Ganesh Machinery at IMTS 2014

1
Ganesh Machinery
IMTS2014
IMTS 2014 Booth S-8045
2

• Ganesh Machinery is a respected name in the
  industry with their exceptional customer service
  and high quality products.
• With their 15,000 sq. ft. operation and a 40,000
  sq. ft. machine warehouse they are able to
  produce machines for thousands of customers all
  over the world.

3
IMTS2014

• September, 8th to 13th , 2014 ? Chicago,
  Illinois.
• The International Manufacturing Technology Show
  is the largest manufacturing technology trade
  show in the United States, with over 100,000
  attendees and over one million square feet of
  exhibit space.

Ganesh Machinery will be a featured exhibitor in
booths S-8045 and S-8048 in the Metal Cutting
Pavilion.
4
Showcasing Ganesh

• At the exhibition, Ganesh Machinery will be
  introducing new Multitasking CNC Lathes, as well
  as, presenting CNC Turning Milling Center,
  Vertical Machining Center -- High Speed VMC, and
  CNC Big Bore Oil Country Lathes.

On the next few pages, were going to look at the
products that Ganesh will be exhibiting this fall
at IMTS.
5
Cyclone 52-BY2 B" Axis 9 Axis
Specifications Specifications
Bar Capacity 51mm
Spindle Speed 6,000 RPM
Total Tools 36
Live Tools 12
6
Cyclone-32 CS
Specifications Specifications
Bar Capacity 36mm
Total Tools 27
Live Tools 11
OD Turning Tools 6 OD Tools
7
VFM-2818 Express 27.95" X 17.71" Travel
Specifications Specifications
Spindle Speed 12,000 RPM
Spindle HP 15
Spindle Taper 40
Traverse Rate - IPM 1417
8
GT-3060 CNC Big Bore Oil Country Lathe
Specifications Specifications
Spindle Bore 6 5/8
Spindle HP 30
Spindle Nose A2-11
Available Controls Fanuc/Fagor
9
IMTS2014

• September, 8th to 13th , 2014 ? Chicago, Illinois.

• Join Ganesh Machinery at the International
  Manufacturing Technology Show
• Metal Cutting Pavilion booths S-8045 and S-8048

10
CONTACT US

• 1-888-542-6374
• http//www.ganeshmachinery.com/
• Ganesh Machinery started in 1985 as a family
  business and now has grown into one of the
  leading makers of CNC machines.
• With a strong focus on customer service and
  quality parts
• Ganesh Machinery has sold and serviced their
• products to thousands of customers.
