Integral Bridges

1
Integral Bridges

• Development of a constitutive model for soil
  structure interaction

2008 Structures Congress - Crossing Borders
April 24-26, 2008
James Banks Alan Bloodworth Thomas Knight Jeffery
Young
2
Integral Bridges

• Concept
• Problem
• Fundamental Behaviour
• Soil Modelling
• Implementation, Testing and Validation
• Further Work
• Outcomes

3
Integral Bridges
g

• Short Span Bridges
• Full/Shallow height
• Backfilled/embedded
• No expansion joints or bearings
• Reduced maintenance and construction costs

4
The Problem
g
5
Soil Element Behaviour
g

• Granular material
• Typical loading for Integral bridge
• Radial Strain - controlled Cyclic Triaxial Tests
• fundamental behaviour for a single element of
  soil behind an abutment

6
Soil Element Behaviour
7
Mathematical Model

• Mathematical Description of the Soil
• Parameters
• Youngs Modulus (Eh)
• Axial Strain (?ea)
• Relative Density (DR)
• Pre-dilation
• Eh and ?ea are proportional to DR
• Post-dilation
• Same behaviour continues

8
Hardening Parameter
9
Element Modelling in Excel
10
FLAC Model of Element
g

• Modelled in FDM programme FLAC
• Single axi-symmetric element for triaxial tests
• Failure represented by Mohr-Coulomb

11
FLAC Model of Element
12
Further Work
g
Centrifuge Prototype Modelled in FLAC
13
Further Work
g

• Magnitudes
• Triangular Stress Envelope

14
Outcomes
g

• Modelled fundamental behaviour
• Implemented and Validated model
• Extended Model to abutment system
• Better bridges

15
www.mottmac.com
www.civil.soton.ac.uk
James Banks - james.banks_at_mottmac.com
