Twin Lobe Roots Blower

1
(No Transcript)
2
Blowers for Industrial Health Fitness
Blowers, compressors and centrifugal fans are
used to pump out gases. It is widely used in
industries to maintain air pollution free
environment. Apart from that blowers are of
different types and each type is destined for
specific purpose. Twin lobe roots blower is one
among them that is preferred in industries for
the following advantages, 1) Higher performance
at moderate compression ratios 2) They are
applied in places where constant discharge or
pressure is required 3) It is highly recommended
in pneumatic conveying system, aeration, cement
plants, aquaculture aeration, etc
3
Twin Lobe Roots Blower - Basic Equipment
Construction and Mechanism
Twin Lobe Roots Blower falls under the category
of positive displacement blowers. It is
constructed with a pair of lobes designed as per
the profile. Lobes are also termed as rotors
rotate inside the casing. In twin lobes one of
the lobes is applied for driving with the help of
external power resource and the other lobe is
driven with the help of gears. The mechanism
starts in terms of the two lobes rotating in
opposite direction however run in constant speed
and remove gases from the circumference.
4
Roots Blowers from PPI Pumps
PPI pumps has been serving several industries
with different types of vacuum pumps, blowers,
and pump spare parts. We customize blowers in
terms of industrial applications. We have twin
lobe roots blower with a capacity of 100 to 8000
Cubic Meter / Hr and it can discharge maximum of
1kg/cm2 pressure.
5
Displacement of Gases and Vacuum Creation
As the twin lobes rotate in opposite direction
air travels inside the cylinder and it is forced
outside by using the pressure created by rotors
rotation. Each rotation helps to remove volumes
of gases and further the rotation of twin lobes
stops air coming inside the cylinder thus
creating vacuum space inside the machine and the
air disposal keeps on continuing through the
discharge system. The gas flow rate depends on
the speed of rotating operation of the lobes. One
of the chief benefits of applying twin lobes
roots blower is that it is a reliable option for
obtaining consistent flow rate irrespective of
the variable pressure discharge conditions as it
depends mostly on the operating speed of the
lobes.
6
More of Vacuum Mechanisms
Other than blowers, PPI pumps stays a great
destination to find different sorts of equipments
related to vacuum technology such as liquid ring
vacuum pumps, single cone vacuum pump, two stage
vacuum pumps, close couple vacuum pumps, chemical
process pumps, etc. Our liquid ring pump has a
great demand in industries including power plant,
sugar mill, process industries, paper and pulp
manufacturing, etc.
7
Contact Us
PPI Pumps Pvt. Ltd. 14 16 E, Phase I, G.I.D.C.
Estate, Vatva,Ahmedabad - Gujarat
(India). Phone[phone] Fax91 (79)
25830578 E-mail sales_at_ppipumps.com
8
www.ppipumps.com
Visit Us
