Primary Pulmonary Hypertension and Sildenafil

1
Primary Pulmonary Hypertension andSildenafil

• Azim E. Surka
• WFUMC
• Resident Grand Rounds
• November 11, 2003

2
Overview

• Background
• WHO Classification
• Epidemiology
• Pathophysiology
• Current Therapies
• Sildenafil

3
Primary Pulmonary Hypertension

• Rare disorder characterized by elevated pulmonary
  arterial pressures
• First described in 1951 by Dresdale
• Presenting symptom is most commonly dyspnea
• Can also present with syncope, chest pain and
  peripheral edema

4
Primary Pulmonary Hypertension

• Incidence is 1-2 cases per million in general
  population
• Mean survival was 2.8 years after diagnosis
• Although survival probably longer since the
  advent of IV epoprostenol

5
Primary Pulmonary HypertensionNIH

• Defines PPH as mean pulmonary arterial pressure
  (PAP) gt 25 mmHg at rest, or gt30 mmHg with
  exertion
• Absence of heart disease, chronic thromboembolic
  disease, underlying pulmonary disorder, or other
  secondary cause

6
WHO Classification

• In 1998 World Health Organization reclassified
  pulmonary hypertension
• Subdivided all Pulmonary Hypertension into 5
  groups
• Primary Pulmonary Hypertension is characterized
  as a subclass of Pulmonary Arterial Hypertension

7
WHO Classification

• Pulmonary Arterial Hypertension
• Primary Pulmonary Hypertension (PPH)
• Familial
• Sporadic
• Related to
• Collagen Vascular Disease
• Congenital systemic to pulmonary shunts
• Portal Hypertension
• HIV
• Drugs/Toxins, i.e. appetite suppressants
• Persistent pulmonary hypertension of the neonate

8
WHO Classification

• Pulmonary venous hypertension
• Left sided valvular or ventricular disease
• Pulmonary Hypertension associated with disorders
  of the respiratory system/ hypoxemia
• COPD, interstitial lung disease, sleep disorders

9
WHO Classification

• Pulmonary hypertension due to chronic thrombotic
  and/or embolic disease
• Pulmonary emboli, and sickle cell disease
• Pulmonary Hypertension due to disorders directly
  affecting pulmonary vasculature
• Sarcoid, schistosomiasis

10
Epidemiology of PPH

• Female predominance of 2 to 1
• No ethnic or geographical predisposition
• Approximately 6 of cases are familial

11
Pathophysiology

• Associated with obstruction of small pulmonary
  arteries
• Microscopic characteristics
• Medial hypertrophy
• Plexiform lesions
• Thrombotic lesions
• Concentric laminar fibrosis
• Bone Morphogenetic Protein Receptor gene found in
  2000 in patients with Familial PPH
• May play role in pathophysiology

12
Pathophysiology
13
Current Therapies

• Calcium Channel Blockers
• Anticoagulation
• Prostacyclin
• Bosentan (endothelin antagonist)
• Lung transplantation

14
Calcium Channel Blockers

• Has shown to benefit small number of people
• Nifedipine and diltiazem are the CCB of choice
• Side effects include hypotension, edema, and
  hypoxemia

15
Anticoagulation

• PPH patients more likely to have thrombosis
  secondary to sluggish blood flow and sedentary
  lifestyle
• Increased levels of thromboxane have also been
  found in PPH patients
• Goal INR 2.0

16
Lung Transplantation

• Only curative therapy for PPH
• Indications
• NYHA Class III or IV despite optimum medical
  therapy
• Cardiac Index less than 2L/min/m2
• Right Atrial Pressure gt 15 mmHg
• Pulmonary Arterial Pressure gt 55mmHg
• Limited by availability

17
Epoprostenol (Flolan)

• Prostacyclin
• Increases exercise capacity and decrease PAP
  after 12 week period
• Improves survival at 1, 3, and 5 years
• Side Effects include hypotension, jaw pain,
  diarrhea, flushing, and nausea and vomiting
• Tachyphalaxis is common and dosages have to be
  increased

