The Dorsal Column-Medial Lemniscal System
"I do not feel obliged to believe that the same
God who has endowed us with sense, reason, and
intellect has intended us to forgo their use." -
Galileo Galilei
2
Introduction

• The dorsal column-medial lemniscus system conveys
  somatic discriminative sensory information from
  touch, vibration, and joint position receptors
• Throughout the system, the fibers are arranged
  somatitopically in relation to their entry into
  the CNS
• The cell bodies reside in the dorsal root and
  trigeminal ganglia

3
Synapsing in the cord
Gracile

• The fibers from the lower
• limbs synapse on the
• Gracile Nucleus.
• Those from the upper
• limbs synpase on the
• Cuneate Nucleus.

Cuneate
4
From below the belt (and above it)

• The fibers from
• the leg, trunk, and
• arm ascend
• ipsilaterally as
• the dorsal columns

C1
C8
L5
5
The great cross over

• Axons leaving the
• dorsal column
• nuclei cross as
• arcuate fibers and
• Ascend as the
• contralateral
• medial lemniscus.

Medulla
6
What about the face?

• At the level of the
• brainstem, primary
• sensory axons from
• the face synapse
• in the principle
• trigeminal nucleus
• and cross to join
• the contralateral
• medial lemniscus.

Midbrain Pons
7
Up, up , and away!

• The medial lemniscus
• ascends to the ventral
• posterior thalamic
• nucleus
• Lateral Division (VPL) - Leg, Trunk, and Arm
• Medial Division (VPM) - Face

8
Top Floor - Cortex

• From the VPL and the
• VPM of the thalamus,
• the fibers extend
• to the primary sensory
• cortex

9
Primary Sensory Cortex

• Sensory information from the dorsal
  column-lemniscal
• system eventually terminates on the postcentral
  gyrus
• of the brain.

10
The Homunculus!
Shoulder, arms, abdomen
Legs, feet, ankles
Hand (large thumb)
The arrangement of fibers correlates to their
entry into the spinal cord.
Face
Tongue
11
And now for the movie.
