Required Navigation Performance RNPRNAV Programs

1
Required Navigation Performance (RNP)/RNAV
Programs

• Roy Grimes
• roy.grimes_at_faa.gov
• Flight Technologies and Procedures Division
  (AFS-400)
• rnp-brfgomwg

FAA / RNP-10 / 3-98
2
PURPOSE

• The purpose of this presentation is to
• Explain the RNP/RNAV concepts and the process
  used to approve operators
• Provide HQ and Regional focal points for RNP/RNAV
• Provide sources of information including the FAA
  RNP website

3
CONTACTS

• FAA Regional RNP/RNAV Focal Points
• (see Web site)
• FAA HQ -Aircraft/Operator Approval Information
• Roy Grimes 202 267-3734
  roy.grimes_at_faa.gov
• Bob Hanson 202 267-3739
  robert.g.hanson_at_faa.gov

4
Oceanic Procedures Website

• Address www.faa.gov/ats/ato/130.htm
• QUICK JUMP MENU links to RVSM, RNP websites,
  Flight Standards Homepage, etc.

5
RNP WEBSITE

• Focuses to date on oceanic ops
• Address www.faa.gov/ats/ato/rnp.htm
• Contents
• FAA Region and HQ RNP Focal Points
• FAA Order 8400.12A
• RNP-10 Operational Approval Outline
• NOTAMS Related RNP-10 Implementation
• Other Files Related to RNP-10 Implementation
• Basic RNAV/RNP-5 AC 90-96

6
FLIGHT STANDARDS INSPECTOR HANDBOOKS AND BULLETINS

• RNP-5 HBAT 98015, HBGA 98-02,
• HBAW 98-06
• RNP-10 HBAT 98-16A, HBGA 98-03A, HBAW 98-07A
• ACCESS www.faa.gov/ats/ato/130.htm QUICK JUMP
  MENU, Aviation Flight Standards Service Safety
  Inspector Handbooks and Bulletins

7
OPERATIONS SPECIFICATIONS PARAGRAPHS

• BO36 CLASS II NAVIGATION USING MULTIPLE LONG
  RANGE NAVIGATION STSTEMS
• B054 CLASS II NAVIGATION USING SINGLE LRNS
• B050 AUTHORIZED AREAS OF EN ROUTE
  OPERATION---LIMITATIONS AND PROVISIONS

8
RNP-10 APPROVAL OUTLINE

• JOINT BULLETIN
• HBAT 98-16A/HBGA 98-03A/HBAW 98-07A
• PARAGRAPH 4 OUTLINES STEPS IN APPROVAL PROCESS
  WITH REFERENCES TO PARAS IN 8400.21A
• Outline with references also published on ATP
  Website

9
WHY DO WE NEED RNP/RNAV

• Navigation component of CNS/ATM
• E.g., 50 NM longitudinal separation criteria
  published in PAC MID/ASIA Regional
  Supplementary Procedures
• Comm DCPC via voice or CPDLC
• Nav RNP-10
• Surveillance 30-min distance verification check
• (ATC judgment ADS needed for extended use)

10
SOURCE DOCUMENTS

• ICAO Doc 9613, 2nd Ed. Manual on Required
  Navigation Performance
• Minimum Aviation System Performance Standards
  RNP for Area Navigation
• (RTCA DO-236A)
• AC 20-RNP and 90-RNP being developed by reps from
  AT,AFS, AIR, Industry in Satellite Operational
  Implementation Team (SOIT) Sub-group
• 4/Q 00 schedule for final draft

11
State CAA RESPONSIBILITY

• ICAO RNP Manual, para 5.5.1
• State of Operator responsible for operational
  approval to operate in various RNP type airspaces

