IPv6 Under The Hood
Mark Dowd Principal Security Architect mark_dowd_at_
mcafee.com
2
Overview

• IP version 4 (IPv4) is a core component of the
  Internets TCP/IP suite
• Time-tested, well-understood and extensively
  studied protocol
• Has some shortcomings when addressing the
  changing needs of the Internet (limited address
  space, security issues, functionality
  limitations, and inefficiencies)
• IP version 6 (IPv6) is IPv4s successor, and
  attempts to address these shortcomings

3
Why IPv6?

• IPv6 is the next-generation Internet
  workhorse-protocol
• Many OSs have IPv6 support (Linux, Windows
  XP2/2k3/Vista, BSD..)
• IPv4 protocol stacks are time-tested and proven
  to work in untrusted and uncertain environments,
  IPv6 stacks are not
• Many OSs have fresh stacks that are ripe for the
  hacking
• Same with firewall-based technologies targeted
  for IPv6
• IPv6 connectivity over the Internet is
  increasingly being made available

4
Covered in this Speech

• We will look at some of the basic building blocks
  of IPv6
• We will consider some of the inherent weaknesses
  in some of the IPv6 protocol design
• Problem areas in host OS stack implementations
• Firewall/IDS/IPS bypassing techniques

5
IPv6 Addressing

• IPv6 Addresses are 128-bit
• Represented as 16-bit words separated by colons
  ()
• Example 0102030405060708090a0b0c0d0e0f00
• Sequences of zeros compressed using
• Example 0102000000000000090a0b0c0d0e0f00
  - 0102090a0b0c0d0e0f00

6
IPv6 Addressing

• Link-local addresses (fe80/64) are only visible
  on a local physical link
• Every IPv6-enabled network interface must have a
  link local address
• Usually an interface will auto-configure its
  link-local address when it is enabled (more on
  this later)
• Site-local addresses (fec0/10) are for internal
  networks
• Much like 192.168 and similar ranges for IPv4

7
IPv6 Addressing

• Unique local addresses (FC00/7) are unique
  network ranges within an organization
• Global Unicast addresses (2000/3) are public
  routable IP addresses
• IPv6 has multicast addresses for sending packets
  to groups of nodes simultaneously. Multicasting
  is also used for broadcasts
• There are also anycast addresses, which is like
  multicast except that a packet will be delivered
  to any one node in the group (the closest node)

8
IPv6 Packet Structure

• An IPv6 packet is composed of an IP header,
  followed by any number of optional extension
  headers, followed by an Upper-Layer (UL) protocol
  header data
• Each optional header can be from 8 bytes in
  length up to 2048 (1 byte length header is
  incremented and multiplied by 8)
• There are a few fixed-length ones that dont
  follow these rules (primarily the fragmentation
  header)

9
IPv6 Packet Structure
10
IPv6 Packet Structure
11
IPv6 Extension Headers

• Hop-by-Hop Header if present, is always first
• Comprises a series of options that are processed
  by each routing hop
• Has TLV-based options including router alerts
  (RSVP) and jumbo payload size for large packets

12
IPv6 Extension Headers

• Destination Options Header
• Also has a series of TLV options, but theyre
  just processed by the destination, not
  intermediate routers
• Fragmentation Header for fragmented packets
  (discussed later)
• Routing Header basically the IPv6 equivalent of
  source routing (we will look at this again later
  too)
• AH/ESP Headers for encrypted communications
• IPv6 Headers encapsulation

13
IPv6 Fragmentation

• IPv4 stacks and firewalls experienced a myriad of
  problems related to fragmentation
• Since fragmentation is the basis of some of the
  attacks we will look at with IPv6 as well, the
  process is explained here
• IP packets can have a series of option headers
  (the non-fragmentable part) followed by a
  fragment header, followed by fragmented data
  (fragmentable part)

14
IPv6 Fragmentation (expected traffic)
15
IPv6 Fragmentation (allowable traffic)
16
Address Discovery

• Local nodes can auto-configure themselves on a
  network to some extent
• This is achieved with ICMPv6 Neighbour
  Advert/Solicitation requests
• Replaces ARP
• There are also related Router Advertisement /
  Router Solicitation exchanges to establish
  MTUs, TTLs, and more

17
Address Discovery

• This stuff isnt performed with any level of
  authentication
• Possible to do similar attacks to ARP Spoofing
  that was popular with IPv4
• Originally demonstrated by Van Hauser from THC
  (http//thc.segfault.net/releases.php)

18
OS Stacks

• Many OSs now have IPv6 stacks
• There are a number of problem areas that can be
  easy to get wrong
• Focusing on these areas is a good place to start
  when conducting an audit of an IPv6 stack

19
OS Stacks - Basic Header Parsing

• In general, length manipulations are safer than
  in IPv4
• Length values for the IPv6 header and options
  headers never include the length of the header
  itself, so no math needs to be done on an
  untrusted length value
• Less likely to have integer underflows
• Special case When length is 0 in the IPv6
  header, a Hop-by-Hop header must follow with a
  Jumbogram options
• What happens when a length exists in the IP
  header and a jumbogram option is supplied?
• What about if there is no jumbogram option and
  the IP header length is 0?

