Trigger Systems at LHC Experiments
Institute of High Energy Physics of the Austrian
Academy of Sciences
  • Manfred Jeitler
  • Instr-2008, Novosibirsk, March 2008

2
  • first particle physics experiments needed no
    trigger
  • were looking for most frequent events
  • people observed all events and then saw which of
    them occurred at which frequency

3
  • later physicists started to look for rare events
  • frequent events were known already
  • searching good events among thousands of
    background events was partly done by auxiliary
    staff
  • scanning girls for bubble chamber photographs

4
(No Transcript)
5
  • due to the extremely small cross sections of
    processes now under investigation it is
    impossible to check all events by hand
  • 1013 background events to one signal event
  • it would not even be possible to record all data
    in computer memories
  • we need a fast, automated decision (trigger) if
    an event is to be recorded or not

6
  • detectors yielding electrical output signals
    allow to select events to be recorded by
    electronic devices
  • thresholds (discriminators)
  • logical combinations (AND, OR, NOT)
  • delays
  • available in commercial modules
  • connections by cables (LEMO cables)

7
  • because of the enormous amounts of data at major
    modern experiments electronic processing by such
    individual modules is impractical
  • too big
  • too expensive
  • too error-prone
  • too long signal propagation times
  • ? use custom-made highly integrated electronic
    components (chips)

10 logical operations / module ?
40000 logical operations in one
chip
8
example trigger logic of the L1-trigger of the
CMS experiment
9
(No Transcript)
10
When do we trigger ?
  • bunch structure of the LHC collider
  • bunches of particles
  • 40 MHz
  • a bunch arrives every 25 ns
  • bunches are spaced at 7.5 meters from each other
  • bunch spacing of 125 ns for heavy-ion operation
  • at nominal luminosity of the LHC collider (1034
    cm-2 s-1) one expects about 20 proton-proton
    interactions for each collision of two bunches
  • only a small fraction of these bunch crossings
    contains at least one collision event which is
    potentially interesting for searching for new
    physics
  • in this case all information for this bunch
    crossing is recorded for subsequent data analysis
    and background suppression
  • luminosity quoted for ATLAS and CMS
  • reduced luminosity for LHCb (b-physics
    experiment)
  • heavy-ion luminosity much smaller

11
the LHC experiments
  • 4 major experiments
  • 3 different main physics goals
  • general purpose Higgs, Susy, .....
    ATLASCMS
  • b-physics LHCb
  • heavy ion physics ALICE
  • different emphasis on trigger
  • ATLASCMS high rates, many different trigger
    channels
  • LHCb lower luminosity, need very good vertex
    resolution (b-decays)
  • ALICE much lower luminosity for heavy ions,
    lower event rates, very high event multiplicities

12
trigger first level high
level ATLAS, CMS 40 MHz ? 100 kHz ? 100
Hz LHCb 40 MHz ? 1 MHz ? 2
kHz ALICE 10 kHz ? 1 kHz ? 100 Hz
Event size (bytes)
13
How do we trigger ?
  • use as much information about the event as
    possible
  • allows for the best separation of signal and
    background
  • ideal case complete analysis using all the
    data supplied by the detector
  • problem at a rate of 40 MHz it is impossible to
    read out all detector data
  • (at sensible cost)
  • have to take preliminary decision based on part
    of the event data only
  • be quick
  • in case of positive trigger decision all detector
    data must still be available
  • the data are stored temporarily in a pipeline
    in the detector electronics
  • short term memory of the detector
  • ring buffer
  • in hardware, can only afford a few µs
  • how to reconcile these contradictory requirements
    ?

14
? multi-level trigger
  • first stage takes preliminary decision based on
    part of the data
  • rate is already strongly reduced at this stage
  • 1 GHz of events ( 40 MHz bunch crossings) ?
    100 kHz
  • only for these bunch crossings are all the
    detector data read out of the pipelines
  • still it would not be possible (with reasonable
    effort and cost) to write all these data to tape
    for subsequent analysis and permanent storage
  • the second stage can use all detector data and
    perform a complete analysis of events
  • further reduction of rate 100 kHz ? 100 Hz
  • only the events thus selected (twice filtered)
    are permanently recorded

