Title: Software Visualization


1
Software Visualization
  • CS 7450 - Information Visualization
  • November 14, 2000

2
Software Visualization
  • Definition

The use of the crafts of typography, graphic
design, animation, and cinematography with modern
human- computer interaction and computer graphics
technology to facilitate both the human
understanding and effective use of computer
software.Price, Baecker and Small, 98
3
Challenge
  • Software clearly is abstract data
  • Unlike much information visualization, however,
    software is often dynamic, thus requiring our
    visualizations reflect the time dimension
  • History views
  • Animation
  • ...

4
Subdomains
  • Two main subareas of software visualization
  • Program visualization - Use of visualization to
    help programmers, coders, developers. Software
    engineering focus
  • Algorithm visualization - Use of visualization to
    help teach algorithms and data structures.
    Pedagogy focus

5
Subareas
  • Program Visualization
  • Software engineering
  • Debugging
  • Program analysis
  • Systems
  • Algorithm Visualization
  • Pedagogy
  • Systems
  • Use in classroom
  • Empirical study

6
Todays Talk
  • This is a very big area, so talk will just give a
    flavor of the kinds of techniques and systems
    that have been created
  • Lots of figures
  • Some demos and videos

7
Program Visualization
  • Can be as simple as enhanced views of program
    source
  • Can be as complex as views of the execution of a
    highly parallel program, its data structures,
    run-time heap, etc.

8
Enhanced Code Views
Primarily used as a documentation aid
9
SeeSoft System
  • Pulled-back, far away view of source code
  • Map one line of source to one line of pixels
  • Can indicate line indentation, etc.
  • Like taping your source code to the wall, walking
    far away, then looking back at it

Eick, Steffen and Sumner 92
10
System View
15,000 lines of code in 52 files
Video
11
Use
  • Tracking (typically means mapping this data
    attribute to color)
  • Code modification (when, by whom)
  • Bug fixes
  • Code coverage or hotspots in tests
  • Interactive, can change color mappings, can brush
    views, and so on

12
Tarantula
  • New system that were working on here
  • Utilizes SeeSoft code view methodology
  • Shows results of tests in a suite
  • Helps viewer track down location of faults

13
TarantulaView
Demo
14
Step Up
  • Next step in program visualization is to help
    debugging and performance optimization by
    visualizing program executions
  • Data, data structures, run-time heap, memory,
    control flow, data flow, hot spots, ...

15
Graph Visualization
  • Area that weve already studied which is very
    important to SV
  • Graphs pop up everywhere in software
  • Common use Visualize a call graph, visualize a
    flow chart, ...

16
Sample CallGraph View
17
FIELD
  • Program development and analysis environment with
    a wide assortment of different program views
  • Integrated a variety of UNIX tools
  • Utilized central message server architecture in
    which tools communicated through message passing

Reiss 90
18
FIELD Interface
19
Dynamic Call Graph View
On call stack
Currently active
20
Class Browser
21
Heap View
Color could be When allocated Block size Where
allocated
22
3D Call Graph
Selected file
Groups of calls
Collapsed file
23
PV System
  • Used for understanding application and system
    behavior for purposes of debugging and tuning
  • Users look for trends, anomalies, and
    correlations
  • Ran on RISC/6000 workstations using AIX
  • Trace-driven, can be viewed on-line or off

Kimelman, Rosenburg and Roth 94
24
Different Views
  • Hardware-level performance info
  • Instruction execution rates, cache utilization,
    processor utilization
  • Operating system level activity
  • Context switches, system calls, address space
    activity
  • Communication library level activity
  • Message passing, interprocessor communication
  • Language run-time activity
  • Dynamic memory allocation, parallel loop
    scheduling
  • Application-level activity
  • Data structure accesses, algorithm phase
    transitions

25
Accumulated process times
Call tree
Process run history
Kernel performance stats
26
Memory view
Code views
27
Utility
  • Papers about PV provide a number of specific
    examples of how tool was used to help find and
    diagnose performance problems
  • Authors say that one negative is just limitations
    of workstation display---need to open and align
    lots of windows and that becomes difficult

28
Commercial Systems
  • A number of commercial program development
    environments have begun to incorporate program
    visualization tools such as these
  • Majority are PC-based
  • Has not become as wide-spread as I would have
    anticipated

29
Other Languages
  • Can use program visualization techniques to
    depict software in other languages
  • Functional Lisp
  • Logical Prolog
  • Object-oriented C

30
Concurrent Programs
  • Understanding parallel programs is even more
    difficult than serial
  • Visualization and animation seem naturals for
    illustrating concurrency
  • Temporal mapping of program execution to
    animation becomes critical

Kraemer Stasko 93
31
Performance Visualization
  • One big aspect in concurrent programs is to
    understand how the computation is performing
  • Where can be speeded up
  • Processor utilization
  • Message traffic
  • ...

