Fractal Robotics

1
FRACTAL ROBOTICS
BY Muzammil Shaik ADAMS engg college
2
Presentation overview

• Introduction Of robotics
• Nano Robotics
• Fractal Robotics
• Applications
• Conclusion

3
Introduction Of Robotics
4

• Robots are programmable machines
• They range from small, miniature machines, to
  large crane size constructions

5
Like nanotechnology, Robotics is the
use of technology to design and
manufacture (intelligent) machines, built
for specific purposes, programmed to
perform specific tasks.
6
Nano Robotics

• It deals with the controlled manipulation of
  objects with nanometer scale dimensions
• Nanomanipulation is most effective process.
• It is concerned with construction and
  programming of robots with overall dimensions at
  the nanoscale.

7

• It is concerned with atomic and molecular-sized
  objects and is also called Molecular Robotics.
• Nan robotics research has proceeded along two
  lines
• - first is devoted to simulation
• with nanoscale dimensions.
• - second involves manipulation
• with macroscopic instruments.

8
Applications of Nano Robotics

• it is mainly used in medicine to cure deadly
  disease called cancer
• Very helpful in cosmetics and ceramic engineering
• They are in the range of 1-100 nano meters
• Nano robot is also used to in the automobile
  engineering
• These robots are very easy to control.

9
Fractal Robots
10

• Fractal robot is a new kind of robot made
  from motorized cubic bricks that move under
  computer control.
• These cubic motorized bricks can be
  programmed to move and shuffle themselves to
  change shape to make objects likes a house
  potentially in a few seconds because of their
  motorized internal mechanisms.

11
Example of Fractal Robot

• Example of a Dog shaped fractal robot changing
  into a couch

12
SELF-REPAIR IN FRACTAL ROBOTS.

• Self repair is an important breakthrough for
  realizing micro and nanotechnology related end
  goals.
• Three different kinds of self repair
• -Cube replacement
• -Usage of plates to construct the cubes.
• -Using smaller fractal machines to affect
  self repair inside large cubes.

13
Walking fractal robot performing self repair
14
Applications of fractal robots

• It can be used in medicine.
• In mining.
• Using fractal robots it is possible to build even
  a space station.
• Can be used to build roads and clear mines
• In agriculture

15
(No Transcript)
16
Any Queries ?
