Parallel Crawlers

1
Parallel Crawlers

• Junghoo Cho, Hector Garcia-Molina
• Stanford University

Presented By Raffi Margaliot Ori Elkin
2
What Is a Crawler?

• A program that downloads and stores web pages
• Starts off by placing an initial set of URLs, S0
  , in a queue, where all URLs to be retrieved are
  kept and prioritized.
• From this queue, the crawler gets a URL (in some
  order), downloads the page, extracts any URLs in
  the downloaded page, and puts the new URLs in the
  queue.
• This process is repeated until the crawler
  decides to stop.
• Collected pages are later used for other
  applications, such as a web search engine or a
  web cache.

3
What Is a Parallel Crawler?

• As the size of the web grows, it becomes more
  difficult to retrieve the whole or a significant
  portion of the web using a single process.
• It becomes imperative to parallelize a crawling
  process, in order to finish downloading pages in
  a reasonable amount of time.
• We refer to this type of crawler as a parallel
  crawler.
• The main goal in designing a parallel crawler, is
  to maximize its performance (Download rate)
  minimize the overhead from parallelization.

4
Whats This Paper About?

• Propose multiple architectures for a parallel
  crawler.
• Identify fundamental issues related to parallel
  crawling.
• Propose metrics to evaluate a parallel crawler.
• Compare the proposed architectures using 40
  million pages collected from the web.

The results will clarify the relative merits of
each architecture and provide a good guideline on
when to adopt which architecture.
5
What We Know Already

• Many existing search engines already use some
  sort of parallelization.
• There has been little scientific research
  conducted on this topic.
• Little has been known on the tradeoffs among
  various design choices for a parallel crawler.

6
Our Challenges and Interests

• Overlap download the same page multiple times.
• Need to coordinate between the processes to
  minimize overlap.
• To save network bandwidth and increase the
  crawlers effectiveness.
• Quality download important pages first.
• To maximize the quality of the downloaded
  collection.
• Each process may not be aware of whole web image,
  and make a poor crawling decision based on its
  own image of the web.
• Make sure that the quality of downloaded pages is
  as good for a parallel crawler as for a
  centralized.
• Communication bandwidth to prevent overlap and
  improve quality,
• Need to periodically communicate to coordinate.
• Communication grows significantly as number of
  crawling processes increases.
• Need to minimize communication overhead while
  maintaining effectiveness of crawler.

7
Parallel Crawlers Advantages 1

• Scalability
• Due to enormous size of the web, it is imperative
  to run a parallel crawler.
• A single-process crawler simply cannot achieve
  the required download rate.
• Network-load dispersion
• Multiple crawling processes of a parallel crawler
  may run at geographically distant locations, each
  downloading geographically-adjacent pages.
• We can disperse the network load to multiple
  regions.
• Might be necessary when a single network cannot
  handle the heavy load from a large-scale crawl.
• Network-load reduction
• A parallel crawler may actually reduce the
  network load.
• If a crawling process in Europe collects all
  European pages, and another in north America
  crawls all north American pages, the overall
  network load will be reduced, because pages go
  through only local networks.

8
Parallel Crawlers Advantages 2

• Downloaded pages can be transferred to a central
  location, to build a central index.
• Transfer can be smaller than the original page
  download traffic, by using some of the following
  methods
• Compression once the pages are collected and
  stored, it is easy to compress the data before
  sending them to a central location.
• Difference send only difference between previous
  image and the current one. Many pages are static
  and do not change very often, this scheme can
  significantly reduce the network traffic.
• Summarization in certain cases, we may need only
  a central index. Extract the necessary
  information for the index and transfer this only.

9
Parallelization Is Not All

• To build an effective web crawler, many more
  challenges exist
• How often a page changes and how often it should
  be revisited to maintain page up to date.
• Make sure a particular web site is not flooded
  with HTTP requests during a crawl.
• What pages to download and store in limited
  storage space?
• Retrieve important or relevant pages early,
  to improve quality of downloaded pages.
• All these are important, but our focus is
  crawler parallelization, because received
  significantly less attention than the others.

