OSP Cable and Drop Wire Selection

1
OSP Cable and Drop Wire Selection

• OSP Expo
• Tony Squires
• Product Manager, Cable
• Sumitomo Electric Lightwave

2
Topics

• New Fiber Technologies
• Improved Bend Sensitivity
• Cable Principles
• New Cable Designs

3
Getting the most from optical fibers

• The most cost effective PON - point to multipoint
  architecture uses splitters, WDM and TDM.
• WDM drives the need for a broader operating
  window.

4
Low or Zero Water Peak Fiber

• Historically the 1383 nm had to be avoided by
  system designers. New processing techniques have
  eliminated the water peak and the entire 1280
  to 1625 nm region is available.

5
Topics

• New Fiber Technologies
• Improved Bend Sensitivity
• Cable Principles
• New Cable Designs

6
Single Mode Optical Fiber
PureAccessTM Ruggedized FTTH Fiber

• Reduced bending characteristics
• Improved environmental robustness
• Bend fiber tubes tighter
• Less sensitive to human error
• Splice compatible to PureBand fiber
• Ideal for Drop cables Jumpers

7
Improved Fiber Geometry

• Improved fiber performance.
• Reduced need for core alignment splicing. Less
  expensive and easier V-groove alignment can be
  used.

8
Topics

• New Fiber Technologies
• Improved Bend Sensitivity
• Cable Principles
• New Cable Designs

9
Cable Jacket Materials

• Polyethylene good UV resistance
• Medium Density easy entry
• High Density lower coefficient of friction
• Flame Retardant required inside buildings
• PVC poly vinyl chloride
• Flame resistance
• Abrasion Resistant
• Used for Riser Cable Yellow Single Mode, Orange
  Multimode
• Cross Linked Polymers
• Used in the presence of high electromagnetic
  fields
• Flouro Polymers
• Plenum cable for use above drop ceilings
• Steam Tunnel Cables

10
Key to all OSP fiber cablesExcess Length
11
Loose Tube Features

• Reverse Oscillating Lay - ROL
• Adequate room for excess length required in high
  tensile environments.
• Dielectric or armored options.
• Note The central strength members provide much
  of the stability. Therefore, they need to be
  anchored in all closures per the closure
  instructions. Also long lengths of un-cabled
  loose tubes will shrink and may experience loss
  increases.

12
Micro Duct vs. Air Blown Fiber
13
Air Blown Fiber FutureFLEX System

• Reconfigurable Pt-to-Ptcabling system
• Transition between indoor outdoorwithout
  splices
• Non-disruptive
• Defer fiber costs
• Upgrades less than1/10th conventional

14
All Dielectric Self Support
15
Central Tube Cable

• Available in both Ribbon or Bundle subunits.
• Higher fiber density typical.
• Extended fiber count range thru 864-fiber.
• Peelable ribbon matrix material for easy
  termination.
• Cost Saving benefits of mass fusion splicing.
• Restoration and Network downtime reductions.
• Eliminates many thermal shrinkage issues inherent
  to Loose Tube buffer tubes.
• Dielectric Armored Construction

16
Topics

• New Fiber Technologies
• Improved Bend Sensitivity
• Cable Principles
• New Cable Designs

17
Time Saving Cable Designs

• Dry cables using water blocking yarns and tapes.

18
Modular Ribbon

• 3 robust 4 fiber ribbons are encapsulated to make
  one 12 fiber ribbon.
• Designed to accommodate 4 fiber splits from
  feeder cables.
• Splice compatible with conventional 12 fiber
  ribbons
• Split by hand or splitting tool.

19
FTTH Drop Cables
Product Line Summary

• Low Cost, High Performance Cables

20
Drop Cable Advancements
Profile extrusion techniques.

• Flame retardant / Service
• Up to 12 fibers
• Applicable GR-20 GR-492
• Standard drop hardware
• Aerial - Span Lengths (200500 ft)
• Buried - 300 lb tensile

21
FTTP Drop Cables
All-Dielectric Buried Drop

• Flame retardant option
• Up to 12 fibers
• PureBand fiber 0.35/0.25 dB/km
• 7.6 x 4.6 mm dimensions
• 27 lbs/kft weight
• Applicable GR-20, TR-843
• Buried - 300 lb tensile
• Aerial Span lengths (75,150,250 ft)(33 proof
  strain under max load)
• Compatible with standard P-clamps
• Compatible with standard tools
• 3rd Party Tested by ITS Labs

22
Locatable Dielectric Drop Cable

• Copper zip messenger locatable with dielectric
  benefits.
• More flexible than armored cables.
• Thermal stability (-40ºc to 70ºc).
• Available in both Flame Retardant PVC or OSP
  Standard LLDPE.

23
Cable and Drop Wire Selection

• Fiber
• Wider Operating Windows
• More Robust
• Cable
• Safer Work Environment.
• Economic use of Materials.
• Easier to Enter.
• Faster to Install.