20
OS Stacks - Basic Header Parsing

• Optional headers of course need their length
  verified to ensure that they dont specify a
  length larger than the packet
• Failure to do so would result in potential kernel
  panics or memory corruption
• TLV parsing within Destination options and
  Hop-by-Hop options can also skip out of bounds if
  careful checks arent in place
• This is possible on BSD, although it doesnt seem
  to buy you anything (maybe an interesting evasion
  technique)

21
OS Stacks Error Generation

• A number of checks are needed to ensure generated
  errors cant create smurf-like scenarios
• Destination should not be multicast
• Source should not be multicast
• IPv4 mapped addresses are also dangerous,
  exposing potential IPv4 multicast/broadcast
  addresses

22
OS Stacks - Routing

• Usually a host has to be configured to forward
  packets to perform the routing specified in the
  packet
• Many special cases they need to be careful of
• Multicast Destinations
• Multicast Next Hops
• IPv4-mapped Destinations
• IPv4-mapped Next Hops
• Link-local or site-local hops
• Globally-unique local hops

23
OS Stacks - Fragmentation

• Fragmentation is interesting for a few reasons
  errors in implementation, fingerprinting, and
  firewall/IDS de-synchronization
• IPv4 stacks had a few major vulnerabilities due
  to incorrect reassembly
• Errors in fragmentation either result in memory
  corruption, out of bounds kernel reads,
  mistakenly thinking fragments are complete and
  passing it to a higher layer, or accidentally
  including auxilary data

24
OS Stacks Fragmentation Quirks

• Fragmentation also exposes unique behaviour of
  the OS
• Windows will discard fragment queues if overlaps
  are found in most cases
• BSD will discard an overlapped fragment, but keep
  the queue
• Linux allows overlaps using the same algorithm as
  its IPv4 stack (favors earlier fragments)
• Timeouts and thresholds will also differ

25
Firewalling

• IPv6 is a good target to undermine firewall
  rulesets
• Simple packet filtering through to more complex
  state mechanisms
• For packet filtering want to block certain
  upper-layer protocols, extension headers, or more
  specific information (certain ports, or
  properties within extension headers)

26
Firewalling Packet Filtering

• Extension Headers are desirable to filter
• Things like routing extensions can be
  particularly useful in violating policy
• Filtering packets containing them should be
  fairly easy, but there are some tricks to it
• Based around handling fragmented packets

27
Firewalling Packet Filtering

• One method we can employ is the NUL fragment
  technique
• Set the offset to 0 and the MF bit also clear
• OS stacks will all ignore this header and
  continue regular processing
• Some packet filters will try to record it for
  reassembly and so forth
• Linux IPs conntrack netfilter module does this

28
Firewalling Packet Filtering

• Otherwise, we can just fragment a datagram with a
  series of optional headers following
• Put the optional header being filtered in a non
  0-offset fragment

29
Firewalling Packet Filtering

• Most packet filters only check the first
  (0-offset fragment)
• For good reason processing other datagrams is
  wrong because the data in the fragment might not
  even be options
• The only way to detect extensions in these
  fragments is to reassemble the datagram first
• Filters attempting to detect payloads in non-0
  offset fragments are trivially bypassed

30
Firewalling Packet Filtering

• What about upper layer protocols
  (TCP/UDP/ICMP/others) ?
• We can do the same thing in some cases
• Filling the first fragment with just extension
  headers make it hard for the packet filter to
  figure out what kind of data is in the packet
• Dealing with non 0-offset packets is easy to get
  wrong really cant rely on anything after
  fragment header

31
Firewalling Packet Filtering

• Why? Again, it might be halfway through another
  option or some data
• Result Parsing data as extension headers when
  theyre not
• Next Header value in non 0-offset fragment is
  ultimately ignored
• IPTables/IP6Fw actually pays attention to this
  next header to figure out upper-layer protocols,
  so you can match on pretty much arbitrary rules

32
Firewalling Packet Filtering

• Fragmentation is a good way of desynchronizing a
  firewall or IDS
• Using this technique, we make the firewall/packet
  filter see a different kind of packet than the
  end host
• Result incorrect match which could allow packets
  through that are meant to be blocked
• Exploit variances in how the firewall reassembles
  packets and how the end host does

33
Firewalling Duplicate Fragment Sets

• Duplicate Fragment Sets is sending two sets of
  fragments, both of which assemble and can pass a
  firewall inspection
• Both fragment sets have the same ID field
• We then want to have select fragments dropped
  from each assembled fragment set to create a new
  assembled packet that shouldnt have been allowed

