Diagnosing Anomalies with NetworkWide Analysis

1
Diagnosing Anomalies with Network-Wide Analysis

• Anukool Lakhina, Mark Crovella, Christophe Diot

2
Network Anomaly Diagnosis

• Am I being attacked?
• Is someone scanning my network?
• Are there worms spreading?
• A sudden traffic shift?
• An equipment outage?
• Something never seen before?

A general, unsupervised method for reliably
detecting and classifying network anomalies is
needed
3
My Talk in One Slide

• A general system to detect classify anomalies
  at ISPs and enterprises
• Central Message Network-wide analysis of
  network data can expose many anomalies
• Analyze readily-available SNMP and NetFlow data
• Expose both operational malicious incidents

4
Motivating Problems
Distributed DOS Attack
Large Traffic Shifts(Operational Event)
Worm scan observable in network-wide traffic
5
Example Problem of Distributed Attacks
NYC
Victimnetwork
LA
ATLA

• Continue to become more prevalent CERT04
• Financial incentives for attackers, e.g.,
  extortion
• Increasing in sophistication worm-compromised
  hosts and bot-nets are massively distributed

6
Today Detect at Edge
NYC
Victimnetwork

• Detection easy
• Anomaly stands out visibly
• Mitigation hard
• Exhausted bandwidth
• Need upstream providers cooperation
• Spoofed sources

LA
ATLA
HSTN
7
Power of Network-Wide Analysis Detect at Core
Peak rate 300Mbps Attack rate 19Mbps/flow
IPLS
Distributed Attacks easier to detect at the
ingress
8
A Need for Network-Wide Management

• Effective diagnosis of attacks requires a
  whole-network approach
• Simultaneously inspecting traffic on all flows
• Useful in many contexts
• Managing traffic in enterprise networks
• Worm propagation, insider misuse, operational
  problems

9
Talk Outline

• Measuring Network-Wide Traffic
• Detecting Network-Wide Anomalies
• Beyond Volume Detection Traffic Features
• Automatic Classification of Anomalies
• Summary

10
Origin-Destination Traffic Flows

• Traffic entering the network at the origin and
  leaving the network at the destination (i.e.,
  the traffic matrix)
• Use routing (IGP, BGP) data to aggregate NetFlow
  traffic into OD flows
• Massive reduction in data collection

11
Networks Evaluated

• Abilene research network (Internet2)
• 11 PoPs, 121 OD flows, anonymized, 1/100
  sampling, 5 min bins
• Géant Europe research network
• 22 PoPs, 484 OD flows, not anonymized, 1/1000
  sampling, 10 min bins
• Sprint European commercial network
• 13 PoPs, 169 OD flows, not anonymized,
  aggregated, 1/250 sampling, 10 min bins

12
But, This is Difficult!
How do we extract anomalies and normal behavior
from noisy, high-dimensional data in a
systematic manner?
13
Turning High Dimensionality into a Strength

• Traditional traffic anomaly diagnosis builds
  normality in time
• Methods exploit temporal correlation
• Whole-network view is an attemptto examine
  normality in space
• Make use of spatial correlation
• Useful for anomaly diagnosis
• Strong trends exhibited throughout network are
  likely to be normal
• Anomalies break relationships between traffic
  measures

14
The Subspace Method LCDSIGCOMM 04

• An approach to separate normal anomalous
  network-wide traffic
• Designate temporal patterns most common to all
  the OD flows as the normal subspace
• Remaining temporal patterns form the anomalous
  subspace
• Then, decompose traffic in all OD flows by
  projecting onto the two subspaces to obtain

Residual trafficvector
Traffic vector of all OD flows at a particular
point in time
Normal trafficvector
15
The Subspace Method, Geometrically
In general, anomalous traffic results in a large
sizeof For higher dimensions, use Principal
Component Analysis LPCSIGMETRICS 04
Traffic on Flow 2
Traffic on Flow 1
16
Subspace Method Detection

• Error Bounds on Squared Prediction Error
• Assuming Normal Errors
• Jackson and Mudholkar, 1979
• Full details in our paper LCDSIGCOMM 04

17
An example malicious anomaly
No Dominant Source IP Dominant Dest. IP 80 of
P and 92 of F traffic. Cause DOS attack
18
An Operational Anomaly
19
Summary of Anomaly Types Found LCDIMC04
False Alarms
Unknown
Traffic ShiftOutageWormPoint-Multipoint
Alpha
Overloads
DOS
Scans
20
Automatically Classifying Anomalies
LCDSIGCOMM05

• Goal Classify anomalies without restricting
  yourself to a predefined set of anomalies
• Approach Leverage 4-tuple header fields
• SrcIP, SrcPort, DstIP, DstPort
• In particular, measure dispersion in features
• Then, apply off-the-shelf clustering methods

21
Traffic Feature Distributions

• Typical Traffic

22
Feature Entropy for Classification
Bytes
Port scan dwarfed in volume metrics
Packets
H(Dst IP)
But stands out in feature entropy, which
revealsstructure
H(DstPort)
23
Clustering Known Anomalies (2-D view)
Known Labels
Cluster Results
Dispersed
Legend Code Red Scanning Single source DOS
attack Multi source DOS attack
(DstIP)
(SrcIP)
(SrcIP)
Concentrated
Dispersed
Summary Correctly classified 292 of 296
injected anomalies
24
Example of Anomaly Clusters
Dispersed
Legend Code Red Scanning Single source DOS
attack Multi source DOS attack
(DstIP)
(SrcIP)
Dispersed
Concentrated
Summary Correctly classified 292 of 296
injected anomalies
25
Summary

• Network-Wide Detection
• Broad range of anomalies with low false alarms
• In papers Highly sensitive detection, even when
  anomaly is 1 of background traffic
• Anomaly Classification
• Feature clusters automatically classify anomalies
• In papers clusters expose new anomalies
• Network-wide data and feature analysis are
  promising tools for general anomaly diagnosis

26
Overview of System We Are Building

• Top level functionality
• Data Collection Processing
• Anomaly Diagnosis
• Data Inspection
• Query Builder
• Web-based interface ajax driven
• Multi-user system

27
More information

• For more information, see papers slides at
• http//cs-people.bu.edu/anukool/pubs.html
• Ongoing Work implementing algorithms in a
  prototype system
• Your feedback cooperation appreciated!
• Comments, data, deployment

28
Screenshot Slides coming soon
29
Backup slides
30
Previous Work on Anomaly Detection

• Largely focused on
• Point solutions
• not a general approach
• Rule-based classification
• not unsupervised
• Data from single links
• not network-wide

31
Automatic Diagnosis of a DOS Attack
Anomaly Detection Anomaly detected in packet
traffic of se1 to fr1 OD flow
Anomaly Classification DDOS attack Flooding
attack across dispersed destination ports, and
concentrated on single victim IP 193.54.168.72
(univ-paris8.fr)
32
Automatic Diagnosis of a Network Scan
Anomaly Detection Anomaly detected in entropy
traffic of at1 to le1 OD flow not visible in
bytes or packets
Anomaly Classification Network scan across
dispersed destinations for single TCP port 6129
(used by the Dameware remote administration
software, known to be vulnerable and often used
by viruses).
33
Abilene Clusters Reveal New Anomalies
Insights 3 and 4 different types of
scanning 7 NAT box?
