SensorNet Information Architecture

1
(No Transcript)
2
SensorNet Information Architecture

• The Right Information
• The Right People
• The Right Time
• Integrated and Interoperable

3
(No Transcript)
4
Information Networking

• Collect
• Process
• Disseminate

5
The Problems We Are Addressing

• Stove piped sensor networks and systems
• Non-standard and proprietary interfaces
• Lack of near-real-time situational awareness
• Lack of consistent and common data
• Need for simultaneous data from multiple sources
• Need for interoperable information
• National / Scalable solution

6
Capabilities

• Augments and integrates National, State, Local
  infrastructure and process
• Transitions with new procedures, sensors and
  technology (future proof)
• Based on standards for commercial support and
  competitive pricing
• Near-real-time detection protection and
  deterrence

7
A Tested TestBed Process
Create Integrated Concept Team
Conduct Mission Area Analysis and Needs Analysis
Develop Concept And Architecture
Proof of Concept/Identify Technologies
Prototype Experimentation/ refine Requirements
and Procedures
Handoff to DHS/DoD Field New Capability
Develop Operational Requirements
8
Program Phases
I. Concept II. Rapid Prototyping III.
Operational Prototyping

• Functional Requirements
• National Standards
• Technical Specifications for Interoperability

9
Proof of Concept

• 2.9 M
• Enabled architecture development, initial systems
  design, and limited trials to support the proof
  of concept

10
Collaborators Partners

• Tennessee Office of Homeland Security
• National Oceanic and Atmospheric Administration
• University of Tennessee
• University of Kansas
• Virginia Tech
• Naval Research Lab
• Lawrence Berkley Lab
• CECOM
• Dielectric

• Hughes Satellite
• American Tower Corp
• Keyhole
• Oracle
• Sprint
• Nortel
• Smiths Detection
• Far West Technologies
• Nuc Safe
• Exploranium

11
Many Sensors
Many Applications
Chemical
SensorNet
Radiological
Total Situation Awareness
Ubiquitous, Securable, Scalable, and Reliable
Plug and Play
Open and Extensible
Performance Support
Meteorological
Open GIS Web Feature Service
IEEE 1451
IP
Analysis, Modeling,and Prediction
SensorNet Interoperability Standards Netcentric
Data Services Architecture
Biological
12
Interfaces
Data
Services
Security
Transport/Comms
A standardized core leads Interoperability-
Plug and Play - Lower Cost
OGC
IEEE 1451
Network Capable Application Processor (NACAP)
Transducer software
Network Protocol
Sensors
Transducer Module(s)
Intel
Transducer Interface
Network hardware
Plume Models
Application Software
Population Models
Transducer Electronic Data Sheets (TEDS)
Web-Based Applications
Transducer hardware interface spec
Transducer logical interface specification
Network protocol specification
- Information Interoperability - Integrated Web
Services technologies - Reduced barriers between
real world, information about the real world, and
distributed users - Framework for
next-generation vendor-neutral distributed
geoprocessing and location systems - Flexible
future applications assembled from multiple,
network-enabled geoprocessing and location
services
- An industry-wide, open standard -
Providing common interfaces between
sensors/actuators and instruments,
microprocessors, or networks - Analog,
digital, and wireless interfaces -
Self-describing sensor via the Transducer
Electronic Data Sheet (TEDS)
13
What we are
SensorNet takes on the CORE
Control Center Applications
Control
Sensor
Mobile
Actuator
Data Center