15
How does the trigger actually select events ?
  • the first trigger stage has to process a limited
    amount of data within a very short time
  • relatively simple algorithms
  • special electronic components
  • ASICs (Application Specific Integrated Circuits)
  • FPGAs (Field Programmable Gate Arrays)
  • something in between hardware and software
    firmware
  • written in programming language (VHDL) and
    compiled
  • fast (uses always same number of clock cycles)
  • can be modified at any time when using FPGAs
  • the second stage (High-Level Trigger) has to
    use complex algorithms
  • not time-critical any more (all detector data
    have already been retrieved)
  • uses a computer farm (large number of PCs)
  • programmed in high-level language (C)

16
How does the trigger actually select events ?
  • the first trigger stage has to process a limited
    amount of data within a very short time
  • relatively simple algorithms
  • special electronic components
  • ASICs (Application Specific Integrated Circuits)
  • FPGAs (Field Programmable Gate Arrays)
  • something in between hardware and software
    firmware
  • written in programming language (VHDL) and
    compiled
  • fast (uses always same number of clock cycles)
  • can be modified at any time when using FPGAs
  • the second stage (High-Level Trigger) has to
    use complex algorithms
  • not time-critical any more (all detector data
    have already been retrieved)
  • uses a computer farm (large number of PCs)
  • programmed in high-level language (C)
  • see Marta Felcinis talk tomorrow

17
ATLASCMSwhats the difference ?
  • similar task
  • similar conditions
  • similar technology

18
ATLASCMSwhats the difference ?
  • similar task
  • similar conditions
  • similar technology
  • lets hope both ATLAS and CMS will fly ....
  • .... and none will crash

19
ATLASCMSwhat is common ?
  • same physics objectives
  • same input rate
  • 40 MHz bunch crossing frequency
  • similar rate after Level-1 trigger
  • 50 .. 100 kHz
  • similar final event rate
  • 100 .. 200 Hz to tape
  • similar allowed latency
  • pipeline length
  • within this time, Level-1 trigger decision must
    be taken and detectors must be read out
  • 3 µs
  • 2.5 µs for ATLAS, 3.2 µs for CMS

20
ATLASCMSwhat is different ?
  • different magnetic field
  • toroidal field in ATLAS (plus central solenoid)
  • get track momentum from ? (pseudorapidity)
  • solenoidal field only in CMS
  • get track momentum from f (azimuth)
  • number of trigger stages
  • two stages (Level-1 and High-Level Trigger)
    in CMS
  • ATLAS has intermediate stage between the two
    Level-2
  • Level-2 receives Regions of Interest (RoI)
    information from Level-1
  • takes a closer look at these regions
  • reduces rate to 3.5 kHz
  • allows to reduce data traffic

21
ATLASCMSwhich signals are used by the
first-level trigger ?
  • muons
  • tracks
  • several types of detectors (different
    requirements for barrel and endcaps)
  • in ATLAS
  • RPC (Resistive Plate Chambers) barrel
  • TGC (Thin Gap Chambers) endcaps
  • not in trigger MDT (Monitored Drift Tubes)
  • in CMS
  • DT (Drift Tubes) barrel
  • CSC (Cathode Strip Chambers) endcaps
  • RPC (Resistive Plate Chambers) barrel
    endcaps
  • calorimeters
  • clusters
  • electrons, jets, transverse energy, missing
    transverse energy
  • electromagnetic calorimeter
  • hadron calorimeter
  • only in high-level trigger tracker detectors
  • silicon strip and pixel detectors, in ATLAS also
    straw tubes
  • cannot be read out quickly enough

22
how to find muon tracks ?(CMS solenoidal field)
23
calorimeter trigger
24
ATLASCMSprinciple of the first-level trigger
  • data are stored in pipelines for a few
    microseconds
  • e.g. in CMS 3.2 ?s 128 clock cycles at 40
    MHz
  • question of cost
  • decision must never take longer! (must be
    synchronous!)
  • ? no iterative algorithms
  • decision based on look-up tables
  • all possible cases are provided for
  • OR, AND, NOT can also be represented in this way

25
principle of event selection ATLAS vs. CMS
  • CMS
  • no cuts at individual low-level trigger systems
  • only look for muons, electrons, jets, choose the
    best of these candidate objects and forward to
    Level-1 Global trigger
  • so, all possible kinds of events may be combined
  • selection is only made by Level-1 Global
    Trigger
  • trigger information from all muon detectors and
    calorimeter systems available completely
    flexible
  • High-Level trigger analyzes complete detector
    data for the whole detector
  • ATLAS
  • Level-1 trigger delivers numbers of candidate
    objects
  • muon tracks, electron candidates, jets over
    appropriate threshold
  • no topological information used (no angular
    correlation between different objects)
  • Level-2 trigger carries out detailed analysis for
    Regions of Interest
  • using complete detector information for these
    regions
  • High-Level trigger analyzes complete detector
    data for the whole detector

