Trialog

1

• Trialog
• EHS
• Technology
• Paris, Oct 1999
• www.trialog.com

2
Home Systems Products and Services
3
History
4
Projects

• Trialog is an instrumental player in a number of
  projects focused on Home Networking
• Metering Sockets
• Tele Diagnostic
• FT Télédomotis
• ETHOS Electrical Metering Load Management
• GAP Gas Appliances
• CHABLIS Low-cost intelligent sockets

5
Metering Sockets

• Analysing Power Usage

Metering Sockets Detect Starting time and the
consumption per 15 mn
A BOX records information
PC monitors statistics
6
Freezer / Fridge consumption
7
FT Télédomotis Telco Gateway
CENELEC !
8
ETHOS European Utilities

• In UK, France, Italy, and Denmark electricity
  meters will supply the same type of Information
• Tariff
• Economy-level
• Index, etc.

Heaters, Hot Water, Domestic Appliances can use
this information
9
GAP Gas Utilities
Controller
Heating Zone 1

• Development of Gas Enabler
• Infrastructure to promote Gas usage.
• Gas based heating is widely used in Europe
• More confort,
• More security,
• Less comsumption

Radiator
Valve
Boiler
Heating Zone 2
Thermostat
Interface
Gas Meter
Gas Meter
EHS Powerline Network
10
Chablis Low-Cost Intelligent Sockets

• Intelligent Sockets
• Addresses a large market
• Large markets mean lower costs
• Up to 40 cost reduction

Mono-Directional
Bi-Directional
11
Trialog EHS Road Map

• 1992 Trialog in EHS Components ESPRIT project
• 1994 Implementation of EHS lt 10 KB
• First EHS software on one microprocessor
• 1995 Decision to deliver the software as a
  library
• Development of a new library EHSLite
• Tests Environment, Certification
• 1996 Financial Investment and Products
• Complexity several Media, Micro,
  Standardisation,
• Convergence with EIB and BBus.

12
Initial Available Specification
Application Layer 7
Application Table Directory
Network Layer 3
Route
Data Link Layer 2
Medium Access Rule
Physical Layer 1
Signal Processing medium
dependant
13
Convergence Migration Strategy
EHS Application, EHS Plug Play, EHS Power Line
unchanged
14
EHS 1.3 to A-Mode Migration Strategy

• Minor changes in API
• No change in Hardware

API
Application Process
Network Management
Network Management
Easy Installation
Plug Play
Application Layer
Shared Variable
Command Langage
Network Layer
Hardware
15
Trialog Libraries Approach

• Library tested on
• thousands of test cases
• ensures interoperability
• eases development
• short time to market
• ensures compatibility

Only the necessary part of the protocol is
included in a node
A library includes the FULL EHS Protocol
16
The Library Approach Avantages

• To address
• Technology dimensions
• Evolution of specification
• Interoperability and Conformance
• Reliability / Performance / Optimisation
• Trialog provides to Manufacturers
• EHS Technology Libraries, Tools, Support,
  Training

Which lamp to switch on ? It was simpler before
!....
17
Libraries for Embedded System Applications
8051 H8 ST7
EHSLite for Low-End Appliances 6K ROM , 150 RAM
EHSLiteRx for Receive-Only Appliances 3K ROM ,
100 RAM
Application CallBacks
Application CallBacks
Object Oriented programming
Board Support Package
Board Support Package
modem ST7537
modem ST7537
18
Application Programming Interface (API)

• House Address management
• Create HA
• Distribute HA
• Obtain existing HA
• Address Management
• Start Registration
• Registration Notification
• Add / Remove Group Address
• Remote Application Table Management
• Start Enrolment Verify Entry Validity
• Add / Remove Entry
• Save table in NVRAM

Delay Management Start Delay Delay
Notification Remove Delay Communication
Management Send Message over network Receive
Message Layer 2 acknowledgement
Application
API
Library
19
Library for PC Windows
EHS-WinLib an EHS library for Windows 95
Visual C Reliable Connection with serial link
to a EHS PL box For the development of
Controller / Tester User Interface /
Internet Gateway
20
Development Kit
Internal or external RAM Internal or external ROM
Flash memory or UV PROM, Support for I2C
EEPROM Power Line interface Modem 7537 HS-1 Rx
and Tx LED indicators RS-232 serial link Access
ports of the micro-controller 2 user push
buttons, 2 user LEDs, 1 reset button Several
Power Line tests points Support for the use of
any standard emulator 12 jumpers for configuration
21
A Powerful Development Tool
EHS-Simul runs EHS Applications on a simulated
network AND a real network before they are
embedded on a board
22
EHS-Simul Windows
23
Marketing Actions

• Promotion with STMicroelectronics (Power line
  modem)
• CENELEC
• EHS Books
• Active in Standardisation
• Chairman of EHS Technical Group
• Chairman of Convergence Plug Play Group
• Member of Convergence System Group
• Partnership with Utilities / White Goods
  manufacturers

24
Research and Development
Short-term R D Product oriented Optimisat
ion, Tests, New Library versions Convergence
with Building Mgt Medium-term R D New
technologies com. real-time New markets and
services Internet Technology RF and HAVI
Long-term R D Embedded Java High Speed PL
25
End-to-End Connection
User
Server (Web, CTI,..)
Tel Cable ISDN xDSL
Internet
Gateway
After-Sale Service