Information
SensorNet Components
Node
Transportable
Control Center
Network Services
Data Center Service
Data Center
Communication Service
NetCentric Service
3rdParty Apps
Fixed
Physical Data Interface Specifications
14
Outside Providers
Sensor Data Query
Users (consumers)
SensorNet-wide Services
Data Subscr. (SPS)
External WFS
Subscribe
Sensor Data
External Data Consumers/ Applications Data
Fusion Emer. Mgmt. State HS Dept
Native Data Service
WFS Adapter
Ontology (OWL)
Dir. Services (UDDI/LDAP)
Network
Node Sensor Data
Data Center
Data Publ. (subscription)
Sensor Data
WFS Listener
Secure, intelligent, multi- carrier, traffic
routing with failover intelligence from the node.
May act as Outside Provider (on left)
Plume and Other Models
Data Query (WFS)
Center Database
Alert Listener
Alerts
EOCs
Alert Publisher
Alerts Via CAP
Emergency Responders
Node Mgmt.
Data Publ. (WFS/OM)
Alert Publ. (WNS)
Mgmt. Srvs. (SensorML, SPS, etc.)
Services WFS Web Feature Service SAS Sensor
Alert Service, formerly Web Alert
Service SPS Sensor Planning Service SOS
Sensor Observation Service, formerly Sensor
Collection Service WNS Web Notification
Service UDDI Universal Description,
Discovery and Integration
Node Management
Personnel Alerts
Routing Control
Secondary Alert
Operational Agents
Node
Database
Node Web GUI
Sys. Admin.
SensorNet Sys. Admin. GUI
Encodings OM Observations Measurements Sensor
ML Sensor Model Language CAP Common Alert
Protocol
1451 Wrapper
Control SW
Information Flows Sensor data various encodings
over WFS, will examine SOS Node Sensor data OM
over WFS, will examine SCS Alerts Currently
WNS, probably change to SAS Personnel Alerts
pager, email, etc. Node Management does auto
configuration, will incorporate SensorML
Non-1451
1451
General GIS Geographic Information System GUI
Graphical User Interface
S
E
N
S
O
R
S
Data Control
15
Prototyping

• FY 04 Funding, 20M
• Embraced Netcentric Architecture
• Deployed at sites in NYC, Wash DC, and Tennessee
• Fort Bragg, our first operational prototyping
  sponsor

16
Trial Locations (Calendar 04 projection)

• 3 SensorNet nodes in New York plus data from
  CECOM sensors (police cars, ferries)
• 5 SensorNet nodes in Washington DC
• Installed at the Forrestal building on 31 Oct 03
• 10 SensorNet nodes in Tennessee
• Possible mobile sensor tie-in with truck weigh
  station
• 5 SensorNet nodes at Fort Bragg, North Carolina
• Installed first set of sensors 27 Feb 04

17
Testbed Locations

• Watt Road Truck Weigh Station
• Fort Bragg
• Mobile / Rapidly Deployable (Large Public Event)

18
SensorNets Transportation Based Threat
Assessment Demonstration At Watt Road

• 2nd Busiest Truck Weigh/Inspection Station In US
• Joint SensorNet/ITS Sensor Node
• Sensors
• Radiation Portal Monitors
• Exploranium
• NucSafe
• Radiation Gamma Spectrometry
• Exploranium GR-135
• Toxic Chemical
• Smiths Detection Centurian
• Smiths Detection APD-2000
• Gamma Radiation
• Far West
• Meteorological
• Video
• Vehicle Weight
• Shipping Bill of Laden
• RFID Tags of Radioactive Isotope Shipments
• Driver Credentials

19
Integration of Transportation Based Threat
Assessment forSensorNets Interdiction Philosophy

• Integrate truck transportation threat assessment
  data from weigh stations in Tennessee, South
  Carolina, and Kentucky
• Integrate water borne transportation threat
  assessment from the Watts Bar Dam Locks
• Develop a vehicle deployable radiation node based
  upon a NucSafe BackPack detector

Truck Passing Through Radiation Detectors At Watt
Road Weigh Station
20
(No Transcript)
21

• Fort Bragg is a city
• 20 million square feet of office buildings
• 11 shopping centers
• 28 restaurants
• 11 miles of railroad lines
• major medical center
• 8 schools
• 11 churches
• 183 recreational facilities
• 5,000 homes
• 11,000 family members
• 67,000 population
• stretches across six counties
• approximately 250 square miles in size

Womack Army Hospital
22
Total Installation Awareness
Sensors and Sensor Status NOAA Weather Radiologica
l/Nuclear Chemical Biological Video Intrusion
Detection EPA Air and Water Quality Fixed Assets
and Status Electrical Gas Water Communications Tra
ffic Control Systems
First Responder Location and Status
Personnel Fire Trucks Police Cars
Ambulances Population Disposition
Location Density Traffic
23
HFIR
24
Nuclear Facilities Monitoring for Safety and
Response

