Title: Finite Geometry in a Nutshell


1
Finite Geometry in a Nutshell
  • Jeffrey Iverson

2
An Introduction
  • Consider a line segment, a stick of thin
  • spaghetti, if you will.

3
An Introduction
  • Consider a line segment, a stick of thin
  • spaghetti, if you will.
  • This segment can be split into smaller and
    smaller segments, suggesting an infinite amount
    of points.

4
An Introduction
  • Consider a line segment, a stick of thin
  • spaghetti, if you will.
  • This segment can be split into smaller and
    smaller segments, suggesting an infinite amount
    of points.
  • In modern times, things are known to be made up
    of atoms and subatomic particles.

5
An Introduction
  • This segment can be split into smaller and
    smaller segments, suggesting an infinite amount
    of points.
  • In modern times, things are known to be made up
    of atoms and subatomic particles.
  • So one is to believe that there are only a finite
    number of atoms in the universe.

6
An Introduction
  • In modern times, things are known to be made up
    of atoms and subatomic particles.
  • So one is to believe that there are only a finite
    number of atoms in the universe.
  • So the question presents itself. Does it make
    sense to investigate a geometry where the axioms
    talked about the existence of finite points?

7
An Introduction
  • So one is to believe that there are only a finite
    number of atoms in the universe.
  • So the question presents itself. Does it make
    sense to investigate a geometry where the axioms
    talked about the existence of finite points?
  • And does it make sense to talk about finite
    geometries?

8
An Introduction


Sure Does!
9
Definition
  • A finite geometry is any geometric system that
    has only a finite number of points. Euclidean
    geometry, for example, is not finite, because a
    Euclidean line contains infinitely many points.
    A finite geometry can have any (finite) number of
    dimensions.

10
Definition (cont)
  • Today, we will define objects in our geometry as
    a non-empty set of points and a non-empty set of
    lines, where a line is a given subset of the set
    of points that contains at least two elements.

11
Definition (cont)
  • Today, we will define objects in our geometry as
    a non-empty set of points and a non-empty set of
    lines, where a line is a given subset of the set
    of points that contains at least two elements.
  • Also, the objects in a given geometry are defined
    by a set of axioms. Any constructed examples of
    the geometry must satisfy every axiom.

12
Definition (cont)
  • Today, we will define objects in our geometry as
    a non-empty set of points and a non-empty set of
    lines, where a line is a given subset of the set
    of points that contains at least two elements.
  • Also, the objects in a given geometry are defined
    by a set of axioms. Any constructed examples of
    the geometry must satisfy every axiom.
  • Lets go over some classical examples of finite
    geometries.

13
Classical examples.
  • Projective Planes
  • Affine Planes
  • Near Linear Spaces
  • Linear Spaces
  • Designs
  • Biplanes

For the Axioms of each of these geometries,
visit http//home.wlu.edu/7Emcraea/Finite_Geometr
y/Introduction/Prob2FiniteGeometries/Problem2.htm
14
Projective Planes
  • Projective Planes
  • Two distinct points are contained in a unique
    line
  • Two distinct lines interest at a unique point
  • There exists four points of which no three are
    incident with the same line.
  • Projective Planes
  • Two distinct points are contained in a unique
    line
  • Two distinct lines interest at a unique point
  • There exists four points of which no three are
    incident with the same line.

The first two axioms are pretty much
self-explanatory.
15
Projective Planes
  • Projective Planes
  • Two distinct points are contained in a unique
    line
  • Two distinct lines interest at a unique point
  • There exists four points of which no three are
    incident with the same line.
  • Projective Planes
  • Two distinct points are contained in a unique
    line
  • Two distinct lines interest at a unique point
  • There exists four points of which no three are
    incident with the same line.

The first two axioms are pretty much
self-explanatory. The third axiom says there are
four points however, with the first two axioms
there must be at least 7 points.
16
Projective Planes
  • So what exactly do we get with only 7 points?
  • Definition In finite geometry, the Fano plane
    is the projective plane with the least number of
    points and lines 7 each.
  • How would we construct this?