34
Firewalling Duplicate Fragment Sets
35
Firewalling Duplicate Fragment Sets

• How do we drop select fragments?
• In IPv4 it was possible setting the TTL on some
  packets to a low value so they would expire after
  the firewall but before the end host
• Thomas Lopatic used an inventive technique
  involving abuse of the timestamp IP option
• In IPv6, its much easier because there are a lot
  of ways to invalidate a packet, especially if
  theyre not examined particularly closely by a
  firewall

36
Firewalling Packet Invalidation

• Low TTL easy technique but probably will be
  detected
• Destination Option TLVs can be used to force the
  host to drop fragments (as can HBH ones, but each
  hop will pick those up)
• Invalid routing options not a 0-type route or
  has a multicast destination
• Valid routing options that have multiple entries
  to deliver to the same host or router just before
  the end host, thus eating up TTLs
• Timing attacks

37
Firewalling Packet Invalidation

• Sometimes packet filters/firewalls will let you
  have unknown headers too, whereas the end host
  will drop them
• Firewalls/filters also often will allow you to
  put hop by hop option headers anywhere, whereas
  end hosts dont
• Insert a HBH option somewhere in the middle of
  the packet and it will never make it through
  processing

38
Firewalling Fragment Stacking

• Fragment stacking is a technique where you put
  multiple fragment headers inside a single
  datagram
• Alternatively, you have a fragment header
  somewhere inside a fragmented packet
• When the packet is reassembled, the newly formed
  packet is still a fragment of another chain!
• You can nest fragment headers arbitrarily deep

39
Firewalling Fragment Stacking
40
Firewalling Fragment Stacking

• Useful for messing with firewalls trying to
  reconstruct the packet stream
• Firewalls packet filters record information about
  either the first fragment header they see, or the
  last one
• This can lead to them making inaccurate decisions
  about what the packet really contains
• Also useful for firewalls attempting to cache
  IDs to prevent duplicate fragment set attacks

41
Firewalling Stateful Inspection

• Stateful inspection firewalls are generally
  harder than packet filters
• Fragment duplication and stacking can help to
  bypass them
• Another thing they need to be careful of is
  TCP/UDP header processing
• Some firewalls will inspect flags of a TCP packet
  to decide whether a connection is open or not

42
Firewalling Stateful Inspection

• A trick here was to send an overlapping fragment
  at offset 1 in a TCP packet, overwriting the
  flags portion of the header
• Lots of implementations check for this, even in
  IPv6
• That particular check is not useful in IPv6
  though, because the TCP header doesnt need to
  start at offset 0
• We can pad with extension headers, thus causing
  it to check potentially invalid flags
• Pretty hard to pull off still though, due to the
  way most hosts to fragmentation

43
Firewalling Stateful Inspection

• We can also supply TCP or UDP packets that are
  not going to ever get to the host
• This might be useful if we want the firewall to
  maintain or teardown a connection entry
• We can use the techniques for invalidating
  packets described earlier
• TTLs, routing headers, invalid destinations, and
  so on

44
Firewalling Stateful Inspection

• Routing Headers might also provide some
  interesting possibilities
• What if we route the packet around to a less
  protected interface on a target host?
• Maybe we can use this to elicit some sort of
  response due to misplaced trust
• Windows XP firewall seems to exhibit some
  behavior like this
• What if we could entice a host/router to send a
  packet that was originated by us back to us?
• Using the routing header with the attacking host
  as one of the hops can be used to accomplish this

45
Firewalling Stateful Inspection
46
Firewalling Stateful Inspection
47
Firewalling Stateful Inspection

• Lets say we wanted to contact a target machine
  on port 22, but the firewall only lets in port 80
• It has TCP connection awareness
• We send a packet (src port 22, dest port 80)
  with their IP as a source address and destination
• They get it, inspect the routing header and send
  it back
• Should redirect in this case really, but at least
  Windows and BSD seem to route wherever you want
  (Linux will send a redirect)

48
Firewalling Stateful Inspection

• Firewall sees packet (source port 22, dest port
  80) and makes a new connection entry
• We now have the possibility of contacting the
  target on port 22
• Potential problems careful flags checks might
  detect something is up
• Anti-spoofing will see source and destination
  address the same, or at least source address not
  valid for receiving interface
• Tunneling can come in handy here

49
Tunneling Data

• Tunneling is a big issue in IPv6, especially for
  nodes that do both IPv4 and IPv6
• IPv6 over IPv4
• IPv4 over IPv6
• IPv6 over IPv6 (supported by default on Windows)
• Arbitrary levels of nesting
• Combined with fragmentation tricks, firewalls
  have their work cut out for them

50
Tunneling Data

• Tunneling to hosts has several uses
• Bypassing firewall rules
• Contacting hosts behind a firewall using routing
  combined with tunneling
• Contacting non-routable (link-local/site-local)
  addresses using routing headers
• Additional bonus that your tunneled IP data is
  not going to be subject to anti-spoofing and
  other validation in many cases
• Special Address Classes are also useful we
  could route over to their IPv4 accessible network
  for example

51
Questions?

• Any Questions?
