COE 341 Data Computer Communications
(T081)Dr. Marwan Abu-Amara

• Chapter 6
• Digital Data Communications Techniques

2
Contents

• Asynchronous and Synchronous Transmission
• Types of Errors
• Error Detection
• Parity Check
• Cyclic Redundancy Check (CRC)

3
Asynchronous and Synchronous Transmission

• To communicate meaningful data serially between
  TX and RX, signal timing should be the same at
  both
• Timing considerations include
• Rate
• Duration
• Spacing
• Need to synchronize RX to TX
• Two ways to achieve this
• Asynchronous Transmission
• Synchronous Transmission

• RX needs to sample the received
• data at mid-points
• So it needs to establish
• - Bit arrival time
• - Bit duration

4
Need for RX and TX Synchronization

• Clock drift (example)
• If the receiver clock drifts by 1 every sample
  time,
• For Tb 1 msec, total drift after 50 bit
  intervals 50 X 0.01 0.5 msec
• i.e. instead of sampling at the middle, the
  receiver will sample bit 50 at the edge of the
  bit
• RX and TX clocks are out-of-synch ? Communication
  Error!
• In general, of correctly sampled bits 0.5
  Tb/(n/100)Tb 50/n,
• where n is the timing error between TX and RX
• Two approaches for correct reception
• Send only a few bits (e.g. a character) at a time
  (that RX can
• sample correctly before losing sync) ?
  Asynchronous Transmission
• Keep receiver clock synchronized with the
  transmitter clock ? Synchronous
  Transmission

5
Asynchronous Transmission Character-Level
Synchronization

• Avoids the timing problem by NOT sending long,
  uninterrupted streams of bits.
• So data is transmitted one character at a time
• Has a distinct start bit
• Consists of only 5 to 8 bits (so drift will not
  be a serious problem)
• Has a distinct stop bit
• Character is delimited (at start end) by known
  signal elements start bit stop element
• Sync needs to be maintained only for the duration
  of a character
• The receiver has a new opportunity to
  resynchronize at the beginning of next character
• ? Timing errors do not accumulate from character
  to character

6
Asynchronous Transmission
(Min)
Binary 1
Binary 1
RX waits for a character following the end of the
previous character

• The stop element confirms end of character ?
  otherwise Framing Error
• Stop elements continue (idling)
• until next character

RX knows how many bits To expect in a
character, and keeps counting them following
the start bit
Parity bit Even or Odd parity?
S1 receiver in idling state S2 receive in
receiving state
7
Asynchronous Transmission

• Framing error
• Erroneous detection of end/start of a character
• Can be caused by
• Noise (1 is the idling stop bit)
• 1 1 1 1 0 1 1 1 1 1
• Incorrect timing of bit sampling due to drift of
  RX clock affects bit count

Erroneous Start bit due to noise
8
Asynchronous Transmission

• Errors due to lack of sync for an 8-bit system
• Let data rate baud rate 10 kbps
• Bit interval 1/10k 100 ms
• Assume RXs clock is faster than TX by 6
  (i.e. RX thinks the bit interval
  is 94 ms)
• RX checks mid-bit data at 47 ms and then at 94 ms
  intervals
• Bit 8 is wrongly sampled within bit 7 (bit 7 read
  twice!)
• Possibility of a framing error at the end

893
9
Asynchronous Transmission Efficiency

• Uses 1 start bit 2 stop bits (i.e. 3 non-data
  bits)
• with 8-bit characters and no parity
• ? Efficiency 8/(83) 72
• ? Overhead 3/(83) 28

10
Asynchronous Transmission Pros Cons

• Advantages
• Simple
• Cheap
• Good for data with large gaps (keyboard)
• Cons
• Overhead of 2 or 3 bits per character (20)
• Timing errors accumulate for large character sizes

11
Synchronous Transmission Bit-Level
Synchronization

• Allows transmission of large blocks of data
  (frames)
• TX and RX Clocks must be synchronized to prevent
  timing drift
• Ways to achieve bit-level sync
• Use a separate clock line between TX and RX
• Good over short distances
• Subject to transmission impairments over long
  distances
• Embed clock signal in data
• e.g. Manchester or Differential Manchester
  encoding
• Or carrier frequency for analog signals