10
Architecture of Parallel Crawler

• A parallel crawler consists of multiple crawling
  processes c-proc.
• C-proc performs single-process crawler tasks
• Downloads pages from the web.
• Stores downloaded pages locally.
• Extracts URLs from downloaded pages and follows
  links.
• Depending on how the c-procs split the download
  task, some of the extracted links may be sent to
  other c-procs.

11
C-procs Distribution

• The c-procs performing these tasks may be
  distributed

at geographically distant locations.
on the same local network
Distributed Crawler
Intra-site Parallel Crawler
12
Intra-site Parallel Crawler

• All c-procs run on the same local network.
• Communicate through a high speed interconnect.
• All c-procs use the same local network when they
  download pages from remote web sites.
• The network load from c-procs is centralized at
  a single location where they operate.

13
Distributed Crawler

• C-procs run at geographically distant locations.
• Connected by the internet (or a WAN).
• Can disperse and even reduce network load on the
  overall network.
• When c-procs run at distant locations and
  communicate through the internet, it becomes
  important how often and how much c-procs need to
  communicate.
• The bandwidth between c-procs may be limited and
  sometimes unavailable, as is often the case with
  the internet.

14
Coordination to Avoid Overlap

• To avoid overlap, c-procs need to coordinate
  with each other on what pages to download.
• This coordination can be done in one of the
  following ways
• Independent download.
• Dynamic assignment.
• Static assignment.
• In the next few slides we will explore each of
  these methods

15
Overlap Avoidance Independent Download

• Download pages totally independently without any
  coordination.
• Each c-proc starts with its own set of seed URLs
  and follows links without consulting with other
  c-procs.
• Downloaded pages may overlap.
• We may hope that this overlap will not be
  significant if all c-procs start from different
  seed URLs.
• Minimal coordination overhead.
• Very scalable.
• We will not directly cover this option due to its
  overlap problem.

16
Overlap Avoidance Dynamic Assignment

• A central coordinator logically divides the web
  into small partitions (using a certain
  partitioning function).
• Dynamically assigns each partition to a c-proc
  for download.
• Central coordinator constantly decides on what
  partition to crawl next and sends URLs within
  this partition to a c-proc as seed URLs.
• C-proc downloads the pages and extracts links
  from them.
• Links to pages in the same partition are followed
  by the c-proc in another partition are reported
  to coordinator.
• Coordinator uses link as a seed URL for
  appropriate partition.
• Web can be partitioned at various granularities.
• Communication between c-proc and the central unit
  may vary depending on the granularity of
  partitioning function.
• Coordinator may become major bottleneck and need
  to be parallelized.

17
Overlap Avoidance Static Assignment

• The web is partitioned and assigned to each
  c-proc before they start to crawl.
• Every c-proc knows which c-proc is responsible
  for which page during a crawl, and the crawler
  does not need a central coordinator.
• Some pages in the partition may have links to
  pages in another partition inter-partition
  links.
• C-proc may handle inter-partition links in a
  number of modes
• Firewall mode.
• Cross-over mode.
• Exchange mode.

18
Site S1 Is Crawled by C1 and Site S2 Is Crawled
by C2
19
Static Assignment Crawling Modes Firewall Mode

• Each C-proc downloads only the pages within its
  partition and does not follow any inter-partition
  link.
• All inter-partition links are ignored and thrown
  away.
• The overall crawler does not have any overlap,
  but may not download all pages,
• C-procs run independently - no coordination or
  URL exchanges.

20
Static Assignment Crawling Modes Cross-over Mode

• C-proc downloads pages within its partition.
• When it runs out of pages in its partition, it
  follows inter-partition links.
• Downloaded pages may overlap but the overall
  crawler can download more pages than the firewall
  mode.
• C-procs do not communicate with each other,
  follow only the links they discovered.

21
Static Assignment Crawling Modes Exchange Mode

• C-procs periodically and incrementally exchange
  inter-partition URLs.
• Processes do not follow inter-partition links.
• The overall crawler can avoid overlap, while
  maximizing coverage.

22
Methods for URL Exchange Reduction

• Firewall and cross-over
• Independent.
• Overlap.
• May not download some pages.
• Exchange mode avoids these problems but requires
  constant URL exchange between c-procs.
• To reduce URL exchange
• Batch communication.
• Replication.

