How to simplify clash detection process in Navisworks?

1
Tesla Outsourcing Services

• How to simplify clash detection process in
  Navisworks?

Visit Us www.teslaoutsourcingservices.com Email
Us projects_at_teslaoutsourcingservices.com
2
How to simplify clash detection process in
Navisworks?

• Identification of clashes and their
  rectification is a very challenging job for AEC
  professionals as thousands of design errors are
  identified by them once 3D models are completed
  for multiple building disciplines in Revit.
  Making right alterations or changes in 3D models
  once clashes are identified between model
  elements during clash detection process is not
  that easy as it sounds.
• High intelligence along with sufficient
  knowledge of software application is required for
  resolving identified clashes. It is quite easy to
  run a clash test in Autodesk applications like
  Navisworks but to react to the results is
  certainly not that simple especially when
  countless clashes are detected.

3
How to simplify clash detection process in
Navisworks?

• Here, design and construction professionals
  are required to effectively use the tools that
  are incorporated in Navisworks for sorting out
  identified clashes.
• Tips for simplifying clash detection process
• The first thing that should be done by Navisworks
  users before they go ahead with conducting a
  clash test is to effectively set up the elements
  or items that they would like to compare during
  clash detection in the Batch tab.
• This can be done by accessing clash detective
  tool from where Batch tab can be accessed by
  Navisworks users.
• Elements of a model are compared with the
  elements of another model so that if they are
  clashing with each other it can be identified in
  the clash detection process.

4
How to simplify clash detection process in
Navisworks?

• One of the most important tasks of Navisworks
  users is to effectively recognize the clashes and
  then group them according to their similarity.
• When clashes are grouped together according to
  their potential to create obstacles for AEC
  professionals in construction, it becomes easy
  for them to understand the nature of the clashes.
• Its easy to manage clashes when they are grouped
  together as it allows team members to understand
  their impact on the project. When impact of the
  clashes is successfully realized by team members
  they provide effective solutions for rectifying
  them.
• Another important thing for Navisworks users is
  to properly understand the mechanism of Results
  tab.

5
How to simplify clash detection process in
Navisworks?

• They must know how to use the information that is
  available to them under different columns in
  Results tab. The results of the clash tests can
  be accessed from a multi-column table in the
  results tab.
• So users must know the uses of the information in
  different columns for the purpose of sorting out
  the clashes.
• For example the Status column of the
  multi-column table include the information
  concerning the status of the clashes for example
  a clash is resolved by users then it is displayed
  as Resolved within status column.
• So, if Navisworks users have appropriate
  knowledge of different tools that are available
  within clash detective they can easily simplify
  the process by using them.
