IST 441 Nutch: Design

1
IST 441 NutchDesign Crawling

• TA
• Saurabh Kataria
• Instructor
• C. Lee Giles

2
Outline

• Overview/Basics
• Crawling Technical Details
• Nutch as a web crawler
• Nutch as a complete web search engine
• Installation/Usage (with Demo)

3
Overview

• Complete web search engine
• Nutch Crawler Indexer/Searcher (Lucene) GUI

• Plugins
• MapReduce Distributed FS (Hadoop)
• Java based, open source, many customizable
  scripts available at (http//lucene.apache.org/nut
  ch/)
• Features
• Customizable
• Extensible (e.g. extend to Solr for enhanced
  portability)

4
Search Engine Basic Workflow
5
What is Nutch?

• Open source search engine
• Written in Java
• Built on top of Apache Lucene

6
Advantages of Nutch

• Scalable
• Index local host or entire Internet
• Portable
• Runs anywhere with Java
• Flexible
• Plugin system API
• Code pretty easy to read work with
• Better than implementing it yourself!

7
Data Structures used by Nutch

• Web Database or WebDB
• Mirrors the properties/structure of web graph
  being crawled
• Segment
• Intermediate index
• Contains pages fetched in a single run
• Index
• Final inverted index obtained by merging
  segments (Lucene)

8
WebDB

• Customized graph database
• Used by Crawler only
• Persistent storage for pages links
• Page DB Indexed by URL and hash contains
  content, outlinks, fetch information score
• Link DB contains source to target links,
  anchor text

9
Segment

• Collection of pages fetched in a single run
• Contains
• Output of the fetcher
• List of the links to be fetched in the next run
  called fetchlist
• Limited life span (default 30 days)

10
Index

• To be discussed later

11
Crawling

• Cyclic process
• crawler generates a set of fetchlists from the
  WebDB
• fetchers downloads the content from the Web
• the crawler updates the WebDB with new links that
  were found
• and then the crawler generates a new set of
  fetchlists
• And Repeat till you reach the depth

12
Nutch as a crawler
Initial URLs
CrawlDB
Webpages/files
update
get
read/write
generate
read/write
Segment
13
Nutch as a complete web search engine
Partially Crawled Data
(Lucene)
Index
(Lucene)
GUI
(Tomcat)
14
Crawling 10 stage process

• bin/nutch crawl -dir -depth
  crawl.log
• 1. admin db create Create a new WebDB.
• 2. inject Inject root URLs into the WebDB.
• 3. generate Generate a fetchlist from the
  WebDB in a new segment.
• 4. fetch Fetch content from URLs in the
  fetchlist.
• 5. updatedb Update the WebDB with links from
  fetched pages.
• 6. Repeat steps 3-5 until the required depth
  is reached.
• 7. updatesegs Update segments with scores and
  links from the WebDB.
• 8. index Index the fetched pages.
• 9. dedup Eliminate duplicate content (and
  duplicate URLs) from the indexes.
• 10. merge Merge the indexes into a single
  index for searching.

15
Demo Configuration

• Configuration files (XML)
• Required user parameters
• http.agent.name
• http.agent.description
• http.agent.url
• http.agent.email
• Adjustable parameters for every component
• E.g. for fetcher
• Threads-per-host
• Threads-per-ip

16
Configuration

• URL Filters (Text file) (conf/crawl-urlfilter.txt)

• Regular expression to filter URLs during crawling
• E.g.
• To ignore files with certain suffix
• -\.(gifexezipico)
• To accept host in a certain domain
• http//(a-z0-9\.)apache.org/

17
Installation Usage

• Installation
• Software needed
• Nutch release
• Java
• Apache Tomcat (for GUI)
• Cgywin (for windows)

18
Installation Usage

• Usage
• Crawling
• Initial URLs (text file or DMOZ file)
• Required parameters (conf/nutch-site.xml)
• URL filters (conf/crawl-urlfilter.txt)
• Indexing
• Automatic
• Searching
• Location of files (WAR file, index)
• The tomcat server

19
Demo site we would crawl?

• http//ist441.ist.psu.edu

20
Site Structure
http//ist441.ist.psu.edu/
A.html
B.html
A_dup.html
C.html
C_dup.html
Wikipedia.org
21
Demo Some Commands

• Crawl
• bin/nutch crawl -dir -depth
  crawl.log
• Analyze webDB
• bin/nutch readdb stats
• bin/nutch readdb dumppageurl
• bin/nutch readdb dumplinks
• bin/nutch readdb -linkurl
• sls -d / head -1
• bin/nutch segread -dump s

22
Next Meeting

• Indexing!!!!!!!
• Searching!!!!!!

23
QA?
24
References

• http//lucene.apache.org/nutch/ -- Official
  website
• http//wiki.apache.org/nutch/ -- Nutch wiki
  (Seriously outdated. Take with a grain of salt.)
• http//lucene.apache.org/nutch/release/ Nutch
  source code
• www.nutchinstall.blogspot.com Installation guide
• http//www.robotstxt.org/wc/robots.html The web
  robot pages
