Title: SNOLAB DataGrid


1
SNOLAB DataGrid
  • This presentation will probably involve audience
    discussion, which will create action items. Use
    PowerPoint to keep track of these action items
    during your presentation
  • In Slide Show, click on the right mouse button
  • Select Meeting Minder
  • Select the Action Items tab
  • Type in action items as they come up
  • Click OK to dismiss this box
  • This will automatically create an Action Item
    slide at the end of your presentation with your
    points entered.
  • Alain Bellerive
  • Canada Research Chair

2
OUTLINE
  • Introduction
  • - The Scope of Particles Astrophysics
  • - Sudbury Neutrino Observatory (SNO and SNOLAB)
  • - Data Flow and Partnership with ORION
  • - Identify Global Networking Needs
  • SNOLAB DataGrid
  • - Activities at Carleton University and in
    Sudbury
  • - Data Distribution Support to International
    Collaborators
  • Summary

3
Scope Particle Physics
  • Study fundamental forces of nature and its
    elementary constituents.
  • The neutrino is the second most abundant particle
    in the Universe.
  • Use the sun to investigate the properties of weak
    interacting particles called neutrinos !
  • The earth receives around 100 billions neutrinos
    per second and cm2.


4
Solar Neutrino Problems
Light Element Fusion Reactions
p p ?2H e ?e
99.75
p e- p ? 2H ?e
0.25
10-5
3He p ?4He e ?e
7Be e- ?7Li ?e
15
?e(Measured)? 1/3 ?e(Model)
8B ? 8Be e ?e
0.02
Neutrino Production in the Sun
?e oscillate to ??? as discovered by SNO BIG
SCIENCE
5
Data Flow for SNO
  • Raw Data
  • Rate for neutrino runs is 15 Hz 2 Kb/event
  • Rate for calibration runs is 50-200 Hz lt200
    Kb/event
  • Label the data by runs (i.e. time) and running
    conditions
  • Each year SNO records around 1Tb of raw data.
  • Event Summary
  • Reduced data set from pattern recognition
  • Event summary files used for data analysis
  • Correspond to another 200 Gb per year
  • Monte Carlo (MC) Simulation
  • Large volume of MC events to be distributed
    world-wide
  • Scale by a factor of 20 or 400 the amount of
    simulated data compared to the raw data collected
  • MC data required correspond to 1-3 Tb per year

6
Early Partnership with ORION
  • In 2001, the network limitation was the slow
    connectivity via the 7 Mb/sec ATM connection
    between Toronto ? Sudbury
  • Major improvement in May 2003 with connection to
    ORION THANKS!
  • Led to quick turn-around for diagnostics, data
    analysis, and publication

7
CFI International Venture SNOLAB
New cavern at the 6800 ft level !!!
8
SNOLAB Requirements
  • The present data flow from SNO will only be a
    part of the data expected from the new SNOLAB
  • For the design of experiments for this facility,
    there will be substantial Monte Carlo simulations
    required and for the processing of data a further
    requirement will exist beyond the present SNO
    needs
  • Need to support at least three major experiments
    to study
  • Low energy solar neutrinos
  • Double Beta decay
  • Search for Dark Matter
  • In the future, SNO and SNOLAB, will benefit
    substantially from a high-speed national network
    CANet4 ORION dedicated to science


9
Connectivity Raw Data Computing
  • Fast Ethernet switches (Gb/s) and optical fibres
    connection from underground to the surface
    building Thanks for matching funds from ORION
  • A total of 10-100 Tb of data needs to be
    accessible by all the member institutions of
    SNOLAB in Ontario
  • Not a lot of data (compared to others experiments
    in HEP)
  • Need to move the data out of Sudbury
  • Particle physics does not share the need of
    parallel computing like in other discipline HEP
    requires a stable and users oriented platform
  • Focus on throughput computing
  • Some calculations need to performed on-site, but
    the majority will be done remotely
  • Users and computing resources are scattered
    around the world

Connection underground ? surface (ok)
Data Flow (manageable)
Computing (distributed resources)
Network (challenge)
10
SNOLAB DataGrid
HPC
GRID
GridComputing (solution)
NETWORK
  • Advances in distributed computing, high quality
    networks, and powerful and cost-effective
    commodity-based computing have given rise to this
    Grid computing
  • Grid projects present fresh challenges for a
    number of reasons, such as the difficulty of
    coordinating the use of widely distributed
    resources owned and controlled by many
    organizations
  • The Grid introduces the concept of the virtual
    organization as a group of both users and
    computing resources from a number of real
    organizations that are brought together to work
    on a particular project
  • The objective of the SNOLAB DataGrid project is
    to assist the next generation of scientific
    exploration, which requires intensive computation
    and analysis of shared large-scale datasets
    across universities in Ontario e.g. Queens
    Carleton Laurentian Guelph.
  • Need support for the development of
    infrastructure for distributing data across large
    area networks (i.e. people involvement)

11
Partnership and Challenges
  • Particle physicists are concerned with the
    management of large data samples
  • Benefits from the dedication of ORION to
    interconnect Carleton, Queens, Laurentian, and
    SNOLAB
  • Development of point-to-point light-path
    connection in partnership with CANARIE
  • Rely on the Globus Tool Kit developed for
    advanced distributed computing in High Energy
    Physics experiments
  • SNOLAB main objective is the DATA aspect (not
    computational)
  • Identify common research area with partners in
    Ontario
  • Stimulate development of the framework needed for
    the data movements foresee in the next wave of
    network development
  • Gain expertise for future Grid applications in
    particle physics (LHC) and other sectors
    (banking, stock market, medical imaging, etc)
  • Call for large/secure/reliable data storage over
    a wide network of collaborators in Ontario and
    around the world

12
Data Distribution Architecture
  • Progress towards research and deployment of a
    DataGrid at SNOLAB
  • Alain Bellerive (Physics/Carleton)
  • Aksel Hallin (Physics/Queens)
  • Wade Hong (Physics/Carleton)
  • Shikharesh Majumdar (Syst. Eng./Carleton)
  • Clarence Virtue (Physics/Laurentian)

GridComputing (solution)
SNOLAB
Carleton
Queens
Laurentian
13
Summary
Leadership of Canada in Underground
Science Goal International leadership of SNOLAB
in Particle Astrophysics Opportunity Establish
SNOLAB indisputable scientific authority in the
fields of elementary particle physics and the
evolution of the Universe Benefits Investment in
academic training and forefront research
DataGrid Role Distribute the data collected at
SNOLAB Research Discussions on fundamental
science is stimulated with the fast connectivity
between physicists and the need for data
management and analysis in collaborative effort
Infrastructure Development of the tools for
wide data distribution


  • Framework and Prove of concept at SNOLAB
  • Gain expertise now in direct research
    involvement in data movement
  • Production prototype on real data in preparation
    for LHC
  • Workflow of Open Grid Service Architecture
    (OGSA) towards
  • Web Services
  •
