denim Jeans fashion effects machines

1
Hot Tek Jeans Finishing Range

• www.hottek.com


  www.allied-technologist.com

2

Now Connect us on www.hottek.com

•


• Factory Head office Allied Automation
  Engineers ,Jhumra Road Mansoorabad
  Faisalabad-PAKISTAN ZIP code 38000Tel 92 41
  8737029 ,8739029 Fax [phone]
• www.hottek.com
• Key contact Persons
• Mr.Rehan Akmal CEO Cell 0092 321 7619000
  03367619000
• rehan_at_allied-technologist.com
  hottek.rehan_at_gmail.com
• Miss.Muneeba A Hafeez GM MKT Cell 0092 321
  6690211 0320 7619000
• muneeba_at_allied-technologist.com
  hottek.muneeba_at_gmail.com
• General inquiryinfo_at_allied-technologist.com

• Product List
• Heat Transfer Machines (wide Range)
• Label Transfer Machines
• Screen Making equipments
• Screen Printing equipments
• Conveyor Dryers (Gas/Electrical/Uv)
• Screen Printing Machines-Garments
• Screen Printing Machines-Socks/Gloves
• Tent Printing Machines
• Jeans Ovens
• Whisker Machines/wrinkle Machines
• Scrappers/PP spray Booth range
• Jeans Grinding Machines
• Roller Type Fusing Machines
• Shrink wrap machines
• Packing Machines
• PLC
• Customize Machine Design Services

3

• Factory Head office Allied Automation
  Engineers,Jhumra Road Mansoorabad
  Faisalabad-PAKISTAN ZIP code 38000Tel 92 41
  8737029 ,8739029 Fax [phone]www.hottek.c
  om www.allied-technologist.
  comKey Contact Persons Mr.Rehan Akmal
  Chief Executive OfficerEmail

  Rehan_at_allied-technologist.comCell
  92 -321-7619000
  .92-336-7619000Muneeba Abdul Hafeez
  GM Marketing Email

  muneeba_at_allied-technologist,.comCell
  92
  -321- 6690211 , 92-320-7619000

4
Content

• Wrinkle/Whisker Machine Range
• Grinding Machine
• Scraping Machine
• Spray Booth
• Jeans Baking Oven-Box Type Range
• Jeans Baking Oven-Conveyor Type Range

5
Wrinkle /whisker Machine Range
6
Hot Tek 3D MF (3D Wrinkle Machine)

• Features-
•
• Totally Mild Steel Structure.
• Both Side Wrinkle at a Time, Area adjustable
• Pneumatic Control.
• Individual Digital Temperature Time Control
• Digital Alarm System.
• Electric Vacuum suction System.

7
3D Regional Crinkle Machine

• Features
• Totally Mild Steel Structure.
• Both Side Wrinkle at a Time, Area adjustable
• Pneumatic Control.
• Individual Digital Temperature Time Control
• Digital Alarm System.
• Electric Vacuum suction System.
•

8
Cylinder Type Wrinkle Machine (for crunching)
MODEL HOT TEK CW Features Totally
Mild Steel Structure. Maximum Wrinkle Area Up
To 8 Inches. Pneumatic Control. Digital
Temperature Time Control. Digital Alarm
System. Machine Fitted on Stand (Not Desktop)
9
Bubble Whisker Machine-Single Head,02 stations
Specifications Special Designed Machine for
Bubble whisker effects. HOTTEK BUBBLE WHISKER
MACHINE Specially designed Bubble Whisker
Machine for Bubble whisker design on jeans. We
designed as per end user requirements . MS Pipe
structure . Electrical Consumption 7.5
KW Voltage 3Phase
Electrical Control Digital Control
Time and Temperature Production
60 to 80 Pc per hour
10
Automatic 3D Natural Whisker
Machine Infrared Heating
Hot Tek 3D Natural Whisker Machine specially
design for make Natural Whiskers /Bubble Whiskers
on any portion of Jeans Pants
Specifications -Totally Mild Steel Strong
Structure -Maximum Wrinkle Area Up -08 Station
Vacuum Plates For Heavy Product -IR(Infrared)Curin
g System. -Maximum production in minimum
Time. -Energy Efficient and Labor cost saving.
11
3D Natural Whisker Machine-Steam Attachment
12
Heat Transfer Press Range