12
TRANSITION PERIOD PROPOSAL

• ESTABLISH RNAV X
• ENCOMPASS CRITERIA OF EXISTING RNAV ACS
• PHASE IN CRITERIA OF DO-236 FOR ENROUTE
  OPERATIONS

13
AIRCRAFT APPROVALS

• RNP APPROVED BY CERTIFICATION
• B747-400, B-777 CNS package incorporates GPS,
  RNP, Satellite Data Link and Surveillance
• B737 and GIV CNS packages incorporate RNP
• A-330 A-340 CNS packages certified (need to
  confirm)
• RNP-5 -10 APPROVED USING EXISTING CRITERIA
  (e.g., ACs) as cited in FAA Order 8400.12A
  AC 90-96

14
RNP/RNAV CONCEPT

• RNP a statement of the navigation performance
  accuracy necessary for operation within a defined
  airspace
• NAV Performance Accuracy The Total System Error
  (TSE) allowed in the individual lateral and
  longitudinal dimensions (95 Probability basis)
• Used for statement of operating requirement
• (E.g., RNP-10, RNP-4, RNP-.3)
• RNP for Time and Vertical application under
  development addressed in DO-236A

15
ELEMENTS OF APPROVAL

• RNP/RNAV IS MORE COMPLETE MEASURE OF NAVIGATION
  PERFORMANCE
• 1. TOTAL SYSTEM ERROR 95 PROBABILITY BASIS
• 2. RNAV EQUIPMENT FEATURES (LOWER RNP TYPES
  ENHANCED FEATURES REQUIRED (EG., ALERTS,
  DISPLAYS)
• 3. LOWER RNP TYPES, EVALUATE
• NAV INTEGRITY CONTAINMENT 10-5
• NAV CONTINUITY CONTAINMENT 10-5

16
ELEMENTS OF TSE LATERAL

• Position estimation (primary)
• Flight Technical Error (FTE)
• Path definition (consistent path computation)
• Display error

17
ELEMENTS OF TSE LONGITUDINAL

• Position estimation (primary)
• Path definition
• Display error

18
RNP
10 NAUTICAL MILES
10 NAUTICAL MILES
10
10
RNP-10 AIRCRAFT EXAMPLE
19
RNP-5 -10 RELATIONSHIP TO EXISTING ACs AND FARs

• Order 8400.12A and AC 90-96 aircraft can be
  evaluated against existing ACs or FARs to
  establish RNP eligibility
• 8400.12A and AC 90-BRNAV show the judgments made
  that establish RNP eligibility using existing
  criteria
• Example INS or IRU system approval IAW PART 121,
  Appendix G can meet RNP-10 for 6.2 hours without
  further evaluation

20
AIRCRAFT SEPARATION - 50NM
21
RNP-10 CAPABILITY IS NAV ELEMENT OF50 NM LATERAL
SEPARATION

• Minimum 50 NM lateral separation (actual track
  separation is 55-60 NM) was implemented on NOPAC
  tracks on 4/23/98
• Specific details of the RNP-10 approval process
  are contained in FAA Order 8400.12A dated 2/9/98

22
RNP-10 APPROVAL PROCESS

23
ISSUES FOR 50-LAT/RNP-10 EXPANSION

• RNP-10 ELIGIBILITY OF INS AND IRS EQUIPPED
  AIRCRAFT FOR NEW PACOTS ROUTES
• EMPHASIS ON WEATHER DEVIAITON PROCEDURES
• PILOT AND CONTROLLER USE OF BEST COMM OPTION FOR
  WX DEVIATIONS HF, HF PHONE PATCH, SAT VOICE,
  CPDLC
• EMPHASIS ON CORRECT FILING OF R EQUIPMENT
  SUFFIX IN ICAO FLIGHT PLAN

24
ISSUES (CONT.)

• CONTINUED INPUT OF OPERATOR AND AIRCRAFT INFO TO
  APPROVALS DATABASE
• ATP-130 RNP WEBSITE SHOWS DATA AND ADDRESS FOR
  DATABASE
• ALASKA/PACIFIC CHART SUPPS UPDATED

