An Intro of Shakti Submersible Pumps

1
Introduction of Shakti Submersible Pumps
2
Index

• INTRODUCTION OF SUBMERSIBLE PUMPS
• STRUCTURE OF SUBMERSIBLE PUMPS
• APPLICATIONS OF SUBMERSIBLE PUMPS
• ADVANTAGES OF SUBMERSIBLE PUMPS
• INRODUCTION OF SHAKTI SUBMERSIBLE PUMPS
• PACKAGE DETAILS OF SUBMERSIBLE PUMPS
• SPECIFICATION OF SHAKTI SUBMERSIBLE PUMPS
• SUMMARY OF SHAKTI SUBMERSIBLE PUMPS
• FOR MORE INFORMATION CONTECT US

3
INTRODUCTION OF SUBMERSIBLE PUMPS
A submersible pump is a type of hermetically
sealed pump device that operates by pushing,
rather than pulling, water during its pumping
process. It is able to function in this manner
because, like the name suggests, the pump is
fully submerged in the liquid to be pumped.
4
STRUCTURE OF SUBMERSIBLE PUMPS
5
APPLICATIONS OF SUBMERSIBLE PUMPS
6
ADVANTAGES OF SUBMERSIBLE PUMPS

• Submersible pumps are designed to be tightly
  contained underwater units. Thus, they are
  completely watertight, and risks of leakages and
  electric contacts are eliminated. This ensure
  that the pump will suffer from no internal
  damage, and thus minimizes repair costs.
• The second advantage of a submersible pump is in
  how it interacts with the water. Indeed, due to
  the fact that the pump uses no suction to get the
  water through to the pipes or hoses, the pressure
  is optimized. This allows the water to move over
  a greater distance, which can be useful for
  larger farms.
• The greatest advantage of a submersible pump
  however lies in the fact that unlike other types
  of pumps, they do not need to be primed before
  operating. This not only saves time, but also
  reduces risks of overexertion.

7
SHAKTI SUBMERSIBLE PUMPS
Shakti submersible water pump is in high demand
due to its innovative mechanical design and
impeccable quality. It has carved a niche as the
most predominant submersible pump and the company
is one of the leading suppliers of submersible
pumps in India. It is available in all size
range starting from 100 mm.  Shakti submersible
pumps are manufactured from the superlative
quality raw material using advanced fabrication
technology, which ensure optimum performance and
excellent quality.
8
PACKAGE DETAILS OF SUBMERSIBLE PUMPS
AVILABLE SHAKTI SUBMERSIBLE PUMPS DETAILS-
100 mm well size (4) 150 mm well size (6) 200
mm well size (8) 250 mm well size (10) 300 mm
well size (12) 360 mm well size (14)
100 mm well size (4) 150 mm well size (6) 200
mm well size (8) 250 mm well size (10) 300 mm
well size (12)
4 inch well size 6 inch well size 8 inch well
size 10 inch well size 12 inch well size
9
SPECIFICATION OF SHAKTI SUBMERSIBLE PUMPS
PUMPED LIQUIDS Clean, thin, non-aggressive
liquids without solid particles or
fibers OPERATING CONDITIONS Flow rate, Q 1.2
m3/h - 280 m3/h Head, H Max 670m
Type range QF
Nominal flow rate x 10 Ipm 210
Number of impellers  -5
First impeller with reduced diameter (A,B or C) -A
Second impeller with reduced diameter (A,B or C)   B
SS-304, SS-316 N
Motor Installation Installation Installation
Motor Flow Velocity Past Motor Vertical Horizontal
4, 6 8 0.15 m/s 40ºc 40ºc
10
The speed of the motors is approximately 4"
motors n2870 min-1 6motors n2870 min-1 8"
to 12" motors n2870 min-1 The measurements
were made with airless water at a temperature 2
of 20c.The curves apply to a kinematic viscosity
of 1mm /s. When pumping liquids with a density
higher than that of water, motors with
correspondingly higher outputs must be used. The
bold curves indicate the recommended performance
range. The performance curves are inclusive of
possible losses such as non-return valve loss.
11