32
PerformanceViews
Kiviat Diagram
Message traffic
33
POLKA
  • We developed a system, POLKA, that was designed
    to help people build visualizations of concurrent
    programs
  • Used for both program and algorithm visualization
  • Used for different programming models message
    passing, shared memory threads, ...

Stasko Kraemer 93
34
Message Passing Systems
PVM/Conch
Topol, Stasko, Sunderam 98

35
Shared Memory Threads
Pthreads
Zhao Stasko 95
36
PVaniM
  • Visualizing PVM programs on-line
  • Must use sampling, not tracing due to sheer
    number of events
  • Shows machine loads, host utilization, memory
    used, messages sent, communication patterns, etc.

Topol, Stasko Sunderam 98
37
PVaniM
Basic system UI
38
Algorithm Visualization
  • Learning about algorithms is one of the most
    difficult things for computer science students
  • Very abstract, complex, difficult to grasp
  • Idea Can we make the data and operations of
    algorithms more concrete to help people
    understand them?

39
Algorithm Animation
  • Common name for area
  • Dynamic visualizations of the operations and data
    of computer algorithm as it executes
  • Abstraction is key concept

40
Sorting Out Sorting
  • Seminal work in area
  • 30 minute video produced by Ron Baecker at
    Toronto in 1981
  • Illustrates and compares nine sorting algorithms
    as they run on different data sets

41
SoS Views
Video
42
Balsa
  • First main system in area
  • Used in electronic classroom at Brown
  • Introduced use of multiple views and interesting
    event model

Brown 88
43
Example Animation
44
Tango
  • Added smooth animation to algorithm animation
  • Simplification of the design/programming process
    (easier programming model and framework)
  • Formal model of the animation, the
    Path-Transition Paradigm

Stasko 90
45
Tango
Multiple frames from bubblesort
46
Tango Model
  • Image, Location, Path, Transition

Location fromloc, toloc Image
ball Path path1, path2 Transition
mover ball AssocRetrieve("ID",
paramvalue) fromloc ImageLoc(ball,
Center) toloc LocCreate(0.4, 0.7) path1
PathMakeType(Clockwise) path2
PathExample(fromloc, toloc, path1) mover
TransCreate(Move, ball, path2) TransPerform(mover
)
Samplecode
47
POLKA
  • Improved animation design model
  • Object-oriented paradigm
  • Multiple animation windows
  • Much richer visualization/animation capabilities

Stasko Kraemer 93
48
POLKA
Demo
49
POLKA Model
  • Location, AnimObject, Action
  • Introduce explicit animation time (frame)

0 1 2 3 4 5 6 7 8 9
t
50
POLKA Programming Model
Circle circ Loc loc, center
Action act int len circ new
Circle(this,1, 0.2,0.3, 0.1,"red", 1.0)
circ-Originate(time) center
circ-Where(PART_C) loc new Loc(0.6,
0.5) act new Action("MOVE", center, loc,
20) len circ-Program(time, act) time
Animate(time, len)
51
Semantic Zooming
Sorting 5000 elements
View all data
Zoom to first 10
Zoom further
52
Polka-3D
  • 3-D and VR version of Polka
  • Same animation model
  • Use third dimension to
  • Enhance visual aesthetics
  • Portray 3-D data
  • Encode more program attributes
  • Not sure appropriate for algorithm animation

Stasko Wehrli 93
53
POLKA-3D
Quicksort side view Blue dots are as in 2-d
view Colored planes represent exhanges
54
Zeus
  • Successor to Balsa
  • Utilized sound and provided 3D version
  • Provided visualizations of many computational
    geometry algorithms

Brown 91
55
Zeus Animations
Video
56
Evaluating Effectiveness
  • Do algorithm animations actually help students
    learn?
  • Thats the claim, but unproven
  • Conducted a number of empirical studies to answer
    question
  • Compare learning with animation to learning
    without
  • Measuring understanding is difficult

57
Results
  • Somewhat mixed, but some studies do show benefits
  • - Potential for pedagogical aid is there, but
    just cant throw animation at algorithm and
    expect it to help
  • Interaction is a key
  • Blindly watching algorithm animation not really
    helpful
  • Student must interact with animation and be
    engaged
  • Animations help motivation, can make algorithm
    less intimidating

58
Current State of SV
  • Research continues
  • Some use of algorithm animations as pedagogical
    aids
  • Program visualization trickling into commercial
    tools

59
Whats Needed? (PV)
  • Better analysis of what software developers want
    and need
  • Flexible displays providing overview and detail
  • Improved tracing/monitoring/analysis capabilities

60
Whats Needed? (AA)
  • Focus on interactive tools
  • Simpler animation construction
  • Empirical validation of value

61
References
  • All referred to papers
  • Software Visualization, MIT Press, 1998
