Title: Lessons Learned from Organic Synthesis


1
Lessons Learned from Organic Synthesis
Joshua J. Nyman Howard Hughes Medical Institute
Summer Scholar Research Project
Mentor Dr. Yan Zhang, Department of Medicinal
Chemistry, VCU School of Pharmacy
2
Background
  • Anibamine is a natural product, but recently it
    has been successfully synthesized in the
    laboratory.
  • Anibamine can be used as an anti-HIV drug
  • It has a unique chemical structure.

_
TFA
Anibamine
3
The Research Project
  • The objective of the research project was to
    synthesize the ring system of anibamine and then
    to alter the stereochemistry of its side-chains.

_
TFA
Anibamine
4
My Synthesis Route
K2CO3
acetylacetone

3-cyano-4,6-dimethyl-2-hydroxypyridine (2-hydroxy-
4,6-dimethyl-nicotinonitrile)
, TFA, H2SO4
cyanoacetamide
CuCN, DMF
under nitrogen gas
5-bromo-2-hydroxy-4,6-dimethyl-nicotinonitrile
1,2-dihydro-4,6-dimethyl-2-oxopyridine-3,5-dicarbo
nitrile
Tetrabutylammonium bromide, P2O5
2-bromo-4,6-dimethylpyridine-3,5-dicarbonitrile
5
Forming the Pyridine Ring
K2CO3
acetylacetone
cyanoacetamide
3-cyano-4,6-dimethyl-2-hydroxypyridine
  • An aqueous solution of potassium carbonate was
    prepared.
  • Acetylacetone and cyanoacetamide were added to
    the solution.
  • A stir bar was placed into the resulting mixture
    and the mixture was allowed to stir at room
    temperature for 24 hours.

6
Forming the Pyridine Ring
  • After 24 hours of stirring, the mixture was
    vacuum filtrated, yielding a white powder.
  • Melting point was on the high end of the
    literature melting point, and the thin-layer
    chromatography provided a positive presumptive
    test for the pyridine ring product.
  • A proton-NMR was also done on the resultant
    compound, but was later to found to be of little
    value based on the solvent used to dissolve the
    sample.

Images Barnard College Organic Chemistry Lab
7
Brominating the Pyridine Ring
, TFA, H2SO4
  • The product of the previous reaction was
    dissolved in concentrated sulfuric acid and
    trifluoracetic acid, while in an ice bath.
    N-bromosuccinimide was then added.
  • This reaction was run multiple times with varying
    degrees of purity.
  • Melting points taken of the product(s) were 10
    to 15 degrees too high in a couple of cases.
  • Thin-layer chromatography suggested some
    compounds were impure.
  • Product appeared to be a light yellow in the more
    impure products and white in the purer products.

8
Brominating the Pyridine Ring
, TFA, H2SO4
  • It seems the purity of this reaction could have
    been affected by certain techniques.
  • For example
  • Removing the reaction mixture from the ice bath
    Exothermic reaction
  • Rate of addition Adding the NBS too quickly
    likely resulted in an undesired side reaction.
  • Acid-Base reaction.

9
Adding a Cyano- Group to the Pyridine Ring
CuCN, DMF
under nitrogen gas
  • This reaction had some special considerations
  • One of the chemicals used in this reaction is a
    highly toxic compound called cuprous cyanide
    (a.k.a. copper (I) cyanide).
  • Handling the cyanide required great care

10
Adding a Cyano- Group to the Pyridine Ring
Oil Pump
  • All reactants had to be very dry!!!

11
Adding a Cyano- Group to the Pyridine Ring
CuCN, DMF
under nitrogen gas
  • The cuprous cyanide was dissolved in
    dimethylformamide along with the product from the
    previous reaction.
  • The mixture was then refluxed for 48 hours under
    nitrogen gas.

12
Adding a Cyano- Group to the Pyridine Ring
  • My compound being refluxed under nitrogen
    protection

13
Adding a Cyano- Group to the Pyridine Ring
CuCN, DMF
under nitrogen gas
  • This reaction gave me multiple problems
  • Proton NMR, Thin-Layer Chromatograhy tests, and
    melting point tests impure.
  • Because of this, I wasnt able to proceed further
    before the end of this program.

14
Lessons Learned
  • Organic synthesis can be very tricky, especially
    when trying to form natural products.
  • I learned not only to think about the products I
    am trying to synthesize, but also about which
    products I do not want to synthesize (i.e.
    impurities) and how to prevent them.
  • Its not just what chemicals you add, but how you
    add them. Temperature, rate of addition, and
    other factors can have a considerable impact on
    the overall synthesis.

15
References and Acknowledgements
  • A special thanks to Dr. Yan Zhang (my mentor) for
    sharing his expertise, his laboratory, and for
    making this an exceptional research learning
    experience.
  • Also a special thanks to Dr. Guo Li and Kendra
    Haney, for generously sharing their time and for
    their guidance.
  • And to all of the others brilliant individuals
    in Dr. Zhangs lab whose efforts contributed to
    my learning experience.

16
References and Acknowledgements
  • Literature (the primary source for my research
    project and background information presented in
    this presentation)
  • Guo Li, Karen Watson, Robert W. Buckheit, and Yan
    Zhang Total Synthesis of Anibamine, a Novel
    Natural Product as a Chemokine Receptor CCR5
    Antagonist Organic Letters 2007. Vol 9. 10
    2043-2046.

17
References and Acknowledgements
  • Pictures and Graphics
  • Title Slide Erlenmeyer Flasks
  • Department of Chemistry BiochemistryNorthern
    Arizona University
  • www.nau.edu/chem/Images/flasks.jpg
  • Slide 10 Reflux Apparatus and White Compound in
    Erlenmeyer Flask
  • Barnard College Organic Chemistry Lab
  • http//www.barnard.edu/chem/orgolab/lab2.htm