23
URL Exchange ReductionBatch Communication

• Wait with transferring an inter-partition URL,
  collect a set of URLs and send in a batch.
• A c-proc collects all inter-partition URLs until
  it downloads k pages.
• Partitions collected URLs and sends them to an
  appropriate c-proc.
• Starts to collect a new set of URLs from the next
  downloaded pages.
• Advantages
• Less communication overhead.
• Absolute number of exchanged URLs will decrease.

24
URL Exchange Reduction Replication

• The number of incoming links to pages on the web
  follows a Zipfan distribution.
• Reduce URL exchanges by replicating the most
  popular URLs at each c-proc and stop
  transferring them.
• Identify the most popular k URLs based on the
  image of the web collected in a previous crawl
  (or on the fly) and replicate them.
• Significantly reduce URL exchanges, even if we
  replicate a small number of URLs.
• Replicated URLs may be used as the seed URLs.

25
Ways to Partition the WebURL-hash Based

• Partition based on hash value of the URL.
• Pages in the same site can be assigned to
  different c-procs.
• Locality of link structure is not reflected in
  the partition.
• There will be many inter-partition links.

26
Ways to Partition the WebSite-hash Based

• Compute the hash value only on the site name of a
  URL.
• Pages in the same site will be allocated to the
  same partition.
• Only some of the inter-site links will be
  inter-partition links.
• Reduce the number of inter-partition links
  significantly.

27
Ways to Partition the WebHierarchical

• Partition the web hierarchically based on the
  URLs of pages.
• For example, divide the web into three
  partitions
• .Com domain.
• .Net domain.
• All other pages.
• Fewer inter-partition links - pages may point to
  more pages in the same domain.
• In preliminary experiments, no significant
  difference between the previous scheme, as long
  as each scheme splits the web into roughly the
  same number of partitions.

28
Summary of Options Discussed
29
Evaluation Models

• Metrics that will quantify the advantages and
  disadvantages of different parallel crawling
  schemes, and used in the experiments
• Overlap
• Coverage
• Quality
• Communication overhead

30
Evaluation ModelsOverlap

• We define the overlap of downloaded pages as
• N the total number of pages downloaded.
• I the number of unique pages downloaded.
• The goal of a parallel crawler is to minimize the
  overlap.
• Firewall or exchange modes downloads only within
  partition - overlap is always zero.

31
Evaluation ModelsCoverage

• Not all pages get downloaded.
• In firewall mode based crawlers in in particular.
• We define the coverage of downloaded pages as
• I number of unique pages downloaded.
• U the total number downloaded.

32
Evaluation ModelsQuality

• Crawlers cannot download the whole web.
• Try to download an importantor relevant
  section of the web.
• To implement this policy importance metric (like
  backlink count).
• A single-process crawler - constantly keeps track
  of how many backlinks each page has, and first
  visits the page with the highest backlink count.
• Pages downloaded in this way may not be the top 1
  million pages, because the page selection is not
  based on the entire web, only on what has been
  seen so far.

33
Evaluation ModelsQuality Cont.

• Formalization of quality of downloaded pages
• A hypothetical oracle crawler, which knows the
  exact importance of every page.
• PN - most important N pages the oracle crawler
  downloads.
• AN - set of N pages that an actual crawler
  downloaded.
• The quality of a parallel crawler may be worse
  than single-process - metrics depend on the
  global structure of the web.
• Each c-proc knows only the pages it downloaded -
  less information on page importance than a
  single-process crawler.
• To avoid this need to periodically exchange
  information on page importance.
• Quality of an exchange mode crawler may vary
  depending on how often it exchanges information.

34
Evaluation ModelsCommunication Overhead

• In exchange mode need to exchange messages to
  coordinate their work swap their
  inter-partition URLs periodically.
• To quantify how much communication is required
  for this exchange, we define communication
  overhead as the average number of inter-partition
  URLs exchanged per downloaded page.
• A crawler based on the the firewall and the
  cross-over mode do not have any communication
  overhead, because they do not exchange any
  inter-partition URLs.

35
Comparison of 3 Crawling Modes