12
Synchronous Frame Format

• Typical Frame Structure

Preamble/Postamble flags ensure frame-level
synchronization
13
Synchronous Transmission Efficiency

• Example HDLC scheme uses a total of 48 bits for
  control, preamble, and postamble fields per
  frame
• With a data block consisting of 1000 characters
  (8-bits per character),
• ? Efficiency 8000/(800048) 99.4
• ? Overhead 48/8048 0.6
• Higher efficiency and lower overhead compared to
  asynchronous

14
Errors in Digital Transmission

• Error occurs when a bit is altered between
  transmission and reception (0 ? 1 or 1 ? 0)
• Two types of errors
• Single bit errors
• One bit altered
• Isolated incidence, adjacent bits not affected
• Typically caused by white noise
• Burst errors
• Contiguous sequence of B bits in which first,
  last, and any number of intermediate bits are in
  error
• Caused by impulse noise or fading (in wireless)
• More common, and more difficult to handle
• Effect is greater at higher data rates
• What to do about these errors
• Detect them (at least, so we can ask TX to
  retransmit!)
• Correct them (if we can)

15
Error Detection Correction Motivation

• Assume NO error detection or correction Number
  of erroneous frames received would be
  unacceptable
• Hence, for a frame of F bits,
• Prob frame is correct (1-BER)F Decreases
  with increasing BER F
• Prob frame is erroneous 1 - (1-BER)F Frame
  Error Rate (FER)

A frame of F bits
All bits must be Correct!
Prob 1st bit in error BER Prob 1st bit
correct 1-BER
Prob 2nd bit in error BER Prob 2nd bit
correct 1-BER
Prob Fth bit in error BER Prob Fth bit
correct 1-BER
All bits must be Correct!
16
Motivation for Error Detection Correction
Example

• ISDN specifies a BER 10-6 for a 64kbps channel
• Frame size F 1000 bits
• What is the FER?
• FER 1 (1 BER)F 1 (0.999999)1000 10-3
• Assume a continuously used channel
• How many frames are transmitted in one day
  Number of frames/day (64,000/1000) 24 3600
• 5.5296 106
• How many erroneous frames/day?
• 5.5296 106 10-3 5.5296 103
• Typical requirement Maximum of 1 erroneous frame
  /day!
• i.e. frame error rate is too high!
• ? We definitely need error detection
  correction

17
Frame Error Probabilities
1 0 1 0 1 0 0 0 1 0 1 0 0 0 1
P1
1 - P1
1000
Correct
Erroneous
With an error detection facility
900
100
Errors, Undetected
Errors, Detected
P2
P3
20
80

• P1 P2 P3 1
• Without error detection facility P3 0, and
• P2 1 P1

18
Error Detection Techniques

• Two main error detection techniques
• Parity Check
• Cyclic Redundancy Check (CRC)
• Both techniques use additional bits that are
  added to the payload data by the transmitter
  for the purpose of error detection

19
Error Detection Implementation
Mismatch Error Detected
20
Parity Check

• Simplest error-detection scheme
• Appending one extra bit
• Even Parity Will append 1 such that the total
  number of 1s is even
• Odd Parity Will append 1 such that the total
  number of 1s is odd
• Example If an even-parity is used, RX will check
  if the total number of 1s is even
• If it is not ? error occurred
• Note even number of bit errors go undetected

21
Cyclic Redundancy Check (CRC)

• Burst errors will most likely go undetected by a
  simple parity check scheme
• Instead, a more elaborate technique called Cyclic
  Redundancy Check (CRC) is typically implemented
• CRC appends redundant bits to the frame trailer
  called Frame Check Sequence (FCS)
• FCS is later utilized at RX for error detection
• In a given frame containing n bits, we define
• k number of original data bits
• (n k) number of bits in the FCS field (i.e.
  additional bits)
• So, that the total frame length is k (n k)
  n bits

