Title: SPY Lab


1
SPY Lab
  • Michael Levine
  • mnlevine_at_wisc.edu

2
The Electromagnetic Spectrum
3
Spectrophotometer
4
Lambert-Beer Law
  • A bec log I0/I - log T
  • b is pathlength (usually 1 cm)
  • e is the molar absorptivity (M-1cm-1)
  • c is the concentration (M)
  • T stands for transmittance
  • If absorbance has multiple components
  • A b ?ei8ci

5
Hemoglobin
6
Hemoglobin
  • Hemoglobin is a tetrameric protein
  • 4 subunits a2ß2
  • One heme group per subunit
  • 4 moles heme per mole hemoglobin
  • Three redox states are known in vivo
  • met- , deoxy- and oxy-hemoglobin

7
Hemoglobin, cont.
  • Deoxy-hemoglobin oxy-hemoglobin are the
    functional forms
  • Met-hemoglobin is inactive
  • Apo-hemoglobin can also exist in vitro
  • Ascorbate and Sodium Dithionite will be used to
    reduce hemoglobin samples

8
Hemoglobin Binding Curve
9
Pulse Oximeter
10
Pulse Oximeter
  • Used in hospitals.
  • Uses ratio of red light to infrared light to
    measure oxy to total hemoglobin ratio (oxygen
    saturation)
  • Measures changing spectra with each pulse as
    arteries expand
  • Works even if patient is wearing red nail polish
  • Uses 2 wavelengths of light (660, 905 nm)

11
Pulse Oximeter
  • Used to see if a patient needs supplemental
    oxygen
  • Limitations
  • Does not measure total oxygen
  • Cant tell if patient is anemic
  • Reads 85 if there is met heme present
  • Falsely high for carbon dioxide or cyanide
    poisoning
  • There are expensive pulse oximeters that measure
    carboxy hemoglobin and met hemoglobin that use 7
    wavelengths

12
Experimental Overview
  • Perform experiment in order 1, 2, 5, 4, 3
  • 1 Turn on spectrophotometer and allow it to warm
    up
  • 2 Absorbance spectrum of hemoglobin from 670-230
    nm (do background correction first with buffer
    blank in back).
  • Absorbance at 3 wavelengths (415, 420, 430 nm)
  • Do NOT rezero at this point
  • Use Quartz Cuvette

13
Overview
  • 5 Dithionite Reduced Hemoglobin
  • Change Scan to 670-320 nm
  • Use plastic cuvettes from this point on
  • Dont shake sample

14
Overview
  • 5 (Cont.) Measure absorbance at 415, 420, and
    430 nm
  • Dont re-zero and move on to step 4
  • 4 Changes in spectrum in the presence of
    ascorbate
  • Two scans and then fixed wavelength scan
  • Go on to step 3

15
Overview
  • 3 Molar Absorptivity of hemoglobin in the soret
    region
  • Use plastic cuvettes
  • Be careful while making standard solutions
  • Label your tubes

16
Common Errors
  • Lamp not warmed up
  • Wrong Wavelength
  • Improper blanking
  • Dilution Mistake
  • Dirty or mismatched cuvette
  • Improper seating of cuvette
  • Operation Errors

17
Calculations
  • Show calculations in lab report
  • One of each kind of calculation
  • Calculated concentrations
  • 4 moles heme groups per mole hemoglobin
  • Divide concentration by 4 to get hemoglobin
    concentration

18
Calculations
  • Try to put a file on the web site for matrix
    calculations
  • Use cautiously because it doesnt always work
  • Email me if you need help

19
Considerations
  • Read Manual
  • Review spec instructions
  • Warm up
  • Zero
  • Be patient
  • Perform experiment steps 1, 2, 5, 4, 3
  • Obtain dithionite (Step 5) directly from TA
  • Be careful with quartz cuvettes
  • Write all data in manual (get signed by TA before
    leaving)

20
Report
  • Due Dates
  • Group A Feb 15
  • Group B Feb 22
  • Reports should include the following
  • Cover Page
  • Optical spectra, data sheets and other primary
    results
  • Clearly labeled graphs
  • Example calculations
  • Watch units and significant figures
  • Answers to questions
  • Clear and Concise
