Jet Fuel Vaporization and Condensation: Modeling and Validation

1
Jet Fuel Vaporization and Condensation Modeling
and Validation

• C.E. Polymeropoulos
• Robert Ochs
• Rutgers, The State
• University of New
• Jersey

• International Aircraft
• Systems Fire Protection
• Working Group Meeting

2
Part I Physical Considerations and Modeling
3
Motivation

• Combustible mixtures can be generated in the
  ullage of aircraft fuel tanks
• Need for estimating temporal dependence of F/A
  on
• Fuel Loading
• Temperature of the liquid fuel and tank walls
• Ambient pressure and temperature

4
Physical Considerations

• 3D natural convection heat and mass transfer
• Liquid vaporization
• Vapor condensation
• Variable Pa and Ta
• Multicomponent vaporization and condensation
• Well mixed liquid and gas phases
• Rayleigh number of liquid o(106)
• Rayleigh number of ullage o(109)

5
Principal Assumptions

• Well mixed gas and liquid phases
• Uniformity of temperatures and species
  concentrations in the ullage and in the
  evaporating liquid fuel pool
• Use of available experimental liquid fuel and
  tank wall temperatures
• Quasi-steady transport using heat transfer
  correlations and the analogy between heat and
  mass transfer for estimating film coefficients
  for heat and mass transfer
• Liquid Jet A composition from published data from
  samples with similar flash points as those tested

6
Heat and Mass Transport

• Liquid Surfaces (species evaporation/condensation)

• Fuel species mass balance
• Henrys law (liquid/vapor equilibrium)
• Wagners equation (species vapor pressures)
• Ullage Control Volume (variable pressure and
  temperature)
• Fuel species mass balance
• Overall mass balance (outflow/inflow)
• Overall energy balance
• Natural convection enclosure heat transfer
  correlations
• Heat and mass transfer analogy for the mass
  transfer coefficients

7
Liquid Jet A Composition

• Liquid Jet A composition depends on origin and
  weathering
• Jet A samples with different flash points were
  characterized by Woodrow (2003)
• Results in terms of C5-C20 Alkanes
• Computed vapor pressures in agreement with
  measured data
• JP8 used with FAA testing in the range of 115-125
  Deg. F.
• Present results use compositions corresponding to
  samples with F.P.115 Deg. F. and 120 Deg. F.
  from the Woodrow (2003) data

8
Composition of the Fuels Usedfrom Woodrow (2003)
9
Part II Experimentation
10
Requirements for Experimental Setup

• Ability to vary fuel tank floor temperature with
  uniform floor heating
• Setup with capability of changing ambient
  temperature and pressure with controlled profiles
• Measurement of temporal changes in liquid,
  surface, ullage, and ambient temperatures
• Ability to asses the concentration of fuel in the
  ullage at a point in time

11
Measuring Input Parameters for the Model
Heat Transfer
Mass Transfer
Fuel Properties

• FID Hydrocarbon analyzer used to measure the
  concentration of evolved gasses in the ullage
• Pressure measurement for vaporization calculations

• Fuel tested in lab for flashpoint
• Used fuel composition from published data of
  fuels with similar flashpoints

• Thermocouples on tank surface, ullage, and liquid
  fuel.

12
Experimental Setup

• Fuel tank 36x36x24, ¼ aluminum
• Sample ports
• Heated hydrocarbon sample line
• Pressurization of the sample for sub-atmospheric
  pressure experiments by means of a heated head
  sample pump
• Intermittent (at 10 minute intervals) 30 sec long
  sampling
• FID hydrocarbon analyzer, cal. w/2 propane
• 12 K-type thermocouples
• Blanket heater for uniform floor heating
• Unheated tank walls and ceiling
• JP-8 jet fuel

13
Experimental Setup

• Fuel tank inside environmental chamber
• Programmable variation of chamber pressure and
  temperature
• Vacuum pump system
• Air heating and refrigeration

14
Thermocouple Locations

• Thermocouple Channel
• Left Fuel
• Center Fuel
• Right Fuel
• Left Ullage
• Center Ullage
• Right Ullage
• Rear Surface
• Left Surface
• Top Surface
• Ambient
• Heater
• Heater Temperature Controller

10
9
6
7
5
8
4
3
2
11
1
12
15
Experimental Procedure

• Fill tank with specified quantity of fuel
• Adjust chamber pressure and temperature to
  desired values, let equilibrate for 1-2 hours
• Begin to record data with DAS
• Take initial hydrocarbon reading to get initial
  quasi-equilibrium fuel vapor concentration
• Set tank pressure and temperature as well as the
  temperature variation
• Experiment concludes when hydrocarbon
  concentration levels off and quasi-equilibrium is
  attained

16
Test Matrix

• 5 gallon fuel load for every test
• Temperature, pressure profiles created to
  simulate in-flight conditions

17
Dry Tank Ullage Temperature
Comparison of measured vs. calculated ullage
temperatureShows validity of well-mixed ullage
assumption Calculated vs. Measured Ullage Gas
Temperature
18
Fuel VaporizationConstant Ambient Conditions at
Atmospheric Pressure
Calculated vs. Measured Ullage Vapor Concentration
19
Sea Level Vaporization
Calculated Temporal Mass Transport Occurring
within the Tank
-As fuel temperature increases, mass of liquid
evaporated, and hence stored in the ullage,
increases -As gas concentration in ullage
increases, condensation is seen to occur -As
condensation increases, mass of fuel stored in
the ullage decreases due to fuel condensing
20
Sea Level VaporizationFlammability Assessment
Flammability Assessment using the FAR rule,
0.033ltLFLlt0.045
Flammability Assessment using LeChateliers Rule,
Flammable if LCgt1
21
Simulated Flight Profile up to 30,000 Fuel Tank
Temperatures and Ambient Pressure
Calculated vs. Measured Ullage Vapor Concentration
22
Varying T PModeled Transport Processes
23
Varying T PFlammability Assessment
Flammability Assessment using the FAR rule,
0.033ltLFLlt0.045
Flammability Assessment using LeChateliers Rule,
Flammable if LCgt1
24
Summary of Results

• Experiment was well designed to provide usable
  model validation data
• Model calculations of ullage gas temperature and
  ullage vapor concentration agree well with
  measured values
• Model calculations of mass transport within the
  tank give a good explanation of the processes
  occurring in a fuel tank
• Model can be used to determine the level of
  flammability using either the FAR rule or
  LeChateliers Flammability Rule
• The calculations show that flammability is
  dependent on the composition of the ullage gas.
