Original Simmtronics RAM for Laptops

1
Original Simmtronics RAM for Laptops
http//www.simmtronics.co.in
2
About Us

• Simmtronics Infotech Pvt. Ltd. came into being in
  the year 1994 with a modest beginning in IT
  Industry.
• We are one of the first memory module suppliers
  in India to have received ISO 9001 Certification
• Keeping pace with growth in this sector, the
  company made rapid strides in the business of
  memory modules.
• Product-mix offered by the Company serves every
  type of memory modules is extensively used by the
  producers of various brands of PCs marketed by
  them

3
Types of Memory

• Simmtronics has different types of memories for
  laptops and desktops

4
DDR

• Overview The Memory Module DDR 266/333/400
  CL2.5 a Small Outline Memory module has a density
  between 512MB to 1GB consists DDR Synchronous
  DRAMs. Memory Module is intended for mounting
  into 200-pin edge connector sockets.

• JEDEC Standard
• DDR Speed Grade 266/333/400Mbps
• SO-DIMM 200-pin
• Memory Organization x8 , x16 DRAM chip
• DDR DRAM interface SSTL_25
• CAS latency 2.5-3-3
• Bandwidth 2100/2700/3200MB/s
• VDD voltage 2.5-0.2V
• VDDQ voltage 2.5-0.2V
• Application Notebook
• Serial presence detect (SPD)with EEPROM

5
DDR2

• Overview The Memory Module is DDR2-533/667/800
  CL5 Small Outline in the density range between
  512MB to 2GB consists ofDDR2 667MHz Synchronous
  DRAMs in FBGA packages. Memory Module is intended
  for mounting into 200-pin edge connector sockets.

• JEDEC Standard
• DDR2 Speed Grade 533/667/800Mbps
• SO-DIMM 200-pin
• Memory Organization x8 , x16 FBGA DRAM chip
• DDR2 DRAM interface SSTL_18
• CAS latency 4-4-4
• Bandwidth 4200/5300/6400MB/s
• VDD voltage 1.8-0.1V
• VDDQ voltage 1.8-0.1V
• Serial presence detect with EEPROM

6
DDR3

• Overview Simmtronics has a range from 1GB to 8GB
  with DDR3 1333 MHz SO-DIMM module gives better
  performance with lower power consumption in
  laptops.

• JEDEC Standard
• DDR3 Speed Grade 1333Mbps
• SO-DIMM 204-pin
• Memory Organization x8 FBGA DRAM chip
• DDR3 DRAM interface SSTL_15
• CAS latency 9-9-9
• Bandwidth 10600MB/s
• VDD voltage 1.5-0.075V
• VDDQ voltage 1.5-0.075V
• Serial presence detect (SPD)with EEPROM
• Application Note-Book

7
Contact Details
Company Name Simmtronics Infotech Pvt.
Ltd. Address 206, Deepali Building, 92 Nehru
place New Delhi, 110019 Phone
No 011-41618247/49 91-8510050022 Toll Free
No 1800-11-6100 Website http//simmtronics.co
.in/
