Lecture 08- Subduction Zones
2
Subduction Zones

• When two tectonic plates converge often one will
  get buried or subducted beneath the other
• The plate boundary regions where this occurs are
  called subduction zones

3
Subduction Zones

• There are two types of lithosphere, oceanic and
  continental, so there are three possibilities at
  a convergent boundary
• oceanic and oceanic
• oceanic and continental
• continental and continental
• In which of these cases can subduction occur ?

4
Subduction Zones

• Subduction zones only occur at convergent
  boundaries between oceans and continents, and
  oceans and oceans
• When oceanic lithosphere converges with
  continental lithosphere it is the oceanic
  material that is always subducted beneath the
  continental material.
• When the convergent boundary is between two
  oceans it the older (heavier) plate which usually
  subducts.

5
Subduction Zones

• Examples of an oceanic lithosphere subducting
  beneath a continental lithosphere
• South America subduction zone Nazca plate
  (oceanic) subducting beneath South American plate
  (continental)
• Aleutian subduction zone Pacific plate (oceanic)
  subducting beneath North American plate
  (continental) in Alaska

6
Subduction Zones

• Examples of oceanic lithosphere subducting
  beneath oceanic lithosphere of another plate
• Marianas subduction zone Pacific plate
  subducting beneath Phillipine Sea plate in
  western Pacific
• Tonga subduction zone Pacific plate subducting
  beneath Australian plate in western Pacific

7
General Picture of Subduction
8
General Picture of Ocean-Ocean Convergence
9
General Picture of Ocean-Continent Subduction
10
Second General Example of Ocean-Continent
Subduction
11
The Termination of a Subduction Zone
Indian-Eurasian Boundary
12
Subduction Zones

• Two dominant features associated with subduction
  zones are
• deep earthquakes
• volcanoes

13
Subduction Zones and Deep Earthquakes

• Earthquakes can only occur in brittle material
  (high viscosity)
• It follows that earthquakes happen only in the
  lithosphere, which is usually 100-200 km thick
• However, we observe earthquakes down to a depth
  of 700 km ???

14
Subduction Zones andDeep Earthquakes

• It turns out the the deep earthquakes we observe
  (depth gt 200 km) are occurring in lithosphere
  that has been subducted.
• Deep earthquakes do not occur in any place except
  for subduction zones since this is the only place
  where brittle material (lithosphere) exists below
  its normal depth.

15
Subduction Zones andDeep Earthquakes

• Deep earthquakes occur in planar (2D)
  arrangements called Wadati-Benioff Zones
• Seismologists use the locations of deep
  earthquakes to map out the geometry of subducting
  lithosphere.

16
Sometimes Slab Geometry is Simple
17
Often it is Complicated (South America)
18
Often it is Complicated (Tonga)
19
Subduction Zones and Volcanoes

• Volcanic activity is associated with all active
  subduction zones
• We see dormant and fossil volcanoes at places
  where subduction used to occur
• This type of volcanic activity is fundamentally
  different than volcanoes at mid-ocean ridges and
  hot-spots

20
Subduction Zones and Volcanoes

• As oceanic crust ages and moves away from the
  ridge where it was formed it accumulates
  sediments which are rich is water
• Water also reacts with the newly formed crust and
  becomes chemically bound to it

21
Subduction Zones and Volcanoes

• Some sediment layers get scraped off the
  oceanic crust when it subducts at a trench
  however a large amount of water is retained in
  the subductiong slab of oceanic material.
• Thus, some water gets transported into the mantle
  while chemically bound to the rocks.

22
Subduction Zones and Volcanoes

• At about a depth of 100 km the temperature
  becomes hot enough that a chemical reaction takes
  place and the water is liberated from the
  material which carried it down into the mantle.
• This is called a dehydration reaction.

23
Subduction Zones and Volcanoes

• The free water that has just been liberated
  immediately starts to percolate upwards and
  begins to partially melt the asthenosphere above
  it.
• This partially molten material, and water, is
  much lighter than the surrounding material and
  begins rising

24
Subduction Zones and Volcanoes

• When the partially molten material nears the
  surface it often becomes fully molten because of
  decreasing pressure now we call it magma.
• The outermost crust at the Earths surface is
  cold, brittle and strong so it is difficult for
  the magma to break-through
• Thus magma will often pond beneath volcanoes in a
  magma chamber until the pressure becomes high
  enough for it to break though the outermost crust
  and erupt

25
(No Transcript)
26
(No Transcript)
27
(No Transcript)
28
Subduction Zone Summary

• Subduction zones occur at convergent plate
  boundaries they are burial grounds
• Oceanic material can subduct beneath oceanic
  material on another plate or beneath continental
  material on another plate
• Continental lithosphere never subducts

29
Subduction Zone Summary

• Subduction zones are the only place where deep (gt
  200 km) earthquakes occur
• The deep earthquakes line up on planar
  structure that delineate the subducting oceanic
  plates
• These seismicity patterns are called
  Wadati-Benioff zones

30
Subduction Zone Summary

• Volcanoes are also prevalent at subduction zones.
• They are formed from water that dehydrates from
  the subducting slab (at about 100 km) and the
  percolates upward causing magma formation.
• This volcanic material is chemically distinct
  from MOR volcanoes and hot-spots