18
Epoprostenol (Flolan)

• Delivered through continuous IV pump
• Infection and thrombosis can occur
• Dose Limited by hypotension
• Cost of epoprostenol and pump delivery is
  5000/month
• Iloprost
• Aerosolized prostacyclin
• Available in Europe
• Easier delivery through nebulizer
• Must be dosed 6-12 times a day

19
Bosentan (Tracleer)

• Endothelin 1 and 2 antagonist
• Given Orally
• Endothelin is a potent vasoconstrictor and smooth
  muscle mitogen
• PPH patients have been shown to have greater
  endothelin 1 concentration in plasma and lungs

20
Bosentan (Tracleer)

• Two Randomized controlled trials showed
  improvement in six minute walk time,
  cardiopulmonary hemodynamics, and WHO functional
  Class
• No mortality data on Bosentan

21
Sildenafil (Viagra)

• A Phosphodiesterase 5 Inhibitor (PDE5)
• Currently approved for treatment of Erectile
  Dysfunction in U.S.
• Thought to work by increasing levels of cGMP, a
  vasodilator
• PDE5 is found in greater amounts the lung and
  breaks down cGMP

22
Sildenafil (Viagra)
23
Long Term Treatment With Oral Sildenafil in
Addition to Continuous IV Epoprostenol in
Patients with Pulmonary Arterial
HypertensionStiebellehner, et al. Chest 123,
1293-1295, 2003
24
Stiebellehner, et al.

• Case Study
• Three female patients
• Ages 61, 33, 51
• Patients 1 and 2 had PPH, Patient 3 had PAH
  secondary to closure of atrial septal defect

25
Stiebellehner, et al.

• All had baseline six minute walk time (6MWT) and
  cardiopulmonary hemodynamic measurements
• Primary endpoint was PAP and 6MWT after 5 months
  of therapy

26
Stiebellehner, et al.Baseline Characteristics
27
Stiebellehner, et al.Intervention

• Patient 1 received 50 mg of Sildenafil four times
  a day
• Patient 2 and 3 received 12.5 mg of Sildenafil
  six times a day secondary to nausea and vomiting
• All patients continued with current dose of
  epoprostenol

28
Stiebellehner, et alResults
29
Stiebellehner, et al.

• Conclusions
• All patients had decrease in PAP and increase in
  6MWT after 5 months of therapy
• Effects of sildenafil were additive to
  epoprostenol

30
Stiebellehner, et al.

• Limitations
• Case Series
• Small sample group
• Lack of control
• No randomization

31

• Effect of Inhaled Iloprost Plus Oral Sildenafil
  in Patients with PPH
• Wilkens H, et al Circulation 104 1218-1222, 2001

32
Wilkens, et al

• Crossover study with iloprost and sildenafil
• 5 patients with PPH with NYHA class III or IV
• Exclusion Criteria pregnancy, hypotension, and
  secondary pulmonary hypertension
• Patients admitted to ICU and Swan-Ganz catheters
  were placed
• PAP, CO, and PVR were measured

33
Wilkens, et alPatient Characteristics
34
Wilkens, et alInterventions

• Patients were given iloprost, and measurements
  were taken every 15 minutes for 2 hours
• Patients were then given two 25 mg doses of
  Sildenafil 30 minutes apart, and Swan-Ganz
  measurements were taken
• Patients were given additional 50 mg of
  sildenafil if there was no response after 60 min
• Patients were then given inhaled iloprost 90
  minutes after first sildenafil

35
Wilkens, et alResults

• PAP
• Iloprost
• -16.3 /-2.2 plt0.01
• Sildenafil
• -12.6 /-0.9 plt0.01
• Sildenafil Iloprost
• -24.7/-3.0 plt0.002

36
Wilkens, et al
37
Wilkens, et alResults

• Similar Decreases in Pulmonary Vascular
  Resistance
• Iloprost
• -43.8/- 3.9 (plt0.05)
• Sildenafil
• -21.8 /- 3.0 (plt0.05)
• Sildenafil and Iloprost
• -43.0 /- -2.7 (plt0.02)

