Title: CSE 541 Numerical Methods


1
CSE 541Numerical Methods
  • Monte Carlo Methods

2
Monte-Carlo Methods
  • A Monte-Carlo method refers to any method that
    makes use of random numbers
  • Numerical Analysis
  • Simulation of natural phenomena
  • Simulation of experimental apparatus

3
Monte-Carlo Techniques
  • Sample Applications
  • Integration
  • System simulation
  • Computer graphics modeling and rendering
  • Physical phenomena - radiation transport
  • Communications - bit error rates
  • VLSI designs - tolerance analysis

4
Modelling Fractal Mountains
  • Fractals represent controlled randomness to
    produce natural looking behavior

5
A Monte-Carlo Method to Approximate p
  • Take a unit circle (centered at the origin) and a
    bounding box (square with side length 2)
  • Acircle p
  • Asquare 4
  • Take a point (x, y) inside the square
  • The probability ((x, y) -1 x 1 and -1 y
    1 is inside the circle) chance the point
    will be inside the circle

outside
inside
For example, what is the chance of a heads if you
flip a coin?
6
A Monte-Carlo Method to Approximate p
  • OK, lets flip a coin
  • Consider the following procedure
  • Initialize Ncircle 0 and Nsquare 0
  • Choose a random point (x, y)
  • If (x, y) is inside the circle then increment
    Ncircle
  • Increment Nsquare
  • Repeat

Run this N times
7
A Monte-Carlo Method to Approximate p
  • The probability a random point is inside the unit
    circle
  • Choose N random points and let M Ncircle
  • Approximate p

As N Þ a better approximation
8
Estimate p Using Monte-Carlo
  • Results
  • N 10,000 p 3.1388
  • N 100,000 p 3.1452
  • N 1,000,000 p 3.14164
  • N 10,000,000 p 3.1422784

9
Choosing Random Numbers
  • Does it matter how the N random numbers are
    chosen?
  • Choose random numbers evenly across the space

p 4
p 4
p 0
10
Estimate p Using Monte-Carlo
  • double x, y, pi
  • const int m_nMaxSamples 100000000
  • int count 0
  • for (int k 0 k
  • x 2.0 drand48() 1.0 // Map to the range
    -1,1
  • y 2.0 drand48() 1.0
  • if (xx yy
  • pi 4.0 (double) count / (double)m_nMaxSamples

11
Random Numbers
  • Definition of random from Merriam-Webster
  • Main Entry randomFunction adjectiveDate
    15651 a lacking a definite plan, purpose, or
    pattern b made, done, or chosen at random random passages from the book2 a relating to,
    having, or being elements or events with definite
    probability of occurrence b
    being or relating to a set or to an element of a
    set each of whose elements has equal probability
    of occurrence also
    characterized by procedures designed to obtain
    such sets or elements

12
Random Numbers
  • Random numbers
  • A set of numbers that have nothing to do with the
    other numbers in the sequence
  • In a uniform distribution of random numbers in
    the range 0,1 , every number has the same
    chance of turning up
  • 0.00001 is just as likely as 0.5000

13
Random Sampling
  • Use some chaotic system (Balls in a barrel
    Lotto)
  • Use a process that is inherently random
  • Radioactive decay
  • Thermal noise
  • Cosmic ray arrival
  • Tables of a few million random numbers
  • Hooking up a random machine to a computer

14
Computer Generated Random Numbers
  • Definition of algorithm from dictionary.com
  • algorithm
  • n a precise rule (or set of rules) specifying
    how to solve some problem.

15
Random vs. Pseudo-random
  • Random numbers have no defined sequence or
    formulation. Thus, for any n random numbers, each
    appears with equal probability.
  • Computer limitations
  • Algorithms A precise rule (or set of rules)
    specifying how to solve some problem. Implies one
    value depends on the others.
  • Machine precision If we restrict ourselves to
    the set of 32-bit integers, then our numbers will
    start to repeat after some very large n. The
    numbers thus clump within this range and around
    these integers.
  • pseudo-random adj. Of, relating to, or being
    random numbers generated by a definite, nonrandom
    computational process.
  • Computer algorithms are restricted to generating
    pseudo-random numbers

16
John Von Neumann (circa 1946)
  • An algorithm to randomly generate 10 digit
    integers
  • Start with a 10 digit integer
  • Square it and take middle 10 digits from the
    answer
  • Example 57721566492 33317792380594909291
  • Need to map these to a particular range, e.g. 0,
    1
  • Smaller numbers lump together and create short
    loops
  • For example, 4 digit integers
  • 61002 37210000
  • 21002 04410000
  • 41002 16810000
  • 51002 65610000

17
Pseudo-random Number Generators
  • Most pseudo-random number generators use the
    following two tools
  • Modulo arithmetic
  • Large prime numbers

