Title: Projectiles, Energy, Momentum


1
Projectiles, Energy, Momentum
  • Louis Aronowitz
  • Manish Amin
  • Russell Macalintal
  • Alex Kryszuk

2
Diagram
3
Purpose
  • To perform an experiment that will illustrate the
    concepts of physics such as
  • Conservation of momentum
  • Conservation of energy
  • Projectile motion

4
Data to be Collected
  • Mass of car, pendulum, and ball using scale
  • Velocity at which ball is launched (given)
  • Length of Car using meter stick
  • Height of the table using meter stick
  • Final height of the pendulum using meter stick
  • Velocity of car at top of track using Photogate
  • Experimental value of horizontal distance of the
    projectile using meter stick

5
Equations
  • MballVi MpendulumVi (Mball Mpendulum)Vcombo
  • Plug in the data to find the velocity of the ball
    and pendulum combination
  • E (1/2)McomboVi2
  • Use the velocity of the combo to find the total
    energy of the pendulum and ball
  • (1/2)McarV2 MgY (1/2)McarV2
  • Use the initial velocity of the car obtained from
    the photogate to determine the cars final
    velocity at the bottom of the track
  • ?Y Vit (1/2)gt2
  • Use the height of the table and Vi 0 to find
    the time it takes for the projectile to hit the
    floor
  • Vx ?X / t
  • Use the calculated time to find the other value
    for the final velocity of the car

6
Data Collected
  • Mass of Car 0.0255 kg
  • Length of Car 0.07 m
  • Mass of Ball 0.0765 kg
  • Mass of Pendulum 0.204 kg
  • Velocity of the Ball 6.46 m/s
  • Height traveled by Pendulum 0.035 m
  • Velocity of Car at the top 1.675 m/s
  • Height of the Table 0.885 m
  • Distance of Projectile 0.99 m

7
Results
  • Initial velocity of pendulum 1.76 m/s
  • Energy of the Pendulum and Ball combo 0.43 J
  • Energy of the car .092 J
  • Final velocity of car (conservation of energy)
    2.687 m/s
  • Time of flight 0.42 sec
  • Distance traveled by the projectile (accepted
    value) 1.142 m
  • Final velocity of car (kinematic equations)
    2.357 m/s
  • Work of Friction 0.021 J
  • error for distance of projectile 13

8
Sources of Error
  • Energy lost to sound.
  • Wind resistance.
  • Human error in measurement.
  • Entire setup was not aligned.
  • Inconsistency of the pendulum hitting the car.
  • Track isnt sturdy.
