Title: Stanislaw Wasilewski


1
A PRELIMINARY STUDY OF THE UNSTEADY STATES OF THE
VENTILATION PARAMETERS AT THE LONGWALL FACE
DURING THE SHEARER OPERATION
  • by
  • Stanislaw Wasilewski
  • Strata Mechanics Institute of the Polish Academy
    of Sciences, Krakow, PolandAGH University of
    Science and Technology, Krakow Poland
  • Marian Branny
  • AGH University of Science and Technology, Krakow
    Poland

The 12th U.S./North American Mine Ventilation
Symposium Reno University, June 9-11, 2008,
Reno, Nevada, USA
2
A PRELIMINARY STUDY OF THE UNSTEADY STATES OF
THE VENTILATION PARAMETERS AT THE LONGWALL FACE
DURING THE SHEARER OPERATION
  • Introduction
  • Experiment at longwall B-5
  • experiment place
  • experiment conditions
  • Registration of air parameters at longwall B-5
  • Experiment results discussion
  • Summary

3
A PRELIMINARY STUDY OF THE UNSTEADY STATES OF
THE VENTILATION PARAMETERS AT THE LONGWALL FACE
DURING THE SHEARER OPERATION
v
v
Effects of obstructions in the cross-section of
the airways
4
A PRELIMINARY STUDY OF THE UNSTEADY STATES OF
THE VENTILATION PARAMETERS AT THE LONGWALL FACE
DURING THE SHEARER OPERATION
  • Introduction
  • Experiment at longwall B-5
  • experiment place
  • experiment conditions
  • Registration of air parameters at longwall B-5
  • Experiment results discussion
  • Summary

5
A PRELIMINARY STUDY OF THE UNSTEADY STATES OF
THE VENTILATION PARAMETERS AT THE LONGWALL FACE
DURING THE SHEARER OPERATION
Diagram of the area of longwall B-5
6
A PRELIMINARY STUDY OF THE UNSTEADY STATES OF
THE VENTILATION PARAMETERS AT THE LONGWALL FACE
DURING THE SHEARER OPERATION
945 m
longwall B5
250 m
The experiment was done on 13.07.2006 from 800
to 1100 hrs
Technological and raw coal haulage parameters at
longwall B-5
7
A PRELIMINARY STUDY OF THE UNSTEADY STATES OF
THE VENTILATION PARAMETERS AT THE LONGWALL FACE
DURING THE SHEARER OPERATION
  • Introduction
  • Experiment at longwall B-5
  • experiment place
  • experiment conditions
  • Registration of air parameters at longwall B-5
  • Experiment results discussion
  • Summary

8
A PRELIMINARY STUDY OF THE UNSTEADY STATES OF
THE VENTILATION PARAMETERS AT THE LONGWALL FACE
DURING THE SHEARER OPERATION
Diagram of the area of longwall B-5 together with
the site of installation of basic and additional
sensors of the monitoring system
9
A PRELIMINARY STUDY OF THE UNSTEADY STATES OF
THE VENTILATION PARAMETERS AT THE LONGWALL FACE
DURING THE SHEARER OPERATION
Barometric pressures in the area of longwall B-5
during experiment
10
A PRELIMINARY STUDY OF THE UNSTEADY STATES OF
THE VENTILATION PARAMETERS AT THE LONGWALL FACE
DURING THE SHEARER OPERATION
P5-P4
P4-P3
P5-P3
Diagram of sensors distribution at longwall B-5
during the experiment on 13.07.2005
11
A PRELIMINARY STUDY OF THE UNSTEADY STATES OF
THE VENTILATION PARAMETERS AT THE LONGWALL FACE
DURING THE SHEARER OPERATION
  • Introduction
  • Experiment at longwall B-5
  • experiment place
  • experiment conditions
  • Registration of air parameters at longwall B-5
  • Experiment results discussion
  • Summary

12
A PRELIMINARY STUDY OF THE UNSTEADY STATES OF
THE VENTILATION PARAMETERS AT THE LONGWALL FACE
DURING THE SHEARER OPERATION
Pressure drops in the area of longwall B-5
13
A PRELIMINARY STUDY OF THE UNSTEADY STATES OF
THE VENTILATION PARAMETERS AT THE LONGWALL FACE
DURING THE SHEARER OPERATION
Air velocity in the area of longwall B-5
14
A PRELIMINARY STUDY OF THE UNSTEADY STATES OF
THE VENTILATION PARAMETERS AT THE LONGWALL FACE
DURING THE SHEARER OPERATION
The shearer dimensions approximately 1,51,5
2,25 m2,. It was roughly 30 of the active
cross-section of the longwall (S 6,5 m2)
Air velocity at longwall B-5
15
A PRELIMINARY STUDY OF THE UNSTEADY STATES OF
THE VENTILATION PARAMETERS AT THE LONGWALL FACE
DURING THE SHEARER OPERATION
Air velocity at longwall B-5
16
A PRELIMINARY STUDY OF THE UNSTEADY STATES OF
THE VENTILATION PARAMETERS AT THE LONGWALL FACE
DURING THE SHEARER OPERATION
Saturday and Sunday (brake in coal winning)
Air velocity at longwall B-5
17
A PRELIMINARY STUDY OF THE UNSTEADY STATES OF
THE VENTILATION PARAMETERS AT THE LONGWALL FACE
DURING THE SHEARER OPERATION
Methane concentration at longwall B-5
18
A PRELIMINARY STUDY OF THE UNSTEADY STATES OF
THE VENTILATION PARAMETERS AT THE LONGWALL FACE
DURING THE SHEARER OPERATION
Summary
  • Absolute pressures registered in the area of the
    longwall show considerable changeability. During
    coal winning and movement of a shearer in
    longwall evident effects of pressure changes were
    observed.
  • Movement of a shearer in longwall have an impact
    upon temporary and local disturbances of airflow
    what was registered by an anemometer installed at
    the longwall. Large dimensions of machines used
    in heavy duty longwalls, as a mobile obstacle
    limiting the corss-section of the longwall during
    coal winning process, creates a local increase in
    air velocity.
  • During coal winning in a longwall one can observe
    methane concentration increase at sequent
    methanometers alongside the longwall in
    conformity with direction of airflow. At the same
    time one can see the effect of convection of
    methane in the airflow direction.
  • The investigations have confirmed that
    disturbances of ventilation conditions induced by
    movement of a shearer have a local character.
    Emission of methane caused by coal winning has an
    essential influence on formation of methane
    concentration distribution in the longwall.