26
LHCb the challenge
  • study b-meson decays
  • need very good vertex resolution
  • lower luminosity
  • 2 ? 1032
  • 50 times lower than ATLAS and CMS
  • aim at having only one proton-proton collision
    per bunch crossing
  • to correctly attribute primary and secondary
    vertices pile-up protection
  • important difference from ATLAS CMS !
  • achieved by deliberately defocusing the beam
  • detector looks rather like a fixed-target
    experiment
  • concentrate on forward direction
  • single-arm forward spectrometer
  • can take useful data at initial low-luminosity
    LHC operation

27
LHCb the approach
  • Level-0 trigger
  • implemented in hardware
  • reduction from 40 MHz bunch-crossing rate down to
    1 MHz
  • 10 times more than ATLAS or CMS !
  • allowed latency 4 µs
  • reject pile-ups (several proton collisions in one
    bunch crossing)
  • uses also vertex detector (VELO, VErtex
    LOcator)
  • different from other LHC experiments
  • alongside muon and calorimeter information
  • High-Level trigger
  • computer farm, using full detector information
  • reduce data rate to 2 kHz
  • 20 times more then ATLAS or CMS

28
ALICE the challenge
  • study heavy-ion collisions
  • quark-gluon plasma
  • study also proton-proton interactions for
    comparison
  • lower bunch-crossing frequency and luminosity for
    heavy ions
  • bunches arrive every 125 ns
  • luminosity 1027 cm-2 s-1
  • factor of 10 millions below proton-proton
    luminosity
  • rate 10 kHz for lead-lead collisions
  • 200 kHz for proton collisions
  • enormous complexity of events
  • tens of thousands of tracks per event
  • per pseudorapidity interval dN / d? 8000

29
(No Transcript)
30
ALICE the approach
  • detectors can be slower, but must cope with high
    track multiplicity
  • ? choice of Time Projection Chamber (TPC) as
    principal tracking detector (drift time up to
    100 µs !)
  • no spatial correlation of objects in first-level
    trigger
  • is done by High Level Trigger, which has much
    bigger time budget
  • past-future protection protect against pile-up
    of events from different bunch crossings
  • some detectors are faster than the TPC ? for
    certain studies, read out only them
  • detector clusters
  • only LHC detector which aims at analyzing partial
    events


31
ALICE the approach
  • detectors can be slower, but must cope with high
    track multiplicity
  • ? choice of Time Projection Chamber (TPC) as
    principal tracking detector (drift time up to
    100 µs !)
  • no spatial correlation of objects in first-level
    trigger
  • is done by High Level Trigger, which has much
    bigger time budget
  • past-future protection protect against pile-up
    of events from different bunch crossings
  • some detectors are faster than the TPC ? for
    certain studies, read out only them
  • detector clusters
  • only LHC detector which aims at analyzing partial
    events


32
ALICE the trigger structure
  • no pipeline (as in the other LHC experiments)
  • trigger dead-time
  • only one or a few events can be buffered at low
    level before readout
  • several low-level triggers with different
    latencies for different subdetectors
  • Level-0 1.2 µs
  • Level-1 6.5 µs
  • Level-2 88 µs
  • computer farm for High-Level Trigger

33
Where we are today ...
  • trigger is one of the most challenging and
    important tasks in major experiments at modern
    hadron colliders
  • at LHC, very similar setup for most experiments
  • only heavy-ion experiment ALICE differs
    significantly
  • when accelerator goes online, we will see which
    solutions are most appropriate
  • draw lessons for the future

34
... and where do we go from here?
  • upgrading the LHC to Super-LHC makes sense only
    if trigger systems are upgraded at the same time
  • ATLAS and CMS will have to use their trackers in
    the first-level trigger
  • but this is easier said than done
  • remember Hans-Jürgen Simonis comments on the CMS
    tracker
  • probably, computers will get faster and more
    (all?) trigger processing will be done in
    software
  • stay tuned ... and help!

35
THANK YOU
  • ??????? to the organizers of Instr-2008 for
    inviting me to give this presentation
  • Thanks to all members of the ATLAS, CMS, LHCb and
    ALICE collaborations who helped me to prepare it

36
backup
37
structure of the ATLAS Level-1 trigger
38
structure of the CMS Level-1 trigger
39
LHCb the detector
Write a Comment
User Comments (0)