D (k)
FCS (n-k)
1 0 1 0 0 0 1 1 0 1
01110
T(n)
22
CRC Generation

• CRC generation is all about finding the FCS given
  the data (D) and a divisor (P)
• There are three equivalent ways to generate the
  CRC code
• Modulo-2 Arithmetic Method
• Polynomial Method
• Digital Logic Method

D (k)
FCS or F (n-k)
1 0 1 0 0 0 1 1 0 1
01110
T (n)
110101
P (n-k1)
23
Modulo 2 Arithmetic

• Binary arithmetic without carry
• Equivalent to XOR operation
• i.e
• 0 ? 0 0 1 ? 0 1 0 ? 1 1 1 ? 1 0
• 1 ? 0 0 0 ? 1 0 1 ? 1 1
• Examples

24
CRC Error Detection Process

• Given k-bit data (D), the TX generates an (n
  k)-bit FCS field (F) such that the total n-bit
  frame (T) is exactly divisible by some
  (n-k1)-bit predetermined devisor (P) (i.e. gives
  a zero remainder)
• In general, the received frame may or may not be
  equal, in value, to the sent frame
• Let the received frame be (T)
• In error-free transmission T T
• The RX then divides (T) by the same known
  divisor (P) and checks if there is any remainder
• If division yields a remainder then the frame is
  erroneous
• If the division yields zero remainder then the
  frame is error-free unless many erroneous bits in
  T resulted in a new exact division by P
• (This is very unlikely but possible, causing an
  undetected error!)

25
CRC Generation
T 2 (n k) ? D F
(n-k) left shifts (multiplications by 2)
Data D
?
LSB

• P is 1-bit longer than F

26
CRC Generation

• T 2(n k) ? D F, What is F that makes T
  divides P exactly ?
• Claim F is the remainder obtained from dividing
  2(n k) ? D by divisor P
• where Q is the quotient and F is the remainder
• If this is the correct F, T should now divide P
  with Zero remainder
• Note For F to be a remainder when dividing by P,
  it should be 1-bit smaller

(1)
27
CRC Generation Modulo-2 Arithmetic Method

• At TX CRC Generation (using previous rules)
• Multiply 2(n k) ? D (left shift by
  (n-k) bits)
• Divide 2(n k) ? D / P
• Use the resulting (n k)-bit remainder as the
  FCS
• At RX CRC Checking RX divides the received T
  (i.e. T) by the known divisor (P) and checks if
  there is any remainder

28
Example Modulo-2 Arithmetic Method

• Given
• D 1 0 1 0 0 0 1 1 0 1
• P 1 1 0 1 0 1
• Find the FCS field
• Solution
• First we note that
• The size of the data block D is k 10 bits
• The size of P is (n k 1) 6 bits
• ? Hence the FCS length is n k 5
• ? Total size of the frame T is n 15 bits

29
Example Modulo-2 Arith. Method

• Solution (continued)
• Multiply 2(n k) ? D
• 2(5) ? 1 0 1 0 0 0 1 1 0 1 1 0 1 0 0 0 1 1 0 1
  0 0 0 0 0
• This is a simple shift to the left by five
  positions
• Divide 2(n k) ? D / P (see next slide for
  details)
• 1 0 1 0 0 0 1 1 0 1 0 0 0 0 0 1 1 0 1 0 1
  yields
• Quotient Q 1 1 0 1 0 1 0 1 1 0
• Remainder R 0 1 1 1 0
• So, FCS R 0 1 1 1 0 Append it to D to get
  the full frame T to be transmitted
• T 1 0 1 0 0 0 1 1 0 1 0 1 1 1 0
• M FCS

30
Example Modulo-2 Arith. Method
of bits lt of bits in P, ? result of division
is 0
Checks you should do (exercise) - Verify
correct operation, i.e. that 2(n-k)D PQ R -
Verify that obtained T (101000110101110) divides
P (110101) exactly (i.e. with zero remainder)
FCS F
31
Problem 6-12

• For P 110011 D 11100011, find the CRC

32
Chances of missing an error by CRC error detection

• Let E be an n-bit number with a bit 1 at the
  position of each error bit error occurring in T
• Error occurring in T causes bit reversal
• Bit reversal is obtained by XORing with 1
• So, received Tr T ? E
• Error is missed (not detected) if Tr is divisible
  by P
• Since T is made divisible by P, this requires
  that E is also divisible by P!.
• That is a bit unlikely!