18
Linear Congruential Methods
  • Lehmer (circa 1948)
  • where a, c ³ 0 , m I0,a,c
  • Advantage Very fast
  • Problems
  • Poor choice of the constants can lead to very
    poor sequences
  • The relationship will repeat with a period no
    greater than m

19
The RANDU Generator (IBM, circa 1960s)
  • Algorithm
  • This generator was later found to have a serious
    problem

2D Distribution
20
Prime Numbers
  • The remainder when a number is divided by a prime
    is random
  • The number 231 1 is a prime number, a 75, c
    0, m 231 1
  • This algorithm calculates some number and then
    takes the lower-order bits (mod operator)
  • The integers in the sequence are mapped to 0,
    1, the xis
  • I0 is called the seed of the process

21
The Algorithm Drand48
  • Let a 2736731631558, c 138, and m 248
  • Uses higher-bit integers to generate 48-bit
    random numbers

22
Other Ideas
  • Why use integers?
  • Was more efficient on old computers
  • Why use one seed?
  • Has a greater period than m
  • The RANMAR generator (CERN Library) uses
  • 103 initial seeds and a period of 1043
  • The ultimate random number generator?

23
Properties of Pseudo-random Numbers
  • These algorithms generate periodic sequences
    (hence not random). A random number generated may
    match our initial seed.
  • The restriction to quantized numbers (a
    finite-set), leads to problems in
    high-dimensional space
  • The individual digits in the random number may
    not be independent. There may be a higher
    probability that a 3 will follow a 5.

24
Property 2 Higher Dimensional Space
  • Quantized numbers lead to problems in
    high-dimensional space
  • Many points end up to be co-planar
  • For example, in two dimensions numbers may
    cluster to lines

25
Property 2 Higher Dimensional Space
  • The Marsaglia Effect (1968)
  • Random numbers fall mainly in planes (or
    hyperplanes)
  • 3D distribution of RANDU

Problems seen when observed at the right angle
26
The C Standard Library Functions
  • include
  • Function rand (type man rand on the Unix
    command line)
  • Only results in 16-bit integers
  • Has a periodicity of 231 though
  • Rather poor pseudo-random number generator
  • Function random (type man random)
  • Results in 32-bit integers
  • Uses rand() to build an initial table
  • Has a periodicity of around 269
  • Slightly better pseudo-random number generator
  • Function drand48 (type man drand48)
  • Uses double precision
  • Pretty good routine
  • May not be as portable

27
Initializing With Seeds
  • You can set the seed with srand, srandom or
    srand48
  • A seed value will generate the same sequence of
    random numbers
  • Deterministic program using the same seed will
    produce the same program output on each run
  • Non-deterministic program using a different seed
    on each run will produce different program
    outputs
  • For example, call the seed method with the
    lower-order bits of the system clock

28
Deterministic Program
  • A procedurally generated mountain
  • If we re-generate the fractal mountain every time
    the camera moves, we dont want the mountain to
    change

29
Mapping Random Numbers
  • Most computer library support for random numbers
    only provides random numbers over a fixed range
  • Random integers from zero to some maximum M
  • Random floating-point or double-precision numbers
    mapped to the range 0 1
  • You need to map this to your desired range
  • Our approximation to p example requires numbers
    in the range -1 1
  • Use translate and scale operations (remember
    Gaussian Quadrature)

30
Monte-Carlo Techniques
  • Problem What is the probability that 10 dice
    throws add up exactly to 32?
  • Exact Way. Calculate this exactly by counting all
    possible ways of making 32 from 10 dice
  • We may not always be able to compute an exact
    way
  • Approximate (Lazy) Way. Simulate throwing the
    dice (say 500 times), count the number of times
    the results add up to 32, and divide this by 500.
  • Lazy Way can get quite close to the correct
    answer quite quickly

31
1D Function Integration
  • Exact way Analytical Integration
  • Approximate way Quadrature
  • Approximate way Monte-Carlo
  • Randomly sample the area enclosed by x ÃŽ a, b
    and y ÃŽ 0, max (p(x))

32
1D Function Integration
  • Intuitively

33
Monte-Carlo And Integration
  • A Monte-Carlo approach can be advantageous for
    integration if
  • The function is defined over a complicated domain
  • Integration in higher dimensions

34
Complicated Domain
  • Define two domains
  • D Complicated domain
  • D Simple domain and a superset of D
  • Pick random points over D
  • Count
  • N points over D
  • N points over D

35
Complex and Higher Dimensions
  • Higher dimensional shapes can be complex
  • Need a very fine grid for standard quadrature to
    get samples in Region R
  • Monte-Carlo methods can make use of all points in
    the simpler domain

36
Higher Dimensions
  • Our Standard Quadrature approaches compute a
    numerical value of a definite integral by
  • where points xi are uniformly spaced

37
Higher Dimensions
  • Consider integral in d dimensions
  • The error with N sampling points is

38
Monte-Carlo Error
  • From probability theory, the Monte Carlo error
    decreases with sample size N as
  • independent of dimension d