• DOE O 151.1 Guides For Site Alert, Emergency, and
  General Emergency
• HFIR-SensorNet Contributions
• Sensor Placement for Wireless and Wireline
  Communication
• Standards-based Real-time Data Gathering,
  Forwarding, and Display
• Authorized Access to Data via Open Standards
• ORNL Emergency Operations and Response
• Integration of Applications and Sensing
  Infrastructure
• Weather and Radiological Data to Plume Models
• Monitoring and Response

25
Mobile SensorNet
Transportable Node for Dense Sensor Deployments
Ruggadized Laptop Node for Rapid Deployment
Mini-node, Limited number of sensors
Micro-node, Sensor-Phone
26
Remote Mobile Deployment of SensorNet for Large
Public Events
State Operations Center
Information
- 2000 Km NLOS -
Local Operations Center
- 200 Km NLOS -
Deployable Operations Center And Response Cell
- 2 Km LOS -
S
S
Mobile and Fixed Sensors
S
Mobile Quick Erect Antennas
S

• Bristol Speedway
• 300,000 400,000 visitors
• 100,000 passenger vehicles

27
(No Transcript)
28
(No Transcript)
29
What is SensorNet?
SensorNet is an ORNL-led initiative, in
collaboration with the Open Geospatial Consortium
(OGC), the National Institute for Standards and
Technology (NIST), and the IEEE to develop and
implement interoperability standards for
ubiquitous, cost-effective, and secure sensor
networks.
30
Why are SensorNet Standards Needed?

• Networking sensors with intelligent decision
  support platforms enhances the ability to detect
  chemical, biological, radiological, and nuclear
  (CBRN) threats.
• For applications that detect, fuse, and analyze
  sensor data, simultaneous access to multiple
  sensor sources broadens the range of threats that
  can be detected and reduces the time to confirm,
  interdict, and respond to a threat.
• The cost to deploy proprietary, homogenous,
  stove-pipe sensor networks is prohibitive.
  Standards promote interoperability and a
  competitive market place for users.

31
Bragg Experimental SensorNet Testbed (BEST)

• A DOE WFO initiative, BEST will be the venue for
  the integration of ORNLs SensorNet program with
  a state-of-the-art regional Public Safety
  Answering Point (PSAP) to produce the prototype
  for a standardized Integrated Incident Management
  Center (I2MC).
• BEST will characterize the DoDs requirements for
  Total Installation Awareness.
• BEST will provide Fort Bragg and ORNL a joint
  opportunity to introduce SensorNets
  interoperability standards to a baseline PM
  GUARDIAN facility.

32
Integrated Incident Monitoring Center (I2MC)
Functions
SensorNet Functions Environmental Monitoring and
Surveillance   Incident Detection
Incident Coordination/Communication Regional
Response and Evacuation Control
Information Dissemination Routine Data Archival
PSAP Functions Association of Public-Safety
Communications Officials (APCO) National
Emergency Number Association (NENA) Emergency
Call-Taking Emergency Dispatch
Emergency Response Tracking and
Management Records Management
33
Integrated Incident Management Center (I2MC)
34
ORNLs SensorNet Middleware
Many Sensors
Many Applications
www.sensornet.gov
Radiological
Command-and-Control
Open Geospatial Consortium Sensor Web Enablement
Net Centric Enterprise Services
IEEE 1451
Chemical
Performance Support
Ubiquitous, Securable, Scalable, and Reliable
Plug and Play
Open and Extensible
Meteorological
Analysis, Modeling, and Prediction
Non-Proprietary
Biological
35
How is SensorNet working with the Army?
Deployment
Engineering
Development
The installation, operation, and maintenance of
testbeds that address user requirements. Bragg
Experimental Sensornet Testbed Total
Installation Awareness Integrated Incident
Management Center
Standardization
The integration of ORNLs middleware with
commercial hardware, sensors, decision support
software, communications, and data bases to
produce an end-to-end system.
Research
ORNLs reference implementation of the SensorNet
interoperability standards. SensorNet
middleware enables an adaptive, flexible, and
pervasive web that interconnects plug-n-play
sensors with applications. The middleware
development contributes to the SensorNet
Implementation Guide.
ORNLs collaboration with the Open Geospatial
Consortium, NIST, IEEE, and others to define the
set of international and open standards for
sensor network interoperability.
ORNLs research into sensor network
interoperability, architectures, and applications.