33
CRC Generation Polynomial Method

• A k-bit word (D) can be expressed as a polynomial
  D(x) of degree (k-1) in a dummy variable x, with
• The polynomial coefficients being the bit values
• The powers of X being the corresponding powers of
  2
• bk-1 bk-2 b2 b1 b0 ? bk-1Xk-1 bk-2Xk-2
  b1X1 b0X0
• where bi (k-1 i 0) is either 1 or 0
• Example1 an 8 bit word D 11011001 is
  represented as D(X) x7x6x4x31
• Ignore polynomial terms corresponding to 0 bits
  in the number

34
CRC Mapping Binary Bits into Polynomials

• Example2 What is x4D(x) equal to?
• x4D(x) x4(x7x6x4x31)
  x11x10x8x7x4, the equivalent bit pattern is
  110110010000 (i.e. four zeros appended to the
  right of the original D pattern)
• Example3 What is x4D(x) (x3x1)?
• x4D(x) (x3x1) x11x10x8x7x4 x3x1,
  the equivalent bit pattern is 110110011011 (i.e.
  pattern 1011 x3x1 appended to the right of
  the original D pattern)

35
CRC Generation The Polynomial Way
Polynomial
Binary Arithmetic

• T(X) X(n k) ? D(X) F(X)

• T 2(n k) ? D F

36
CRC Calculation - Procedure

1. Shift pattern D(X), (n-k) bits to the left, i.e.
   perform the multiplication X(n-k)D(X)
2. Divide the new pattern by the divisor P(X)
3. The remainder of the division, R(X) (i.e. n-k
   bits), is taken as FCS
4. The frame to be transmitted T(X) is
   X(n-k)D(X) FCS

37
Example of Polynomial Method

• D 1 0 1 0 0 0 1 1 0 1 (k 10)
• P 1 1 0 1 0 1 (n k 1 6)
• n k 5 ? n 15
• Find the FCS field
• Solution
• D(X) X9 X7 X3 X2 1
• P(X) X5 X4 X2 1
• X5D(X)/P(X) (X14 X12 X8 X7 X5)/(X5 X4
  X2 1)
• This yields a remainder R(X) X3 X2 X
  (details on next slide)
• i.e. F 01110
• R is n k 5-bit long ? Remember to indicate
  any 0 bits!

38
Example of Polynomial Method
F R
D
1 0 1 0 0 0 1 1 0 1
01110
T
Insert 0 bits to make 5 bits
110101
P
39
Choice of P(X)

• How should we choose the polynomial P(X)
  (or equivalently the divisor P)?
• The answer depends on the types of errors that
  are likely to occur in our communication link
• As seen before, an error pattern E(X) will be
  undetectable only if it is divisible by P(X)
• It can be shown that all the following error
  types are detectable
• All single-bit errors, if P(X) has two terms or
  more
• All double-bit errors, if P(X) has three terms or
  more
• Any odd number of errors, if P(X) contains the
  factor (X1)
• Any burst error whose length is less than the FCS
  length (n k)
• A fraction (1-2-(n-k-1) ) of error bursts of
  length (n-k1)
• A fraction (1-2-(n-k) ) of error bursts of
  length gt (n-k1)

40
Choice of P(X)

• In addition, if all error-patterns are equally
  likely, and r n - k length of the FCS,
  then
• For a burst error of length (r 1), the
  probability of undetected error is 1/2(r 1)
• For a longer burst error i.e. length gt (r 1),
  the probability of undetected error is 1/2 r
• There are four widely-used versions of P(X)
• CRC-12 P(X) X12 X11 X3 X2 X 1
• (r 13 -1 12)
• CRC-16 P(X) X16 X15 X2 1 (r
  17 -1 16)
• CRC-CCITT P(X) X16 X12 X5 1
• CRC-32 P(X) X32 X26 X23 X22 X16 X12
  X11 X10 X8 X7 X5 X4 X2 X 1
• (r 33 -1 32)