• For Jeans Garments

13
For Jeans Waistband Transfer
Specification - -Heat Transfer Machine (Double
Action Automatic) -Heat Plate Size 1X 20
(Teflon Coated) -Pneumatically Up Down(
Adjustable Pressure) -Power 2000 Watt.
-Voltage (Input) 220 Volt-Single Phase -Air
Pressure 30 -60 PSI. -Digital Temperature
Control -Digital Temperature Control with PID
(Up to 300 C)Time(99 Sec).-Large Character
LCD-Alarm Indication on LCD.-Auto Manual
Selection for Reset.-Digital Piece and Life
Counter.Latest Additional Features-Machine
Ideal Warring to Avoid Heat Loss and Energy
Saving.-Resettable Counter.-Counter Data save
even in Power Failure.-Transfer Time from 1
Second to 240 Second.-Accidental Press
Safety.Cross Laser Marker System Optional
14
Heat Press For Transfer on Waistband
Special Heat Transfer Machine For Transfer
Stickers on Jeans pant Waist Band. Technical
Specifications Plate size         4 x 12
inches Power               1 kw Voltage
  220 Air pressure 65PS
15
Heat Transfer Press For Shiny Effects
16
Equipment For Grinding and Scraping
17
Edge Grinding Machine FT-4 (04 stations)
Totally Mild Steel Structure. Specially Design
for Pocket Edge and Bottom Edge
Grinding. Independent Speed Control for Each
Head (For Different Grinding effects)
18
Automatic Trouser Brushing Machine
19
Manual Jeans Brushing Machine
Features- -Mild Steel Structure (Stove
Painted). -Regulated Air filling inflate in
Balloons. -Automatic front and Back
Turning. Specification- 1-220 Volt Single
Phase. 2-300 Watt Maximum 3-4.56 Bar Air
Pressure. 4-150kg Weight.
20
PP Spray Booth

• Features
• M.S Pipe Strong Structure.
• Cabinet Covered by G.I sheet (20SWG) Painted.
• Bottom water storage tank for water curtain made
  by
• G.I Sheet 20 SWG).
• Heavy Duty Suction Blower (instead of Fan).
• Water Recycle Pump with Filter.
• Dummy Tilt Position by Pneumatic.
• Dummy Rotate by Pneumatic (Optional)
• Automatic Air Pressure Regulation in Balloons.
• Spray Gun (Optional).
• The Length of the cabinet varies depending on the
  number of dummies.
•

21
Curing Ovens for Jeans Baking

• Box Type
• Conveyor Type

22
Jeans Baking Oven-Box Type (Electrical /Gas)

• MODEL HOT TEK HT10
• Features
• Electrical /Gas Heat Exchanger for indirect
  Heating.
• Overall Machine Height 85in.
• Overall Machine width x Depth 48inches x
  60inches.
• Overall Machine weight 180kg.
• Electrical Requirement 220V AC 50HZ.
• Production Rate 20Pcs /hr (in 2 Cycles)

23
Jeans Baking Oven -Electrical Gas

• Features
• Production Rate 200 Pcs/hr.
• Natural and LPG Gas Burner with Automation.
• Automatic fume Drain System during process and
  end of Cycle.
• Electrical Consumption 4.5Kw.
• Electrical Requirement 440v AC 50HZ 3 Phase.
• Digital Temperature (Max 200C)and Timer
  (120min)
• Overall Machine Height 8Ft.
• Internal Height 7Ft.
• Internal Depth 10Ft.
• Internal width 8Ft.
• Overall Machine Weight 1500kg

24
Jeans Baking Conveyor Type Oven
(Electrical Gas)
25
Jeans Baking Conveyor Type Oven
(Electrical Gas)
Specifications and Features Oven Size
L32Ft
x W8ft x H 8.5Ft Conveyor Length
117Ft L Type. Hanger
inside chamber
85Pcs Hanger Outside chamber
35Pcs Speed
6 Hanger/Minute
(Variables) Heat Insulation
1150 C-130CKg Density Oven
Inner Lining
16 SWG.GI Sheet. Oven Outer Lining
18 SWG GI-Painted
Sheets. Heating System (1000000 BTU/h)
Indirect Heating from Fire Tube Heat Exchanger
220 Sq FT Digital Time
(Conveyor Speed) and Temperature Control with PLC
(Programmable Logic Controller) 10.h.p Blower
Motor.(For Hot Air Flow) ½ h.p Burner Blower
Motor. 1.h.p Air Curtain Blower. 1.h.p Hood Fan
Motor. 2.h.p Conveyor Gear Motor with Frequency
Inverter. All Motors with Overload
Protection. Floor Lighting. Conveyor Auto
Lubrication System. Double Burner one with Heat
Exchanger other without Heat Exchanger.