• QF2, QF5, QF6, QF12, QF20, QF25 CURVE
• Q/H The curves are inclusive of valve and inlet
  losses at the actual speed
• Power Curve Bpkw/Stage shows pump power input
  per stage
• Efficiency Curve Efficiency shows pump stage
  efficiency
• QF10, QF15, QF30, QF50, QF75, QF100, QF125,
  0F160, QF210, QF270, QF360 CURVE
• Q/H The curves are inclusive of valve and inlet
  losses at the actual speedOperation without
  non-return valve will increase the actual head at
  nominal performance by 0.5 to 1.0 m
• NPSHR The curve is inclusive of suction case and
  shows required inlet pressure
• Power Curve It shows pump power input at the
  actual speed for each individual pump size
• Efficiency Curve Efficiency shows pump stage
  efficiency

12
SHAKTI SUBMERSIBLE PUMPS STRUCTURE
BEARINGS WITH SAND CHANNELS All bearings are
water- lubricated and have a square shape,
enabling sand particles, if any, to leave the
pump together with the pumped liquid. INLET
STRAINER The inlet strainer prevents particles
over a certain size from entering the pump.
13
NON-RETURN VALVE
All pumps are equipped with a reliable non-return
valve in the valve casing preventing back flow in
connection with pump stoppage. Furthermore , the
short closing time of the non-return valve means
that the risk of destructive water hammer is
reduced to a minimum. The valve casing is
designed for optimum hydraulic properties to
minimize the pressure loss across the valve and,
thus, contributes to the high efficiency of the
pump.
14
PRIMING SCREW All QF and QF 30 pumps are fitted
with a priming screw. Consequently, dry running
is prevented because the priming screw will make
sure that pump bearing are always lubricated. Due
to the semi-axial impellers of large QF pumps
(except for QF 30) this priming is automatically
provided. However, it applies to all pump types
that if the water table is lowered to a level
below the pump inlet neither pump nor motor will
be protected against dry running.
15
STOP RING The stop ring prevents damage to the
pump during transport and in case of up-thrust in
connection with start-up.The stop ring, which
is designed as a thrust bearing limits axial
movements of the pump shaft. Example QF
125 The stationary part of the stop ring (A) is
secured in the top bowl (Upper intermediate
chamber). The rotating part (B) is fitted above
the collet split cone(c).
16
SUMMARY OF SHAKTI SUBMERSIBLE PUMPS
A WIDE PUMP RANGE We offer submersible pumps
with energy- efficient duty points ranging from
1m3/h to 280 /h. The pump range consists of many
pump sizes and each pump size is available with
an optional number of stages to match any duty
point. HIGH PUMP EFFICIENCY Often pump
efficiency is a neglected factor compared to the
price variations and are without importance of
pump and motor efficiencies APPLICATIONS We
offer a complete range of pumps and motors which
as a standard are made completely of stainless
steel AISI-304. This provides for good wear
resistance and a reduced risk of corrosion when
pumping ordinary cold water with a minor content
of chloride. LOW INSTALLATION COSTS Stainless
steel means low weight facilitating the handling
of pumps and resulting in low equipment costs and
reduced installation and service time. In
addition pumps will be as new after service due
to the high wear resistance of stainless steel
17
FOR MORE INFORMATION CONTECT US
Shakti Pumps (I) Ltd.Plot No. 401, Sector -
3,Pithampur - 454774Dist. - Dhar (M.P.)
India Call Us -91 7292 410500
Shakti Pumps (FZE)P O Box 8521Sharjah
International Free ZoneSharjah UAE 971 5088
31589
Shakti Pumps USA LLC1339 Bennett Drive,Unit
165, Longwood,FL 32750, USA 1 - 407-574-4001
