on in-home water test results
• consult unbiased water quality experts
• explore all alternatives
• new source, pollution control,
• maintenance