38
Wilkens, et al
39
Wilkens, et al

• Conclusions
• Effects of iloprost began to wear off after 1
  hour
• Sildenafils effect on PAP and PVR was still
  evident after 90 min
• Additive effect of two agents together
• Most of effect of sildenafil was after the first
  25 mg dose

40
Wilkens, et al

• Limitations
• Small sample group
• No randomization
• Open crossover study

41

• Combination Therapy with Oral Sildenafil and
  Inhaled Iloprost Severe Pulmonary Hypertension
• Ghofrani, et al Annals Internal Medicine, 136
  515-522, 2002

42
Ghofrani, et al

• Randomized open label trial in the ICU
• 30 Patients
• 16 patients with Pulmonary Arterial Hypertension
• 10 with PPH and 6 with CREST
• 13 with chronic thromboembolic disease
• 1 with PH secondary to aplasia of left pulmonary
  artery
• 23 women and 7 men

43
Ghofrani, et al

• Inclusion Criteria
• Severe PAH i.e. PAP gt40mm Hg
• NYHA class III or IV
• Exclusion Criteria
• Pulmonary Hypertension secondary to COPD
• Pulmonary Venous Congestion
• Congenital Heart Disease
• Pregnancy
• Inflammatory Lung Disease

44
Ghofrani, et al

• After Swan-Ganz catheter placement, each patient
  had a trial of inhaled nitric oxide
• PAP, PVR, CI, and SVR were measured
• Iloprost was delivered after all measurements had
  returned to baseline
• Iloprost decreased PAP, PVR, and Increased CI

45
Ghofrani, et alPatient Characteristics
46
Ghofrani, et al
47
Ghofrani, et al
48
Ghofrani, et al
49
Ghofrani, et al
50
Ghofrani, et al

• Conclusions
• Sildenafil lowered PAP and PVR and increased CI
  without many systemic symptoms or side effects
• Combination of drugs had more dramatic but
  transient benefit
• Improved hemodynamics of those with PPH and
  chronic thromboembolic disease

51
Ghofrani, et al

• Limitations
• Small Sample Size
• Lack of placebo control
• Open trial
• Lack of long term data

52
Long-Term Treatment with Oral Sildenafil is
Safe and Improves Functional Capacity and
Hemodynamics in Patients with Pulmonary Arterial
Hypertension Michelakis ED, Tymchak W, et al
Circulation 108 2066-2069
53
Michelakis et al.

• Case Review
• Aimed to show long-term safety and efficacy of
  sildenafil
• 5 patients enrolled in the study
• 4 with PPH
• Primary endpoint was 6MWT and PAP at 3 months
  after initiation of the sildenafil

54
Michelakis et al.

• Patients
• Four were NYHA class III and 1 was NYHA class II
• All patients were stable for past three months
  with no changes in therapy
• All were on diuretics and coumadin and patients 2
  and 4 were on calcium channel blockers as well
• Patients were excluded if they were on
  epoprostenol or NYHA class IV

55
Michelakis et al.Results

• PAP decreased 25.7 /- 10 plt0.007
• Statistically significant increases in 6MWT
  plt0.001
• 3 patients who had cardiac MRI had decreases in
  size of right ventricle, increase in RV EF, and
  reverse of paradoxical septal shift

56
Michelakis et al.

• Conclusions
• Sildenafil with traditional therapies reduced PAP
  and increased 6MWT after 3 months
• Limitations
• Small sample size
• Lack of placebo control
• Lack of randomization

57
Cost Analysis
58
Final Conclusions

• Sildenafil alone and in combination with other
  therapies has benefit for treating patients with
  PPH
• Sildenafil decreases PAP, PVR, and increases CO
  and 6MWT
• Benefits of sildenafil are its cost, ease of
  delivery, and few side effects

59
Final Conclusions

• May benefit those awaiting transplantation and to
  those who have maximized their epoprostenol dose
• Need larger multi-center randomized controlled
  trials that shows long-term hemodynamic or
  mortality benefit of sildenafil before it can be
  used in routine treatment of PPH

60
(No Transcript)
