Water

1
HUAMAN URINARY SYSTEM
2
Human Urinary System
3
Human Urinary System
4
Structure of Mammalian Kidney

• made up of three parts
  -cortex - a
  light outer region
• -medulla - a dark inner region
• -pelvis - a whitish central region leads to
  ureter
• contains numerous tiny tubules called nephrons

5
Structure of Mammalian Kidney
6
Structure of Nephron
7
Nephron
8
How does a nephron work ?
By two ways, one is ultrafiltration and the other
is reabsorption
9
Ultrafiltration

• diameter of tiny artery leading to the glomerulus
  is larger than the one leaving, so a pressure is
  set up as blood tries to force its way out of the
  smaller tube
• the high hydrostatic pressure forces small
  molecules through the walls of capillaries and
  Bowmans capsule into the capsular space

10

• fluid which filtered into the nephron is called
  glomerular filtrate

• glomerular filtrate has the same composition as
  that of blood except that it does not contain
  blood cells, blood proteins blood platelets

11
Reabsorption

• reabsorption is the process of absorbing useful
  substances into capillaries which wrapped around
  tubule
• as in glomerular filtrate, some substances like
  glucose and amino acid are useful to human so
  they are absorbed back while fluid travels along
  the tubule

12

• those urea which remains in the fluid pass the
  whole nephron and finally drains into collecting
  duct which leads to pelvis and form urine

• urine contains mostly water, with urea and excess
  mineral salts

13

• reabsorption of all the glucose and amino acids
  and some salts begins in the first convolution
  and finished when the fluid reaches loop of Henle

14

• useful substances are reabsorbed by diffusion
  down the concentration gradient and active
  transport against concentration gradient

• in collecting duct, water is mainly reabsorbed by
  osmosis but the first convolution actually
  reabsorbs the largest amount of water

15
Functions of Kidney

• kidney mainly has three functions
• osmoregulation
• removal of excess salt
• excretion

16
Functions of Kidney -
Osmoregulation
drink a lot of water
Amount of water in blood CONSTANT
17
Functions of Kidney -
Osmoregulation
after sweating
Amount of water in blood CONSTANT
18
Functions of Kidney -
Removal of Excess Salt
after eating a salty meal
19
Functions of Kidney -
Excretion

• amino acids are broken down in liver to form
  urea by deamination
• Urea is carried by blood to the kidneys which
  excrete them from the body in the form of urine

20
Kidney Failure and Artificial Kidney

• some kidney diseases can lead to kidney failure
  and the kidneys can no longer function properly
• toxic substances will accumulate in blood and
  patient will die

21
KIDNEY FAILURE

• Caused by
• Bacterial infection
• External mechanical damage
• High blood pressure

22
Dialysis fluid in
Air trap
Air trap
clean blood

Blood carrying waste
Dialysis fluid out
pump
23

• artificial kidney is a bulky machine attached to
  patient which is used to filter and clean
  patients blood

• artificial kidney make use of the principle of
  dialysis. It has a filter made of cellophane
  which acts as a selectively permeable membrane

24

• along one side of the membrane is the patients
  blood while the other side is dialysis fluid
  which has the same contain as plasma except urea

• only urea diffuses from patients blood into
  dialysis fluid through cellophane filter
• blood without urea will return to patient through
  his vein

25

• dialysis fluid flows in direction opposite to
  that of blood flow to increase the efficiency of
  diffusion of urea into dialysis fluid

• other than using artificial kidney, kidney
  transplant is another possible method but only
  few people are willing to donate their kidneys
  after death

26
KIDNEY MACHINE
27
(No Transcript)
28
(No Transcript)