FCS is 1-bit shorter than P
FCS Size
P(X) always starts with 1
41
Some CRC Applications

• CRC-8 and CRC-10 (not shown) are used in ATM
• CRC-12 is used for transmission of 6-bit
  characters. Its FCS length is 12-bits
• CRC-16 CRC-CCITT are used for 8-bit characters
  in the US and Europe respectively
• Used in HDLC
• CRC-32 is used for IEEE 802.3 LAN standard

42
CRC Generation Digital Logic

• k 10 (size of D) (known data to be TXed)
• n k 1 6 size of P (known divisor) P (X)
  X5X4X21 (110101)
• n k 5 size of FCS (to be determined at TX)
• n 15

• 5-element left-shift register
• Initially loaded with 0s
• After n left shifts, register will contain the
  required FCS

Always An XOR at C0
P X5X4X2X0

• Divisor is hardwired as feedback connections
• via XOR gates into the shift register cells
• Starting at LSB, for the first (n-k) bits of P,
  add an XOR only for 1 bits

43
CRC Generation at TX
P X5X4X2X0
Start with Shift Register Cleared to 0s
C0 in
C2 in
C4 in
MSB
D
Inputs formed with Combination Logic
MSB
FCS generated in the shift register after n (15)
shift steps
44
CRC Checking at RX
P X5X4X2X0
Start with Shift Register Cleared to 0s
C0 in
C2 in
C4 in
MSB
15 bits
D
D
Received Frame, T
MSB
FCS
Inputs formed with Combination Logic
0s in the shift register after n (15) shift
steps (if no errors)
45
Problem 6-13

• A CRC is constructed to generate a 4-bit FCS for
  an 11-bit message. The generator polynomial is
  X4X31
• Draw the shift register circuit that would
  perform this task
• Encode the data bit sequence 10011011100
  (leftmost bit is the LSB) using the generator
  polynomial and give the code word
• Now assume that bit 7 (counting from the LSB) in
  the code word is in error and show that the
  detection algorithm detects the error

46
Problem 6-13 Solution
Input data

• a)

?
?
C0
C1
C2
C3
P(X) X4X31
b) Data (D) 1 0 0 1 1 0 1 1 1 0 0 D(X) 1
X3 X4 X6 X7 X8 X4D(X) X12 X11 X10
X8 X7 X4 T(X) X4M(X) R(X) X12
X11 X10 X8 X7 X4 X2 Code
0 0 1 0 1 0 0 1 1 0 1 1 1 0 0 c) Code in error
0 0 1 0 1 0 0 1 1 0 0 1 1 0 0 yields a
nonzero remainder ? error is detected
LSB
47
Error Correction

• Once an error is detected, what action can RX
  take? (i.e. I found an error, now what? ?)
• Two alternatives
• RX asks for a retransmission of the erroneous
  frame
• Adopted by data-link protocols such as HDLC and
  transport protocol such as TCP
• A Backward Error Correction (BEC) method
• RX attempts to correct the errors if enough
  redundancy exists in the received data
• TX uses Block Coding to allow RX to correct
  potential errors
• A Forward Error Correction (FEC) method
• Use in applications that leave no time for
  retransmission, e.g. VoIP.

48
Error Correction vs. Error Control

• Backward error correction by retransmission is
  not recommended in the
  following cases
• Error rate is high (e.g. wireless communication)
• Will cause too much retransmission traffic ?
  network overloading
• Transmission distance is long (e.g. satellite,
  submarine optical fiber cables)
• Network becomes very inefficient (Not utilized
  properly)
• Usually
• Error Correction methods Those that use FEC
  techniques
• Error Control methods Those that use
  retransmission
