Supervised Learning of Edges and Object Boundaries

1
Supervised Learning ofEdges and Object
Boundaries

• Piotr Dollár
• Zhuowen Tu
• Serge Belongie

2
The problem
?
3
Outline

• I. Motivation
• II. Problem formulation
• III. Learning architecture (BEL)
• IV. Results

4
Outline

• I. Motivation
• Why edges?
• Why not edges?
• Why learning?
• II. Problem formulation
• III. Learning architecture (BEL)
• IV. Results

5
Why edges?

• Reduce dimensionality of data
• Preserve content information
• Useful in applications such as
• object detection
• structure from motion
• tracking

6
Why not edges?

• But, not that useful, why?
• Difficulties
• Modeling assumptions
• Parameters
• Multiple sources of information (brightness,
  color, texture, )
• Real world conditions
• Is edge detection even well defined?

7
Canny edge detection
Canny is optimal w.r.t. some model.
8
Canny edge detection
1. smooth
2. gradient
3. thresh, suppress, link
And yet
9
Canny difficulties

• Modeling assumptions
• Step edges, junctions, etc.
• Parameters
• Scales, threshold, etc.
• Multiple sources of information
• Only handles brightness
• Real world conditions
• Gaussian iid noise? Texture

10
Modern methods

• Modeling assumptions
• Complex models, computationally prohibitive
• Parameters
• Many, may use learning to help tune
• Multiple sources of information
• Typically brightness, color, and texture cues
• Real world conditions
• Aimed at real images

11
Modern methods (Pb)
Pb Martin et al. PAMI04
12
Why learning?

• Modeling assumptions
• minimal
• Parameters
• none
• Multiple sources of information
• Automatically incorporated
• Real world conditions
• training data

13
Outline

• I. Motivation
• II. Problem formulation
• III. Learning architecture (BEL)
• IV. Results

14
Problem formulation (general)
image scene interpretation that can include
spatial location and extent of objects, regions,
object boundaries, curves, etc. 0/1 function
that encodes spatial extent of a component of W
Obtaining optimal or likely W or SW can be
difficult. Let
We seek to learn this distribution directly from
image data. To further reduce complexity, we can
discard the absolute coordinates of S
where N(c) is the neighborhood of I centered at c.
15
Problem formulation (edges)
image segmentation 1 on boundaries of segments,
0 elsewhere
16
Discriminative framework
Goal is to learn from
human labeled images
Given an image I and n interpretations W obtained
by manual annotation, we can compute
Sample positive and negative patches according to
above
Finally train a classifier!
17
Discriminative framework
Edge point present in center?
NO
YES
18
Outline

• I. Motivation
• II. Problem formulation
• III. Learning architecture (BEL)
• IV. Results

19
Learning architecture

• Large training set O(108)
• but correlated
• very variable data
• Want generic, efficient features
• applicability to any domain
• fast computation essential
• Boosting a natural choice

20
AdaBoost
Taken from tutorial by Jiri Matas and Jan Sochman
21
Decision Stumps

• Weak learners

(where f is some feature of x)
22
AdaBoost (decision stumps)
. . .
23
Cascaded classifiers

• Minimize computation during testing
• Especially useful for skewed prior
• Viola-Jones face/pedestrian detection

24
Cascade (AdaBoost)
25
Probabilistic boosting trees

• Expected amount of computation decreases
  significantly
• Once a mistake is made, it cannot be undone
• Cascade also made problem easier! Ideally,
  splitting data creates two sub-problems each much
  easier than original

26
Probabilistic boosting trees
27
Probabilistic boosting trees

• Retain efficiency of cascades
• Add power when necessary
• Prone to overfitting
• Tree was necessary to obtain good results.

28
Haar features

• Feature response
• (image response to green squares)
• (image response to red squares)
• Applied to many views of the data
• grayscale, color, Gabor filter outputs, etc.
• at many orientations, locations, etc
• Fast computation using integral images
• Hundreds of thousands of candidate features

29
Outline

• I. Motivation
• II. Problem formulation
• III. Learning architecture (BEL)
• IV. Results
• Gestalt laws
• Natural images
• Road detection
• Object Boundaries

30
Results

• Boosted edge learning (BEL)
• Compare to method with best known performance
  (Pb), and also to Canny
• Comparison not quite fair

Pb Martin et al. PAMI04
31
Gestalt laws

• Gestalt laws of perceptual organization
• Symmetry, closure, parallelism, etc.
• Govern how component parts are organized into
  overall patterns
• The hard part of edge detection
• What can and cannot be achieved in our framework?

32
Analogies

• AB C ?

33
Gestalt laws parallelism
34
Gestalt laws modal completion
35
Gestalt laws alternate interpretation
36
Outline

• I. Motivation
• II. Problem formulation
• III. Learning architecture (BEL)
• IV. Results
• Gestalt laws
• Natural images
• Road detection
• Object Boundaries

37
Natural Images

• Berkeley Segmentation Dataset and Benchmark
• Standard dataset for edge detection with 300
  manually annotated images
• Modern benchmark for comparing edge detection
  algorithms
• Notes
• Edge detection in natural images is hard
• Possibly ill-defined problem
• Evil but necessary comparison

38
Natural Images results
39
Natural Images results
40
Natural Images probabilities
human
BEL
Pb
41
Outline

• I. Motivation
• II. Problem formulation
• III. Learning architecture (BEL)
• IV. Results
• Gestalt laws
• Natural images
• Road detection
• Object Boundaries

42
Road detection
location of roads in scene 1 if pixel is on the
road, 0 elsewhere

• Road detection is not edge detection
• But same learning architecture
• Ground truth obtained from map data

43
Road detection (training)
(the 2 training images)
44
Road detection (testing)
(the testing image)
(Winchester Dr. was not detected)
45
Outline

• I. Motivation
• II. Problem formulation
• III. Learning architecture (BEL)
• IV. Results
• Gestalt laws
• Natural images
• Road detection
• Object Boundaries

46
Object boundaries
location and extent of object of interest 1 on
boundaries of object, 0 elsewhere

• Must tune to specific type of edge
• Algorithms that model edges not applicable
• Potentially most useful application

47
Object boundaries (context)
48
Object boundaries (training)

49
Object boundaries (ground truth)
50
Object boundaries (Canny)
F-score .10
51
Object boundaries (Pb)
F-score .13
52
Object boundaries (BEL)
F-score .79
53
Algorithm roundup
54
Summary

• Define edges only in terms of labeled data,
  minimal modeling assumptions
• Minimize human effort in adapting algorithm to
  particular domain

• Fast, affordable edge detection for the masses!

55
Thank you!