17
Constructing the Fano Plane
  • By the axioms for a projective plane, there are
    four points (p, q, r, s), no three of which are
    collinear. So there must be two distinct
    intersecting lines l and l.

18
Constructing the Fano Plane
  • Let q and r be the points that lie on l and l
    respectively, that are distinct from the point of
    intersection s, and let p be the fourth point
    that lies on neither l nor l.

19
Constructing the Fano Plane
  • Any two points determine a unique line, and any
    two lines intersect at a unique point. So create
    a line from l to l from q through p. Also,
    create another line from l to l from r through
    p. Label the intersection q and r.

20
Constructing the Fano Plane
  • By the axioms for a projective plane, all points
    must be connected, thus, we connect q and r,
    creating line l. Note that for any two lines
    (not through p), we must be able to go from a
    given point on any line, through p, to some point
    on another given line. Thus, we
    must create a line from s through p, to l.

21
Constructing the Fano Plane
  • We will call the new point t. Finally, we must
    have the points r, q and t connected by a line.
    The result is the Fano plane.

22
Order of a Projective Plane
  • Theorem
  • A projective plane of order n, has n2n1 points
    as well as the same number of lines. Each line
    contains n1 points and each point lies on n1
    lines.

23
Order of a Projective Plane
  • Proof (partial)
  • Let P be an arbitrary point.
  • By Axiom 1, every point in the plane, X
    determines a line together with P, which clearly
    passes through P.
  • Hence, all the points of X lie on the n1 lines
    incident with P. (not proved).

24
Order of a Projective Plane
  • Proof (partial)
  • Let P be an arbitrary point.
  • By Axiom 1, every point in the plane, X
    determines a line together with P, which clearly
    passes through P.
  • Hence, all the points of X lie on the n1 lines
    incident with P. (not proved).

25
Order of a Projective Plane
  • Proof (partial)
  • Let P be an arbitrary point.
  • By Axiom 1, every point in the plane, X
    determines a line together with P, which clearly
    passes through P.
  • Hence, all the points of X lie on the n1 lines
    incident with P. (not proved).

26
Order of a Projective Plane
  • Proof
  • determines a line together with P, which clearly
    passes through P.
  • Hence, all the points of X lie on the n1 lines
    incident with P. (not proved).
  • Each of these lines are incident with n points
    other than P, so there are n(n1) of them and
    including P, we get n2n1 points in X.

27
Order of a Projective Plane
  • Proof
  • Hence, all the points of X lie on the n1 lines
    incident with P. (not proved).
  • Each of these lines are incident with n points
    other than P, so there are n(n1) of them and
    including P, we get n2n1 points in X.
  • There is a similar type of proof for the number
    of lines in X.

28
More on Fano Planes
  • A Fano Plane is a projective plane of order 2.
  • Every line is incident with 3 points
  • Every point is incident with 3 lines
  • There are 7 points and 7 lines.

29
What about larger planes?
  • Today, it is well established that projective
    planes of order n exist when n is a prime power.
  • It is conjectured that no finite planes exist
    with orders that arent prime powers (not
    currently proven).
  • The best result is the Bruck-Ryser Theorem.

30
What about larger planes?
  • It is conjectured that no finite planes exist
    with orders that arent prime powers (not
    currently proven).
  • The best result is the Bruck-Ryser Theorem.
  • This theorem states If n is a positive integer
    of the form 4k1 or 4k2 and n is not equal to
    the sum of two integer squares, then n is not the
    order of a finite plane.

31
Future Studies
  • Finite Geometry is a huge field.
  • It can involve any finite number of dimensions
  • Incidence matrices
  • And many other different types of finite
    geometries as stated earlier.

32
Homework
  • An affine plane is derived from a projective
    plane by removing a line from the projective
    plane as well as its respective points.
  • Construct an affine plane using a well a simple
    projective plane geometry.

33
Sources
  • http//home.wlu.edu/7Emcraea/Finite_Geometry/Tabl
    eOfContents/table.html
  • http//www-math.cudenver.edu/7Ewcherowi/courses/m
    6406/m6406f.html
  • http//finitegeometry.org/
  • http//www.answers.com/topic/fano-plane