25
OPS CONCEPT

• 50NM LAT SEPARATION MINIMUM APPLIED BETWEEN /R
  AIRCRFT.
• ENHANCES CONTROLLER CAPABILITY TO GRANT CLEARANCE
  TO DEVIATE WHEN 100NM TRACK SPACING APPLIED
• UNAPPROVED AIRCRAFT MAY FILE RANDOM TRACKS
  MINIMUM 100NM FROM
• RNP-10 PACOTS TRACKS
• IF JOINING NOPAC, FOLLOW ANCHORAGE NOTAM

26
DOCUMENTS FOR OPERATOR RNP APPROVAL

• Operation Specifications - Air Carrier Operations
  B036, B038, B050
• Letters of Authorization - General Aviation
  Operations (FAA Order 8700.1, Chapter 222)
• Format for the LOA in FAA Order 8400.12A,
  Appendix 3, Documentation Required to Complete
  the Approval Process

27
BASIC RNP-10 ELIGIBILITY GROUPS

• FAA Order 8400.12A reference paragraph is Para12,
  Determining Aircraft Eligibility
• Group I Approval shown in Airplane Flight
  Manual. Approval by aircraft certification
  action.
• Group II Previously approved under existing
  standards
• Group III Approved by data collection

28
GROUP I - AIRCRAFT ELIGIBILITY

• These are aircraft that have been approved by
  aircraft certification for an RNP capability
• If an aircraft has an RNP navigation capability
  stated in the Airplane Flight Manual, then it is
  considered eligible for RNP-10

29
GROUP II- AIRCRAFT

• Aircraft are considered RNP-10 eligible that meet
  one of the following criteria
• Qualify for the /E suffix as defined in the AIM
• Equipped with INSs or IRUS that have been
  approved in accordance with 14 CFR PART 121,
  Appendix G
• Primary means GPS equipped and operated in
  accordance with HBAT 95-09
• Multisensor system approved in accordance with AC
  20-130A
• Supplemental GPS (i.e.., used with another
  approved LRNS) in accordance with AC 90-94 and
  HBAT 95-02
• Currently approved for Australian RNAV or North
  Atlantic MNPS operations

30
GROUP III - AIRCRAFT

• Aircraft that do not satisfy the eligibility for
  Group I or Group II Aircraft
• Operators may obtain approval for Group III
  Aircraft by conducting an operational data
  collection in accordance with FAA Order 8400.12A,
  Appendix 1 or Appendix 6

31
PERIODIC DATA COLLECTION METHOD

• Two procedures
• A hand held GPS receiver is used to grade the
  INS/IRU during flight (high quality unit
  recommended)
• A single, un-updated gate position is used as a
  data point to determine an RNP-10 limit
• Both procedures are contained in Appendix 6 of
  FAA Order 8400.12A

32
RNP-10 TIME LIMITS FOR INS/IRU EQUIPPED AIRCRAFT

• Baseline is 6.2 hours for aircraft approved using
  existing criteria (e.g.., Appendix G of Part 121,
  MNPS approval)
• RNP-10 time limit may be larger if operator or
  manufacturer proves the capability IAW 8400.12A
• Effect of En Route updates
• Automatic DME/DME updating Baseline minus 0.3
  hours
• Automatic DME/VOR updating Baseline minus 0.5
  hours
• Manual updating Baseline minus 1.0 hour

33
EXTENDED INS/IRU TIME LIMIT

• Operators needing extended time limit for the INS
  or IRU take action IAW 8400.12A, Para 12D
• Extended time limit established by Aircraft
  Certification Office during initial certification
  or after evaluation of manufacturer or operator
  data
• Operator can take credit for triple mix using
  operational data to verify what credit is
  justified
• Operator can conduct operational data collection
  IAW Appendix 1 or 6 to justify extended time
  limit for individual INS systems

34
ACO APPROVED RNP-10 TIMELIMIT (AREA OF OPS) FOR
INS AND IRUS

• CAROUSEL IV INS 6.2 HOURS
• LTN 72 INS 6.2 HOURS
• LTN 92 10.0 HOURS
• B767, 747-400, MD-11
• HW IRUS 12 HOURS
• TIME LIMITS FOR INDIVIDUAL OPERATORS EXTENDED
  BASED ON APPENDIX 1 OR 6 DATA COLLECTION

35
ROUTE EVALUATION FOR INS/IRU EQUIPPED AIRCRAFT IN
GROUPS II AND III

• The operator must establish its capability to
  comply with RNP-10 time limit on all RNP-10
  routes (fixed or flex tracks) on which it intends
  to fly
• Start Point for Calculation The calculation
  should start at the point where the system is
  placed in the navigation mode or the point where
  it is expected to be updated

36
ROUTE EVALUATION FOR INS/IRU EQUIPPED AIRCRAFT IN
GROUPS II AND III

• Stop Point for Calculation The stop point may
  be one of the following
• the point at which the aircraft will begin to
  navigate by reference to ICAO Standard Navaids
  (VOR, DME, NDB) and/or comes under radar
  surveillance from ATC or
• the point at which the navigation system is
  expected to be updated
• the point where RNP-10 approval is not required

37
USE OF PRIMARY MEANS GPS FOR RNP-10 OPERATIONS

• Primary navigation GPS meets RNP-10 without time
  limits
• Dual GPS equipment is required
• If GPS is the only long-range navigation system,
  Fault Detection and Exclusion Program (FDE)
  required. (Includes Receiver Autonomous
  Integrity Monitoring (RAIM).
• Max FDE outage is 34 minutes
• Max FDE outage included as condition of dispatch
  or departure

38
GPS FOR RNP-10 OPERATIONS

• Multi-sensor systems incorporating GPS approved
  IAW AC 20-130A are eligible for RNP-10 without a
  time limit
• Aircraft equipped with an approved GPS system and
  another approved LRNS (e.g. INS) are also
  eligible for RNP-10 without time limit
• Approval must be IAW AC 90-94 and HBAT
  95-02

39
PILOT KNOWLEDGE OF RNP-10 REQUIREMENTS

• Commercial operator - Incorporates applicable
  8400.12A items into training programs and manuals

• General Aviation - Must show during application
  process that pilots will possess knowledge of
  RNP-10 policy and procedures
• Operator may elect to have pilots trained using
  in-house program or a contracted program or may
  elect to confirm pilot knowledge on application

40
CONTINUED AIRWORTHINESS (MAINTENANCE) PROGRAMS

• Reference 8400.12A, Paragraph 14
• Previously approved maintenance programs for
  long-range navigation systems should be
  acceptable for RNP-10 operations
• Operators that have not previously been approved
  for oceanic operations (Class II Navigation)
  using long range navigation systems must submit
  appropriate maintenance programs changes for FAA
  review

41
REF. PARAGRAPH, PARA 9, APPLICATION PROCESS

• The application should contain the following
  elements
• (1) Airworthiness Documents that establish the
  aircraft/nav system group being proposed, its
  RNP-10 approval status, and a list of airframes
  in that group
• (2) Approved RNP-10 Time Limit - where INS/IRUs
  only LRNS
• (3) Documentation of RNP-10 area of operations or
  tracks where specific aircraft/nav system is
  eligible
• (4) Documentation of operating practices and
  procedures for RNP-10
• (5) Documentation of pilot and/or dispatcher
  knowledge of RNP-10

42
APPLICATION PROCESS CONTINUED

• (6) Documentation that appropriate Maintenance
  practices and procedures for RNP-10 have been
  adopted
• (7) Minimum Equipment List (MEL) updates, if
  applicable
• (8) Operating history that identifies past
  problems and incidents, if any, and actions
  taken to correct the situation
• (9) Awareness of the necessity for follow up
  action after navigation error reports and the
  potential for removal of RNP-10 operating
  authority

43
CONCLUSION

• States have responsibility to approve aircraft
  and operators for flight on routes where RNP is
  required
• FAA Order 8400.12A contains the process and
  procedures for approval of aircraft and operators
• RNP-10 Operational Approval Outline outline or
  checklist with references to paragraphs in
  8400.12A
• Both are on web site www.faa.gov/ats/ato/rn
  p.htm

44
CONCLUSION

• For questions, contact regional focal points or
  HQ OPRs as necessary
